Related Manuals for Dodge 2010 Avenger

Summary of Contents for Dodge 2010 Avenger

  • Page 1 Avenger 2 0 1 0 O W N E R ’ S M A N U A L...

  • Page 2: Introduction

    TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...

  • Page 4: Table Of Contents

    CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .

  • Page 5: Introduction

    4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
  • Page 6 INTRODUCTION 5...

  • Page 7: Warnings And Cautions

    6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.

  • Page 8: Vehicle Modifications/Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.

  • Page 10: Things To Know Before Starting Your Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
  • Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Open Window Feature — If Equipped ......24 Using The Panic Alarm .
  • Page 12 Adjustable Upper Shoulder Belt Anchorage . . . 45 Rear Seat Belts ..... . . 46 Automatic Locking Retractors (ALR) Mode —...

  • Page 13: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys from your authorized dealer.
  • Page 14 NOTE: • If you try to remove the key before you place the shift lever in PARK, the key may become trapped tempo- rarily in the ignition switch lock cylinder. If this occurs, rotate the key to the right slightly, then remove the key as described.

  • Page 15: Key-In-Ignition Reminder

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked car is an invitation to thieves. Always remove key from the ignition and lock all doors when leaving the vehicle unattended. Key-In-Ignition Reminder Opening the driver’s door when the key is in the ignition, sounds a signal to remind you to remove the key.

  • Page 16: Replacement Keys

    NOTE: A key, which has not been programmed, is also considered an invalid key even if it is cut to fit the ignition switch lock cylinder for that vehicle. During normal operation, after turning the ignition switch, the Vehicle Security Light will turn on for three seconds for a bulb check.

  • Page 17: Customer Key Programming

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). This PIN is required for authorized dealer replacement of keys. Duplication of keys may be performed at an authorized dealer or by using the Customer Key Pro- gramming procedure.

  • Page 18: General Information

    The new Sentry Key is programmed. The Remote Keyless Entry (RKE) transmitter will also be pro- grammed during this procedure. Repeat this procedure to program up to eight keys. If you do not have a programmed Sentry Key , contact your authorized dealer for details.

  • Page 19: Rearming The System

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rearming The System If something triggers the alarm, and no action is taken to disarm it, the Vehicle Security Alarm will turn off the horn after three minutes, turn off all of the visual signals after 15 minutes, and then the Vehicle Security Alarm will rearm itself.

  • Page 20: To Disarm The System

    To Disarm The System Either press the UNLOCK button on the RKE transmitter or insert a valid Sentry Key into the ignition lock cylinder and turn the key to the ON/START position. NOTE: • The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm.

  • Page 21: Remote Keyless Entry (Rke) - If Equipped

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This feature also turns on the approach lighting (if equipped). Refer to “Electronic Vehicle Information Cen- ter (EVIC)/Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information. The interior lights will fade to off after approximately 30 seconds or they will immediately fade to off once the ignition switch is turned ON.

  • Page 22: To Unlock The Doors

    Vehicle Key To Unlock the Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The Illuminated Entry system (if equipped) will also turn on.
  • Page 23 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Release both buttons at the same time. 3. Test the feature while outside of the vehicle, by pressing the LOCK/UNLOCK buttons on the RKE trans- mitter with the ignition in the LOCK position, and the key removed.

  • Page 24: To Lock The Doors

    3. Test the feature while outside of the vehicle, by pressing the LOCK/UNLOCK buttons on the RKE trans- mitter with the ignition in the LOCK position, and the key removed. 4. Repeat these steps if you want to return this feature to its previous setting.

  • Page 25: To Unlatch The Trunk

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the following steps: 1. Press the LOCK button on a programmed RKE trans- mitter for at least four seconds, but not longer than 10 seconds.

  • Page 26: Programming Additional Transmitters

    headlights and park lights will flash, the horn will pulse on and off, and the Illuminated Entry system (if equipped) will turn on. The Panic Alarm will stay on for three minutes unless you turn it off by pressing the PANIC button a second time or if the vehicle speed is 5 mph (8 km/h) or greater.

  • Page 27: General Information

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Remove and replace the battery. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3. To assemble the RKE transmitter case, snap the two halves together.

  • Page 28: How To Use Remote Start

    How to Use Remote Start All of the following conditions must be met before the engine will remote start: • Shift lever in PARK • Doors closed • Hood closed • Trunk closed • Hazard switch off • Brake switch inactive (brake pedal not pressed) •...
  • Page 29 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • If an engine fault is present the vehicle will start and then shut down 10 seconds later. • For security, power window operation is disabled when the vehicle is in the Remote Start mode. •...

  • Page 30: Door Locks

    DOOR LOCKS Manual Door Locks Use the manual door lock plunger to lock the doors from inside the vehicle. If the plunger is down when the door is closed, the door will lock. Make sure the keys are not inside the vehicle before closing the door. Manual Lock Plunger THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 WARNING!

  • Page 31: Power Door Locks

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked vehicle is an invitation to thieves. Always remove the key from the ignition and lock all of the doors when leaving the vehicle unattended. Power Door Locks A door lock switch is located on the driver and passenger door panel.
  • Page 32 Auto Unlock On Exit The doors will unlock automatically on vehicles with power door locks if: 1. The Automatic Unlock Doors On Exit feature is en- abled. 2. The transmission shift lever was in gear and the vehicle speed returned to 0 mph (0 km/h). 3.

  • Page 33: Child Protection Door Lock System (Rear Doors)

    32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws. Child Protection Door Lock System (Rear Doors) The Child Protection Door Locks (Rear Doors) are located inside the rear edge of the door.

  • Page 34: Power Windows

    NOTE: For emergency exit with the system engaged, move the lock plunger up (UNLOCKED position), roll down the window, and open the door with the outside door handle. POWER WINDOWS Power Window Switches The window controls on the driver’s door trim panel operate the door windows and the rear windows NOTE: •...

  • Page 35: Auto Window Down - If Equipped

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE There is a single window control on the passenger’s door trim panel, which operates the passenger door window. The window controls will operate when the ignition switch is turned to the ON or ACC position, and when the accessory delay feature is active.

  • Page 36: Auto Window Up - If Equipped

    Auto Window Up — If Equipped Lift the window switch to the second detent, release, and the window will go up automatically. To cancel the Auto Up movement, operate the switch either in the up or down direction and release the switch. To close the window part way, lift the window switch to the first detent and release it when you want the window to stop.

  • Page 37: Window Lockout Switch

    36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window LOCK button.

  • Page 38: Trunk Release

    buffeting occurs with the sunroof open, then adjust the sunroof opening to minimize the buffeting. TRUNK RELEASE Use the Remote Keyless Entry (RKE) transmitter to open the trunk from outside the vehicle. From inside the vehicle the trunk lid can be released by pressing the TRUNK RELEASE button located on the instrument panel to the left of the steering wheel.

  • Page 39: Trunk Internal Emergency Release

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Trunk Internal Emergency Release As a security measure, a Trunk Internal Emergency Release lever is built into the trunk latching mechanism. In the event of an individual being locked inside the trunk, the trunk can be simply opened by pulling on the glow-in-the-dark handle attached to the trunk latching mechanism.
  • Page 40 • An energy-absorbing steering column and steering wheel • Knee bolsters/blockers for front seat occupants • Front seat belts incorporate pretensioners to enhance occupant protection by managing occupant energy during an impact event — if equipped • All seat belt systems (except the driver’s) include Automatic Locking Retractors (ALRs), which lock the seat belt webbing into position by extending the belt all the way out and then adjusting the belt to the...

  • Page 41: Lap/Shoulder Belts

    40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even on short trips. Someone on the road may be a poor driver and cause a collision that includes you. This can happen far away from home or on your own street.
  • Page 42 WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
  • Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt that is buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you.
  • Page 44 WARNING! • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries. Ribs aren’t as strong as shoulder bones.
  • Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.

  • Page 46: Adjustable Upper Shoulder Belt Anchorage

    Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180°...

  • Page 47: Rear Seat Belts

    46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you will prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position.

  • Page 48: Seat Belt Pretensioners - If Equipped

    Seat Belt Pretensioners — If Equipped The seat belts for both front seating positions may be equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
  • Page 49 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE However if during a front impact, a secondary rear impact occurs, the AHR may deploy based on the sever- ity and type of the impact. Active Head Restraint (AHR) Components 1 — Head Restraint Front 3 —...
  • Page 50 1. Grasp the deployed AHR from the rear seat. Hand Positioning Points On AHR 2. Position the hands on the top of the deployed AHR at a comfortable position. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism.
  • Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3 — Final Downward Movement To Engage Locking Mecha- nism 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. AHR In Reset Position NOTE: •...

  • Page 52: Enhanced Seat Belt Use Reminder System (Beltalert )

    Enhanced Seat Belt Use Reminder System (BeltAlert ) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the BeltAlert will alert the driver to buckle the seat belt.

  • Page 53: Seat Belts And Pregnant Women

    52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Watch for the Seat Belt Reminder Light to turn on while unbuckling and off while re-buckling the seat belt. It may be necessary to retract the seat belt partially each time when unbuckling. 4.

  • Page 54: Supplemental Restraint System (Srs) - Airbags

    WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.

  • Page 55: Airbag System Components

    54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation that are based on the severity and type of collision. This vehicle may be equipped with driver and/or front passenger seat track position sensors that may adjust the inflation rate of the Advanced Front Airbags based upon seat position.

  • Page 56: Advanced Front Airbag Features

    • Knee Impact Bolster • Driver Advanced Front Airbag • Passenger Advanced Front Airbag • Supplemental Seat-Mounted Side Airbags (SAB) • Supplemental Side Airbag Inflatable Curtains (SABIC) • Front and Side Impact Sensors • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors •...
  • Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not put anything on or around the airbag covers or attempt to open them manually. You may damage the airbags and you could be injured because the airbags may no longer be functional. The protective covers for the airbag cushions are designed to open only when the airbags are inflat- ing.
  • Page 58 When the airbag deploys, it opens the seam between the front and side of the seat’s trim cover. Each airbag deploys independently, that is a left side impact deploys the left airbag only and a right-side impact deploys only the right airbag. Supplemental Side Airbag Inflatable Curtain (SABIC) —...
  • Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system includes side impact sensors adjacent to both front and rear seat occupants that are calibrated to deploy the SABIC airbags during impacts that require airbag occupant protection. WARNING! • If your vehicle is equipped with left and right Supplemental Side Airbag Inflatable Curtain (SABIC), do not stack luggage or other cargo up high enough to block the location of the SABIC.
  • Page 60 WARNING! Infants in rear facing child restraints should NEVER ride in the front seat of a vehicle with a passenger Advanced Front Airbag. An airbag deployment can cause severe injury or death to infants in that posi- tion. Children that are not big enough to wear the vehicle seat belt properly (see section on Child Restraints) should be secured in the rear seat in child restraints or belt- positioning booster seats.

  • Page 61: Airbag Deployment Sensors And Controls

    60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center. Phone numbers are provided under If You Need Assistance . WARNING! •...
  • Page 62 The ORC determines if deployment of the front and/or side airbags in a frontal or side collision is required. Based on the impact sensors signals, a central electronic ORC deploys the Advanced Front Airbags, SABIC airbags — if equipped, Supplemental Seat-Mounted Side Airbags — if equipped, and front seat belt pretensioners —...
  • Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE in the ACC position, or not in the ignition, the airbag system is not on and the airbags will not inflate. The ORC contains a backup power supply system that may deploy the airbags even if the battery loses power or it becomes disconnected prior to deployment.
  • Page 64 separate and fold out of the way as the airbags inflate to their full size. The airbags fully inflate in about 50 to 70 milliseconds. This is about half of the time it takes to blink your eyes. The airbags then quickly deflate while helping to restrain the driver and front passenger.
  • Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE covers the window. The airbag inflates in about 30 ms (about one-quarter of the time that it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area where the side curtain airbag inflates.
  • Page 66 NOTE: Front and/or side airbags will not deploy in all collisions. This does not mean something is wrong with the airbag system. If you do have a collision, which deploys the airbags, any or all of the following may occur: •...
  • Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you.

  • Page 68: Event Data Recorder (Edr)

    Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. While the airbag system is designed to be mainte- nance free, if any of the following occurs, have an authorized dealer service the system immediately. •...
  • Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Under certain circumstances, EDR data may not be recorded (e.g., loss of battery power). In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be used by Chrysler Group LLC and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle perfor-...

  • Page 70: Child Restraints

    3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that are recorded: • Diagnostic trouble code(s) and warning light status for electronically-controlled safety systems, including the airbag system • Vehicle speed • Engine RPM •...
  • Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat owner’s manual to ensure you have the correct seat for your child.
  • Page 72 Older Children and Child Restraints Children who weigh more than 20 lbs (9 kg) and who are older than one year can ride forward-facing in the vehicle. Forward-facing child seats and convertible child seats used in the forward-facing direction are for children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year.
  • Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE bend over the front of the seat when their back is against the seatback, should use the lap/shoulder belt in a rear seat. • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
  • Page 74 CAUTION! When your child restraint is not in use, secure it in the vehicle with the seat belt or remove it from the vehicle. Don’t leave it loose in the vehicle. In a sudden stop or collision, it could strike the occupants or seatbacks and cause serious personal injury.
  • Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE restraints having tether straps and hooks for connection to the top tether anchorage, have been available for some time. In fact, many child restraint manufacturers will provide add-on tether strap kits for some of their older products.
  • Page 76 Remind all children in the vehicle that the seat belts are not toys and should not be played with, and never leave your child unattended in the vehicle. Installing the LATCH-Compatible Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint.
  • Page 77 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE cover directly behind the seat where you are placing the child restraint and attach the tether strap to the anchor- age, being careful to route the tether strap to provide the most direct path between the anchor and the child restraint.
  • Page 78 Installing Child Restraint Tether Strap 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint. 1— Cover A— Tether Strap Hook 3— Attaching Strap B— Tether Anchor 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat.
  • Page 79 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using the Vehicle Seat Belt The passenger seat belts are equipped with Automatic Locking Retractors (ALRs), which are designed to keep the lap portion tight around the child restraint. The seat belt must be in the Automatic Locking Mode in order to enable a child restraint to be tightly installed.

  • Page 80: Engine Break-In Recommendations

    Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seatback, should use the lap/shoulder belt in a rear seat. Make sure that: •...

  • Page 81: Safety Tips

    80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. For the recommended viscosity and quality grades refer to “Maintenance Procedures”...

  • Page 82: Exhaust Gas

    Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.

  • Page 83: Safety Checks You Should Make Inside The Vehicle

    82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
  • Page 84 WARNING! Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious per- sonal injury. • Always make sure that floor mats are properly attached to the floor mat fasteners. • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the...

  • Page 85: Periodic Safety Checks You Should Make Outside The Vehicle

    84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.

  • Page 86: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......89 Inside Day/Night Mirror ....89 Automatic Dimming Mirror —...
  • Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold-Flat Front Passenger Seat ... 102 Folding Rear Seat ....103 Folding Rear Seat Center Armrest .
  • Page 88 Electronic Speed Control ....118 To Activate ......118 To Set a Desired Speed .
  • Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Storage ......134 Driver’s Side Sunglass Holder — If Equipped .

  • Page 90: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).

  • Page 91: Understanding The Features Of Your Vehicle

    90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.

  • Page 92: Adjusting Side View Mirrors

    Power Mirror Switch After selecting a mirror, move the knob in the same direction you want the mirror to move. When finished, return the knob to the center O (OFF) position to guard against accidentally moving a mirror position. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 Mirror Directions Adjusting Side View Mirrors Outside Mirror —...

  • Page 93: Illuminated Vanity Mirrors - If Equipped

    92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirror — Passenger Side Adjust the convex outside mirror so you can just see the side of your vehicle in the part of the mirror closest to the vehicle. WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are.

  • Page 94: Uconnect™ Phone - If Equipped

    Uconnect™ Phone — IF EQUIPPED Uconnect™ Phone is a hands-free system that allows you to use voice commands to dial a phone number stored in your cellular phone. Press the Uconnect™ Phone button on the radio or steering wheel controls (if equipped) and follow the instructions to pair the cellular phone.

  • Page 95: Manual Front Seat Adjustments

    94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seat Adjustments The adjusting bar is located at the front of the seats, near the floor. Pull the bar upward to move the seat to the desired position. After releasing the adjusting bar, apply forward and rearward body pressure to be sure the seat is latched.

  • Page 96: Driver Seat Manual Height Adjuster - If Equipped

    Driver Seat Manual Height Adjuster — If Equipped A lever style height adjustment feature enhances comfort for petite as well as tall drivers. A lever with a ratcheting mechanism, located on the outboard side of the seat, raises and lowers it. Total travel is 2.2 in. (56 mm). Manual Seat Height Adjustment Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Reclining Bucket Seats...

  • Page 97: Lumbar Support - If Equipped

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked.

  • Page 98: Adjusting Active Head Restraints

    Adjusting Active Head Restraints Active Head Restraints can reduce the risk of injury in the event of a rear impact. The Active Head Restraint should be adjusted so the top of the head restraint is located above the top of your ear. Adjusted Head Restraint UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 To raise the head restraint, pull upward on the head...
  • Page 99 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For comfort the Active Head Restraints can be tilted forward and backward. To tilt the head restraint closer to the back of your head, pull outward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.

  • Page 100: Power Seats - If Equipped

    • In the event of deployment of an Active Head Re- straint, refer to “Occupant Restraints/Resetting Active Head Restraints (AHR)” in “Things to Know Before Starting Your Vehicle” for further information. WARNING! • Driving a vehicle with the head restraints removed or improperly adjusted could cause serious injury or death in the event of a collision.
  • Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the seat up, down, forward, rearward, or to tilt the seat. Use the seatback control to adjust the angle of the seatback. Power Seat Switches 1 — Seatback Control 2 — Seat Control WARNING! Adjusting a seat while the vehicle is moving is dangerous.

  • Page 102: Heated Seats - If Equipped

    Heated Seats — If Equipped This feature heats the front driver and passenger seats. The controls for the heated seats are located in the center console below the climate controls. After turning the ignition ON, you can choose from High, Low, or Off heat settings.

  • Page 103: Fold-Flat Front Passenger Seat

    102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

  • Page 104: Folding Rear Seat

    The hard seatback features a work surface and a molded rim for retaining items stored on the seatback panel. Fold-Flat Front Passenger Seat UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Folding Rear Seat To provide additional storage area, the rear seatback can be folded forward.

  • Page 105: Folding Rear Seat Center Armrest

    104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! The rear cargo area of the vehicle (with the rear seatbacks in the locked-up or folded down position) should not be used as a play area by children. They could be seriously injured in an accident. Children should be seated and using the proper restraint system.

  • Page 106: To Open And Close The Hood

    TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. 1. Pull the hood release lever located under the left side of the instrument panel. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 2.

  • Page 107: Lights

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Use the hood prop rod to secure the hood in the open position. Place the upper end of the prop rod in the hole on the left underside of the hood. Hood Prop Rod Hole Location Before closing the hood, make sure to stow the prop rod in its proper location.

  • Page 108: Headlights And Parking Lights

    passing light, fog lights, instrument panel light dimming and turn signals. The multifunction lever is located on the left side of the steering column. Multifunction Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Headlights and Parking Lights Turn the end of the multifunction lever to the first detent for parking light operation.

  • Page 109: Automatic Headlights - If Equipped

    108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Headlights — If Equipped Turning the end of the multifunction lever to the third detent (AUTO), will activate the automatic headlight system. Headlight Switch With the engine running and the multifunction lever in the AUTO position, the headlights will turn on and turn off based on the surrounding light levels.

  • Page 110: Lane Change Assist

    Turn Signal Control NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.

  • Page 111: Fog Lights - If Equipped

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fog Lights — If Equipped The front fog light switch is on the multifunction lever. To activate the front fog lights, turn on the parking lights or the low beam headlights and pull out the end of the multifunction lever.

  • Page 112: Instrument Panel Dimmer

    Instrument Panel Dimmer Rotate the center portion of the lever to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened. Rotate the center portion of the lever up to increase the brightness of the instrument panel lights when the park- ing lights or headlights are on.

  • Page 113: Windshield Wipers And Washers

    112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle. They will not turn off automatically. Interior lighting also comes on when a door is opened or the dimmer control is turned fully upward, past the second detent.
  • Page 114 Windshield Wiper/Washer Lever Rotate the end of the lever to the LO position for low-speed wiper operation, or to the HI position for high-speed wiper operation. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Changing Wiper Speeds NOTE: The wipers will automatically return to the park position if you turn the ignition switch OFF while they are operating.

  • Page 115: Intermittent Wiper System

    114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Turn the windshield wipers off when driving through an automatic car wash. Damage to the windshield wipers may result if the wiper control is left in any position other than off. •...

  • Page 116: Windshield Washers

    Windshield Washers To use the washer, pull the windshield wiper/washer control lever toward you and hold it for as long as washer spray is desired. If you activate the washer while the wiper control is in the delay range, the wipers will operate in low-speed for two wipe cycles after releasing the lever and then resume the intermittent interval previously selected.

  • Page 117: Mist Feature

    116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mist Feature Push down on the wiper control lever to activate a single wipe to clear the windshield of road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate.

  • Page 118: Tilt/Telescoping Steering Column

    TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The tilt/telescoping control handle is located below the steering wheel at the end of the steering column.

  • Page 119: Electronic Speed Control

    118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL When engaged, the Electronic Speed Control takes over the accelerator operation at speeds greater than 25 mph (40 km/h). The Electronic Speed Control lever is located on the right side of the steering wheel. Electronic Speed Control Lever NOTE: In order to ensure proper operation, the Elec- tronic Speed Control System has been designed to shut...

  • Page 120: To Set A Desired Speed

    WARNING! Leaving the Electronic Speed Control on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the system off when you are not using it. To Set a Desired Speed Turn the Electronic Speed Control ON.

  • Page 121: To Accelerate For Passing

    120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ACCEL lever. If the lever is continually held in the RESUME ACCEL position, the set speed will continue to increase until the lever is released, then the new set speed will be established. Tapping RESUME ACCEL once will result in a 1 mph (2 km/h) speed increase.

  • Page 122: Garage Door Opener - If Equipped

    On steep hills, a greater speed loss or gain may occur so it may be preferable to drive without Electronic Speed Control. WARNING! Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your ve- hicle could go too fast for the conditions, and you could lose control.

  • Page 123: Programming Homelink

    122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Your motorized door or gate will open and close while you are training the universal transceiver. Do not train the transceiver if people, pets or other objects are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
  • Page 124 Place the handheld transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink button you wish to program while keeping the indicator light in view. 3. Simultaneously press and hold both the chosen HomeLink button and the handheld transmitter button until the HomeLink indicator changes from a slow to a rapidly blinking light, then release both the HomeLink and handheld transmitter buttons.
  • Page 125 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This can usually be found where the hanging antenna wire is attached to the garage door opener motor. It is NOT the button normally used to open and close the door. Training The Garage Door Opener 1 —...

  • Page 126: Gate Operator/Canadian Programming

    Using HomeLink To operate, press and release the programmed HomeLink button. Activation will now occur for the trained device (i.e., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.,). The handheld transmitter of the device may also be used at any time.

  • Page 127: Security

    126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE successfully accepted the frequency signal. The indica- tor light will flash slowly and then rapidly when fully trained. If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ,”...

  • Page 128: Power Sunroof - If Equipped

    2. This device must accept any interference that may be received including interference that may cause undesired operation. NOTE: • The transmitter has been tested and it complies with FCC and IC rules. Changes or modifications not expressly approved by the party responsible for com- pliance could void the user’s authority to operate the device.

  • Page 129: Sunroof Operation

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.

  • Page 130: Auto Sunroof Express With Anti-Pinch Protection - If Equipped

    Venting Sunroof — Express Press and release the “Vent” button, the sunroof will open to the vent position. This is called “Express Vent”. Closing Sunroof — Express Press the switch forward and release, the sunroof will close automatically from any position. The sunroof will close fully, then stop automatically.

  • Page 131: Ignition Off Operation

    130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition Off Operation For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power sunroof switch will remain active for 45 seconds after the ignition switch is turned OFF. Opening either front door will cancel this feature.
  • Page 132 The center console power outlet is powered directly from the battery (power available at all times). Items plugged into this power outlet may discharge the battery and/or prevent the engine from starting. Console Interior UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 NOTE: •...

  • Page 133: Cigar Lighter And Ash Receiver - If Equipped

    132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.

  • Page 134: Cupholders

    CAUTION! For vehicles equipped with the heated and cooled cupholder, locate the cup holder ash receiver in the forward cupholder. The optional ash receiver also comes with a cigar lighter. You may use the power outlet, located in the instrument panel below the climate control knobs, or in the bottom of the console compartment, for this cigar lighter.

  • Page 135: Rear Seat Bottle Holder

    134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Seat Bottle Holder There are built-in bottle holders located in both rear door trim panels. Rear Bottle Holder WARNING! If containers of hot liquid are placed in the bottle holder, they can spill when the door is closed, burn- ing the occupants.

  • Page 136: Cargo Area

    Sunglass Holder Cargo Area The 60/40 split-folding rear seat provides cargo-carrying versatility. The seatbacks fold down easily by pulling nylon tabs between the seatbacks and the bolsters. When the seats are folded down, they provide a continuous, nearly flat extension of the load floor. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the...

  • Page 137: Console Features

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • To help protect against personal injury, passengers should not be seated in the rear cargo area. The rear cargo space is intended for load carrying purposes only, not for passengers, who should sit in seats and use seat belts.

  • Page 138: Dual Storage Bins

    Console Features Dual Storage Bins Lifting a latch at the front of the hinged armrest provides access to these storage areas. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Storage Console Detail 1 — Release Top Compartment 2 — Release Bottom Compartment 3 —...

  • Page 139: Video Console - If Equipped

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The lower bin can be accessed directly, without first exposing the upper bin, by operating the right latch with the armrest down. The first storage bin can be used to hold smaller items. The lower storage bin includes a molded-in coin holder, room for CD’s, DVD’s, and a power outlet that allows a cellular phone to recharge while concealed.

  • Page 140: Rear Window Features

    Video Console Refer to “Video Entertainment System — If Equipped,” in “Understanding Your Instrument Panel” for further information. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control (Mode) knob.

  • Page 141: Chill Zone Beverage Cooler Storage Compartment

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Use care when washing the inside of the rear window. Do not use abrasive window cleaners on the interior surface of the window. Use a soft cloth and a mild washing solution, wiping parallel to the heating elements.
  • Page 142 Inside the Chill Zone is a vent which, when opened, allows either air conditioned or fresh air to flow into the Chill Zone compartment. Depending on ambient tem- perature and A/C setting, the compartment can keep beverages cool. For Chill Zone to operate properly, door must remain closed while vehicle is in operation.

  • Page 144: Understanding Your Instrument Panel

    UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....147 Instrument Cluster — Base ....148 Instrument Cluster —...
  • Page 145 144 UNDERSTANDING YOUR INSTRUMENT PANEL List Button (Disc Mode For MP3/WMA Play) ..187 Info Button (Disc Mode For MP3/WMA Play) ..187 Media Center 730N/430 (RER/REN/RBZ) — AM/FM Stereo Radio And CD/DVD/HDD/ NAV —...
  • Page 146 Info Button (CD Mode For MP3 Play) ..214 Operating Instructions - Uconnect™ Phone (If Equipped) ..... . . 215 Uconnect™...
  • Page 147 146 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD Disc Maintenance ....224 Radio Operation And Cellular Phones ..224 Climate Controls ..... . 224 Manual Heating And Air Conditioning .

  • Page 148: Instrument Panel Features

    INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Side Window Demister Outlet 3 — Instrument Cluster 4 — Radio UNDERSTANDING YOUR INSTRUMENT PANEL 147 5 — Beverage Can Cooler Bin 6 — Glove Compartment 7 — Heated Seat Switch — If Equipped 8 —...

  • Page 149: Instrument Cluster - Base

    148 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — BASE...

  • Page 150: Instrument Cluster - Premium

    UNDERSTANDING YOUR INSTRUMENT PANEL 149 INSTRUMENT CLUSTER — PREMIUM...

  • Page 151: Instrument Cluster Descriptions

    150 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Temperature Gauge The temperature gauge shows engine coolant tempera- ture. Any reading below the red area of the gauge shows that the engine cooling system is operating properly. The gauge pointer may show a higher than normal tempera- ture when driving in hot weather, up mountain grades, in heavy stop and go traffic, or when towing a trailer.
  • Page 152 5. Low Fuel Light When the fuel level drops to approximately 2.0 gal- lons (7.6 Liters), the fuel symbol will light and a single chime will sound. NOTE: This light will remain on until a minimum of approximately 3.0 gallons of fuel is added. 6.
  • Page 153 152 UNDERSTANDING YOUR INSTRUMENT PANEL you do not buckle up, the light will remain on. Refer to “Occupant Restraints” in “Things To Know Before Start- ing Your Vehicle” for further information. 9. Oil Pressure Warning Light This light indicates low engine oil pressure. The light will come on and remain on when the ignition switch is turned from the OFF to the ON position, and the light will turn off after the engine is...
  • Page 154 The light will remain on until the cause is corrected. NOTE: The light may flash momentarily during sharp cornering maneuvers which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. If brake failure is indicated, immediate repair is neces- sary.
  • Page 155 154 UNDERSTANDING YOUR INSTRUMENT PANEL 12. Tachometer The silver area of the scale shows the permissible engine revolutions-per-minute (RPM x 1000) for each gear range. Before reaching the red area, ease up on the accelerator to prevent engine damage. 13. Shift Lever Indicator The Shift Lever Indicator is self-contained within the instrument cluster.
  • Page 156 Vehicle Odometer Messages When the appropriate conditions exist, the odometer will display the following messages: door ......Door Ajar deck .
  • Page 157 156 UNDERSTANDING YOUR INSTRUMENT PANEL tighten the fuel filler cap properly and press the odom- eter reset button to turn off the “gASCAP” message. (Refer to “Onboard Diagnostic System — OBDII” in “Maintaining Your Vehicle” for further information). If the problem continues, the message will appear the next time the vehicle is started.
  • Page 158 15. Cruise Indicator — If Equipped This indicator shows that the Electronic Speed Control System is ON. 16. Odometer/Trip Odometer Reset Button Single Trip Odometer Press and release this button to change the display from odometer to trip odometer. The word “Trip” displays to show that the odometer is in Trip Mode.
  • Page 159 158 UNDERSTANDING YOUR INSTRUMENT PANEL If the light is flashing when the engine is running you may experience power loss, an elevated/rough idle, and increased brake pedal effort, and your vehicle may require towing. Immediate service is required. The light will come on when the ignition switch is first turned on and remain on approximately 15 seconds as a bulb check.
  • Page 160 22. Electronic Stability Control (ESC) Activation/ Malfunction Indicator Light — If Equipped The “ESC Activation/Malfunction Indicator Light” in the instrument cluster will come on when the ignition switch is turned to the ON position. It should go out with the engine running.
  • Page 161 160 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System (TPMS) that illuminates a low tire pressure telltale when one or more of your tires is significantly under-inflated.
  • Page 162 tires or wheels on your vehicle, to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. CAUTION! The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle.
  • Page 163 162 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Prolonged driving with the MIL on could cause damage to the engine control system. It also could affect fuel economy and drivability. If the MIL is flashing, severe catalytic converter damage and power loss will soon occur. Immediate service is required.
  • Page 164 should come on. If the light does not come on, have the system inspected by an authorized dealer. 27. Transmission Temperature Warning Light — If Equipped This light indicates that the transmission fluid temperature is running hot. This may occur with severe usage, such as trailer towing.

  • Page 165: Electronic Vehicle Information Center (Evic) - If Equipped

    164 UNDERSTANDING YOUR INSTRUMENT PANEL ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) – IF EQUIPPED The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster. Electronic Vehicle Information Center (EVIC) The EVIC consists of the following: •...

  • Page 166: Electronic Vehicle Information Center (Evic) Displays

    The system allows the driver to select information by pressing the following buttons on the instrument panel switch bank located below the climate controls: Press and release the MENU button to advance the display to Trip Functions or Personal set- tings or to return to the default System status display.

  • Page 167: Oil Change Required - If Equipped

    166 UNDERSTANDING YOUR INSTRUMENT PANEL • Left Rear Turn Signal Light Out (with a single chime) • Right Front Turn Signal Light Out (with a single chime) • Right Rear Turn Signal Light Out (with a single chime) • RKE (Remote Keyless Entry) Battery Low (with a single chime) •...

  • Page 168: Trip Functions

    2. Fully depress the accelerator pedal slowly three times within 10 seconds. 3. Turn the ignition switch to the LOCK position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure. Trip Functions Press and release the MENU button until one of the following Trip Functions displays in the EVIC:...
  • Page 169 168 UNDERSTANDING YOUR INSTRUMENT PANEL • Distance To Empty (DTE) Shows the estimated distance that can be traveled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level.

  • Page 170: Compass Display

    Compass Display The compass heading indicates the direction the vehicle is facing. Press and release the compass button to display one of eight compass heading and the outside tempera- COMPASS ture. Button NOTE: The system will display the last known outside temperature when starting the vehicle and may need to be driven several minutes before the updated tempera- ture is displayed.
  • Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press and release the STEP button until “Calibrate Compass Yes” displays in the EVIC. 4. Press and release the RESET button and the “CAL” indicator will quit flashing. 5. Drive the vehicle slowly (under 5 mph / 8 km/h), completing one or more circles (in an area free from large metal or metallic objects) until the “CAL”...

  • Page 172: Personal Settings (Customer-Programmable Features)

    1. Turn the ignition switch to the ON position. Leave the shift lever in PARK. 2. Press and release the MENU button until “Personal Settings” displays in the EVIC. 3. Press and release the STEP button until “Compass Variance” and the current Variance Value displays in the EVIC.
  • Page 173 172 UNDERSTANDING YOUR INSTRUMENT PANEL Auto Unlock on Exit When ON is selected and the transaxle is in the PARK or NEUTRAL position, all doors will unlock when the driver’s door is opened. To make your selection, press and hold the RESET button until ON or OFF appears. Remote Key Unlock When “Driver Door 1st Press”...
  • Page 174 Headlights With Wipers (Available with Auto Headlights Only) When ON is selected, and the headlight switch is in the AUTO position, the headlights will turn on approxi- mately 10 seconds after the wipers are turned on. The headlights will also turn off when the wipers are turned off if they were turned on by this feature.

  • Page 175: Media Center 230 (Req) - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)

    174 UNDERSTANDING YOUR INSTRUMENT PANEL Display ECO — If Equipped The “ECO” message is located in the EVIC, this message can be turned on or off. To make your selection, press and release the FUNCTION SELECT button until “ON” or “OFF”...
  • Page 176 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping. Turning the ON/VOLUME control knob to the right increases the volume and to the left decreases it.
  • Page 177 176 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button Uconnect™ Phone — If Equipped Press this button to operate the Uconnect™ Phone feature (if equipped). Refer to “Uconnect™ Phone” in the Uconnect™ User Manual located on the DVD for further details. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Uconnect Phone”...
  • Page 178 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in AM, FM or Satellite (if equipped) frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
  • Page 179 178 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected. Many radio stations do not currently broadcast Music Type information. Toggle the MUSIC TYPE button to select the following format types: Program Type 16-Digit Character Display...
  • Page 180 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
  • Page 181 180 UNDERSTANDING YOUR INSTRUMENT PANEL • Angle – Repeatedly pressing SELECT will change the viewing angle if supported by the DVD disc (if equipped). NOTE: • The available selections for each of the above entries varies depending upon the disc. •...
  • Page 182 Audio Language — If Equipped Selecting this item allows you to choose a default audio language (effective only if the language is supported by the disc). You can select a language not listed by scrolling down and selecting other. Enter the country code using the TUNE/SCROLL control knob to scroll up and down to select the number and then push to select.
  • Page 183 182 UNDERSTANDING YOUR INSTRUMENT PANEL a disc is loaded, changes will not be effective. Also, the defaults are effective only if the disc supports the customer-preferred settings. AM and FM Buttons Press the buttons to select AM or FM mode. SET Button —...

  • Page 184: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)

    Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
  • Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL Eject Button — Ejecting Compact Disc(s) Press the EJECT button and the pushbutton with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.

  • Page 186: Notes On Playing Mp3/Wma Files

    Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
  • Page 187 186 UNDERSTANDING YOUR INSTRUMENT PANEL If a disc contains multi-formats, such as CD audio and MP3/WMA tracks, the radio will only play the MP3/ WMA tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files.

  • Page 188: List Button (Disc Mode For Mp3/Wma Play)

    Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files. Loading times for playback of MP3/WMA files may be affected by the following: •...
  • Page 189 188 UNDERSTANDING YOUR INSTRUMENT PANEL Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3/WMA player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
  • Page 190 Operating Instructions — Voice Command System (If Equipped) For the radio, Refer to “Voice Command” in the Uconnect™ User Manual located on the DVD for further details. Refer to the Uconnect™ User Manual located on the DVD for further details. Operating Instructions - Uconnect™...

  • Page 191: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/ Nav - If Equipped

    190 UNDERSTANDING YOUR INSTRUMENT PANEL DTS™ DTS™ and DTS™ 2.0 are trademarks of Digital The- ater Systems, Inc. MEDIA CENTER 730N/430 (RER/REN/RBZ) — AM/FM STEREO RADIO AND CD/DVD/HDD/NAV — IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate.
  • Page 192 3. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed. 4.

  • Page 193: Clock Setting Procedure - Rer/Ren Radio

    192 UNDERSTANDING YOUR INSTRUMENT PANEL Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed.
  • Page 194 displayed. To move the minute backward, touch the screen where the word “Min” with the arrow pointing downward is displayed. 6. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time.

  • Page 195: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)

    194 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen. 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
  • Page 196 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
  • Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.

  • Page 198: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window. Select the button (1 to 6) you wish to lock onto this station and press and release that button.
  • Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD player and the CD icon will illuminate on the radio display.
  • Page 200 If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF. NOTE: Ejecting with the ignition OFF is not allowed on convertible or soft-top models (if equipped).

  • Page 201: Notes On Playing Mp3 Files

    200 UNDERSTANDING YOUR INSTRUMENT PANEL Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
  • Page 202 Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times. Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files.

  • Page 203: Operation Instructions - Auxiliary Mode

    202 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.

  • Page 204: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio

    MEDIA CENTER 130 (RES/RSC) — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 130 (RES/RSC) UNDERSTANDING YOUR INSTRUMENT PANEL 203 Operating Instructions —...
  • Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
  • Page 206 2. Adjust the hours by turning the right side TUNE/ SCROLL control knob. 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob.

  • Page 207: Music Type Button

    206 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display.
  • Page 208 Program Type 16-Digit Character Display College College Country Country Foreign Language Language Information Inform Jazz News News Nostalgia Nostalga Oldies Oldies Personality Persnlty Public Public Rhythm and Blues R & B Religious Music Rel Musc Religious Talk Rel Talk Rock Rock Soft Soft Rock...
  • Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select between the following items: • Set Clock — Pressing the SELECT button will allow you to set the clock. Adjust the hours by turning the TUNE/SCROLL control knob.

  • Page 210: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM stations). DISC/AUX Button Pressing the DISC/AUX button will allow you to switch from AM/FM modes to DISC/AUX mode. Operation Instructions —...
  • Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! (Continued) • Do not use adhesive labels. These labels can peel away and jam the player mechanism. • RES is a single CD player. Do not attempt to insert a second CD if one is already loaded. •...

  • Page 212: Notes On Playing Mp3 Files

    AM/FM Button Press the button to select either AM or FM mode. SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace.
  • Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL a number instead. With a maximum number of files, exceeding 20 folders will result in this display. With 200 files, exceeding 50 folders will result in this display.) • Maximum number of characters in file/folder names: •...

  • Page 214: List Button (Cd Mode For Mp3 Play)

    MPEG Sampling Fre- Specification quency (kHz) MPEG-1 Au- 48, 44.1, 32 dio Layer 3 MPEG-2 Au- 24, 22.05, 16 dio Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.

  • Page 215: Info Button (Cd Mode For Mp3 Play)

    214 UNDERSTANDING YOUR INSTRUMENT PANEL begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files). The folder list will time out after five seconds. INFO Button (CD Mode for MP3 Play) Pressing the INFO button repeatedly will scroll through the following TAG information: Song Title, Artist, File Name, and Folder Name (if available).

  • Page 216: Operating Instructions - Uconnect™ Phone (If Equipped)

    Operating Instructions - Uconnect™ Phone (If Equipped) Refer to “Uconnect™ Phone” in the Uconnect™ User Manual located on the DVD for further details. Operating Instructions - Uconnect™ Multimedia (Satellite Radio) (If Equipped) Refer to “Uconnect™ Multimedia (Satellite Radio)” in the Uconnect™...

  • Page 217: Electronic Serial Number/Sirius Identification Number (Esn/Sid)

    216 UNDERSTANDING YOUR INSTRUMENT PANEL Electronic Serial Number/Sirius Identification Number (ESN/SID) Please have the following information available when calling: 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID). 2. Your Vehicle Identification Number. To access the ESN/SID, refer to the following steps: ESN/SID Access With REQ/RES Radios With the ignition switch in the ON/RUN or ACC posi- tion and the radio on, press the SETUP button and scroll...

  • Page 218: Reception Quality

    Reception Quality Satellite reception may be interrupted due to one of the following reasons: • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception in the form of short audio mutes. •...
  • Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL additional three seconds will make the radio display the Song Title all of the time (press and hold again to return to normal display). RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows.

  • Page 220: Operating Instructions - Uconnect™ Phone (If Equipped)

    SET Button – To Set the Pushbutton Memory When you are receiving a channel that you wish to commit to pushbutton memory, press the SET button. The symbol SET 1 will now show in the display window. Select the button (1-6) you wish to lock onto this channel and press and release that button.

  • Page 221: Video Entertainment System (Ves)™ - If Equipped

    220 UNDERSTANDING YOUR INSTRUMENT PANEL VIDEO ENTERTAINMENT SYSTEM (VES)™ — IF EQUIPPED The optional Video Entertainment System (VES)™ in- cludes the following components for rear seat entertain- ment: • A diagonal 7 in (17.8 cm) Liquid Crystal Display (LCD) screen integrated into the center console armrest. The screen features brightness control for optimum day- time and nighttime viewing.
  • Page 222 VES™ Video Screen NOTE: Close the armrest after the LCD screen has been raised to its viewing position. • The radio and DVD player controls allow front seat operation for easy setup in the case of younger rear seat passengers. UNDERSTANDING YOUR INSTRUMENT PANEL 221 •...

  • Page 223: Remote Sound System Controls - If Equipped

    222 UNDERSTANDING YOUR INSTRUMENT PANEL Audio/Video RCA Jacks (AUX Jacks) on the rear of the center console enable the monitor to display video directly from a video camera, connect video games for display on the screen, or play music directly from an MP3 player.

  • Page 224: Right-Hand Switch Functions

    Right-Hand Switch Functions • Press the top of the switch to increase the volume. • Press the bottom of the switch to decrease the volume. • Press the button in the center of the switch to change modes (i.e., AM, FM, etc.). Left-Hand Switch Functions for Radio Operation •...

  • Page 225: Cd/Dvd Disc Maintenance

    224 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE To keep a CD/DVD in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge.

  • Page 226: Manual Heating And Air Conditioning

    Manual Heating and Air Conditioning Manual Temperature Control The Manual Temperature Controls consist of a series of outer rotary dials and inner push knobs. UNDERSTANDING YOUR INSTRUMENT PANEL 225 Blower Control Rotate this control to regulate the amount of air forced through the ven- tilation system in any mode.
  • Page 227 226 UNDERSTANDING YOUR INSTRUMENT PANEL Temperature Control Rotate this control to regulate the tem- perature of the air inside the passenger compartment. Rotating the dial left into the blue area of the scale indicates cooler temperatures while rotating right into the red area indicates warmer temperatures.
  • Page 228 NOTE: For all settings except full cold or full hot, there is a difference in temperature between the upper and lower outlets. The warmer air flows to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Floor Air is directed through the floor outlets with a small amount flowing through the defrost and side...
  • Page 229 228 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • Continuous use of the recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended. • The use of the recirculation mode in cold or damp weather will cause windows to fog on the inside, because of moisture buildup inside the vehicle.

  • Page 230: If Equipped

    • ECONOMY MODE If economy mode is desired, press the A/C button to turn OFF the indicator light and the A/C compressor. Then, move the temperature control to the desired temperature. Automatic Temperature Control (ATC) — If Equipped Automatic Temperature Control UNDERSTANDING YOUR INSTRUMENT PANEL 229 Automatic Operation The Automatic Temperature Control system automati-...
  • Page 231 230 UNDERSTANDING YOUR INSTRUMENT PANEL the desired comfort level require air conditioning, the system will automatically make the adjustment. You will experience the greatest efficiency by simply allowing the system to function automatically. Selecting the “O” (OFF) position on the blower control stops the system completely and closes the outside air intake.
  • Page 232 Blower Control For full automatic operation or for automatic blower operation turn the knob to AUTO position. In manual mode there are seven blower speeds that can be individual selected. In off position the blower will shut off. Manual Operation This system offers a full complement of manual override features, which consist of Blower Preferred Automatic, UNDERSTANDING YOUR INSTRUMENT PANEL 231...
  • Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL...
  • Page 234 The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Panel Air is directed through the outlets in the instrument panel. These outlets can be adjusted to direct airflow. The center instrument panel outlets can be NOTE: aimed so that they are directed toward the rear seat...
  • Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL • Air Conditioner Control Press this button to turn on the air conditioning during manual operation only. When the air conditioning is turned on, cool dehumidified air will flow through the outlets selected with the Mode control dial. Press this but- ton a second time to turn OFF the air conditioning.

  • Page 236: Operating Tips

    • Most of the time, when in Automatic Operation, you can temporarily put the system into Recirculation Mode by pressing the Recirculation button. However, under certain conditions, while in Automatic Mode, the system is blowing air out the defrost vents. When these conditions are present, and the Recirculation button is pressed, the indicator will flash and then turn off.
  • Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Interior fogging on the windshield can be quickly re- moved by turning the mode selector to Defrost. The Mix mode can be used to maintain a clear windshield and provide sufficient heating. If side window fogging be- comes a problem, increase blower speed.
  • Page 238 UNDERSTANDING YOUR INSTRUMENT PANEL 237 Control Setting Suggestions for Various Weather Conditions...

  • Page 240: Starting And Operating

    STARTING AND OPERATING CONTENTS Starting Procedures ....243 Automatic Transmission ....243 Normal Starting .
  • Page 241 240 STARTING AND OPERATING General Information ....254 Driving On Slippery Surfaces ... . . 255 Acceleration .
  • Page 242 Compact Spare Tire ....285 Tire Spinning ..... . . 286 Tread Wear Indicators .
  • Page 243 242 STARTING AND OPERATING Fuel Requirements ....307 Selection Of Engine Oil For Flexible Fuel Vehicles (E85) And Gasoline Vehicles ..308 Starting .

  • Page 244: Starting Procedures

    STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons.

  • Page 245: Starting And Operating

    244 STARTING AND OPERATING motor will continue to run, and it will disengage auto- matically when the engine is running. If the engine fails to start, the starter will disengage automatically in 10 sec- onds. If this occurs, turn the ignition switch to the LOCK position, wait 10 to 15 seconds, then repeat the “Normal Starting”...

  • Page 246: After Starting

    the way to the floor and hold it there while cranking the engine. This should clear any excess fuel in case the engine is flooded. CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again.

  • Page 247: Engine Block Heater - If Equipped

    246 STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded, three-wire extension cord. The engine block heater cord is bundled under the hood between the headlight assembly and the Totally Inte- grated Power Module (Fuse Box) on the driver’s side of...
  • Page 248 Shift Lever NOTE: You MUST press and hold the brake pedal down while shifting out of PARK. STARTING AND OPERATING 247 WARNING! • It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed.

  • Page 249: Key Ignition Park Interlock

    248 STARTING AND OPERATING WARNING! (Continued) • Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the vehicle into PARK, remove the key from the ignition, and apply the parking brake.

  • Page 250: Automatic Transmission Ignition Interlock System

    • Insert the ignition key and rotate it to the ON position • Remove the cup holder liner • Insert a key, screwdriver, or finger into the front hole then push and hold the manual override release lever forward. • While holding the release lever forward, move the shift lever from PARK to NEUTRAL.
  • Page 251 250 STARTING AND OPERATING Never attempt to use PARK while vehicle is in motion. Apply parking brake when leaving vehicle in this range. When parking on a flat surface, place the shift lever in the PARK position first, and then apply the parking brake. When parking on a hill, it is important to set the parking brake before placing the shift lever in PARK, otherwise the load on the transmission locking mechanism may...
  • Page 252 NEUTRAL This range is used when vehicle is standing for pro- longed periods with engine running. Engine may be started in this range. Set the parking brake if you must leave the vehicle. WARNING! Do not coast in NEUTRAL and never turn off the ignition to coast down a hill.
  • Page 253 252 STARTING AND OPERATING DRIVE 3— Four-Speed Transmission This range eliminates shifts into fourth gear. The trans- mission will operate normally in first and second gear. Shifts into third may be delayed to provide second gear operation at higher speeds. The 3 range should also be used when descending steep grades to prevent brake system distress.

  • Page 254: Autostick - If Equipped

    In the event that the problem has been momentary, the transmission can be reset to regain all forward gears. 1. Stop the vehicle. 2. Shift into PARK. 3. Turn the ignition OFF, and restart the engine. 4. Shift into the desired gear range and resume driving. NOTE: Even if the transmission can be reset, it is recommended that you visit a dealer at your earliest possible convenience.

  • Page 255: General Information

    254 STARTING AND OPERATING AutoStick is deactivated when the shift lever is shifted from the AutoStick (+/-) position into the DRIVE position. General Information • You can start out, from a stop, in any gear except sixth. The system will ignore attempts to upshift at too low of a vehicle speed.

  • Page 256: Driving On Slippery Surfaces

    DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the front wheels to pull errati- cally to the right or left. This phenomenon occurs when there is a difference in the surface traction under the front (driving) wheels.

  • Page 257: Driving Through Water

    256 STARTING AND OPERATING DRIVING THROUGH WATER Driving through water more than a few inches/ centimeters deep will require extra caution to ensure safety and prevent damage to your vehicle. Flowing/Rising Water WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off).
  • Page 258 CAUTION! (Continued) • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission, axle, etc.) for signs of contamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.

  • Page 259: Power Steering

    258 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.

  • Page 260: Power Steering Fluid Check

    Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated.
  • Page 261 260 STARTING AND OPERATING The parking brake lever is located in the center console. To apply the parking brake, pull the lever up as firmly as possible. To release the parking brake, pull the lever up slightly, press the center button, then lower the lever completely.
  • Page 262 make it difficult to move the shift lever out of PARK. The parking brake should always be applied whenever the driver is not in the vehicle. WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

  • Page 263: Anti-Lock Brake System (Abs)

    262 STARTING AND OPERATING ANTI-LOCK BRAKE SYSTEM (ABS) The Anti-Lock Brake System (ABS) provides increased vehicle stability and brake performance under most braking conditions. The system operates with a separate computer to modulate the hydraulic pressure to prevent wheel lock-up and avoid skidding on slippery surfaces. WARNING! •...
  • Page 264 The “Anti-Lock Brake Warning Light” moni- tors the Anti-Lock Brake System. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the “Anti-Lock Brake Warning Light” remains on or comes on while driving, it indicates that the anti-lock portion of the brake system is not functioning and that service is required.

  • Page 265: Electronic Brake Control System

    264 STARTING AND OPERATING • the clicking sound of solenoid valves, • brake pedal pulsations, • and a slight drop or fall away of the brake pedal at the end of the stop. These are all normal characteristics of ABS. WARNING! The Anti-Lock Brake System contains sophisticated electronic equipment that may be susceptible to...

  • Page 266: Traction Control System (Tcs)

    help avoid skidding on slippery surfaces during braking. Refer to “Anti-Lock Brake System” in “Starting and Operating” for further information. Traction Control System (TCS) This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability.

  • Page 267: Hill Start Assist (Hsa) - If Equipped

    266 STARTING AND OPERATING WARNING! • The BAS cannot prevent the natural laws of phys- ics from acting on the vehicle, nor can it increase braking efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
  • Page 268 HSA Activation Criteria The following criteria must be met in order for HSA to activate: • Vehicle must be stopped • Vehicle must be on a 7% or greater incline • Gear selection matches vehicle uphill direction (i.e., vehicle facing uphill is in forward gear; vehicle back- ing uphill is in REVERSE gear).
  • Page 269 268 STARTING AND OPERATING 1. Center the steering wheel (front wheels pointing straight forward). 2. Shift the transmission into NEUTRAL. 3. Apply the parking brake. 4. Start the engine. 5. Release the clutch pedal. 6. Rotate the steering wheel one-half turn to the left. 7.

  • Page 270: Electronic Stability Control (Esc)

    Electronic Stability Control (ESC) This system enhances directional control and stability of the vehicle under various driving conditions. ESC cor- rects for over/under steering of the vehicle by applying the brake of the appropriate wheel to assist in counter- acting the over/under steer condition. Engine power may also be reduced to help the vehicle maintain the desired path.
  • Page 271 270 STARTING AND OPERATING WARNING! (Continued) • ESC cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning. Only a safe, attentive, and skillful driver can prevent accidents. • The capabilities of an ESC-equipped vehicle must never be exploited in a reckless or dangerous manner, which could jeopardize the user’s safety or the safety of others.
  • Page 272 ESC Operating Modes All ESC equipped vehicles can choose the following ESC operating modes: ESC On This is the normal operating mode for ESC. Whenever the vehicle is started the ESC system will be in this mode. This mode should be used for almost all driving situa- tions.

  • Page 273: Tire Safety Information

    272 STARTING AND OPERATING WARNING! In the Partial ESC mode, the engine torque reduction and stability features are desensitized. Therefore, the enhanced vehicle stability offered by ESC is unavail- able. NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, it may be desirable to switch to the “Partial Off”...
  • Page 274 NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
  • Page 275 274 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
  • Page 276 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...

  • Page 277: Tire Identification Number (Tin)

    276 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.

  • Page 278: Tire Terminology And Definitions

    Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.

  • Page 279: Tire Loading And Tire Pressure

    278 STARTING AND OPERATING Tire Loading and Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire Placard Location...
  • Page 280 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear, and spare tires.
  • Page 281 280 STARTING AND OPERATING 3. Subtract the combined weight of the driver and pas- sengers from XXX lbs or XXX kg. 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
  • Page 282 STARTING AND OPERATING 281...

  • Page 283: Tires - General Information

    282 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.

  • Page 284: Tire Inflation Pressures

    WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread.
  • Page 285 284 STARTING AND OPERATING CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...

  • Page 286: Radial-Ply Tires

    loading may be required for high-speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail.

  • Page 287: Tire Spinning

    286 STARTING AND OPERATING WARNING! Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h). Temporary-use spare tires have limited tread life. When the tread is worn to the tread wear indicators, the temporary use spare tire needs to be replaced.

  • Page 288: Tread Wear Indicators

    Refer to “Freeing A Stuck Vehicle” in “What To Do In Emergencies” for further information. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one.

  • Page 289: Life Of Tire

    288 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.

  • Page 290: Tire Chains

    WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.

  • Page 291: Snow Tires

    290 STARTING AND OPERATING CAUTION! Damage to the vehicle may result if tire chains are used. SNOW TIRES Some areas of the country require the use of snow tires during Winter. Standard tires are of the all-season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall.

  • Page 292: Tire Pressure Monitor System (Tpms)

    Tire Rotation TIRE PRESSURE MONITOR SYSTEM (TPMS) The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure. STARTING AND OPERATING 291 The tire pressure will vary with temperature by about 1 psi (7 kPa) for every 12 F (7 C).
  • Page 293 292 STARTING AND OPERATING The TPM System will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above the recom- mended cold placard pressure. Once the low tire pressure warning (Tire Pressure Monitoring Telltale Light) illumi- nates, you must increase the tire pressure to the recom- mended cold placard pressure in order for the “Tire...
  • Page 294 CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warning have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.

  • Page 295: Base System

    294 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System The Tire Pressure Monitor System (TPMS) uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure levels.
  • Page 296 will repeat, providing the system fault still exists. The “Tire Pressure Monitoring Telltale Light” will turn off when the fault condition no longer exists. A system fault can occur due to any of the following: 1. Jamming due to electronic devices or driving next to facilities emitting the same Radio Frequencies as the TPM sensors.

  • Page 297: Premium System - If Equipped

    296 STARTING AND OPERATING 5. Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, the TPMS will update automatically and the “TPM Telltale Light” will turn OFF, as long no tire pressure is below the low-pressure warning limit in any of the four active road tires.
  • Page 298 more of the four active road tires. In addition, the Electronic Vehicle Information Center (EVIC) will display a graphic showing the pressure values of each tire with the low tire pressure values flashing. STARTING AND OPERATING 297 Should this occur, you should stop as soon as possible, and inflate all tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value.
  • Page 299 298 STARTING AND OPERATING (- -) in place of the pressure value to indicate which sensor is not being received. If the ignition key is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the “Tire Pressure Monitoring Telltale Light”...

  • Page 300: General Information

    2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, the “TPM Telltale Light” will remain ON, a chime will sound, and the EVIC will still display a flashing pressure value in the graphic display.

  • Page 301: Fuel Requirements

    300 STARTING AND OPERATING The tire pressure sensors are covered under one of the following licenses: United States ..... KR5S120123 Canada .

  • Page 302: Reformulated Gasoline

    (with the ap- propriate octane rating for your engine) before consider- ing service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) which...

  • Page 303: E-85 Usage In Non-Flex Fuel Vehicles

    302 STARTING AND OPERATING NOTE: The 2.7L engine is now rated for E85 Ethanol use (EXCEPT CALIFORNIA EMISSION STATES). Only vehicles with the E-85 fuel filler door label can operate on E-85. Refer to “Flexible Fuel” in “Starting and Operating” for further information.

  • Page 304: Materials Added To Fuel

    blended with MMT provides no performance advantage beyond gasoline of the same octane number without MMT. Gasoline blended with MMT reduces spark plug life and reduces emission system performance in some vehicles. The manufacturer recommends that gasoline without MMT be used in your vehicle. The MMT content of gasoline may not be indicated on the gasoline pump, therefore, you should ask your gasoline retailer whether or not his/her gasoline contains MMT.

  • Page 305: Carbon Monoxide Warnings

    304 STARTING AND OPERATING CAUTION! (Continued) • An out-of-tune engine, or certain fuel or ignition malfunctions, can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunctioning and may require immediate service.

  • Page 306: Flexible Fuel (2.7L Only) - If Equipped

    WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the trunk closed when driving your vehicle to prevent carbon monoxide and other poisonous exhaust gases from entering the vehicle.
  • Page 307 306 STARTING AND OPERATING NOTE: The 2.7L engine is now rated for E85 Ethanol use (EXCEPT CALIFORNIA EMISSION STATES). Only vehicles with the E85 fuel filler door label can operate on E85. E85 Fuel Cap CAUTION! Only vehicles with the E85 fuel filler door label can operate on E85.

  • Page 308: Ethanol Fuel (E85)

    Ethanol Fuel (E85) E85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury. Never have any smok- ing materials lit in or near the vehicle when remov- ing the fuel filler tube cap (gas cap) or filling the tank.

  • Page 309: Selection Of Engine Oil For Flexible Fuel Vehicles (E85) And Gasoline Vehicles

    308 STARTING AND OPERATING • Some additives used in regular gasoline are not fully compatible with E85 and may form deposits in your engine. To eliminate driveability issues that may be caused by these deposits, a supplemental gasoline additive, such as MOPAR Techron may be used.

  • Page 310: Replacement Parts

    Replacement Parts Many components in your Flexible Fuel Vehicle (FFV) are designed to be compatible with ethanol. Always be sure that your vehicle is serviced with correct ethanol com- patible parts. CAUTION! Replacing fuel system components with non-ethanol compatible components can damage your vehicle. Maintenance If you operate the vehicle using E85 fuel, follow the maintenance schedule section of this manual.
  • Page 311 310 STARTING AND OPERATING After removing the gas cap, place the gas cap tether cable over a hook on the inside of the fuel door. This keeps the gas cap suspended away from and protects the vehicle’s surface. Tether Cable NOTE: If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.

  • Page 312: Loose Filler Cap Message

    WARNING! (Continued) • Never add fuel when the engine is running. This is in violation of most state and federal fire regula- tions and doing so will cause the MIL to turn on. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.

  • Page 313: Gross Vehicle Weight Rating (Gvwr)

    312 STARTING AND OPERATING The label contains the following information: • Name of manufacturer • Month and year of manufacture • Gross Vehicle Weight Rating (GVWR) • Gross Axle Weight Rating (GAWR) front • Gross Axle Weight Rating (GAWR) rear •...

  • Page 314: Overloading

    Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory service as long as you do not exceed the GVWR and front and rear GAWR. The best way to figure out the total weight of your vehicle is to weigh it when it is fully loaded and ready for operation.

  • Page 315: Common Towing Definitions

    314 STARTING AND OPERATING To maintain warranty coverage, follow the requirements and recommendations in this manual concerning ve- hicles used for trailer towing. If you have any questions or concerns after reviewing this section, please consult your dealer to for full details on the towing capabilities of the vehicle.
  • Page 316 Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR. Refer to “Vehicle Loading/Vehicle Certifica- tion Label”...

  • Page 317: Trailer Hitch Classification

    316 STARTING AND OPERATING Trailer Hitch Classification The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Refer to the Trailer Towing Weights (Maximum Trailer Weight Ratings) chart for the Max.

  • Page 318: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Max. Frontal Area 2.4L/Auto See Note 2 2.7L/Auto See Note 2 3.5L/Auto 22 sq.ft. (2.0 sq.m) Refer to local laws for maximum trailer towing speeds. Note 1: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and it should never exceed the weight referenced on the Tire and Loading Information placard.

  • Page 319: Trailer And Tongue Weight

    318 STARTING AND OPERATING CAUTION! Towing a trailer with a larger than recommended frontal area could cause the engine to overheat or cause severe engine damage under extreme condi- tions. Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.

  • Page 320: Towing Requirements

    NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on your vehicle. Refer to “Tire Safety Information/Tire and Loading Information Placard”...
  • Page 321 320 STARTING AND OPERATING WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: • Make certain that the load is secured in the trailer and that it will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
  • Page 322 WARNING! (Continued) 3. GAWR 4. Trailer tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve 10% of trailer tongue weight as a percentage of total trailer weight). Towing Requirements – Tires • Do not attempt to tow a trailer while using a compact spare tire.
  • Page 323 322 STARTING AND OPERATING • An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. •...

  • Page 324: Towing Tips

    Towing Tips Before setting out on a trip, practice turning, stopping, and backing the trailer in an area located away from heavy traffic. Make sure all trailer and vehicle lights are working properly — including hazard flashers. Automatic Transmission The DRIVE range can be selected when towing. How- ever, if frequent shifting occurs while in this range, third gear for a four-speed automatic and the fifth gear for a six-speed AutoStick should be selected.

  • Page 325: Recreational Towing (Behind Motorhome, Etc.)

    324 STARTING AND OPERATING • Use speed control in flat terrain and with light loads to maximize fuel efficiency. Cooling System To reduce potential for engine and transmission over- heating, take the following actions: • City Driving When stopped for short periods of time, shift the trans- mission into NEUTRAL and increase engine idle speed.

  • Page 326: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....327 If Your Engine Overheats ....327 Engine Oil Overheating (2.4L Engine Only) —...
  • Page 327 326 WHAT TO DO IN EMERGENCIES Towing A Disabled Vehicle ....341 Towing With The Ignition Key ... 341 Towing Without The Ignition Key .

  • Page 328: Hazard Warning Flasher

    HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the instrument panel, below the radio. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.

  • Page 329: What To Do In Emergencies

    328 WHAT TO DO IN EMERGENCIES NOTE: There are steps that you can take to slow down an impending overheat condition: • If your air conditioner (A/C) is on, turn it off. The A/C system adds heat to the engine cooling system and turning the A/C off can help remove this heat.

  • Page 330: Jacking And Tire Changing

    JACKING AND TIRE CHANGING WARNING! • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. Never start or run the engine while the vehicle is on a jack.

  • Page 331: Preparations For Jacking

    330 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
  • Page 332 WARNING! (Continued) • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle. • Block the wheel diagonally opposite the wheel to be raised. • Set the parking brake firmly and set an automatic transmission in PARK;...
  • Page 333 332 WHAT TO DO IN EMERGENCIES NOTE: The jack handle attaches to the side of the jack with two attachment points. When the jack is partially expanded, the tension between the two attachment points holds the jack handle in place. Removing Jack Handle From Jack 2.
  • Page 334 WHAT TO DO IN EMERGENCIES 333 Front Jacking Location Rear Jacking Location 4. Turn the jack screw to the left until the jack can be placed under the jacking location. Once the jack is positioned, turn the jack screw to the right until the jack head is properly engaged with the lift area closest to the wheel to be changed.
  • Page 335 334 WHAT TO DO IN EMERGENCIES WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 5. Raise the vehicle by turning the jack screw to the right, using the swivel wrench.

  • Page 336: Jump-Starting

    WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve- hicle. Always stow the jack parts and the spare tire in the places provided. 10. Place the deflated (flat) tire in the cargo area and have the tire repaired or replaced as soon as possible.

  • Page 337: Preparations For Jump-Start

    336 WHAT TO DO IN EMERGENCIES WARNING! Do not attempt jump-starting if the battery is frozen. It could rupture or explode and cause personal injury. Preparations for Jump-Start The battery in your vehicle is located between the left front headlight assembly and the left front wheel splash shield.
  • Page 338 WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be injured by moving fan blades. • Remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact.

  • Page 339: Jump-Starting Procedure

    338 WHAT TO DO IN EMERGENCIES WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result. Jump-Starting Procedure WARNING! Failure to follow this procedure could result in per- sonal injury or property damage due to battery ex- plosion.

  • Page 340: Freeing A Stuck Vehicle

    5. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged battery. Once the engine is started, remove the jumper cables in the reverse sequence: 6.
  • Page 341 340 WHAT TO DO IN EMERGENCIES front wheels. Then shift back and forth between RE- VERSE and FIRST gear. Using minimal accelerator pedal pressure to maintain the rocking motion, without spin- ning the wheels, is most effective. NOTE: If your vehicle is equipped with Electronic Stability Control (ESC), turn the system to Partial OFF before attempting to “rock”...

  • Page 342: Towing A Disabled Vehicle

    TOWING A DISABLED VEHICLE Towing With The Ignition Key Front Wheel Drive Your vehicle may be towed (with all four wheels flat on the ground), under the following conditions: • The shift lever must be in NEUTRAL. • The distance to be traveled must not exceed 15 miles (25 km).

  • Page 343: Towing Without The Ignition Key

    342 WHAT TO DO IN EMERGENCIES If you must use the accessories (wipers, defrosters, etc.) while being towed, the key must be in the ON position, not the ACC position. Make certain the transaxle remains in NEUTRAL. Towing Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position.

  • Page 344: Towing Without Power - Override Transaxle Interlock System

    Towing Without Power — Override Transaxle Interlock System Special care must be taken when the vehicle is towed with the ignition in the LOCK position. A dolly should be used under the front wheels if the rear wheels are raised. Proper towing equipment is necessary to prevent dam- age to the vehicle.

  • Page 346: Maintaining Your Vehicle

    MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.4L ... . . 347 Engine Compartment — 2.7L ... . . 348 Engine Compartment —...
  • Page 347 346 MAINTAINING YOUR VEHICLE Adding Washer Fluid ....364 Exhaust System ..... 364 Cooling System .

  • Page 348: Engine Compartment - 2.4L

    ENGINE COMPARTMENT — 2.4L 1 — Engine Coolant Reservoir 2 — Power Steering Fluid Reservoir 3 — Automatic Transmission Dipstick 4 — Brake Fluid Reservoir 5 — Integrated Power Module 6 — Power Distribution Center MAINTAINING YOUR VEHICLE 347 7 — Air Cleaner Filter 8 —...

  • Page 349: Engine Compartment - 2.7L

    348 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.7L 1 — Engine Coolant Reservoir 2 — Coolant Pressure Cap 3 — Power Steering Fluid Reservoir 4 — Automatic Transmission Dipstick (Four-Speed Only) 5 — Brake Fluid Reservoir 6 — Integrated Power Module 7 —...

  • Page 350: Engine Compartment - 3.5L

    ENGINE COMPARTMENT — 3.5L 1 — Engine Coolant Reservoir 2 — Coolant Pressure Cap 3 — Power Steering Fluid Reservoir 4 — Brake Fluid Reservoir 5 — Totally Integrated Power Module (TIPM) MAINTAINING YOUR VEHICLE 349 6 — Air Cleaner Filter 7 —...

  • Page 351: Onboard Diagnostic System - Obd Ii

    350 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as maintaining engine emissions well within current government regu-...

  • Page 352: Emissions Inspection And Maintenance Programs

    the gas cap is properly tightened. Press the trip odometer “Reset” button to turn off the message. If the problem persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the “Malfunction Indicator Light (MIL).”...

  • Page 353: Replacement Parts

    352 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.

  • Page 354: Dealer Service

    DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service Manuals are available which include detailed service information for your vehicle. Refer to these Service Manuals before attempting any procedure yourself.

  • Page 355: Engine Oil

    354 MAINTAINING YOUR VEHICLE CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
  • Page 356 CAUTION! Do not overfill the engine. Overfilling the engine will cause oil aeration, which can lead to loss of oil pressure and an increase in oil temperature. This could damage your engine. Change Engine Oil The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
  • Page 357 356 MAINTAINING YOUR VEHICLE CAUTION! Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Such damage is not covered by the New Vehicle Limited Warranty. Engine Oil Viscosity (SAE Grade) – 2.4L and 2.7L Engines SAE 5W-20 engine oil is recommended for all operating temperatures.

  • Page 358: Engine Oil Filter

    Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Synthetic Engine Oils You may use synthetic engine oils provided the recom- mended oil quality requirements are met, and the recom- mended maintenance intervals for oil and filter changes are followed.

  • Page 359: Engine Air Cleaner Filter

    358 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter WARNING! The air induction system (air cleaner, hoses, etc.) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc.) unless such removal is necessary for repair or maintenance.
  • Page 360 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.

  • Page 361: Air Conditioner Maintenance

    360 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.

  • Page 362: A/C Air Filter - If Equipped

    Refrigerant Recovery and Recycling R-134a air conditioning refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.

  • Page 363: Body Lubrication

    362 MAINTAINING YOUR VEHICLE 5. Disengage the two retaining tabs that secure the filter cover to the HVAC housing and remove the cover. A/C Air Filter Replacement 6. Remove the A/C Air Filter by pulling it straight out of the housing. 7.

  • Page 364: Windshield Wiper Blades

    quiet, easy operation and to protect against rust and wear. Prior to the application of any lubricant, the parts concerned should be wiped clean to remove dust and grit; after lubricating excess oil and grease should be removed. Particular attention should also be given to hood latching components to ensure proper function.

  • Page 365: Adding Washer Fluid

    364 MAINTAINING YOUR VEHICLE present please proceed to clean wiper blades with humid cloth removing any debris that may be affecting its function. Adding Washer Fluid The fluid reservoir for the windshield washers is located in the engine compartment. Be sure to check the fluid level in the reservoir at regular intervals.
  • Page 366 WARNING! • Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, refer to “Safety Tips/Exhaust Gas” in “Things To Know Before Starting Your Vehicle”...
  • Page 367 366 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage. NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you.

  • Page 368: Cooling System

    Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position. The fan is tempera- ture controlled and can start at anytime the igni- tion switch is in the ON position. •...
  • Page 369 368 MAINTAINING YOUR VEHICLE Selection Of Coolant Use only the manufacturer’s recommended coolant. Re- fer to “Fluids, Lubricants, and Genuine Parts” in “Main- taining Your Vehicle” for further information. CAUTION! • Mixing of engine coolant (antifreeze) other than specified HOAT engine coolant (antifreeze), may result in engine damage and may decrease corro- sion protection.
  • Page 370 replacement. To prevent reducing this extended mainte- nance period, it is important that you use the same engine coolant (antifreeze) throughout the life of your vehicle. Please review these recommendations for using Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze). When adding engine coolant (antifreeze): •...
  • Page 371 370 MAINTAINING YOUR VEHICLE WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add engine coolant (antifreeze) when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
  • Page 372 The radiator normally remains completely full, so there is no need to remove the radiator cap unless checking for engine coolant (antifreeze) freeze point or replacing cool- ant. Advise your service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month.

  • Page 373: Brake System

    372 MAINTAINING YOUR VEHICLE • Make sure that the radiator and coolant recovery bottle overflow hoses are not kinked or obstructed. • Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean.
  • Page 374 Clean the top of the master cylinder area before removing the cap. If necessary, add fluid to bring the fluid level up to the requirements described on the brake fluid reser- voir. Overfilling of fluid is not recommended because it may cause leaking in the system.

  • Page 375: Automatic Transmission

    374 MAINTAINING YOUR VEHICLE WARNING! (Continued) • To avoid contamination from foreign matter or moisture, use only new brake fluid or fluid that has been in a tightly closed container. Keep the master cylinder reservoir cap secured at all times. Brake fluid in a open container absorbs moisture from the air resulting in a lower boiling point.
  • Page 376 Fluid Level Check – 2.4L and 2.7L Engines Use the following procedure to check the automatic transmission fluid level properly: 1. Park the vehicle on level ground. 2. Run the engine at curb idle speed for a minimum of 60 seconds. 3.
  • Page 377 376 MAINTAINING YOUR VEHICLE CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than that recommended by the manufacturer will result in more frequent fluid and filter changes.

  • Page 378: Appearance Care And Protection From Corrosion

    CAUTION! Do not use chemical flushes in your transmission as the chemicals can damage your transmission compo- nents. Such damage is not covered by the New Vehicle Limited Warranty. Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage.
  • Page 379 378 MAINTAINING YOUR VEHICLE Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or equiva- lent, or a mild car wash soap, and rinse the panels completely with clear water. • If insects, tar, or other similar deposits have accumu- lated on your vehicle, use MOPAR Super Kleen Bug and Tar Remover or equivalent to remove.
  • Page 380 • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating, have your vehicle repaired as soon as pos- sible.
  • Page 381 380 MAINTAINING YOUR VEHICLE To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution fol- lowed by rinsing. Do not use abrasive cleaning components, solvents, steel wool or other aggressive material to clean the lenses.
  • Page 382 if absolutely necessary. Do not use harsh cleaners or Armor All . Use MOPAR Total Clean or equivalent to clean vinyl upholstery. Cleaning Leather Upholstery MOPAR Total Clean or equivalent is specifically recom- mended for leather upholstery. Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth.

  • Page 383: Cleaning Center Console Cupholders

    382 MAINTAINING YOUR VEHICLE Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic. When cleaning the lenses, care must be taken to avoid scratching the plastic. 1. Clean with a wet, soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners.

  • Page 384: Fuses

    FUSES Totally Integrated Power Module (TIPM) The TIPM is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini fuses. A label that identifies each component may be printed on the inside of the cover. Refer to the graphic below for FUSES/TIPM location.
  • Page 385 384 MAINTAINING YOUR VEHICLE Cartridge Cavity Mini Fuse Fuse — 10 Amp Red 30 Amp — Green 30 Amp — Green 40 Amp Green Cartridge Description Cavity Ignition Off Draw (IOD) – Power Mirror Switch/Climate Controls Ignition Off Draw (IOD) Sense 1 Ignition Off Draw (IOD)
  • Page 386 Cartridge Cavity Mini Fuse Fuse 40 Amp — Green 15 Amp Lt. — Blue — 10 Amp Red 40 Amp — Green Cartridge Description Cavity Fuse Battery Feed – Radiator Fan Relay IGN Run/ACC – Cigar Lighter/ PWR Sunroof Ignition Off Draw (IOD) –...
  • Page 387 386 MAINTAINING YOUR VEHICLE Cartridge Cavity Mini Fuse Fuse 25 Amp — Natural — 10 Amp Red 15 Amp Lt. — Blue — 10 Amp Red Cartridge Description Cavity Battery Feed — PWR Sunroof Feed Ignition Run — Heated Mirrors - If Equipped Auto Shutdown (ASD) Relay...
  • Page 388 Cartridge Cavity Mini Fuse Fuse — 10 Amp Red 30 Amp — Pink Cartridge Description Cavity Fuse Battery Feed – Switch Bank/ Diagnostic Link Connector/ 40 Amp Powertrain Green Control Module (PCM) Battery Feed – Anti-Lock Brakes (ABS) Module – 30 Amp If Equipped/ Pink...

  • Page 389: Vehicle Storage

    388 MAINTAINING YOUR VEHICLE CAUTION! • When installing the Totally Integrated Power Module cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the Totally Integrated Power Module, and possibly result in an electrical system failure.

  • Page 390: Bulb Replacement

    LIGHT BULBS – Exterior Low Beam Headlamp ..... H11 High Beam Headlamp ....9005 Front Park/Turn Signal/Side Marker Lamp .
  • Page 391 390 MAINTAINING YOUR VEHICLE 3. Rotate bulb and connector ⁄ from assembly. CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. turn and pull outward 4. Pull the bulb out of the socket and replace the bulb. 5.

  • Page 392: Fog Lamps

    Fog Lamps 1. Access to the lamps through the lower fascia cutout is limited. 2. Turn the steering wheel to allow access and remove the inner fender shield. MAINTAINING YOUR VEHICLE 391 3. Rotate the bulb and connector wise. 4. Pull the bulb off of connector and replace with a new one.

  • Page 393: Taillamps, Rear Turn Signals And Backup Lamps

    392 MAINTAINING YOUR VEHICLE Taillamps, Rear Turn Signals and Backup Lamps The turn signal, brake, taillamps and backup lamps are located in the rear corner body panel housing. 1. Open the trunk and gently pull back the trunk liner behind the taillamp. 2.
  • Page 394 3. Grasp the taillamp and pull firmly outward pushing gently on the studs from inside to disengage the lamp housing. MAINTAINING YOUR VEHICLE 393 4. Twist and remove socket from lamp. 5. Remove bulb from socket and replace.

  • Page 395: License Plate Lamp

    394 MAINTAINING YOUR VEHICLE License Plate Lamp 1. Remove two retaining screws holding the light lens in place. 2. Gently pry the lamp assembly loose. 3. Pull bulb from socket, replace and reattach the lamp assembly with the two retaining screws. Center High-Mounted Stop Lamp 1.
  • Page 396 MAINTAINING YOUR VEHICLE 395 3. Replace the bulb and reinstall the socket into the housing by locking it in place with a twist.

  • Page 397: Fluid Capacities

    396 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) All Engines — (Except 2.4L PZEV) 2.4L PZEV (Partial Zero Emissions Vehicle) Engine Oil with Filter 2.4L Engine (SAE 5W-20, API Certified) 2.7L Engine (SAE 5W-20, API Certified) 3.5L Engine (SAE 10W-30, API Certified) Cooling System* 2.4L Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula or equivalent)

  • Page 398: Fluids, Lubricants, And Genuine Parts

    FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil – 2.4L and 2.7L Engines Engine Oil – 3.5L Engine Engine Oil Filter Spark Plugs – 2.4L Engine except PZEV* Spark Plugs – 2.4L Engine with PZEV* Spark Plugs – 2.7L Engine Spark Plugs –...

  • Page 399: Chassis

    398 MAINTAINING YOUR VEHICLE Component Fuel Selection – 2.4L and 2.7L En- gines Fuel Selection – 3.5L Engine * PZEV = Partial Zero Emission Vehicle Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part 87 Octane 87 Octane Acceptable –...

  • Page 400: Maintenance Schedules

    MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..400 Maintenance Schedule ....400 Required Maintenance Intervals ..402...

  • Page 401: Emissions Control System Maintenance

    400 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
  • Page 402 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been six months since your last oil change even if the oil change indicator message is NOT illumi- nated.
  • Page 403 402 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant reservoir, brake master cylinder, and transmission and add as needed. •...
  • Page 404 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule ❏...

  • Page 405: Service Schedule

    404 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule ❏...
  • Page 406 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (2.4L Engine except PZEV*). ❏ Adjust parking brake on vehicles equipped with four wheel disc brakes.
  • Page 407 406 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule ❏...
  • Page 408 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule ❏...
  • Page 409 408 MAINTENANCE SCHEDULES 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule ❏...
  • Page 410 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule ❏...
  • Page 411 410 MAINTENANCE SCHEDULES 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (2.4L Engine except PZEV*). ❏...
  • Page 412 102,000 Miles (170,000 km) or 102 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the spark plugs (2.4L PZEV*, 2.7L and 3.5L Engines). ❏ Replace the timing belt (3.5L Engine). ❏...
  • Page 413 412 MAINTENANCE SCHEDULES 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏...
  • Page 414 126,000 Miles (210,000 km) or 126 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule ❏...
  • Page 415 414 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule ❏...
  • Page 416 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs (2.4L Engine except PZEV*). ❏ Adjust parking brake on vehicles equipped with four wheel disc brakes.
  • Page 417 416 MAINTENANCE SCHEDULES * PZEV = Partial Zero Emission Vehicle † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle.

  • Page 418: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......419 Prepare For The Appointment .
  • Page 419 418 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......425 Treadwear ......425 Traction Grades .

  • Page 420: Suggestions For Obtaining Service For Your Vehicle

    SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.

  • Page 421: Chrysler Group Llc Customer Center

    420 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.

  • Page 422: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.

  • Page 423: Warranty Information

    422 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.

  • Page 424: In Canada

    If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
  • Page 425 424 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts. • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.

  • Page 426: Department Of Transportation Uniform Tire Quality Grades

    DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
  • Page 427 426 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
  • Page 428 INDEX...
  • Page 429 428 INDEX About Your Brakes ..... . . 259 ABS (Anti-Lock Brake System) ....262 Adding Engine Coolant (Antifreeze) .
  • Page 430 Automatic Transaxle ....12,243,246,374 Adding Fluid ....375,376,398 Filter ....... 376 Fluid and Filter Changes .
  • Page 431 430 INDEX Caps, Filler Fuel ....... 309 Oil (Engine) ....347,348,349,356 Power Steering .
  • Page 432 Contract, Service ......421 Coolant Pressure Cap (Radiator Cap) ..369 Cooler, Beverage .
  • Page 433 432 INDEX Door Locks, Automatic ....30 Door Opener, Garage ..... 121 Driving On Slippery Surfaces .
  • Page 434 Oil Selection ..... . . 355,396 Oil Synthetic ......357 Overheating .
  • Page 435 434 INDEX Fluid Level Checks Automatic Transaxle ....375,376 Brake ......372,398 Cooling System .
  • Page 436 Gauges Coolant Temperature ....150 Fuel ....... 150 Odometer .
  • Page 437 436 INDEX Ignition Key Removal ..... 12 Illuminated Entry ......19 Immobilizer (Sentry Key) .
  • Page 438 Leaks, Fluid ......84 Life of Tires ......288 Light Bulbs .
  • Page 439 438 INDEX Tires ....... 278 Locks Auto Unlock ......31 Child Protection .
  • Page 440 Odometer ......154 Trip ......154,157 Oil Change Indicator .
  • Page 441 440 INDEX Power Door Locks ......30 Mirrors ......90 Outlet (Auxiliary Electrical Outlet) .
  • Page 442 Replacement Bulbs ..... . . 388 Replacement Keys ......15 Replacement Parts .
  • Page 443 442 INDEX Cleaning ......104 Heated ......101 Lumbar Support .
  • Page 444 Steering Wheel Mounted Sound System Controls ......222 Storage ......134,388 Storage, Vehicle .
  • Page 445 444 INDEX Radial ......285 Replacement ......288 Rotation .
  • Page 446 Transporting Pets ......79 Tread Wear Indicators ....287 Trip Odometer .
  • Page 447 446 INDEX Wheel and Wheel Trim ....379 Wheel and Wheel Trim Care ....379 Wind Buffeting .
  • Page 448 Chrysler Group LLC 10D41-126-AC Printed in U.S.A. 3rd Edition...

Table of Contents

Save PDF
