Page 1 Charger 2 0 1 0 O W N E R ’ S M A N U A L S R T...
Page 2: Introduction
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6 INTRODUCTION 5...
Page 7: Vehicle Identification Number
The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN Location Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove or alter the VIN.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . 12 Key FOB .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using The Panic Alarm ....21 Programming Additional Transmitters ..21 Transmitter Battery Replacement .
Page 12 Supplemental Restraint System (SRS) - Airbags ......49 Airbag Deployment Sensors And Controls . . . 55 Event Data Recorder (EDR) .
Page 13: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The Wireless Ignition Node (WIN) operates similar to an ignition switch. It has four operating positions, three with detents and one that is spring-loaded. The detent posi- tions are LOCK, ACC, and ON.
Page 14: Key Fob
Key Fob The Key Fob operates the ignition switch. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
Page 15: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches, radio, power sunroof (if equipped), and power outlets will remain active for 10 minutes after the ignition switch is turned to the LOCK position.
Page 16: Sentry Key
NOTE: The Key-In-Ignition reminder only sounds when the Key Fob is placed in the LOCK or ACC ignition position. SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.
Page 17: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Replacement Keys NOTE: Only Key Fobs that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Key Fob is programmed to a vehicle, it cannot be programmed to any other vehicle.
Page 18: Vehicle Security Alarm - If Equipped
• This device must accept any interference that may be received, including interference that may cause undes- ired operation. VEHICLE SECURITY ALARM — IF EQUIPPED The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the ignition switch for unau- thorized operation.
Page 19: Illuminated Entry - If Equipped
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm. • The Vehicle Security Alarm remains armed during trunk entry. Pressing the TRUNK button will not disarm the Vehicle Security Alarm.
Page 20: Remote Keyless Entry (Rke)
The lights will fade to off after approximately 30 seconds or they will immediately fade to off once the ignition switch is turned ON from the LOCK position. NOTE: None of the courtesy lights will operate if the dimmer control is in the “defeat” position (extreme downward position), unless the overhead map/reading lights are turned on manually.
Page 21: To Lock The Doors
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE within five seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on. Remote Key Unlock, Driver Door/All Doors 1st Press This feature lets you program the system to unlock either the driver’s door or all doors on the first press of the...
Page 22: To Unlatch The Trunk
To Unlatch the Trunk Press the TRUNK button on the RKE transmitter two times within five seconds to unlatch the trunk. Using the Panic Alarm To turn the Panic Alarm feature on or off, press and hold the PANIC button on the RKE transmitter for at least one second and release.
Page 23: General Information
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Battery access is through a door located on the rear of the Key Fob. Insert a small, flat blade screwdriver into the slot and gently pry open the access door. Battery Replacement 1—...
Page 24: Remote Starting System - If Equipped
If your RKE transmitter fails to operate from a normal distance, check for these two conditions: 1. A weak battery in the transmitter. The expected life of the battery is a minimum of three years. 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios.
Page 25 24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Mon- oxide (CO) which is odorless and colorless. Car- bon Monoxide is poisonous and can cause serious injury or death when inhaled.
Page 26 To Exit Remote Start Mode without Driving the Vehicle Press and release the REMOTE START button one time, or allow the engine to run for the entire 15-minute cycle. NOTE: To avoid unintentional shut downs, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request.
Page 27: Door Locks
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks To lock each door, push the door lock plunger on each door trim panel downward. To unlock each door, pull the door lock plunger on each door trim panel upward. Door Lock Plunger If the door lock plunger is down when you shut the door, the door will lock.
Page 28: Power Door Locks
Power Door Locks A power door lock switch is on each front door trim panel. Use this switch to lock or unlock the doors. Power Door Lock Switch If you press the power door LOCK switch while the Key Fob is in the ignition, and any front door is open, the power locks will not operate.
Page 29 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks Programming The Automatic Door Locks feature can be enabled or disabled as follows: • For vehicles equipped with the Electronic Vehicle Information Center (EVIC), refer to “Electronic Vehicle Information Center (EVIC)/Personal (Customer-Programmable Features)”...
Page 30 3. The transmission is in NEUTRAL or PARK. 4. The driver door is opened. 5. The doors were not previously unlocked. 6. The vehicle speed is 0 mph (0 km/h). Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled as follows: •...
Page 31: Child Protection Door Lock
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Protection Door Lock To provide a safer environment for small children riding in the rear seats, the rear doors are equipped with a Child Protection Door Lock system. To Engage the Child Protection Door Lock System 1.
Page 32 WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. Failure to follow this warning may result in serious injury or death. NOTE: •...
Page 33: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Repeat Steps 1 and 2 for the opposite rear door. NOTE: After disengaging the Child Protection Door Lock system, always test the door from the inside to make certain it is in the desired position. WINDOWS Power Windows The window controls on the driver’s door control all the...
Page 34 WARNING! Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches. Such entrapment may result in serious injury or death. AUTO-Down Feature The driver door power window switch and some model passenger door power window switches have an AUTO- down feature.
Page 35 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To close the window part way, lift the window switch to the first detent and release it when you want the window to stop. The power window switches will remain active for up to 60 minutes after the ignition switch is turned off.
Page 36: Wind Buffeting
Window Lockout Switch Reset Anytime the vehicle battery is disconnected or goes dead, the AUTO-up function will be disabled. To reactivate the AUTO-up feature, perform the following procedure after vehicle power is restored: THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 1.
Page 37: Trunk Lock And Release
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK LOCK AND RELEASE The trunk lid can be released from inside the vehicle by pressing the TRUNK RELEASE button located on the instrument panel to the left of the steering wheel. NOTE: The transmission must be in PARK before the button will operate.
Page 38: Trunk Safety Warning
TRUNK SAFETY WARNING WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended. Once in the trunk, young children may not be able to escape, even if they entered through the rear seat.
Page 39 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Advanced Front Airbags for driver and front passen- • Supplemental Side Airbag Inflatable Curtains (SABIC) for the driver and passengers seated next to a window — if equipped • An energy-absorbing steering column and steering wheel •...
Page 40: Lap/Shoulder Belts
Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision that includes you. This can happen far away from home or on your own street. Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
Page 42 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Inserting Latch Plate into Buckle THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries.
Page 44 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as possible and keep it snug.
Page 45: Lap/Shoulder Belt Untwisting Procedure
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the driver and front passenger seats, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Push and fully depress the button above the webbing to release the anchorage, then move it up or down to the position that fits you best.
Page 46: Automatic Locking Retractors (Alr) Mode - If Equipped
3. Slide the latch plate upward over the folded webbing. The folded webbing must enter the slot at the top of the latch plate. 4. Continue to slide the latch plate up until it clears the folded webbing. Automatic Locking Retractors (ALR) Mode — If Equipped In this mode, the shoulder belt is automatically pre- locked.
Page 47: Seat Belt Pretensioners - If Equipped
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners — If Equipped The seat belts for both front seating positions may be equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
Page 48 For front passenger seats equipped with BeltAlert, your vehicle is equipped to detect when it is occupied. The BeltAlert warning system is not activated when the front passenger seat is unoccupied. The BeltAlert warn- ing system may be triggered when an animal or heavy object is on the front passenger seat or when the seat is folded flat (if equipped).
Page 49: Seat Belts And Pregnant Women
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Turn the ignition switch to the LOCK position. A single chime will sound to signify that you have success- fully completed the programming. BeltAlert can be reactivated by repeating this procedure. NOTE: Although BeltAlert has been deactivated, the Seat Belt Reminder Light will continue to illuminate as long as the driver’s seat belt is unbuckled.
Page 50: Supplemental Restraint System (Srs) - Airbags
Supplemental Restraint System (SRS) - Airbags This vehicle has Advanced Front Airbags for both the driver and front passenger as a supplement to the seat belt restraint systems. The driver’s Advanced Front Air- bag is mounted in the center of the steering wheel. The passenger’s Advanced Front Airbag is mounted in the instrument panel, above the glove compartment.
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation based on the severity and type of collision. This vehicle may be equipped with driver and/or front passenger seat track position sensors that may adjust the inflation rate of the Advanced Front Airbags based upon seat position.
Page 52 • Supplemental Side Airbag Inflatable Curtains (SABIC) • Front and Side Impact Sensors • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors Advanced Front Airbag Features The Advanced Front Airbag system has multistage driver and front passenger airbags. This system provides output appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), which may receive information from the front impact...
Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped SABIC airbags may offer side-impact and vehicle rollover protection to front and rear seat outboard occupants in addition to that provided by the body structure. Each airbag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side-impact head injuries.
Page 54 The system includes side impact sensors adjacent to both front and rear seat occupants that are calibrated to deploy the SABIC airbags during impacts that require airbag occupant protection. WARNING! • If your vehicle is equipped with left and right Supplemental Side Airbag Inflatable Curtain (SABIC), do not stack luggage or other cargo up high enough to block the location of the SABIC.
Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Infants in rear-facing child restraints should NEVER ride in the front seat of a vehicle with a passenger Advanced Front Airbag. An airbag deployment can cause severe injury or death to infants in that posi- tion.
Page 56: Airbag Deployment Sensors And Controls
If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center. Phone numbers are provided under If You Need Assistance”. WARNING! • Relying on the airbags alone could lead to more severe injuries in a collision.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Airbags are designed to provide addi- tional protection by supplementing the seat belts in certain frontal collisions depending on the severity and type of collision. Advanced Front Airbags are not ex- pected to reduce the risk of injury in rear, side, or rollover collisions.
Page 58 Also, the ORC turns on the Airbag Warning Light in the instrument panel for approxi- mately six to eight seconds for a self-check when the ignition is first turned on. After the self-check, the Airbag Warning Light will turn off. If the ORC detects a malfunction in any part of the system, it turns on the Airbag Warning Light, either momentarily or continuously.
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE separate and fold out of the way as the airbags inflate to their full size. The airbags fully inflate in about 50 to 70 milliseconds. This is about half of the time it takes to blink your eyes.
Page 60 Enhanced Accident Response System In the event of an impact causing airbag deployment, if the communication network remains intact, and the power remains intact, depending on the nature of the event the ORC will determine whether to have the Enhanced Accident Response System perform the follow- ing functions: •...
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • As the airbags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the non-toxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat.
Page 62 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 63: Event Data Recorder (Edr)
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. While the airbag system is designed to be mainte- nance free, if any of the following occurs, have an authorized dealer service the system immediately.
Page 64 2. Under certain circumstances, EDR data may not be recorded (e.g., loss of battery power). In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be used by Chrysler Group LLC and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle perfor- mance.
Page 65: Child Restraints
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that are recorded: • Diagnostic trouble code(s) and warning light status for electronically-controlled safety systems, including the airbag system •...
Page 66 There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat Owner’s Manual to ensure you have the correct seat for your child. Use the restraint that is correct for your child.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system.
Page 68 WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint. •...
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren) Your vehicle’s rear seat is equipped with the child restraint anchorage system called LATCH. The LATCH system provides for the installation of the child restraint without using the vehicle’s seat belts, instead securing the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle...
Page 70 LATCH Anchorages Installing the LATCH-Compatible Child Restraint System We urge you to follow the manufacturer’s directions carefully when installing your child restraint. Not all child restraint systems will be installed as described here. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Again, carefully follow the installation instructions that are provided with the child restraint system.
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap.
Page 72 WARNING! Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint. Installing Child Restraints Using the Vehicle Seat Belts The passenger seat belts are equipped with either cinch-...
Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the belt still can’t be tightened, or if pulling and pushing on the restraint loosens the belt, you may need to do something more. Disconnect the latch plate from the buckle, turn the buckle around, and insert the latch plate into the buckle again.
Page 74: Engine Break-In Recommendations
2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. 3. Attach the tether strap hook (A) of the child restraint to the anchor (B) and remove slack in the tether strap according to the child restraint manufacturer’s instruc- tions.
Page 75: Safety Tips
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. For the recommended viscosity and quality grades refer to “Maintenance Procedures”...
Page 76: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 77: Safety Checks You Should Make Inside The Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 78 WARNING! Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious per- sonal injury. • Always make sure that floor mats are properly attached to the floor mat fasteners. • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the...
Page 79: Periodic Safety Checks You Should Make Outside The Vehicle
78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 80: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......83 Inside Day/Night Mirror ....83 Automatic Dimming Mirror —...
Page 81 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 116 Voice Command System Operation ..116 Commands ......118 Voice Training .
Page 82 Overhead Console Map/Reading Lights ..134 Interior Lights ..... . 135 Windshield Wipers And Washers ..136 Intermittent Wiper System .
Page 83 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Security ......151 Troubleshooting Tips ....151 General Information .
Page 84: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 83 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 85: Automatic Dimming Mirror - If Equipped
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 86: Outside Mirrors Folding Feature - If Equipped
WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger side convex mirror.
Page 87: Power Mirrors
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors The power mirror switch is located on the driver’s door trim panel, next to the power door lock switch. A rotary knob selects the left mirror, right mirror or off position. Power Mirror Control After selecting a mirror, move the knob in the same direction you want the mirror to move.
Page 88: Illuminated Vanity Mirrors - If Equipped
Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is located on the sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward. The light turns on automatically. Closing the mirror cover turns off the light. Illuminated Vanity Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 Uconnect™...
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 Uconnect™ Phone allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s...
Page 90: Operation
Uconnect™ Phone Button Depending on the vehicle options, either the radio or the mirror will contain the two control buttons (Uconnect™ Phone button) and (Voice Command button) that will en- able you to access the system. Voice Command Button Actual button location may vary with the ra- dio.
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing. • For each feature explanation in this section, only the combined form of the voice command is given.
Page 92 To complete the pairing process, you will need to refer- ence your cellular phone Owner’s Manual. The Uconnect™ website may also provide detailed instruc- tions for pairing. The following are general phone to Uconnect™ Phone pairing instructions: • Press the button to begin.
Page 93 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dial by Saying a Number • Press the button to begin. • After the Ready prompt and the following beep, say Dial. • The system will prompt you to say the number you want to call.
Page 94 • After the Ready prompt and the following beep, say Phonebook New Entry. • When prompted, say the name of the new entry. Use of long names helps the Voice Command and it is recom- mended. For example, say Robert Smith or Robert instead of Bob.
Page 95 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Automatic download and update, if supported, begins as soon as the Bluetooth wireless phone connection is made to the Uconnect™ Phone, for example, after you start the vehicle. • A maximum of 1000 entries per phone will be down- loaded and updated every time a phone is connected to the Uconnect™...
Page 96 NOTE: • The phone handset must support Bluetooth OBEX transfers of phonebook entries to use this feature. • Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth , and you may see a message on the phone display that the Bluetooth link is busy.
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in the phonebook, call the number you just edited, or return to the main menu. Phonebook Edit can be used to add another phone number to a name entry that already exists in the phonebook.
Page 98 Delete/Erase “All” Uconnect™ Phonebook Entries • Press the button to begin. • After the Ready prompt and the following beep, say Phonebook Erase All. • The Uconnect™ Phone will ask you to verify that you wish to delete all the entries from the phonebook. •...
Page 99: Phone Call Features
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features The following features can be accessed through the Uconnect™ Phone if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the Uconnect™...
Page 100 in progress. To go back to the first call, refer to Toggling Between Calls in this section. To combine two calls, refer to Conference Call in this section. Place/Retrieve a Call From Hold To put a call on hold, press the a single beep.
Page 101: Uconnect™ Phone Features
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say Redial. • The Uconnect™ Phone will call the last number that was dialed from your cellular phone. NOTE: This may not be the last number dialed from the Uconnect™...
Page 102 • Continue to follow the system prompts to complete the language selection. After selecting one of the languages, all prompts and voice commands will be in that language. NOTE: After every Uconnect™ Phone language change operation, only the language-specific 32-name phone- book is usable.
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone does slightly lower your chances of successfully making a phone call as to that for the cellular phone directly. WARNING! Your phone must be turned on and paired to the Uconnect™...
Page 104 Voice Mail Calling To learn how to access your voice mail, refer to Working with Automated Systems. Working with Automated Systems This method is used in instances where one generally has to press numbers on the cellular phone keypad while navigating through an automated telephone system.
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Some paging and voice mail systems have system time out settings that are too short and may not allow the use of this feature. Barge In - Overriding Prompts The “Voice Command” button can be used when you wish to skip part of a prompt and issue your voice command immediately.
Page 106: Advanced Phone Connectivity
phone, the audio will be played through your vehicle’s audio system. The Uconnect™ Phone will work the same as if you dial the number using Voice Command. NOTE: Certain brands of cellular phones do not send the dial ring to the Uconnect™ Phone to play it on the vehicle audio system, so you will not hear it.
Page 107 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you would like to connect or disconnect the Bluetooth connection between a Uconnect™ Phone paired cellular phone and the Uconnect™ Phone, follow the instructions described in your cellular phone User’s Manual. List Paired Cellular Phone Names •...
Page 108: Things You Should Know About Your Uconnect™ Phone
• After the Ready prompt and the following beep, say Setup Phone Pairing. • At the next prompt, say Delete and follow the prompts. • You can also press the button at any time while the list is being played, and then choose the phone you wish to delete.
Page 109 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To restore the Voice Command system to factory default settings, enter the Voice Training session via the above procedure and follow the prompts. Voice Command • For best performance, adjust the rearview mirror to provide at least ⁄...
Page 110 • Phonebook (Downloaded and Uconnect™ Phone Lo- cal) name recognition rate is optimized when the entries are not similar. • Numbers must be spoken in single digits. “800” must be spoken “eight-zero-zero” not “eight hundred”. • You can say O (letter O ) for 0 (zero). •...
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bluetooth Communication Link Cellular phones have been found to lose connection to the Uconnect™ Phone. When this happens, the connec- tion can generally be reestablished by switching the phone off/on. Your cellular phone is recommended to remain in Bluetooth ON mode.
Page 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111...
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113...
Page 115 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 116 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 117: General Information
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 118 NOTE: If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the Voice Command for the beep, and say your command. Pressing the Voice Command system is speaking is known as “barging in.”...
Page 119: Commands
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Commands The Voice Command system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the Voice Command button.
Page 120 Radio FM To switch to the FM band, say “FM” or “Radio FM”. In this mode, you may say the following commands: • “Frequency” (to change the frequency) • “Next Station” (to select the next station) • “Previous Station” (to select the previous station) •...
Page 121 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Memo To switch to the voice recorder mode, say “Memo”. In this mode, you may say the following commands: • “New Memo” (to record a new memo) — During the recording, you may press the Voice Command button to stop recording.
Page 122: Voice Training
NOTE: Keep in mind that you have to press the Voice Command button first and wait for the beep before speaking the “Barge In” commands. Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers the Uconnect™ Voice “Voice Training”...
Page 123: Power Seats
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Seats The power seat switch is on the outboard side of the seat near the floor. Use this switch to move the driver’s seat up or down, forward or rearward, or to recline the seatback.
Page 124: Power Reclining Seats
Power Reclining Seats The recliner control is located on the outboard side of the seat. Power Seat Recline Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured.
Page 125: Lumbar Support
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lumbar Support This feature allows you to increase or decrease the amount of lumbar support. Turn the control lever for- ward to increase and rearward to decrease the desired amount of lumbar support. Lumbar Support Control Lever Head Restraints Head restraints can reduce the risk of injury in the event...
Page 126 Adjustable Head Restraint To remove the head restraint, pull upward on the head restraint to its highest position, push in both buttons at the base of each head restraint rod, and simultaneously pull up on the head restraint. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Removing Head Restraint To install the head restraint, insert the head restraint rods into each guide, apply pressure down on the headrest...
Page 127: Heated Seats
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Ensure that the front of the head restraint is facing toward the front of the vehicle. WARNING! Driving a vehicle with the head restraints removed or improperly adjusted could cause serious injury or death in the event of a collision.
Page 128: Folding Rear Seat
WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
Page 129 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Folding Rear Seats When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. WARNING! • Be certain that the seatback is securely locked into position.
Page 130: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. 1. Pull the hood release lever located under the left side of the instrument panel. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 2.
Page 131: Lights
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood, until it is open approxi- mately 6 in (15 cm), and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
Page 132: Automatic Headlights - If Equipped
Headlight Switch Rotate the headlight switch clockwise to the first detent for parking light and instrument panel light operation. Rotate the headlight switch to the second detent for headlight, park light, and instrument panel light operation. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Automatic Headlights —...
Page 133: Headlight Time Delay
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Headlights On with Wipers feature can be enabled or disabled. Refer to “Electronic Vehicle Information Center (EVIC)/Customer-Programmable Features” in “Under- standing Your Instrument Panel” for further information. Headlight Time Delay This feature provides the safety of headlight illumination for up to 90 seconds (programmable) when leaving your vehicle in an unlit area.
Page 134: Fog Lights
Fog Lights The front fog light switch is built into the head- light switch. To activate the front fog lights, turn on the parking lights or the low beam headlights and press the headlight switch. To turn off the front fog lights, either press headlight switch again or turn off the headlight switch.
Page 135: Turn Signals
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. NOTE: •...
Page 136: Interior Lights
Overhead Console Interior Lights The interior lights come on when a door is opened. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched on manually or are on UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 because a door is open.
Page 137: Windshield Wipers And Washers
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dome Light Position Rotate the dimmer control completely upward to the second detent to turn on the interior lights. The interior lights will remain on when the dimmer control is in this position. Interior Light Defeat (OFF) Rotate the dimmer control to the extreme bottom OFF position.
Page 138: Intermittent Wiper System
Rotate the end of the multifunction lever to the first detent past the intermittent settings for low-speed wiper operation, or to the second detent past the intermittent settings for high-speed wiper operation. CAUTION! Turn the windshield wipers off when driving through an automatic car wash.
Page 139: Mist Feature
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Sudden loss of visibility through the windshield could lead to an accident. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with the defroster before and during windshield washer use.
Page 140: Tilt/Telescoping Steering Column
TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping control handle is located below the steering wheel at the end of the steering column.
Page 141: Adjustable Pedals - If Equipped
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ADJUSTABLE PEDALS — IF EQUIPPED The adjustable pedals system is designed to allow a greater range of driver comfort for steering wheel tilt and seat position. This feature allows both the brake and accelerator pedal to move toward or away from the driver to provide improved position with the steering wheel.
Page 142: Electronic Speed Control
• The pedals can be adjusted while driving. • The pedals cannot be adjusted when the transmission is in REVERSE or when the Electronic Speed Control is CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls.
Page 143: To Activate
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: In order to ensure proper operation, the Elec- tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at the same time. If this occurs, the Electronic Speed Control System can be reactivated by pushing the Electronic Speed Control ON/OFF button and resetting the desired vehicle set speed.
Page 144: To Deactivate
• The Electronic Speed Control may not engage if a different size tire is installed on one wheel, such as the compact spare tire. To Deactivate The system will disable Electronic Speed Control without erasing the memory if you: • Softly tap the brake pedal. •...
Page 145: To Accelerate For Passing
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To decrease speed while Electronic Speed Control is set, push down and hold the Electronic Speed Control lever in SET DECEL. Release the Electronic Speed Control lever when the desired speed is reached, and a new set speed will be established.
Page 146: Overhead Console
OVERHEAD CONSOLE The overhead console contains courtesy/reading lights and storage for sunglasses. Universal Garage Door Opener (HomeLink ) buttons and power sunroof switch may also be included, if equipped. Overhead Console UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Courtesy/Reading Lights At the forward end of the console are two courtesy/ reading lights.
Page 147: Garage Door Opener - If Equipped
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink unit operates off your vehicle’s battery.
Page 148: Programming Homelink
WARNING! • Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people, pets, or other objects are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 149 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Place the handheld transmitter 1 to 3 in (3 to 8 cm) from the HomeLink buttons while keeping the EVIC display in view. For optimal training, point the battery end of the hand- held transmitter away from the HomeLink .
Page 150 This can usually be found where the hanging antenna wire is attached to the garage door opener motor (it is NOT the button normally used to open and close the door). 1 — Garage Door Opener 2 — Training Button UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 6.
Page 151: Gate Operator/Canadian Programming
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Gate Operator/Canadian Programming Canadian radio-frequency laws require transmitter sig- nals to “time-out” (or quit) after several seconds of transmission – which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.
Page 152: Reprogramming A Single Homelink Button
Reprogramming A Single HomeLink Button To reprogram a channel that has been previously trained, follow these steps: 1. Place the ignition in the RUN position. 2. Press and hold the desired HomeLink button for 20 seconds until the EVIC display states “CHANNEL # TRAINING.”...
Page 153: General Information
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with FCC rules Part 15 and Industry Canada RSS-210. Operation is subject to the following two conditions: 1. This device may not cause harmful interference 2. This device must accept any interference that may be received including interference that may cause undesired operation NOTE: The transmitter has been tested and it complies...
Page 154: Opening Sunroof - Express
WARNING! • Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death. •...
Page 155: Pinch Protect Override
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE sunroof will automatically retract. Remove the obstruc- tion if this occurs. Next, press the power sunroof switch forward and release to Express Close. Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the power sunroof switch forward and hold for two seconds after the reversal occurs.
Page 156: Sunroof Maintenance
Sunroof Maintenance Use only a non-abrasive cleaner and a soft cloth to clean the glass panel. Ignition Off Operation The power sunroof switch will remain active for up to 60 minutes after the ignition switch is turned OFF. Opening either front door will cancel this feature. The time for this feature is programmable.
Page 157 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The 12 Volt power outlet next to the ash receiver tray has power available only when the ignition is in the ON or ACC positions. Front Power Outlet WARNING! Do not place ashes inside the cubby bin located on the center console on vehicle’s not equipped with the ash receiver tray.
Page 158 Center Console Power Outlet WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 WARNING! (Continued) • Do not touch with wet hands. •...
Page 159: Cupholders
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Accessories that draw higher power (i.e., coolers, vacuum cleaners, lights, etc.) will degrade the battery even more quickly. Only use these inter- mittently and with greater caution. • After the use of high power draw accessories or long periods of the vehicle not being started (with accessories still plugged in), the vehicle must be driven a sufficient length of time to allow the...
Page 160: Rear Seat Cupholders
Rear Seat Cupholders The rear seat cupholders are located in the center armrest between the rear seats. The cupholders are positioned forward in the armrest and side-by-side to provide convenient access to beverage cans or bottles while maintaining a resting place for the rear occupants elbows. Rear Seat Cupholders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 STORAGE...
Page 161: Cargo Area - Vehicles Equipped With 60/40
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Two separate storage compartments are also located underneath the armrest. 1 — Release button for bottom compartment 2 — Release button for top compartment 3 — Top Compartment 4 — Bottom Compartment. (You can access this compartment directly, without first exposing the upper compartment, by oper- ating the Release Button for the bottom compartment with the armrest down.)
Page 162 When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. WARNING! • Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers.
Page 163: Rear Window Features
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Place as much cargo as possible in front of the rear axle. Too much weight or improperly placed weight over or behind the rear axle can cause the rear of the vehicle to sway. •...
Page 164: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....166 Instrument Cluster ....167 Instrument Cluster Descriptions .
Page 165 164 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Voice Command System (VR) — If Equipped ... . . 195 Operating Instructions — Uconnect™ Phone — If Equipped ..... . 195 Clock Setting Procedure —...
Page 166 Controlling The iPod Using Radio Buttons ......225 Play Mode ......226 List Or Browse Mode .
Page 167: Instrument Panel Features
166 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Instrument Cluster 3 — Hazard Switch 4 — Electronic Stability Program OFF Button* 5 — Glove Compartment 6 — Radio 7 — Climate Control 8 — Heated Seat Switch* 9 —...
Page 168: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 167 INSTRUMENT CLUSTER...
Page 169: Instrument Cluster Descriptions
168 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the ON position. 2. Trip Odometer Button Press this button to change the display from odometer to either of two trip odometer settings.
Page 170 7. Electronic Throttle Control (ETC) Light This light will turn on briefly as a bulb check when the ignition switch is turned ON. This light will also turn on while the engine is running if there is a problem with the Elec- tronic Throttle Control (ETC) system.
Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, refer to “Maintaining Your Vehicle”...
Page 172 12. Electronic Stability Program (ESP) / Traction Control System (TCS) Indicator Light If this indicator light flashes during accelera- tion, ease up on the accelerator and apply as little throttle as possible. Adapt your speed and driving to the prevailing road conditions, and do not switch off the Electronic Stability Program (ESP).
Page 173 172 UNDERSTANDING YOUR INSTRUMENT PANEL 15. High Beam Light This light will turn on when the high beam headlights are ON. Push the multifunction lever away from the steering wheel to switch the headlights to high beam. 16. Seat Belt Reminder Light This light will turn on for five to eight seconds as a bulb check when the ignition switch is first turned ON.
Page 174 for you to make a record of the odometer reading before the repair/service, so that you can be sure that it is properly reset, or that the door jamb sticker is accurate if the odometer must be reset at zero. This display shows the Electronic Vehicle Information Center (EVIC) messages when the appropriate conditions exist.
Page 175 174 UNDERSTANDING YOUR INSTRUMENT PANEL the brake booster, the ABS pump will run when applying the brake and a brake pedal pulsation may be felt during each stop. The dual brake system provides a reserve braking capac- ity in the event of a failure to a portion of the hydraulic system.
Page 176 The light also will turn on when the parking brake is applied with the ignition switch in the ON position. NOTE: This light shows only that the parking brake is applied. It does not show the degree of brake application. 21.
Page 177 176 UNDERSTANDING YOUR INSTRUMENT PANEL maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 178 23. Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, then the Anti-Lock portion of the brake system is not functioning and service is required.
Page 179: Electronic Vehicle Information Center (Evic)
178 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Prolonged driving with the MIL on could cause damage to the engine control system. It also could affect fuel economy and drivability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required.
Page 180 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: • System status • Vehicle information warning message displays • Tire Pressure Monitor System •...
Page 181: Electronic Vehicle Information Center (Evic) Displays
180 UNDERSTANDING YOUR INSTRUMENT PANEL Press the SCROLL button to scroll through Trip Functions, Performance Pages (if equipped), Uconnect™ gps (if equipped), System Status Messages, and Personal Settings (Customer- SCROLL Programmable Features). The SCROLL button Button also functions as a remote sound system con- trol.
Page 182 • Door(s) Ajar (with a single chime if vehicle is in motion) • Trunk Ajar (with a single chime) • Oil Pressure • Oil Change Required (with single chime) • Low Washer Fluid (with a single chime) • Channel # Transmit •...
Page 183: Engine Oil Change Indicator System
182 UNDERSTANDING YOUR INSTRUMENT PANEL • Braking Distance (if equipped with Performance Pages) • 1/8 Mile (if equipped with Performance Pages) • 1/4 Mile (if equipped with Performance Pages) • Instantaneous G-Force (if equipped with Performance Pages) • Peak G-Force (if equipped with Performance Pages) •...
Page 184: Trip Functions
Trip Functions Press and release the MENU button until one of the following Trip Functions displays in the EVIC: • Average Fuel Economy • Distance To Empty • Trip A • Trip B • Elapsed Time • Display Units of Measure in Press the SCROLL button to cycle through all the Trip Computer functions.
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL When the DTE value is less than 30 miles (48 km) estimated driving distance, the DTE display will change to a text display of LOW FUEL. This display will continue until the vehicle runs out of fuel. Adding a significant amount of fuel to the vehicle will turn off the LOW FUEL text and a new DTE value will display.
Page 186: Performance Pages - If Equipped
Performance Pages — If Equipped WARNING! Measurement of vehicle statistics with the Perfor- mance Pages is intended for off-highway or off-road use only and should not be done on any public roadways. It is recommended that these features be used in a controlled environment and within the limits of the law.
Page 187 186 UNDERSTANDING YOUR INSTRUMENT PANEL • Dashes will display if the vehicle fails to reach 60 mph (100 km/h) in less then 10 seconds. • The time will continue to display until the FUNCTION SELECT button is pressed. • Pressing the FUNCTION SELECT button will clear the current run time and display the vehicle’s best 0-60 mph (0-100 km/h) time.
Page 188 1/8 Mile, 1/4 Mile When selected, this screen displays the time it takes the vehicle to travel 1/8 mile (1/4 mile) within 30 seconds and the vehicle’s speed when it reaches 1/8 mile (1/4 mile). • The feature will “ready” when the vehicle is at 0 mph (0 km/h).
Page 189: Driver-Selectable Surround Sound (Dss) - If Equipped
188 UNDERSTANDING YOUR INSTRUMENT PANEL Digital Speedometer When selected, this screen displays vehicle speed and records top speed. • Press and hold the FUNCTION SELECT button for three seconds to toggle between current speed and top speed. • To reset top speed, quickly press and release the FUNC- TION SELECT button when top speed is displayed.
Page 190 Automatic Compass Calibration This compass is self-calibrating, which eliminates the need to set the compass manually. When the vehicle is new, the compass may appear erratic and the EVIC will display “CAL” until the compass is calibrated. You may also calibrate the compass by completing one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL”...
Page 191: Uconnect™ Gps - If Equipped
190 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Keep magnetic materials away from the top of the instrument panel, such as iPod’s, Cell Phones, Lap- tops and Radar Detectors. This is where the compass module is located, and it can cause interference with the compass sensor, and it may give false readings.
Page 192: System Warnings (Customer Information Features)
used to select an item, and the AUDIO MODE button can be used to return to the previous menu. When the Map display is active, pressing the FUNCTION SELECT but- ton will change the Navigation Unit Display to the Menu. Turn-by-Turn Directions The EVIC displays Turn-by-Turn directions to a pro- grammed destination when Turn-by-Turn Navigation is...
Page 193: Personal Settings (Customer-Programmable Features)
192 UNDERSTANDING YOUR INSTRUMENT PANEL Personal Settings (Customer-Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK. Press and release the MENU button until Personal Set- tings displays in the EVIC. Use the SCROLL button to display one of the following choices.
Page 194 Press is selected, you must press the RKE UNLOCK button twice to unlock the passenger’s doors. When All Doors 1st Press is selected, all of the doors will unlock on the first press of the RKE UNLOCK button. To make your selection, press and release the FUNCTION SELECT button until “Driver Door 1st Press”...
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL “Delay Turning Headlights Off” When this feature is selected, the driver can choose to have the headlights remain on for 0, 30, 60, or 90 seconds when exiting the vehicle. To make your selection, press and release the FUNCTION SELECT button until “0,”...
Page 196: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/Nav - If Equipped
“Display Units of Measure in” The EVIC, odometer, and Uconnect™ gps (if equipped) can be changed between English and Metric units of measure. To make your selection, press and release the FUNCTION SELECT button until “ENGLISH” or “MET- RIC” appears. MEDIA CENTER 730N/430 (RER/REN/RBZ) —...
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL 3. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed.
Page 198: Clock Setting Procedure - Rer/Ren Radio
Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL 4. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed.
Page 200: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
Touch the screen where the words “Show Time if Radio is Off” are displayed to change the current setting. Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. 3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen.
Page 201: Operating Instructions - Radio Mode
200 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio.
Page 202 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change. 5. To exit, press any button/knob, or wait five seconds. RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows.
Page 203 202 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob again to exit setting tone, balance, and fade. AM/FM Button Press the buttons to select either AM or FM mode. SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button.
Page 204: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
Operation Instructions — CD MODE For CD And MP3 Audio Play NOTE: • The ignition switch must be in the ON or ACC position to operate the radio. • This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD Press the EJECT button to eject the CD. If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it.
Page 206: Notes On Playing Mp3 Files
SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the right SEEK button to move to the next ran- domly selected track.
Page 207 206 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of characters in file/folder names: • Level 1: 12 (including a separator . and a three- character extension) • Level 2: 31 (including a separator . and a three- character extension) Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files).
Page 208: Operation Instructions - Auxiliary Mode
Playlist files are not supported. MP3 Pro files are not supported. Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 209: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
208 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when ignition is OFF). MEDIA CENTER 130 (RES/RSC) — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate.
Page 210 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the ON/VOLUME control knob to the right increases the volume and to the left decreases it.
Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Uconnect” message will display on the radio screen. TIME Button Press the TIME button to alternate display of the time and radio frequency.
Page 212 TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency. Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob and BASS will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the bass tones. Push the rotary TUNE/SCROLL control knob a second time and MID will display.
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: 16-Digit Character Program Type No program type or un- defined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Program Type Personality Display...
Page 214 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 215: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
214 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET/RND button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 216 If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the track number, and index time in minutes and seconds.
Page 217: Notes On Playing Mp3 Files
216 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed.
Page 218 The radio uses the following limits for file systems: • Maximum number of folder levels: 8 • Maximum number of files: 255 • Maximum number of folders. (The radio display of file names and folder names is limited. For large numbers of files and/or folders, the radio may be unable to display the file name and folder name and will assign a number instead.
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16...
Page 220: List Button (Cd Mode For Mp3 Play)
LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 221: Uconnect™ Multimedia (Satellite Radio) - If Equipped
220 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect™ Multimedia (Satellite Radio) — If Equipped Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 222 Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. Selecting Uconnect™ Multimedia (Satellite) Mode Press the SAT button until SAT appears in the display. A CD may remain in the radio while in the Satellite radio mode.
Page 223 222 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new channel until you make another selection.
Page 224 Toggle the MUSIC TYPE button again to select the music type. By pressing the SEEK button when the Music Type function is active, the radio will be tuned to the next channel with the same selected Music Type name. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset channel.
Page 225: Universal Consumer Interface (Uci) 0.5 - If Equipped
224 UNDERSTANDING YOUR INSTRUMENT PANEL Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the channels that you commit to pushbutton memory (12 Satellite stations). Operating Instructions - Uconnect™ Phone (If Equipped) Refer to “Uconnect™...
Page 226: Connecting The Ipod
Connecting The iPod Use the provided connection cable to connect an iPod to the vehicle’s 16–pin connector port (which is located in the glove compartment on some vehicles). Once the iPod is connected and synchronized to the vehicle’s UCI system (iPod may take a few seconds to connect), the iPod starts charging and is ready for use by pressing radio switches, as described below.
Page 227: Play Mode
226 UNDERSTANDING YOUR INSTRUMENT PANEL Play Mode When switched to UCI mode, the iPod automatically starts Play mode. In Play mode, use the following buttons on the radio faceplate to control the iPod and display data: • Use the TUNE control knob to select the next or previous track.
Page 228: List Or Browse Mode
• Pressing the REPEAT button will change the iPod mode to repeat the current playing track. • Press the SCAN button to use iPod scan mode, which will play the first five seconds of each track in the current list and then forward to the next song. To stop SCAN mode and start playing the desired track, when it is playing the track, press the SCAN button again.
Page 229 228 UNDERSTANDING YOUR INSTRUMENT PANEL • During all List modes, the iPod displays all lists in “wrap-around” mode. So if the track is at the bottom of the list, just turn the wheel backwards (counter-clockwise) to get to the track faster. •...
Page 230: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Rer/Res Radios Only)
CAUTION! • Leaving the iPod (or any supported device) any- where in the vehicle in extreme heat or cold can alter the operation or damage the device. Follow the device manufacturer’s guidelines. • Placing items on the iPod , or connections to the iPod in the vehicle, can cause damage to the device and/or to the connectors.
Page 231: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
230 UNDERSTANDING YOUR INSTRUMENT PANEL information, call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com, or at www- .siriuscanada.ca for Canadian residents. Electronic Serial Number/Sirius Identification Number (ESN/SID) Please have the following information available when calling: 1.
Page 232: Reception Quality
bikes should be placed as far rearward as possible, within the loading design of the rack. Do not place items directly on or above the antenna. Reception Quality Satellite reception may be interrupted due to one of the following reasons: •...
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL INFO Button Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- able). Also, pressing and holding the INFO button for an additional three seconds will make the radio display the Song Title all of the time (press and hold again to return to normal display).
Page 234: Operating Instructions - Uconnect™ Phone (If Equipped)
SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 235: Kicker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped
234 UNDERSTANDING YOUR INSTRUMENT PANEL KICKER HIGH PERFORMANCE SOUND SYSTEM WITH DRIVER-SELECTABLE SURROUND (DSS) – IF EQUIPPED Your vehicle is equipped with a state of the art audio amplifier that provides 5.1-channel surround sound from any stereo audio source. A new feature of the KICKER audio system offers the ability to choose surround sound for any audio source.
Page 236: Video Entertainment System (Ves)™ - If Equipped
media sources (DVDs, Video CDs, or other video media supported by the radio). Some audio will sound better in DSS modes, others in Stereo mode. When in “Audio Surround” mode, balance is set auto- matically. Fader control is available to add more sur- round audio if desired.
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL • The LCD screen swings up from the rear of the armrest to allow the rear seat passenger(s) to view the display. VES™ Video Screen NOTE: Close the armrest after the LCD screen has been raised to its viewing position.
Page 238: Kicker Mobile Surround (Kms1) - If Equipped
• Two wireless infrared headsets allow rear seat passen- gers to listen to the same or individual audio sources. Audio/Video RCA Jacks (AUX Jacks) on the rear of the center console enable the monitor to display video directly from a video camera, connect video games for display on the screen, or play music directly from an MP3 player.
Page 239: Remote Sound System Controls
238 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the surface of the steering wheel at the three and nine o’clock positions. Remote Sound System Controls Vehicles equipped with steering wheel-mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC).
Page 240: Cd/Dvd Disc Maintenance
When the EVIC is in the Compass/Temp/ Audio screen, press the FUNCTION SE- LECT button to operate various radio, me- dia, and Universal Customer Interface FUNCTION SELECT (UCI) functions (i.e., advance presets, se- Button lect next folder, jump to or start playing songs in playlists, etc., depending on which radio is in the vehicle and if equipped with UCI).
Page 241: Radio Operation And Cellular Phones
240 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna. This condition is not harmful to the radio.
Page 242 Operation of the system is quite simple. Begin by turning the mode control knob (on the right) to AUTO, and place the blower control knob (on the left) to either LO AUTO or HI AUTO. The LO AUTO position should be used for front seat occupants only.
Page 243 242 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • The surface of the climate control panel and the top center of the instrument panel should be kept free of debris due to the location of the climate control sensors. Mud on the windshield may also cause poor operation of this system.
Page 244 UNDERSTANDING YOUR INSTRUMENT PANEL 243...
Page 245 244 UNDERSTANDING YOUR INSTRUMENT PANEL The operator can override the AUTO mode setting to change airflow distribution by rotating the mode control knob (on the right) to one of the following positions. • Defrost Air is directed to the windshield through the outlets at the base of the windshield.
Page 246: Operating Tips
conditioning. An indicator in the button illuminates when manual compressor operation is selected. NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. • Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
Page 247 246 UNDERSTANDING YOUR INSTRUMENT PANEL Winter Operation Use of the air Recirculation mode during Winter months is not recommended because it may cause window fogging. Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower setting.
Page 248 UNDERSTANDING YOUR INSTRUMENT PANEL 247 Control Setting Suggestions for Various Weather Conditions...
Page 250 STARTING AND OPERATING CONTENTS Starting Procedures ....253 Automatic Transmission ....253 Normal Starting (Tip Start) .
Page 251 250 STARTING AND OPERATING General Information ....265 Driving On Slippery Surfaces ... . . 265 Acceleration .
Page 252 Tires — General Information ... . . 292 Tire Pressure ..... . . 292 Tire Inflation Pressures .
Page 253 252 STARTING AND OPERATING Adding Fuel ......312 Fuel Filler Cap (Gas Cap) ....312 Loose Fuel Filler Cap Message .
Page 254: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 255: Normal Starting (Tip Start)
254 STARTING AND OPERATING Normal Starting (Tip Start) NOTE: Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal. Do not press the accelerator. Use the Fob with Integrated Key to briefly turn the ignition switch to the START position and release it as soon as the starter engages.
Page 256: After Starting
If the engine fails to start after you have followed the “Normal Starting” or “Extreme Cold Weather” proce- dures, it may be flooded. To clear any excess fuel, push the accelerator pedal all the way to the floor and hold it. Then, turn the ignition switch to the START position and release it as soon as the starter engages.
Page 257: Automatic Transmission
256 STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 258 • Shift lever position • Accelerator position • Vehicle speed The gear shifting process is continuously adapted, de- pendent on the driving style, the driving situation, and the road characteristics. NOTE: • After selecting any driving position, wait a moment to allow the gear to engage fully before accelerating, especially when the engine is cold.
Page 259: Key Ignition Park Interlock
258 STARTING AND OPERATING WARNING! Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the transmission into PARK, remove the key fob from the ignition switch, and apply the parking brake.
Page 260: Brake/Transmission Interlock Manual Override
Brake/Transmission Interlock Manual Override There is an override for the BTSI that allows you to move the shift lever out of the PARK position if an electrical system malfunction occurs (i.e., dead battery). To access the override, remove the rubber tray from the storage bin located to the right of the shift lever.
Page 261: Five-Speed Automatic Transmission
260 STARTING AND OPERATING Five-Speed Automatic Transmission Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when moving the shift lever between these gears. Shift Lever Gear Ranges PARK...
Page 262 WARNING! Never use the PARK position as a substitute for the parking brake. Always apply parking brake fully when parked to guard against vehicle movement and possible injury or damage. The following indicators should be used to ensure that you have engaged the shift lever in the PARK position: •...
Page 263 262 STARTING AND OPERATING CAUTION! Coasting the vehicle or driving for any other reason with the shift lever in NEUTRAL can result in transmission damage. WARNING! Do not coast in NEUTRAL and never turn off the ignition to coast down a hill. These are unsafe practices that limit your response to changing traffic or road conditions.
Page 264 Temporary Transmission Limp Home Mode The transmission is monitored for abnormal conditions. If a condition is detected that could result in transmission damage, the transmission will engage Limp Home Mode. If vehicle acceleration worsens, or the transmission no longer shifts, the transmission is most likely operating in the Limp Home Mode.
Page 265: Autostick
264 STARTING AND OPERATING AUTOSTICK AutoStick is a driver-interactive transmission that offers manual gear shifting to provide you with more control of the vehicle. AutoStick allows you to maximize engine braking, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations.
Page 266: General Information
one second. The transmission will now operate automati- cally, shifting between the five available gears. General Information • You can start out in first or second gear. The system will ignore attempts to upshift at too low of a vehicle speed.
Page 267: Traction
266 STARTING AND OPERATING Traction When driving on wet or slushy roads, it is possible for a wedge of water to build up between the tire and road surface. This is known as hydroplaning and may cause partial or complete loss of vehicle control and stopping ability.
Page 268: Shallow Standing Water
Shallow Standing Water Although your vehicle is capable of driving through shallow standing water, consider the following Caution and Warning before doing so. CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle.
Page 269: Power Steering
268 STARTING AND OPERATING WARNING! • Driving through standing water limits your vehi- cle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. • Driving through standing water limits your vehi- cle’s braking capabilities, which increases stop- ping distances.
Page 270: Power Steering Fluid Check
• Upon initial start-up in cold weather, the power steer- ing pump may make noise for a short amount of time. This is due to the cold, thick fluid in the steering system. This noise should be considered normal, and it does not in any way damage the steering system.
Page 271: Parking Brake
270 STARTING AND OPERATING WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to ensure accurate fluid level reading. Do not overfill. Use only manufacturer’s recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 272 When the parking brake is applied with the ignition switch in the ON position, the “Brake Warning Light” in the instrument cluster will illuminate. NOTE: • When the parking brake is applied and the transmis- sion is placed in gear, the “Brake Warning Light” will flash.
Page 273: Brake System
272 STARTING AND OPERATING WARNING! (Continued) • Be sure the parking brake is fully disengaged before driving; failure to do so can lead to brake failure and an accident. • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury.
Page 274: Anti-Lock Brake System
Anti-Lock Brake System The Anti-Lock Brake System (ABS) provides increased vehicle stability and brake performance under most braking conditions. The system automatically “pumps” the brakes during severe braking conditions to prevent wheel lock-up. The electronic brake force distribution (EBD) prevents the rear wheels from over-braking and provides greater control of available braking forces applied to the rear axle.
Page 275 274 STARTING AND OPERATING WARNING! • The Anti-Lock Brake System contains sophisti- cated electronic equipment that may be suscep- tible to interference caused by improperly in- stalled high output equipment. This interference can cause possible loss of anti-lock braking capability. Installation of such equipment should be performed by qualified professionals.
Page 276 All vehicle wheels and tires must be the same size and type and tires must be properly inflated to produce accurate signals for the computer. Anti-Lock Brake Light The “Anti-Lock Brake Light” monitors the anti- lock brake system. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds.
Page 277: Electronic Brake Control System
276 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM Your vehicle is equipped with an advanced electronic brake control system commonly referred to as ESP. This system includes the Anti-Lock Brake System (ABS), the Traction Control System (TCS), the Brake Assist System (BAS), and the Electronic Stability Program (ESP).
Page 278: Brake Assist System (Bas)
Brake Assist System (BAS) This system complements the ABS by optimizing the vehicle braking capability during emergency braking maneuvers. This system detects an emergency braking situation by sensing the rate and amount of brake appli- cation and then applies optimum pressure to the brakes. This can help reduce braking distances.
Page 279 278 STARTING AND OPERATING power may also be reduced to assist in counteracting the condition of oversteer or understeer and help the vehicle maintain the desired path. The ESP uses sensors in the vehicle to determine the path that the driver intends to steer the vehicle and compares it to the actual path of the vehicle.
Page 280 The ESP system has three available operating modes: ESP On This is the normal operating mode for the ESP. Whenever the vehicle is started, the ESP system will be in this mode. This mode should be used for most driving situations. The ESP should only be turned OFF for specific reasons as noted in the following paragraphs.
Page 281 280 STARTING AND OPERATING stopped with the engine running. After five seconds, a chime will sound, the “ESP/TCS Indicator Light” will illuminate, and the ESP OFF message will display in the vehicle odometer. Press and release the TRIP ODOM- ETER button located on the instrument cluster to clear this message.
Page 282: Synchronizing Esp
WARNING! With the ESP switched OFF, the enhanced vehicle stability offered by ESP is unavailable. In an emer- gency evasive maneuver, the ESP system will not en- gage to assist in maintaining stability. The “Full Off” ESP mode is intended for off-highway or off-road only. Synchronizing ESP The Malfunction Indicator Light for the ESP is combined with BAS indicator.
Page 283: Tire Safety Information
282 STARTING AND OPERATING NOTE: • The “ESP/TCS Indicator Light” and the “ESP/BAS Malfunction Indicator Light” will turn on momen- tarily each time the ignition switch is turned to the ON position. • Each time the ignition switch is turned to the ON position, the ESP System will be ON even if it was turned OFF previously.
Page 284 NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 285 284 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 286 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 287: Tire Identification Number (Tin)
286 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, DOT = Department of Transportation —...
Page 288: Tire Terminology And Definitions
Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 289: Tire Loading And Tire Pressure
288 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire Placard Location Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 290 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 291 290 STARTING AND OPERATING 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
Page 292 STARTING AND OPERATING 291...
Page 293: Tires - General Information
292 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 294: Tire Inflation Pressures
WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
Page 295 294 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 296: Tire Pressures For High Speed Operation
Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 297: Tread Wear Indicators
296 STARTING AND OPERATING WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) or for more than 30 seconds continuously when you are stuck, and do not let anyone near a spinning wheel, no matter what the...
Page 298: Life Of Tire
Life of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure.
Page 299 298 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 300: Snow Tires
SNOW TIRES Some areas of the country require the use of snow tires during the winter. Standard tires are of the all season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall. If you need snow tires, select tires equivalent in size and type to the original equipment tires.
Page 301: Tire Rotation - Standard Tires
300 STARTING AND OPERATING Tire Rotation – Standard Tires The suggested rotation method is the “side-to-side” as shown in the following diagram. Tire Rotation Tire Rotation – All Season Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram.
Page 302: Tire Pressure Monitor System (Tpms)
TIRE PRESSURE MONITOR SYSTEM (TPMS) The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure. The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C). This means that when the outside temperature decreases, the tire pressure will decrease.
Page 303 302 STARTING AND OPERATING For example, your vehicle may have a recommended cold (parked for more than three hours) placard pressure of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), a temperature drop to 20°F (-7°C) will decrease the tire pressure to approximately 26 psi (179 kPa).
Page 304: Premium System
NOTE: • The TPMS is not intended to replace normal tire care and maintenance or to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure. •...
Page 305 304 STARTING AND OPERATING • Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and • TPM Telltale Light. The matching full size spare wheel and tire assembly (if equipped) has a TPM sensor. The full size spare can be used in place of any of the four road tires.
Page 306 STARTING AND OPERATING 305 turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. Check TPMS Warning If a system fault is detected, the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 307 306 STARTING AND OPERATING If the ignition switch is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the TPM Telltale Light will no longer flash, and the CHECK TPM SYSTEM message will no longer display, and a pressure value will display in place of the dashes.
Page 308: General Information
2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition switch cycle, the TPM Telltale Light will remain ON and a chime will sound. In addition, the graphic in the EVIC will still display a flashing pressure value.
Page 309: Fuel Requirements
308 STARTING AND OPERATING The TPM sensors are regulated under one of the follow- ing licenses: United States ..... KR5S120123 Canada .
Page 310: Gasoline/Oxygenate Blends
The manufacturer supports the use of reformulated gaso- line. Properly blended reformulated gasoline will pro- vide excellent performance and durability of engine and fuel system components. Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions.
Page 311: Mmt In Gasoline
310 STARTING AND OPERATING To fix a Non-FFV vehicle inadvertently fueled once with E85 perform the following: • drain the fuel tank (see your authorized dealer) • change the engine oil and oil filter • disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E85 fuel.
Page 312: Fuel System Cautions
Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s performance: • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine perfor- mance and damage the emissions control system. • An out-of-tune engine or certain fuel or ignition malfunctions can cause the catalytic converter to overheat.
Page 313: Carbon Monoxide Warnings
312 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas, which can kill.
Page 314 NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler cap door reinforcement. Gas Cap Tether Hook STARTING AND OPERATING 313 CAUTION! • Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap (gas cap).
Page 315: Loose Fuel Filler Cap Message
314 STARTING AND OPERATING WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
Page 316: Vehicle Loading
VEHICLE LOADING The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information should be used for passenger and luggage loading as indicated. Do not exceed the specified Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight Rating (GAWR). Vehicle Certification Label Your vehicle has a Vehicle Certification Label affixed to the rear of the driver’s door.
Page 317: Overloading
316 STARTING AND OPERATING WARNING! Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident.
Page 318: Trailer Towing
NOTE: • Refer to the “Vehicle Certification Label” affixed to the rear of the driver’s door for your vehicle’s GVWR and GAWRs. • Refer to the “Tire Placard” for your vehicle’s proper tire pressure. TRAILER TOWING Trailer towing with this vehicle is not recommended. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Recreational towing is allowed ONLY if the driveshaft...
Page 320: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....320 If Your Engine Overheats ....320 TIREFIT Kit .
Page 321: Hazard Warning Flasher
320 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located in the switch bank near the top center of the instrument panel. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 322: Tirefit Kit
CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116°C) or greater pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range 200– 230°F (93–110°C).
Page 323: Tirefit Storage
322 WHAT TO DO IN EMERGENCIES TIREFIT Storage The TIREFIT kit is located in the trunk. TIREFIT Location TIREFIT Kit Components and Operation 1. Sealant Bottle 2. Deflation Button — If Equipped 3. Pressure Gauge 4. Power Button...
Page 324 5. Mode Select Knob 6. Sealant Hose (Clear with Yellow Cap) 7. Air Pump Hose (Black) 8. Power Plug Using the Mode Select Knob and Hoses Your TIREFIT kit may be equipped with either of the following symbols to indicate the air or sealant mode. Selecting Air Mode Turn the Mode Select Knob (5) to this position for air pump operation only.
Page 325: Tirefit Usage Precautions
324 WHAT TO DO IN EMERGENCIES TIREFIT Usage Precautions • Replace the TIREFIT Sealant Bottle (1) and Sealant Hose (6) prior to the expiration date (printed on the bottle label) to assure optimum operation of the sys- tem. Refer to “Sealing a Tire with TIREFIT” section (F) “Sealant Bottle and Hose Replacement”.
Page 326 WARNING! (Continued) • Do not use TIREFIT or drive the vehicle under the following circumstances: − If the cut or puncture in the tire tread is approxi- mately 0.24 in. (6 mm) or larger. − If the tire has any sidewall damage. −...
Page 327: Sealing A Tire With Tirefit
326 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • TIREFIT Sealant solution contains latex. In case of allergic reaction or rash, consult a physician im- mediately. Keep TIREFIT out of reach of children. If swallowed, rinse mouth immediately with plenty of water and drink plenty of water. Do not induce vomiting! Consult a physician immedi- ately.
Page 328 3. Uncoil the Sealant Hose (6) and then remove the yellow cap from the fitting at the end of the hose. 4. Place the TIREFIT kit flat on the ground next to the deflated tire. 5. Remove the cap from the valve stem and then screw the fitting at the end of the Sealant Hose (6) onto the valve stem.
Page 329 328 WHAT TO DO IN EMERGENCIES 2. Connect the Power Plug (8) to a different 12 Volt power outlet in your vehicle or another vehicle, if avail- able. Make sure the engine is running before turning ON the TIREFIT kit. 3.
Page 330 If the tire inflates to the recommended pressure or is at least 26 psi (1.8 Bar) pressure within 15 minutes: 1. Press the Power Button (4) to turn off the TIREFIT kit. 2. Remove the Speed Limit sticker from the top of the Sealant Bottle (1) and place the sticker on the instrument panel.
Page 331 330 WHAT TO DO IN EMERGENCIES WARNING! TIREFIT is not a permanent flat tire repair. Have the tire inspected and repaired or replaced after using TIREFIT. Do not exceed 55 mph (88 km/h) until having the tire repaired or replaced. Failure to follow this warning can result in injuries that are serious or fatal to you, your passengers, and others around you.
Page 332 5. Replace the Sealant Bottle (1) and Sealant Hose (6) assembly at your authorized dealer as soon as possible. Refer to “(F) Sealant Bottle and Hose Replacement.” NOTE: When having the tire serviced advise the autho- rized dealer or service center that the tire has been sealed using the TIREFIT service kit.
Page 333: Jump-Starting Procedures
332 WHAT TO DO IN EMERGENCIES JUMP-STARTING PROCEDURES If your vehicle has a discharged battery it can be jump- started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
Page 334 1 — Remote Negative (-) Post 2 — Remote Positive (+) Post Remote Battery Posts WHAT TO DO IN EMERGENCIES 333 WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on.
Page 335: Jump-Starting Procedure
334 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 336 WARNING! Do not connect the cable to the negative post (-) of the discharged battery. The resulting electrical spark could cause the battery to explode and could result in personal injury. 5. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged battery.
Page 337: Freeing A Stuck Vehicle
336 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
Page 338: Towing A Disabled Vehicle
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires. A tire could explode and injure someone. Do not spin your vehi- cle’s wheels faster than 30 mph (48 km/h) or for longer than 30 seconds continuously without stop- ping when you are stuck and do not let anyone near a spinning wheel, no matter what the speed.
Page 339: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
338 WHAT TO DO IN EMERGENCIES Vehicles equipped with AWD can be towed with the transmission in NEUTRAL and the rear wheels OFF the ground (or the rear driveshaft removed) with no limita- tion on speed or distance. CAUTION! • Do not attempt to tow this vehicle from the front with sling-type towing equipment.
Page 340: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 6.1L ... . . 341 Onboard Diagnostic System — OBD II ..342 Loose Fuel Filler Cap ....342 Emissions Inspection And Maintenance Programs .
Page 341 340 MAINTAINING YOUR VEHICLE Cooling System ..... 358 Brake System ..... . . 363 Automatic Transmission .
Page 342: Engine Compartment - 6.1L
ENGINE COMPARTMENT — 6.1L 1 — Remote Jump Start (Positive Battery Post) 2 — Integrated Power Module 3 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Access Cover 5 — Engine Coolant Reservoir MAINTAINING YOUR VEHICLE 341 6 — Power Steering Fluid Reservoir 7 —...
Page 343: Onboard Diagnostic System - Obd Ii
342 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 344: Emissions Inspection And Maintenance Programs
TRIP ODOMETER button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the MIL. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass an inspection of your vehicle’s emissions control system.
Page 345: Replacement Parts
344 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 346: Maintenance Procedures
NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle. Only do service work for which you have the knowledge and the proper equipment.
Page 347: Engine Oil
346 MAINTAINING YOUR VEHICLE Engine Oil Checking Oil Level To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about five minutes after a fully warmed engine is shut off or before starting the engine after it has sat overnight.
Page 348 CAUTION! Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Such damage is not covered by the New Vehicle Limited Warranty. Engine Oil Viscosity (SAE Grade) SAE 5W-40 engine oil is preferred for use in all operating temperatures.
Page 349: Engine Oil Filter
348 MAINTAINING YOUR VEHICLE Engine Oil Filter The engine oil filter should be replaced with a new filter at every engine oil change. Engine Oil Filter Selection This manufacturer’s engines have a full-flow type oil filter. Use a filter of this type for replacement. The quality of replacement filters varies considerably.
Page 350: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 349 Engine Air Cleaner Filter Selection The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be used to assure most efficient service. MOPAR engine air cleaner filters are a high quality filter and are recommended.
Page 351 350 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 352: Air Conditioner Maintenance
Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time.
Page 353: A/C Air Filter
352 MAINTAINING YOUR VEHICLE Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 354 2. Slide the lid on the filter adapter forward and down and remove the used filter. 3. Install the new filter with arrows pointing in the direction of airflow, which is toward the rear of the vehicle (text and arrows on the filter will indicate this). MAINTAINING YOUR VEHICLE 353 A/C Air Filter Refer to “Maintenance Schedule”...
Page 355: Body Lubrication
354 MAINTAINING YOUR VEHICLE Body Lubrication Locks and all body pivot points, including such items as seat tracks, door hinge pivot points and rollers, liftgate, tailgate, sliding doors and hood hinges, should be lubri- cated periodically with a lithium based grease, such as MOPAR Spray White Lube or equivalent to assure quiet, easy operation and to protect against rust and wear.
Page 356: Adding Washer Fluid
present please proceed to clean wiper blades with humid cloth removing any debris that may be affecting its function. Adding Washer Fluid The windshield washer fluid reservoir is located in the front of the engine compartment. Be sure to check the fluid level in the reservoir at regular intervals.
Page 357 356 MAINTAINING YOUR VEHICLE have an authorized technician inspect the complete ex- haust system and adjacent body areas for broken, dam- aged, deteriorated, or mispositioned parts. Open seams or loose connections could permit exhaust fumes to seep into the passenger compartment. In addition, inspect the exhaust system each time the vehicle is raised for lubri- cation or oil change.
Page 358 CAUTION! (Continued) • Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involving engine misfire or other apparent loss of performance, have your vehicle serviced promptly. Continued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and...
Page 359 358 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position. The fan is tempera- ture controlled and can start at any time the ignition switch is in the ON position.
Page 360 Cooling System – Drain, Flush, and Refill If the engine coolant (antifreeze) is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner. Follow with a thorough rinsing to remove all deposits and chemicals. Properly dispose of the old engine coolant (antifreeze) solution.
Page 361 360 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant (antifreeze) that allows extended maintenance intervals. This engine coolant (antifreeze) can be used up to five years or 102,000 miles (170 000 km) before replacement.
Page 362 Cooling System Pressure Cap The cap must be fully tightened to prevent loss of engine coolant (antifreeze), and to ensure that engine coolant (antifreeze) will return to the radiator from the coolant recovery bottle. The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces.
Page 363 362 MAINTAINING YOUR VEHICLE Coolant Level The coolant bottle provides a quick visual method for determining that the engine coolant (antifreeze) level is adequate. With the engine OFF and cold, the level of the engine coolant (antifreeze) in the bottle should be be- tween the ranges indicated on the bottle.
Page 364: Brake System
• If frequent engine coolant (antifreeze) additions are required, or if the level in the coolant recovery bottle does not drop when the engine cools, the cooling system should be pressure tested for leaks. • Maintain engine coolant (antifreeze) concentration at 50% HOAT engine coolant (antifreeze) (minimum) and distilled water for proper corrosion protection of your engine, which contains aluminum components.
Page 365 364 MAINTAINING YOUR VEHICLE Master Cylinder – Brake Fluid Level Check Check the fluid level in the master cylinder immediately if the brake system warning light indicates system fail- ure. Check the fluid level in the master cylinder when per- forming underhood services.
Page 366: Automatic Transmission
WARNING! (Continued) • To avoid contamination from foreign matter or moisture, use only new brake fluid or fluid that has been in a tightly closed container. Keep the master cylinder reservoir cap secured at all times. Brake fluid in a open container absorbs moisture from the air resulting in a lower boiling point.
Page 367 366 MAINTAINING YOUR VEHICLE CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than that recommended by the manufacturer will result in more frequent fluid and filter changes.
Page 368: Rear Axle
Special Additives Automatic Transmission Fluid (ATF) is an engineered product and its performance may be impaired by supple- mental additives. Therefore, do not add any fluid addi- tives to the transmission. The only exception to this policy is the use of special dyes to aid in detecting fluid leaks.
Page 369: Appearance Care And Protection From Corrosion
368 MAINTAINING YOUR VEHICLE Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and chemicals that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 370 • Use a high quality cleaner wax, such as MOPAR Cleaner Wax to remove road film, stains and to protect your paint finish. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 371 370 MAINTAINING YOUR VEHICLE • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well packaged and sealed. • If a lot of driving is done on gravel roads, consider mud or stone shields behind each wheel. •...
Page 372 • Do not use any harsh solvents or any other form of protectants on Stain Repel products. Interior Care Use MOPAR Fabric Cleaner or equivalent to clean fabric upholstery and MOPAR Carpet Cleaner or equivalent for carpeting. Interior trim should be cleaned starting with a damp cloth, or MOPAR Satin Select or equivalent.
Page 373 372 MAINTAINING YOUR VEHICLE To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution fol- lowed by rinsing. Do not use abrasive cleaning components, solvents, steel wool or other aggressive material to clean the lenses.
Page 374: Fuses
MAINTAINING YOUR VEHICLE 373 Replace the belts if they appear frayed or worn or if the buckles do not work properly. Cleaning the Center Console Cupholders Clean with a damp cloth or towel using a mild detergent with the cupholder in the center console. NOTE: The cupholder cannot be removed.
Page 375 374 MAINTAINING YOUR VEHICLE CAUTION! • When installing the integrated power module cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the integrated power module and possibly result in an electrical system failure.
Page 376 Cavity Car- Mini- Description tridge Fuse Fuse — 30 Amp Starter Green — — — 30 Amp — Windshield Wiper Pink 30 Amp — Anti-Lock Brake System Pink (ABS) Valves 40 Amp — Radiator Fan Green 50 Amp — Anti-Lock Brake System (ABS) Pump Motor —...
Page 377: Rear Power Distribution Center
376 MAINTAINING YOUR VEHICLE Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Opening the Access Panel...
Page 378 CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 379 378 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse 30 Amp — Heated Seats – If Pink Equipped — 20 Amp Fuel Pump Yellow — 20 Amp Sub Amp – If Equipped Yellow — 15 Amp Diagnostic Link Connec- Blue tor (DLC)/Wireless Con- trol Module (WCM)/...
Page 380 Cavity Car- Mini- Description tridge Fuse Fuse — — — — — — — — — — — — — 10 Amp Occupant Restraint Con- troller (ORC) — 10 Amp Ignition Run — 5 Amp Cluster/Electronic Sta- Orange bility Program (ESP)/ Powertrain Control Module (PCM)/Stop Light Switch...
Page 381 380 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse — 10 Amp Cargo Light/Satellite Receiver (SDARS) Video – If Equipped/Vehicle Information Module – If Equipped — 10 Amp Heated Mirrors – If Equipped — 5 Amp Auto Inside Rearview Orange Mirror/Heated Seats –...
Page 382: Vehicle Storage
VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days, you may want to take these steps to protect your battery. • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower setting.
Page 383: Bulb Replacement
382 MAINTAINING YOUR VEHICLE Exterior Low Beam Headlamp (Standard Halogen) ..9006 Low Beam Headlamp – High Intensity Discharge (HID) ....D1S (Serviced at Authorized Dealer) High Beam Headlamp .
Page 384 CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. 3. Disconnect the bulb from the socket assembly and install the replacement bulb.
Page 385 384 MAINTAINING YOUR VEHICLE 3 — Park/Turn Lamp Bulb 4 — Side Marker Lamp Bulb...
Page 386: Low Beam Headlamp, High Beam
Low Beam Headlamp, High Beam Headlamp, and Park/Turn Lamp — Models with High Intensity Discharge Headlamps (HID) HID Headlamps The headlamps are a type of high voltage discharge tube. High voltage can remain in the circuit even with the headlamp switch off and the key removed. Because of this, you should not attempt to service a headlamp bulb yourself.
Page 387: Backup Lamp, Side Marker Lamp, Tail/Turn Lamp, And Tail/Stop Lamp
386 MAINTAINING YOUR VEHICLE Backup Lamp, Side Marker Lamp, Tail/Turn Lamp, and Tail/Stop Lamp 1. Open the trunk. 2. Remove two fasteners from the back of the taillamp assembly. 3. Pull back the trunk liner. 4. Remove the remaining fastener from the back of the taillamp assembly.
Page 388 MAINTAINING YOUR VEHICLE 387 8. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the taillamp assembly. 2 — Side Marker Lamp Bulb 1 — Backup Lamp Bulb...
Page 389 388 MAINTAINING YOUR VEHICLE 3 — Tail/Turn Lamp Bulb 4 — Tail/Stop Lamp Bulb 9. Disconnect the bulb from the socket assembly and install the replacement bulb. 10. Reinstall the bulb and socket assembly into the taillamp assembly, and then turn it clockwise.
Page 390: License Lamp
11. Reinstall the taillamp assembly, fasteners, electrical connector, and trunk liner. 12. Close the trunk. License Lamp 1. Remove the screws securing the lamp to the rear fascia. 2. Remove the bulb and socket assembly. 3. Disconnect the bulb from the socket assembly and install the replacement bulb.
Page 391: Fluid Capacities
390 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 6.1 Liter Engine (SAE 5W-40, API Certified) Cooling System * 6.1 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level. U.S.
Page 392: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. For best performance and maximum protection under all types of operat- ing conditions, the manufacturer only recommends full synthetic engine oils that meet the requirements of Chrysler Material Standard MS-10725 and are approved to MB 229.3 or MB 229.5.
Page 393: Chassis
392 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Rear Axle Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. MOPAR DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 brake fluid is not available, then DOT 4 is acceptable.
Page 394 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..394 Maintenance Schedule ....394 Required Maintenance Intervals ..396...
Page 395 394 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 396 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change, even if the oil change indicator message is NOT illuminated.
Page 397 396 MAINTENANCE SCHEDULES • Check the fluid levels of the coolant reservoir, brake master cylinder, and power steering, add as needed. • Check all lights and other electrical items for correct operation. At Each Oil Change • Change the engine oil filter. •...
Page 398 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule ❏...
Page 399: Service Schedule
398 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule ❏...
Page 400 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
Page 401 400 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule ❏...
Page 402 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule ❏...
Page 403 402 MAINTENANCE SCHEDULES 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule ❏...
Page 404 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule ❏...
Page 405 404 MAINTENANCE SCHEDULES 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Inspect and replace the PCV Valve if necessary.* ❏...
Page 406 102,000 Miles (170,000 km) or 102 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the spark plugs. ❏ Flush and replace the engine coolant if not done at 60 months. Odometer Reading Date Repair Order #...
Page 407 406 MAINTENANCE SCHEDULES 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏...
Page 408 126,000 Miles (210,000 km) or 126 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule ❏...
Page 409 408 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule ❏...
Page 410 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
Page 412: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......413 Prepare For The Appointment .
Page 413 412 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......418 Treadwear ......419 Traction Grades .
Page 414: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 415: Chrysler Group Llc Customer Center
414 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 416: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 417: Warranty Information
416 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 418: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 419: Department Of Transportation Uniform Tire
418 IF YOU NEED CONSUMER ASSISTANCE • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 420: Traction Grades
Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half times as well on the government course as a tire graded 100.
Page 421 420 IF YOU NEED CONSUMER ASSISTANCE Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law. WARNING! The temperature grade for this tire is established for a tire that is properly inflated and not overloaded.
Page 422 INDEX...
Page 423 422 INDEX About Your Brakes ....270,272 ABS (Anti-Lock Brake System) ... . 273,276 Adding Engine Coolant (Antifreeze) .
Page 424 Automatic Door Locks ....27,28 Automatic Headlights ....131 Automatic Temperature Control (ATC) .
Page 425 424 INDEX Brightness, Interior Lights ....135 Bulb Replacement ..... 381,382 Bulbs, Light .
Page 426 Console, Floor ......159 Console, Overhead ..... . . 145 Contract, Service .
Page 427 426 INDEX Door Locks ......26 Door Locks, Automatic ....27 Door Opener, Garage .
Page 428 Fuel Requirements ..... 308 Jump Starting ......332 Oil .
Page 429 428 INDEX Brake ......364 Cooling System ..... . . 358 Engine Oil .
Page 430 General Maintenance ..... 345 Glass Cleaning ......372 Gross Axle Weight Rating .
Page 431 430 INDEX Immobilizer (Sentry Key) ....15 Infant Restraint ......64,65 Information Center, Vehicle .
Page 432 Anti-Lock ......177,275 Automatic Headlights ....131 Brake Assist Warning .
Page 433 432 INDEX Tire Pressure Monitoring (TPMS) ..175,301 Traction Control ..... . . 281 Turn Signal .
Page 434 Exterior Folding ......85 Heated ......86 Outside .
Page 435 434 INDEX Outside Rearview Mirrors ....84 Overhead Console ..... . . 145 Overheating, Engine .
Page 436 Radio, Satellite (Uconnect studios) ... 229 Rear Cupholder ......159 Rear Seat, Folding .
Page 437 436 INDEX Schedule, Maintenance ....394 Seat Belt Maintenance ....372 Seat Belt Reminder .
Page 438 Settings, Personal ......192 Shifting ....... 256 Automatic Transmission .
Page 439 438 INDEX Synthetic Engine Oil ..... . 347 System, Remote Starting ....23 Tachometer .
Page 440 Towing ....... 317 24-Hour Towing Assistance ....102 Behind a Motor Home .
Page 441 440 INDEX Vehicle Identification Number (VIN) ... . 6 Vehicle Loading ....289,315,316 Vehicle Modifications/Alterations .
Page 442 Chrysler Group LLC 10D482-126-AC Printed in U.S.A. 3rd Edition...

Dodge 2010 Charger SRT Owner's Manual

Introduction 1

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

What to Do in Emergencies

Quick Links

Chapters

Related Manuals for Dodge 2010 Charger SRT

Summary of Contents for Dodge 2010 Charger SRT
