Page 1 Challenger SRT8 2 0 1 0 OWNE R ’ S MANUAL...
Page 2: Introduction
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6 INTRODUCTION 5...
Page 7: Vehicle Identification Number
The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel and is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN Location Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove or alter the VIN.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . 12 Key FOB .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Open The Trunk ....24 Using The Panic Alarm ....24 Programming Additional Transmitters .
Page 12 Supplemental Restraint System (SRS) - Airbags ......45 Airbag Deployment Sensors And Controls . . . 51 Event Data Recorder (EDR) .
Page 13: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch.
Page 14: Key Fob
1 — OFF 2 — ACCESSORY (ACCESSORY) 3 — RUN 4 — START THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob.
Page 15: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand. Emergency Key Removal NOTE: You can insert the double-sided emergency key into the lock cylinders with either side up.
Page 16: Key-In-Ignition Reminder
WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Do not leave the Key Fob in the ignition or a vehicle equipped with Keyless Go in the ACC or RUN mode.
Page 17: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system uses Key Fob with factory-mated Remote Keyless Entry (RKE) transmitter and Wireless Ignition Node (WIN) to prevent unauthorized vehicle operation. Therefore, only Key Fobs that are programmed to the vehicle can be used to start and operate the vehicle. The system will not allow the engine to crank if an invalid Key Fob is used to start and operate the vehicle.
Page 18: Customer Key Programming
CAUTION! (Continued) • For vehicles equipped with Keyless Go, always remember to place the ignition in OFF. At the time of purchase, the original owner is provided with a four-digit Personal Identification Number (PIN). Keep the PIN in a secure location. This number is required for authorized dealer replacement of Key Fobs.
Page 19: Rearming Of The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Rearming Of The System If something triggers the alarm, and no action is taken to disarm it, the Vehicle Security Alarm will turn the horn off after three minutes, turn all of the visual signals off after 15 minutes, and then the Vehicle Security Alarm will rearm itself.
Page 20 NOTE: • The driver’s door key cylinder and the trunk button on the RKE transmitter cannot arm or disarm the Vehicle Security Alarm. • The Vehicle Security Alarm remains armed during trunk entry. Pressing the TRUNK button will not disarm the Vehicle Security Alarm. If someone enters the vehicle through the trunk, and opens any door, the alarm will sound.
Page 21: Illuminated Entry
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ILLUMINATED ENTRY The courtesy lights will turn on when you press the UNLOCK button on the Remote Keyless Entry (RKE) transmitter or open any door. The lights will fade to off after approximately 30 seconds or they will immediately fade to off once the ignition switch is placed in RUN from the OFF position.
Page 22: To Unlock The Doors
To Unlock The Doors Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door or twice within five seconds, to unlock both doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.
Page 23 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE activated will cause the alarm to sound. Press the UN- LOCK button to deactivate the Security Alarm. Flash Lights with Remote Key Lock This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- ter.
Page 24: To Lock The Doors
To Lock The Doors Press and release the LOCK button on the RKE transmit- ter to lock both doors. The turn signal lights will flash and the horn will chirp to acknowledge the signal. Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter.
Page 25: To Open The Trunk
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE then immediately press and hold the UNLOCK button until the windows lower to the level desired or until they lower completely. To Open The Trunk Press the TRUNK button on the RKE transmitter two times within five seconds to open the trunk.
Page 26: General Information
1. If the RKE transmitter is equipped with a screw, remove the screw. With the RKE ransmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart. Make sure not to damage the elastomer seal during removal.
Page 27: Remote Starting System
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios. REMOTE STARTING SYSTEM This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conve- niently from outside the vehicle while still maintaining security.
Page 28 To Enter Remote Start Mode Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds. The parking lights will flash and the horn will chirp twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15-minute cycle.
Page 29: Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE equipped). Then, prior to the end of the 15 minute cycle, press and release the START/STOP button. If the START/STOP button is not present, insert the Key Fob into the ignition switch and turn the switch to the ON position.
Page 30: Power Door Locks
If the door lock plunger is down when you shut the door, the door will lock. Therefore, make sure the key is not inside the vehicle before closing the door. WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle.
Page 31 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE locks will not operate. This prevents you from acciden- tally locking the Key Fob in the vehicle. Removing the Key Fob or closing the door will allow the locks to operate. If a door is open, the Key Fob is in the ignition, and the ignition is in the OFF or ACC position, a chime will sound as a reminder to remove the Key Fob.
Page 32 6. The vehicle speed is 0 mph (0 km/h) Automatic Unlock Doors on Exit Programming The Automatic Unlock Doors On Exit feature can be enabled or disabled. Refer to “Electronic Vehicle Infor- mation Center (EVIC)/Personal Settings (Customer- Programmable Features)” in “Understanding Your In- strument Panel”...
Page 33: Windows
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows The window controls on the driver’s door control both of the door windows. Power Window Switches There is a single window control on the passenger’s door trim panel that operates the window on the passenger’s door.
Page 34: Wind Buffeting
AUTO-Down Feature The driver’s door power window switch and passenger door power window switch have an AUTO-down fea- ture. Press the window switch to the second detent, release, and the window will go down automatically. To open the window part way, press the window switch to the first detent and release it when you want the window to stop.
Page 35: Trunk Safety Warning
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The transmission must be in PARK before the button will operate. If equipped with a manual transmis- sion, the vehicle speed must be under 5 mph (8 km/h) before the button will operate. The trunk lid can be released from outside the vehicle by pressing the Trunk Release button on the Re-...
Page 36: Trunk Emergency Release
Trunk Emergency Release Emergency Release The trunk of your vehicle is equipped with an emergency release handle. It is located on the inside of the trunk lid, near the latch, and is coated so that it glows in a darkened trunk.
Page 37 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you will be carrying children too small for adult-sized seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold infant and child restraint systems. For more information on LATCH, see Lower Anchors and Tether for CHildren (LATCH).
Page 38: Lap/Shoulder Belts
ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. The belt webbing retractor is designed to lock during very sudden stops or impacts.
Page 39 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
Page 40 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt.
Page 42: Lap/Shoulder Belt Untwisting Procedure
Removing Slack From Belt 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 WARNING! A frayed or torn belt could rip apart in a collision and...
Page 43: Automatic Locking Retractors (Alr) Mode - If Equipped
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate. 3.
Page 44: Seat Belt Pretensioners - If Equipped
Seat Belt Pretensioners — If Equipped The seat belts for both front seating positions may be equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. These devices improve the performance of the seat belt by assuring that the belt is tight about the occupant early in a collision.
Page 45: Seat Belts And Pregnant Women
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. With both doors closed, and the ignition switch in any position except RUN or START, buckle the driver’s seat belt. 2. Turn the ignition switch to the RUN position, but do not start the engine.
Page 46: Seat Belt Extender
Seat Belt Extender If a seat belt is too short even when fully extended your authorized dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not long enough. When it is not required, remove the extender and store it.
Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: These airbags are certified to the new Federal regulations for Advanced Airbags. The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation based on the severity and type of collision. This vehicle may also be equipped with Supplemental Side Airbag Inflatable Curtains (SABIC) to protect the driver, front, and rear passengers sitting next to a win-...
Page 48 appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), which may receive information from the impact sensors at the front of the car. The first stage inflator is triggered immediately during an impact that requires airbag deployment. The timing of the second stage determines whether the output force is low, medium, or high.
Page 49 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE airbag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side-impact head injuries. The curtains deploy down- ward, covering both windows on the impact side. Supplemental Side Airbag Inflatable Curtains (SABIC) NOTE: •...
Page 50 WARNING! • If your vehicle is equipped with left and right Side Airbag Inflatable Curtain (SABIC), do not stack luggage or other cargo up high enough to block the location of the SABIC. The area where the side curtain airbag is located should remain free from any obstructions.
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ride properly buckled up in the rear seat. Never allow children to slide the shoulder belt behind them or under their arm. If a child from 1 to 12 years old (not in a rear facing child seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint.
Page 52: Airbag Deployment Sensors And Controls
WARNING! (Continued) • Being too close to the steering wheel or instrument panel during front airbag deployment could cause serious injury, including death. Airbags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instru- ment panel.
Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The side airbags will not deploy in all side collisions. Side airbag deployment will depend on the severity and type of collision. Because airbag sensors measure vehicle deceleration over time, vehicle speed and damage by themselves are not good indicators of whether or not an airbag should have deployed.
Page 54 WARNING! Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have the airbag system checked right away.
Page 55 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A quantity of non-toxic gas is generated to inflate the side curtain airbag. The inflating side curtain airbag pushes the outside edge of the headliner out of the way and covers the window. The airbag inflates in about 30 ms (about one-quarter of the time that it takes to blink your eyes) with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area...
Page 56 • Turn on the interior lights, which remain on as long as the battery has power or until the ignition key is removed. • Unlock the doors automatically. If a Deployment Occurs The airbags are designed to deflate immediately after deployment.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Deployed airbags and seat belt pretensioners cannot protect you in another collision. Have the airbags, seat belt pretensioners, and the front passenger seat belt retractor assembly replaced by an authorized dealer as soon as possible. Also, have the Occupant Restraint Controller (ORC) system serviced as well.
Page 58 WARNING! (Continued) • Do not attempt to modify any part of your ad- vanced airbag system. The airbag may inflate accidentally or may not function properly if modi- fications are made. Take your vehicle to an autho- rized dealer for any advanced airbag system ser- vice.
Page 59: Event Data Recorder (Edr)
58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE located on the inside of the fuse block cover for the proper airbag fuses. See your authorized dealer if the fuse is good. Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data param- eters (see list below) in an event data recorder prior to the moment of airbag deployment, or near deployment (if...
Page 60: Child Restraint
accessing the electronic data stored, unless ordered to download data by a court with legal jurisdiction (i.e., pursuant to a warrant). A copy of the data will be provided to the custodial entity upon request. General data that does not identify particular vehicles or crashes may be released for incorporation in aggregate crash databases, such as those maintained by the U.S.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it. Children 12 years and younger should ride properly buckled up in a rear seat, if available.
Page 62 infant carriers do, so they can be used rearward-facing by children who weigh more than 20 lbs (9 kg) but are less than one year old. Both types of child restraints are held in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system.
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Make sure that the child is upright in the seat. • The lap portion should be low on the hips and as snug as possible. • Check belt fit periodically. A child’s squirming or slouching can move the belt out of position.
Page 64 Standards. We also recommend that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it. • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits.
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE strap kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle. All three rear-seating positions have lower anchorages that are capable of accommodating LATCH-compatible child seats.
Page 66 Again, carefully follow the installation instructions that are provided with the child restraint system. The rear seat lower anchorages are round bars located at the rear of the seat cushion where it meets the seatback and are just visible when you lean into the rear seat to install the child restraint.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. • When using the LATCH attaching system to install a child restraint, please ensure that all seat belts not being used for occupant restraints are stowed and out of reach of children.
Page 68 then allow the belt to retract into the retractor. For additional information on ALR, refer to “Automatic Locking Mode”. To install a child restraint, first, pull enough of the seat belt webbing from the retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.
Page 69: Engine Break-In Recommendations
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child.
Page 70: Safety Tips
CAUTION! Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result. NOTE: A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication of difficulty.
Page 71: Exhaust Gas
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or...
Page 72: Safety Checks You Should Make Inside The Vehicle
Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 73: Periodic Safety Checks You Should Make Outside The Vehicle
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 74: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......77 Automatic Dimming Mirror ....77 Outside Mirrors .
Page 75 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 109 Voice Command System Operation ..109 Commands ......111 Voice Training .
Page 76 Flash-To-Pass ..... . . 127 Overhead Console Map/Reading Lights ..128 Interior Lights ..... . 129 Windshield Wipers And Washers .
Page 77 76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Security ......142 Troubleshooting Tips ....143 General Information .
Page 78: Mirrors
MIRRORS Automatic Dimming Mirror This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 79: Outside Mirrors Folding Feature
78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.
Page 80: Power Mirrors
Power Mirrors The power mirror switch is located on the driver’s door trim panel next to the power door lock switch. A rotary knob selects the left mirror, right mirror or off position. Power Mirror Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 79 After selecting a mirror, move the knob in the same direction you want the mirror to move.
Page 81: Illuminated Vanity Mirrors
80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors An illuminated vanity mirror is located on the sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward. The light turns on automatically. Close the mirror cover to turn off the light. Illuminated Vanity Mirror “Slide-On-Rod”...
Page 82: Uconnect™ Phone - If Equipped
NOTE: The Uconnect™ Phone requires a cellular phone equipped with the Bluetooth Hands-Free Profile, Ver- sion 0.96 or higher. See the Uconnect™ website for supported phones. For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400...
Page 83 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation. The Uconnect™ Phone is driven through your Bluetooth “Hands-Free Profile”...
Page 84: Operation
The Uconnect™ Phone can be used with any Hands-Free Profile certified Bluetooth cellular phone. See the Uconnect™ website for supported phones. If your cellu- lar phone supports a different profile (e.g., Headset Profile) you may not be able to use any Uconnect™ Phone features.
Page 85 84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE example, you can use the combined form voice com- mand Phonebook New Entry, or you can break the combined form command into two voice commands: Phonebook and New Entry. Please remember, the Uconnect™ Phone works best when you talk in a normal conversational tone, as if speaking to someone sitting a few feet/meters away from you.
Page 86 • When prompted, after the beep, say Pair a Phone and follow the audible prompts. • You will be asked to say a four-digit Personal Identi- fication Number (PIN), which you will later need to enter into your cellular phone. You can enter any four-digit PIN.
Page 87 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will confirm the phone number and then dial. The number will appear in the display of certain radios. Call by Saying a Name • Press the button to begin. •...
Page 88 • When prompted, enter the number designation (e.g., Home, Work, Mobile, or Pager ). This will allow you to store multiple numbers for each phonebook entry, if desired. • When prompted, recite the phone number for the phonebook entry that you are adding. After you are finished adding an entry into the phone- book, you will be given the opportunity to add more phone numbers to the current entry or to return to the...
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- loaded, there may be a short delay before the latest downloaded names can be used. Until then, if avail- able, the previous downloaded phonebook is available for use.
Page 90 first disconnect or drop the Bluetooth connection to the Uconnect™ Phone, and then send the address book entry via Bluetooth . Please see your phone Owner’s Manual for specific instructions on how to drop the Bluetooth connection. • If the phonebook entry is longer than 24 characters, it will only use the first 24 characters.
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete Uconnect™ Phonebook Entry NOTE: Editing phonebook entries is recommended when the vehicle is not in motion. • Press the button to begin. • After the Ready prompt and the following beep, say Phonebook Delete.
Page 92: Phone Call Features
• Note that only the phonebook in the current language is deleted. • Automatic downloaded phonebook entries cannot be deleted or edited. List All Names in the Uconnect™ Phonebook • Press the button to begin. • After the Ready prompt and the following beep, say Phonebook List Names.
Page 93 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE call, press and hold the button until you hear a single beep, indicating that the incoming call was rejected. Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cellular phone.
Page 94 Conference Call When two calls are in progress (one active and one on hold), press and hold the button until you hear a double beep indicating that the two calls have been joined into one conference call. Three-Way Calling To initiate three-way calling, press the while a call is in progress, and make a second phone call, as described under Making a Second Call While Current Call is in Progress.
Page 95: Uconnect™ Phone Features
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Call continuation is the progression of a phone call on the Uconnect™ Phone after the vehicle ignition key has been switched to OFF. Call continuation functionality avail- able on the vehicle can be any one of three types: •...
Page 96 Emergency Assistance If you are in an emergency and the cellular phone is reachable: • Pick up the phone and manually dial the emergency number for your area. If the phone is not reachable and the Uconnect™ Phone is operational, you may reach the emergency number as follows: •...
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance If you need towing assistance: • Press the button to begin. • After the Ready prompt and the following beep, say Towing Assistance. NOTE: • The towing assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- 3454 for Mexico City and 1-800-712-3040 for outside...
Page 98 When calling a number with your Uconnect™ Phone that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can press the button and say the sequence you wish to enter, followed by the word Send. For example, if required to enter your PIN followed with a pound, (3 7 4 6 #), you can press the button and say, 3 7 4 6 # Send.
Page 99 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF Turning confirmation prompts off will stop the system from confirming your choices (e.g., the Uconnect™ Phone will not repeat a phone number before you dial it). • Press the button to begin.
Page 100: Advanced Phone Connectivity
Mute/Un-Mute (Mute OFF) When you mute the Uconnect™ Phone, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the Uconnect™ Phone: •...
Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say List Phones. • The Uconnect™ Phone will play the phone names of all paired cellular phones in order from the highest to the lowest priority. To “select” or “delete” a paired phone being announced, press the say “Select”...
Page 102: Things You Should Know About Your Uconnect™ Phone
Things You Should Know About Your Uconnect™ Phone Uconnect™ Phone Tutorial To hear a brief tutorial of the system features, press button and say “Uconnect™ Tutorial.” Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the Uconnect™ Phone Voice Training feature may be used.
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Speak normally, without pausing, just as you would speak to a person sitting a few feet/meters away from you. • Make sure that no one other than you is speaking during a Voice Command period. •...
Page 104 • In a convertible vehicle, system performance may be compromised with the convertible top down. Phone Far End Audio Performance • Audio quality is maximized under: • low-to-medium blower setting, • low-to-medium vehicle speed, • low road noise, • smooth road surface, •...
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105...
Page 107 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 108 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 109 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 110: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the Voice Command for the beep, and say your command.
Page 112: Commands
Commands The Voice Command system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the Voice Command button.
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band, say “FM” or “Radio FM”. In this mode, you may say the following commands: • “Frequency” (to change the frequency) • “Next Station” (to select the next station) •...
Page 114 Memo To switch to the voice recorder mode, say “Memo”. In this mode, you may say the following commands: • “New Memo” (to record a new memo) — During the recording, you may press the Voice Command button to stop recording. You proceed by saying one of the following commands: −...
Page 115: Voice Training
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Keep in mind that you have to press the Voice Command button first and wait for the beep before speaking the “Barge In” commands. Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers the Uconnect™...
Page 116 switch is used to adjust the angle of the seatback. Push forward or rearward on the switch to change the position of the seatback. Power Seat Switches 1 — Power Seat Control 2 — Power Seatback Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 WARNING! Adjusting a seat while the vehicle is moving is dangerous.
Page 117: Manual Front Seatback Recline
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seatback Recline To recline: 1. Lean forward in the seat and lift the handle, then lean back to the desired position and release the handle. Recline Lever 2. Lift the handle to return the seatback to an upright position.
Page 118: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Head Restraints Head restraints can reduce the risk of injury in the event of a rear impact. The head restraints should be adjusted so the top of the head restraint is located above the top of your ear.
Page 119: Heated Seats
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Driving a vehicle with the head restraints removed or improperly adjusted could cause serious injury or death in the event of a collision. The head restraints should always be checked prior to operating the vehicle and never adjusted while the vehicle is in motion.
Page 120 Press the switch once to select High-level heat- ing. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off. If high level heating is selected, the system will automati- cally switch to the low level after 30 minutes of continu- ous operation.
Page 121: Easy Entry Seats
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Repeated overheating of the seat could damage the heating element and/or degrade the material of the seat. Easy Entry Seats Pulling upward on the lever, located on the seatback, allows the seatback to dump forward and the seat to slide forward.
Page 122 Rear Folding Seat When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 WARNING! • Be certain that the seatback is securely locked into position.
Page 123: To Open And Close The Hood
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. 1. Pull the hood release lever located under the left side of the instrument panel. Hood Release Lever 2.
Page 124: Lights
CAUTION! To prevent possible damage, do not slam the hood to close it. Lower the hood until it is open approxi- mately 6 in (15 cm), and then drop it. This should secure both latches. Never drive your vehicle unless the hood is fully closed, with both latches engaged.
Page 125: Automatic Headlights
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the headlight switch clockwise to the first detent for parking light and instrument panel light operation. Turn it to the second detent for headlight, parking light and instrument panel light operation. Automatic Headlights This system automatically turns the headlights on or off according to ambient light levels.
Page 126: Daytime Running Lights - If Equipped
To activate the delay feature, place the ignition in the OFF position while the headlights are still on. Then, turn off the headlights within 45 seconds. The delay interval begins when the headlight switch is turned off. If you turn the headlights or parking lights, or place the ignition in the RUN position, the system will cancel the delay.
Page 127: Multifunction Lever
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE An indicator light in the instrument cluster illuminates when the fog lights are turned on. NOTE: The fog lights will operate with the low beam headlights or parking lights on. However, selecting the high beam headlights will turn off the fog lights.
Page 128: Lane Change Assist
NOTE: • If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.
Page 129: Overhead Console Map/Reading Lights
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Overhead Console Map/Reading Lights These lights are mounted between the sun visors on the overhead console. Each light is turned on by pressing the lens. Press the lens a second time to turn off the light. These lights also turn on when a door is opened, or when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is...
Page 130: Interior Lights
Interior Lights The interior lights come on when a door is opened. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition is placed in the OFF position. This will occur if the interior lights were switched on manually or are on because a door is open.
Page 131: Windshield Wipers And Washers
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS The multifunction lever operates the windshield wipers and washer when the ignition is placed in the RUN position. The multifunction lever is located on the left side of the steering column. Windshield Wiper/Washer Control Rotate the end of the multifunction lever to the first detent past the intermittent settings for low-speed wiper...
Page 132: Mist Feature
Mist Feature Push the multifunction lever inward (toward the steering column) to the first detent to activate a single wipe cycle to clear off road mist or spray from a passing vehicle. The wipers will continue to operate until you release the multifunction lever.
Page 133: Tilt/Telescoping Steering Column
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Headlights On with Wipers feature can be enabled or disabled. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Fea- tures)” in “Understanding Your Instrument Panel” for further information. TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward.
Page 134: Electronic Speed Control
WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 135: To Activate
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Activate Push and release the ON/OFF button located on the end of the Electronic Speed Control lever. The indicator light in the instrument cluster will illuminate to show that the speed control system is on. To turn the system off, push and release the ON/OFF button again.
Page 136: To Resume Speed
• Press the brake pedal, or press the clutch pedal to the floor (manual transmission). • Pull the speed control lever toward you (CANCEL). Pushing and releasing the ON/OFF button or turning the ignition OFF erases the set speed from memory. To Resume Speed If you deactivated the Electronic Speed Control without erasing the set speed from memory and your vehicle...
Page 137: To Accelerate For Passing
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate For Passing Press the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. Using Electronic Speed Control on Hills NOTE: The Electronic Speed Control system maintains speed up and down hills.
Page 138: Courtesy/Reading Lights
Overhead Console Courtesy/Reading Lights At the forward end of the overhead console are two courtesy/reading lights. Press the lens to turn on the light. Press it a second time to turn off the light. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 These lights also turn on when a door is opened, when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is...
Page 139 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The HomeLink buttons are located in the overhead console, and contain one, two or three dots/lines desig- nating the different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. WARNING! •...
Page 140: Programming Homelink
Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for up to 20 seconds. The EVIC will display “CLEARING CHANNELS.”...
Page 141 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Some gate operators and garage door openers may require you to replace Step 3 with procedures noted in the “Gate Operator/Canadian Programming” section. 4. Press and hold the just-trained HomeLink button. If the channel has been trained, the EVIC display will now state “CHANNEL # TRANSMIT.”...
Page 142: Gate Operator/Canadian Programming
6. Firmly press and release the LEARN or TRAINING button. The name and color of the button may vary by manufacturer. NOTE: You have 30 seconds in which to initiate the next step after the LEARN button has been pressed. 7.
Page 143: Using Homelink
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE has successfully accepted the frequency signal. The EVIC display will change from “CHANNEL # TRAIN- ING” to “CHANNEL # TRAINED.” If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ”...
Page 144: Troubleshooting Tips
The HomeLink Universal Transceiver is disabled when the Vehicle Security Alarm is active. Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the LEARN button on the garage door opener to complete the training for rolling code.
Page 145: Power Sunroof - If Equipped
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED The power sunroof switch is located between the sun visors on the overhead console. Power Sunroof Switch WARNING! • Never leave children in a vehicle with the key in the ignition switch (or with the ignition in the Accessory or Run position, for vehicles equipped with Keyless Go™).
Page 146: Opening Sunroof - Partially
Opening Sunroof — Partially Press and hold the switch in the rearward position. Release the switch when the sunroof is in the position desired and it will stop moving. If you continue to hold the switch in the rearward position, the sunroof will open fully and then stop automatically.
Page 147: Pinch Protect Override
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold for two seconds after the reversal occurs. This allows the sunroof to move towards the closed position. NOTE: Pinch protection is disabled while the switch is pressed.
Page 148: Sunroof Fully Closed
time for this feature is programmable. Refer to “Elec- tronic Vehicle Information Center (EVIC)/Personal Set- tings (Customer-Programmable Features)” in “Under- standing Your Instrument Panel” for further information. Sunroof Fully Closed Press the switch forward and release to ensure that the sunroof is fully closed.
Page 149 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console power outlet is powered directly from the battery (power available at all times). Items plugged into this power outlet may discharge the battery and/or prevent the engine from starting. WARNING! To avoid serious injury or death: •...
Page 150: Cupholders
CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. Improper use of the power outlet can cause damage. CUPHOLDERS Front Cupholders The front cupholders are located in the center console. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Front Cupholders Illuminated Front Cupholders —...
Page 151: Rear Cupholders
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cupholders The rear seat cupholders are located in the center armrest between the rear seats. The cupholders are positioned forward in the armrest and side-by-side to provide con- venient access to beverage cans or bottles while maintain- ing a resting place for the rear occupants’...
Page 152: Console Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Console Storage The center console has a storage compartment located underneath the armrest, and also contains a 12 Volt power outlet, a molded-in coin holder (designed to hold various size coins). The center console may also be equipped with a Universal Consumer Interface (UCI).
Page 153: Rear Window Features
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control (Mode) knob. Press this button to turn on the rear window defroster and the heated outside mirrors (if equipped).
Page 154: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....156 Instrument Cluster ....157 Instrument Cluster Descriptions .
Page 155 154 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 730N/430 (RER/REN/RBZ) — AM/FM Stereo Radio And CD/DVD/HDD/ NAV — If Equipped ....185 Operating Instructions —...
Page 156 Using This Feature ....212 Controlling The iPod Using Radio Buttons ......213 Play Mode .
Page 157: Instrument Panel Features
156 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlets 2 — Instrument Cluster 3 — Glove Compartment 4 — Radio 5 — Heated Seat Switch 6 — ESP OFF Switch 7 — Hazard Warning Switch 8 — Climate Control 9 —...
Page 158: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 157 INSTRUMENT CLUSTER...
Page 159: Instrument Cluster Descriptions
158 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The pointer shows the level of fuel in the fuel tank when the ignition switch is in the RUN position. 2. Trip Odometer Button Press this button to change the display from odometer to either of two trip odometer settings.
Page 160 7. Electronic Throttle Control (ETC) Warning Light This light will turn on briefly as a bulb check when the ignition switch is placed in RUN. This light will also turn on while the engine is running if there is a problem with the Elec- tronic Throttle Control (ETC) system.
Page 161 160 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116°C) or greater, pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range 200–...
Page 162 10. Airbag Warning Light This light will turn on for six to eight seconds as a bulb check when the ignition switch is first placed in RUN. If the light is either not on during starting, or stays on, or turns on while driving, have the system inspected at an authorized dealer as soon as possible.
Page 163 162 UNDERSTANDING YOUR INSTRUMENT PANEL cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see an authorized dealer as soon as possible. WARNING! If a warning light remains on the system may not be working and you will not have the benefit of ESP or BAS.
Page 164 check or when driving. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” for further information. 17. Shift Lever Indicator — Automatic Transmission Only The Shift Lever Indicator is self-contained within the instrument cluster. It displays the gear position of the automatic transmission.
Page 165 164 UNDERSTANDING YOUR INSTRUMENT PANEL Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the odometer display area. Tighten the fuel filler cap properly and press the TRIP ODOMETER button to turn off the message.
Page 166 If brake failure is indicated, immediate repair is neces- sary. WARNING! Driving a vehicle with the brake light on is danger- ous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident.
Page 167 166 UNDERSTANDING YOUR INSTRUMENT PANEL placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.) As an added safety feature, your vehicle has been equipped with a Tire Pressure Monitoring System...
Page 168 TPMS malfunction telltale after replacing one or more tires or wheels on your vehicle, to ensure that the replacement or alternate tires and wheels allow the TPMS to continue to function properly. CAUTION! The TPMS has been optimized for the original equipment tires and wheels.
Page 169 168 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD. The OBD system monitors engine and automatic transmission control systems. The MIL will turn on when the ignition is in the RUN position before engine start.
Page 170: Electronic Vehicle Information Center (Evic)
ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the instrument cluster. Electronic Vehicle Information Center UNDERSTANDING YOUR INSTRUMENT PANEL 169 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel.
Page 171 170 UNDERSTANDING YOUR INSTRUMENT PANEL • Surround Sound modes (if equipped with Driver- Selectable Surround [DSS]) • Performance Features The system allows the driver to select information by pressing the following buttons mounted on the steering wheel. MENU Button Press and release the MENU button and the mode displayed will change between Trip Functions, Performance Pages, Uconnect™...
Page 172: Electronic Vehicle Information Center (Evic) Displays
Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the EVIC displays the following messages: • Turn Signal On (with a continuous warning chime if the vehicle is driven more than 1 mile [1.6 km] with either turn signal on) •...
Page 173: Engine Oil Change Indicator System
172 UNDERSTANDING YOUR INSTRUMENT PANEL • Right Front Low Pressure (with a single chime) • Right Rear Low Pressure (with a single chime) • Check TPM System (with a single chime) • ESP Off • Check Gascap • Key Fob Battery Low •...
Page 174: Trip Functions
Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the MENU button. To reset the oil change indica- tor system (after performing the scheduled maintenance) refer to the following procedure.
Page 175 174 UNDERSTANDING YOUR INSTRUMENT PANEL Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET” or show dashes for two seconds. Then, the history information will be erased, and the averaging will continue from the last fuel average reading before the reset.
Page 176: Performance Features
Display Units of Measure in To make your selection, press and release the FUNC- TION SELECT button until “ENGLISH” or “METRIC” appears. To Reset The Display Reset will only occur while a resettable function is being displayed. Press and release the FUNCTION SELECT button once to clear the resettable function being dis- played.
Page 177 176 UNDERSTANDING YOUR INSTRUMENT PANEL • 1/8 Mile • 1/4 Mile • Instantaneous G-Force • Peak G-Force • Digital Speedometer To access, press and release the MENU button until Performance Features displays in the EVIC. Press the SCROLL button to cycle through the features. Press the FUNCTION SELECT button to select a feature.
Page 178 • This feature will only function when applying the brakes at speeds above 30 mph (48 km/h). • Engaging the parking brake will disable this feature. • The word “READY” will flash when conditions are met for the event to begin. •...
Page 179: Keyless Go Display - If Equipped
178 UNDERSTANDING YOUR INSTRUMENT PANEL • To clear the vehicle’s best 1/8 mile (1/4 mile) run, press and hold the FUNCTION SELECT button for five seconds. Instantaneous G-Force When selected, this screen displays the current G-Force (lateral and longitudinal) along with a friction circle that displays the directions of the forces.
Page 180: Driver-Selectable Surround Sound (Dss) - If Equipped
Keyless Go Display The round symbol in the middle rotates to point at the new ignition switch position. If desired, the ignition switch position graphic can be set to be constantly visible by pressing the EVIC MENU button until the display appears.
Page 181: Compass Display
180 UNDERSTANDING YOUR INSTRUMENT PANEL Video Surround Mode will only be available for video media sources (DVDs, Video CDs, or other video media supported by the radio). Compass Display The compass readings indicate the direction the vehicle is facing. Press and release the HOME button to display one of eight compass readings and the outside temperature.
Page 182 4. Press and release the FUNCTION SELECT button to start the calibration. The message “CAL” will display in the EVIC. 5. Complete one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL” message turns off.
Page 183: System Warnings (Customer Information Features)
182 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC. 4. Press and release FUNCTION SELECT button until the proper variance zone is selected according to the map.
Page 184 select English, Espanol, or Francais. Then, as you con- tinue, the information will display in the selected lan- guage. NOTE: The EVIC will not change the Uconnect™ lan- guage selection. Refer to “Uconnect™ Phone” in “Under- standing The Features Of Your Vehicle” for further information.
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL Flash Lights with Remote Key Lock When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the RKE transmitter. This feature may be selected with or without the sound horn on lock feature selected.
Page 186: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/Nav - If Equipped
Turn Headlights On with Remote Key Unlock When this feature is selected, the headlights will activate and remain on for up to 90 seconds when the doors are unlocked with the RKE transmitter. To make your selec- tion, press and release the FUNCTION SELECT button until “OFF,”...
Page 187: Operating Instructions - Voice Command System - If Equipped
186 UNDERSTANDING YOUR INSTRUMENT PANEL The REN, RER and RBZ radios contain a CD/DVD player, USB port, and a 30-gigabyte hard drive (HDD). Sirius Satellite Radio is optional. The 6.5 in (16.5 cm) touch screen allows for easy menu selection. The RER radio also contains a Global Positioning System (GPS)-based Navigation system.
Page 188 5. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time. Proceed as follows to change the current setting: 1.
Page 189: Clock Setting Procedure - Rer/Ren Radio
188 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen. 4. Select a time zone by touching the screen where your selection appears. If you do not see a time zone that you want to select, touch the screen where the word “Page”...
Page 190 6. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time. Proceed as follows to change the current setting: 1.
Page 191: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
190 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen. 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 192 Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping. Turning the ON/VOLUME control knob to the right increases the volume, and to the left decreases it.
Page 193 192 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 194: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window. Select the button (1 to 6) you wish to lock onto this station and press and release that button.
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD player and the CD icon will illuminate on the radio display.
Page 196 If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF. NOTE: Ejecting with the ignition OFF is not allowed on convertible or soft-top models (if equipped).
Page 197: Notes On Playing Mp3 Files
196 UNDERSTANDING YOUR INSTRUMENT PANEL Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 198 Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times.
Page 199: Operation Instructions - Auxiliary Mode
198 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 200: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
MEDIA CENTER 130 (RES/RSC) — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. RES/RSC Radio UNDERSTANDING YOUR INSTRUMENT PANEL 199 Operating Instructions —...
Page 201 200 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 202 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change. 5.
Page 203 202 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display.
Page 204 Program Type 16-Digit Character Display College College Country Country Foreign Language Language Information Inform Jazz News News Nostalgia Nostalga Oldies Oldies Personality Persnlty Public Public Rhythm and Blues R & B Religious Music Rel Musc Religious Talk Rel Talk Rock Rock Soft Soft Rock...
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select between the following items: • Set Clock — Pressing the SELECT button will allow you to set the clock. Adjust the hours by turning the TUNE/SCROLL control knob.
Page 206: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM stations). DISC/AUX Button Pressing the DISC/AUX button will allow you to switch from AM/FM modes to DISC/AUX mode. Operation Instructions —...
Page 207 206 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! (Continued) • Do not use adhesive labels. These labels can peel away and jam the player mechanism. • RES is a single CD player. Do not attempt to insert a second CD if one is already loaded. •...
Page 208: Notes On Playing Mp3 Files
AM/FM Button Press the button to select either AM or FM mode. SET/RND Button (Random Play Button) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace.
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL a number instead. With a maximum number of files, exceeding 20 folders will result in this display. With 200 files, exceeding 50 folders will result in this display.) • Maximum number of characters in file/folder names: •...
Page 210 MPEG Sampling Fre- Specification quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 211: List Button (Cd Mode For Mp3 Play)
210 UNDERSTANDING YOUR INSTRUMENT PANEL LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain...
Page 212: Universal Consumer Interface (Uci) - If Equipped
TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when the ignition is OFF). Operating Instructions - Uconnect™ Phone (If Equipped) Refer to “Uconnect™ Phone” in “Understanding The Features If Your Vehicle”.
Page 213: Connecting The Ipod
212 UNDERSTANDING YOUR INSTRUMENT PANEL • Connecting an iPod to the AUX port located in the radio faceplate, plays media, but does not use the UCI feature to control the connected device. Connecting The iPod Use the provided connection cable to connect an iPod to the vehicle’s 16–pin connector port located on the center console.
Page 214: Controlling The Ipod Using Radio Buttons
Controlling The iPod Using Radio Buttons To get into the UCI (iPod ) mode and access a connected iPod , press the “AUX” button on the radio faceplate. Once in the UCI (iPod ) mode, iPod audio tracks (if available from iPod ) start playing over the vehicle’s audio system.
Page 215: List Or Browse Mode
214 UNDERSTANDING YOUR INSTRUMENT PANEL beginning of the track. If you press the SEEK >> button during play mode, it will jump to the next track in the list. • While a track is playing, press the INFO button to see the associated metadata (artist, track title, album, etc.) for that track.
Page 216 the track to be played highlighted on the radio display, press the TUNE control knob to select and start playing the track. Turning the TUNE control knob fast will scroll through the list faster. During fast scroll, you may notice a slight delay in updating the information on the radio display.
Page 217: Uconnect™ Multimedia (Satellite Radio) - If Equipped
216 UNDERSTANDING YOUR INSTRUMENT PANEL • MUSIC TYPE button: The MUSIC TYPE button is another shortcut button to the genre listing on your iPod . CAUTION! • Leaving the iPod (or any supported device) any- where in the vehicle in extreme heat or cold can alter the operation or damage the device.
Page 218: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
information, call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com, or at www- .siriuscanada.ca for Canadian residents. Electronic Serial Number/Sirius Identification Number (ESN/SID) Please have the following information available when calling: 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID).
Page 219: Reception Quality
218 UNDERSTANDING YOUR INSTRUMENT PANEL bikes should be placed as far rearward as possible, within the loading design of the rack. Do not place items directly on or above the antenna. Reception Quality Satellite reception may be interrupted due to one of the following reasons: •...
Page 220 INFO Button Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- able). Also, pressing and holding the INFO button for an additional three seconds will make the radio display the Song Title all of the time (press and hold again to return to normal display).
Page 221: Operating Instructions - Uconnect™ Phone (If Equipped)
220 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 222: Kicker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped
KICKER HIGH PERFORMANCE SOUND SYSTEM WITH DRIVER-SELECTABLE SURROUND (DSS) – IF EQUIPPED Your vehicle is equipped with a state of the art audio amplifier that provides 5.1-channel surround sound from any stereo audio source. A new feature of the KICKER audio system offers the ability to choose surround sound for any audio source.
Page 223: Remote Sound System Controls
222 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED Remote Sound System Controls The remote sound system controls are located on the surface of the steering wheel at the three and nine o’clock positions. Vehicles equipped with steering wheel-mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC).
Page 224: Cd/Dvd Disc Maintenance
If the Compass/Temp/Audio screen is already displayed when the AUDIO MODE button is pressed, then the mode will change (i.e., from AM to FM, to Media mode, etc., depending on which radio is in the vehicle). FUNCTION SELECT Button When the EVIC is in the Compass/Temp/ Audio screen, press the FUNCTION SELECT button to operate various radio, media, and Universal Customer Interface (UCI) functions...
Page 225: Radio Operation And Cellular Phones
224 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e., scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have copyright encoding. Try a known good disc before considering disc player service.
Page 226 Front Blower Control There are four blower speeds. Use this control to regulate the amount of air forced through the system in any mode you select. The blower speed increases as you move the control clockwise from the off position. NOTE: For vehicles equipped with Remote Start, the climate controls will not function during Remote Start operation if the blower control is left in the “O”...
Page 227 226 UNDERSTANDING YOUR INSTRUMENT PANEL Mode Control (Air Direction) Mode control allows you to choose from several selections of air distribu- tion. You can select either a primary mode, as identified by the symbols, or a blend of two of these modes. The closer the control is to a particular mode, the more air distribution you receive from that mode.
Page 228 Defrost Mode Air is directed through the windshield and side window demist outlets. Use DEFROST mode with maximum blower and temperature settings for best windshield and side window defrosting. NOTE: The air conditioning compressor operates in MIX and DEFROST, or a blend of these modes even if the A/C button is not pressed.
Page 229 228 UNDERSTANDING YOUR INSTRUMENT PANEL • The A/C can be deselected manually without disturb- ing the mode control selection. Economy Mode If ECONOMY mode is desired, press the A/C button to turn off the indicator light and the A/C compressor. Rotate the temperature control knob to the desired temperature.
Page 230: Operating Tips
If Outside Ambient Mode Overrides To Temperature Is Less than 40°F Between 40°F and 80°F No Override More than 80°F Bi-Level NOTE: • The feature can be disable by parking the vehicle with the blower control set to the “O” (or OFF) position. •...
Page 231 230 UNDERSTANDING YOUR INSTRUMENT PANEL Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower settings. This will ensure adequate system lubrication to minimize the possibility of compressor damage when the system is started again.
Page 232 UNDERSTANDING YOUR INSTRUMENT PANEL 231 Control Setting Suggestions for Various Weather Conditions...
Page 234: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....237 Manual Transmission – If Equipped ..237 Automatic Transmission –...
Page 235 234 STARTING AND OPERATING Five-Speed Automatic Transmission ..254 Gear Ranges ......254 AutoStick .
Page 236 ESP/BAS Malfunction Indicator Light And ESP/TCS Indicator Light ....279 Tire Safety Information ....280 Tire Markings .
Page 237 236 STARTING AND OPERATING E-85 Usage In Non-Flex Fuel Vehicles ..305 MMT In Gasoline ....306 Materials Added To Fuel .
Page 238: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 239: Automatic Transmission - If Equipped
238 STARTING AND OPERATING WARNING! Do not attempt to push or tow your vehicle to get it started. Unburned fuel could enter the catalytic con- verter and once the engine has started, ignite and damage the converter and vehicle. If the vehicle has a discharged battery, booster cables may be used to obtain a start from another vehicle.
Page 240: Keyless Go
Do not press the accelerator. Use the Fob with Integrated Key to briefly turn the ignition switch to the START position and release it as soon as the starter engages. The starter motor will continue to run, and it will disengage automatically when the engine is running.
Page 241: Normal Starting
240 STARTING AND OPERATING NOTE: The ENGINE START/STOP button should only be removed or inserted with the ignition in the OFF position. Normal Starting Using the ENGINE START/STOP Button – Automatic Transmission Only NOTE: Normal starting of either a cold or a warm engine is obtained without pumping or pressing the accelerator pedal.
Page 242 2. The ignition switch will return to the OFF position. 3. If the shift lever is not in PARK, the ENGINE START/ STOP button must be held for two seconds and vehicle speed must be above 5 mph (8 km/h) before the engine will shut off.
Page 243: Extreme Cold Weather (Below 20°F Or 29°C)
242 STARTING AND OPERATING • If the vehicle speed is above 5 mph (8 km/h), the ENGINE START/STOP button must be held for two seconds before the engine will shut off. The ignition switch position will remain in the ACC position until the vehicle is stopped and the button is pressed twice to the OFF position.
Page 244: If Engine Fails To Start
If Engine Fails To Start WARNING! • Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. • Do not attempt to push or tow your vehicle to get it started.
Page 245: After Starting
244 STARTING AND OPERATING the way to the floor and hold it, then press and hold the ENGINE START/STOP button for no more than 15 sec- onds. Release the accelerator pedal and the clutch pedal, wait 10 to 15 seconds, then repeat the “Normal Starting” procedure.
Page 246: Manual Transmission - If Equipped
WARNING! Remember to disconnect the cord before driving. Damage to the 110-115 Volt electrical cord could cause electrocution. MANUAL TRANSMISSION — IF EQUIPPED Six-Speed Manual Transmission WARNING! You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied.
Page 247 246 STARTING AND OPERATING NOTE: During cold weather, you may experience in- creased effort in shifting until the transmission fluid warms up. This is normal. Manual Shifter Shifting Fully press the clutch pedal before shifting gears. As you release the clutch pedal, lightly press the accelerator pedal.
Page 248 CAUTION! Always make sure the vehicle comes to a complete stop before shifting into REVERSE. Failure to do so may result in transmission damage. You must always use first gear (or Reverse) when starting from a standing position. Recommended Shift Speeds To utilize your manual transmission efficiently for fuel economy, it should be upshifted as listed in recom- mended shift speed chart.
Page 249 248 STARTING AND OPERATING with the clutch engaged (clutch pedal released), but it may also be heard when driving at low engine RPM. Also, this may be more noticeable when the transmis- sion is warm. This is a normal condition and is not an indication of a problem with your clutch or transmission.
Page 250: Automatic Transmission - If Equipped
CAUTION! • If you skip more than one gear while downshift- ing or downshift at too high an engine speed, you could damage the engine, transmission, or clutch. • Do not downshift into first gear when the vehicle is moving faster than 15 mph (24 km/h), as you could damage the engine and/or clutch.
Page 251: General Information
250 STARTING AND OPERATING WARNING! It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 252 • The electronically-controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new vehicle may be somewhat abrupt or soft until after the break-in period. This is a normal condition, and pre- cision shifts will develop within a few shift cycles.
Page 253: Key Ignition Park Interlock
252 STARTING AND OPERATING Over-Temperature Mode The transmission electronics constantly monitor the trans- mission oil temperature. If the transmission exceeds nor- mal operating temperature, the transmission will change the way it shifts to help control the condition. This may result in a slightly different feeling or response during normal operation in DRIVE position.
Page 254 3. Press and maintain firm pressure on the brake pedal. 4. Using the screwdriver, press and hold the override tab through the access port on the center console. Interlock Manual Override STARTING AND OPERATING 253 5. Move the shift lever into the NEUTRAL position. 6.
Page 255: Gear Ranges
254 STARTING AND OPERATING Five-Speed Automatic Transmission Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped. Be sure to keep your foot on the brake pedal when moving the shift lever between these gears. Shift Lever Gear Ranges PARK...
Page 256 WARNING! Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage. The following indicators should be used to ensure that you have engaged the shift lever in the PARK position: •...
Page 257 256 STARTING AND OPERATING CAUTION! Coasting the vehicle or driving for any other reason with the shift lever in NEUTRAL can result in transmission damage. WARNING! Do not coast in NEUTRAL and never turn off the ignition to coast down a hill. These are unsafe practices that limit your response to changing traffic or road conditions.
Page 258: Autostick
damage, the transmission will engage Limp Home Mode. If vehicle acceleration worsens or the transmission no longer shifts, the transmission is most likely operating in the Limp Home Mode. In this mode, the transmission will remain in the current gear until the vehicle is brought to a stop.
Page 259: Operation
258 STARTING AND OPERATING braking, eliminate undesirable upshifts and downshifts, and improve overall vehicle performance. This system can also provide you with more control during passing, city driving, cold slippery conditions, mountain driving, trailer towing, and many other situations. Operation By placing the shift lever in the DRIVE position, it can be moved from side to side.
Page 260: General Information
General Information • You can start out in first or second gear. The system will ignore attempts to upshift at too low of a vehicle speed or downshift at too high of a vehicle speed.. • The transmission will automatically downshift to 1st gear when coming to a stop.
Page 261: Traction
260 STARTING AND OPERATING Traction When driving on wet or slushy roads, it is possible for a wedge of water to build up between the tire and road surface. This is known as hydroplaning and may cause partial or complete loss of vehicle control and stopping ability.
Page 262: Flowing/Rising Water
Flowing/Rising Water WARNING! Do not drive on, or cross, a road or a path where water is flowing and/or rising (as in storm run-off). Flowing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water.
Page 263 262 STARTING AND OPERATING CAUTION! • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission, axle, etc.) for signs of contamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 264: Power Steering
POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.
Page 265: Parking Brake
264 STARTING AND OPERATING checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated. Coordinate inspection efforts through an autho- rized dealer. CAUTION! Do not use chemical flushes in your power steering system as the chemicals can damage your power steering components.
Page 266: Manual Transmission - If Equipped
NOTE: • When the parking brake is applied and the transmis- sion is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound to alert the driver. Fully release the parking brake before attempting to move the vehicle.
Page 267: Automatic Transmission - If Equipped
266 STARTING AND OPERATING Automatic Transmission – If Equipped The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully. To release the parking brake, press the park brake pedal a second time and let your foot up as you feel the brake disengage.
Page 268: Brake System
WARNING! (Continued) • Always fully apply the parking brake when leav- ing your vehicle, or it may roll and cause damage or injury. Also be certain to leave the transmission in PARK. Failure to do so may allow the vehicle to roll and cause damage or injury.
Page 269 268 STARTING AND OPERATING The Electronic Brake Force Distribution (EBD) prevents the rear wheels from over-braking and provides greater control of available braking forces applied to the rear axle. When the vehicle is driven over 7 mph (11 km/h), you may also hear a slight clicking sound as well as some related motor noises.
Page 270 WARNING! • The Anti-Lock Brake System (ABS) contains so- phisticated electronic equipment that may be sus- ceptible to interference caused by improperly in- stalled high output radio equipment. This interference can cause possible loss of anti-lock braking capability. Installation of such equipment should be performed by qualified professionals.
Page 271: Electronic Brake Control System
270 STARTING AND OPERATING All vehicle wheels and tires must be the same size and type and tires must be properly inflated to produce accurate signals for the computer. Anti-Lock Brake Warning Light The “Anti-Lock Brake System (ABS) Warning Light” monitors the anti-lock brake system. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds.
Page 272: Anti-Lock Brake System (Abs)
An additional electronic brake control feature called Hill Start Assist (HSA) is standard on manual transmission models. Anti-Lock Brake System (ABS) This system aids the driver in maintaining vehicle control under adverse braking conditions by controlling hydrau- lic brake pressure. This prevents wheel lock-up to help avoid skidding on slippery surfaces during braking.
Page 273: Brake Assist System (Bas)
272 STARTING AND OPERATING A feature of the TCS system functions similar to a limited-slip differential and controls the wheel spin across a driven axle. If one wheel on a driven axle is spinning faster than the other, the system will apply the brake of the spinning wheel.
Page 274: Hill Start Assist (Hsa) - Manual Transmission Only
Hill Start Assist (HSA) – Manual Transmission Only The HSA system is designed to assist the driver when starting a vehicle from a stop on a hill. HSA will maintain the level of brake pressure the driver applied for a short period of time after the driver takes their foot off of the brake pedal.
Page 275: Electronic Stability Program (Esp)
274 STARTING AND OPERATING For vehicles not equipped with the EVIC, perform the following steps: NOTE: You must complete Steps 1 through 8 within 90 seconds. 1. Center the steering wheel (front wheels pointing straight forward). 2. Shift the transmission into NEUTRAL. 3.
Page 276 The ESP uses sensors in the vehicle to determine the path that the driver intends to steer the vehicle and compares it to the actual path of the vehicle. When the actual path does not match the intended path, the ESP applies the brake of the appropriate wheel to assist in counteracting the condition of oversteer or understeer.
Page 277 276 STARTING AND OPERATING The ESP system has three available operating modes: ESP On This is the normal operating mode for the ESP. Whenever the vehicle is started, the ESP system will be in this mode. This mode should be used for most driving situations. The ESP should only be turned OFF for specific reasons as noted in the following paragraphs.
Page 278 sand, or gravel, it may be desirable to switch to the “Partial Off” mode by momentarily pressing the “ESP OFF” switch. Once the situation requiring “Partial Off” mode is overcome, turn the ESP ON again by momen- tarily pressing the “ESP OFF” switch. This may be done while the vehicle is in motion.
Page 279: Synchronizing Esp
278 STARTING AND OPERATING across an axle quite similarly to a limited slip differential. If one wheel on an axle is spinning faster than the other, the system will apply the brake of the spinning wheel and allow more engine torque to be applied to the wheel that is not spinning.
Page 280: Esp/Bas Malfunction Indicator Light And Esp/Tcs Indicator Light
ESP/BAS Malfunction Indicator Light and ESP/TCS Indicator Light The Malfunction Indicator Light for the ESP is combined with the BAS indicator. The “ESP/ BAS Malfunction Indicator Light” and the “ESP/TCS Indicator Light” in the instrument cluster both come on when the ignition switch is turned to the ON position.
Page 281: Tire Safety Information
280 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings 1 — U.S. DOT Safety Stan- 4 — Maximum Load dards Code (TIN) 2 — Size Designation 5 — Maximum Pressure 3 — Service Description 6 — Treadwear, Traction and Temperature Grades NOTE: •...
Page 282 Tire Sizing Chart Size Designation: P = Passenger Car tire size based on U.S. design standards ...blank... = Passenger Car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%)
Page 283 282 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 284 Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. EXAMPLE: DOT MA L9 ABCD 0301 DOT = Department of Transportation —...
Page 285: Tire Terminology And Definitions
284 STARTING AND OPERATING Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 286: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire and Loading Information Placard STARTING AND OPERATING 285 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry...
Page 287 286 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 288 3. Subtract the combined weight of the driver and pas- sengers from XXX kg or XXX lbs. 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
Page 289 288 STARTING AND OPERATING...
Page 290: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 291: Tire Inflation Pressures
290 STARTING AND OPERATING WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure.
Page 292 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 293: Radial Ply Tires
292 STARTING AND OPERATING loading may be required for high-speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous.
Page 294: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) for more than 30 seconds continu- ously when you are stuck, and do not let anyone near a spinning wheel, no matter what the speed.
Page 295: Life Of Tire
294 STARTING AND OPERATING Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.
Page 296: Tire Chains
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 297: Snow Tires
296 STARTING AND OPERATING CAUTION! Damage to the vehicle may result if tire chains are used. SNOW TIRES Some areas of the country require the use of snow tires during the winter. Standard tires are of the all season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall.
Page 298: Tire Rotation - Four Season/Rsa Tires
Tire Rotation – Four Season/RSA Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram. Tire Rotation STARTING AND OPERATING 297 Tire Rotation – F1 Three Season Tires The suggested rotation method is the “side-to-side” as shown in the following diagram.
Page 299: Tire Pressure Monitor System (Tpms)
298 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure. The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C).
Page 300 For example, your vehicle may have a recommended cold (parked for more than three hours) placard pressure of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), a temperature drop to 20°F (-7°C) will decrease the tire pressure to approximately 23 psi (158 kPa).
Page 301: Premium System
300 STARTING AND OPERATING NOTE: • The TPMS is not intended to replace normal tire care and maintenance or to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure.
Page 302 • Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and • TPM Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “TPM Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires.
Page 303 302 STARTING AND OPERATING Should this occur, you should stop as soon as possible and inflate all of the tires with a low pressure condition (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure inflation value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the “TPM Telltale Light”...
Page 304: General Information
If the ignition switch is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the “TPM Telltale Light” will no longer flash, and the CHECK TPM SYSTEM message will no longer display, and a pressure value will display in place of the dashes.
Page 305: Fuel Requirements
304 STARTING AND OPERATING FUEL REQUIREMENTS 6.1L Engine The 6.1L engine is designed to meet all emissions regulations and provide excel- lent fuel economy and performance when using high-quality premium unleaded gasoline with an octane rating of 91 or higher. Light spark knock at low engine speeds is not harmful to your engine.
Page 306: Gasoline/Oxygenate Blends
Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with oxy- genates such as 10% ethanol, MTBE, and ETBE. Oxygen- ates are required in some areas of the country during the winter months to reduce carbon monoxide emissions. Fuels blended with these oxygenates may be used in your vehicle.
Page 307: Mmt In Gasoline
306 STARTING AND OPERATING • disconnect and reconnect the battery to reset the engine controller memory More extensive repairs will be required for prolonged exposure to E-85 fuel. MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane. Gasoline blended with MMT provides no performance advantage beyond gasoline of the same octane number without MMT.
Page 308: Carbon Monoxide Warnings
CAUTION! (Continued) • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine perfor- mance and damage the emissions control system. • An out-of-tune engine or certain fuel or ignition malfunctions can cause the catalytic converter to overheat.
Page 309: Adding Fuel
308 STARTING AND OPERATING WARNING! (Continued) • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas, which can kill. Never run the engine in a closed area, such as a garage, and never sit in a parked vehicle with the engine running for an extended period.
Page 310 NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door. CAUTION! • Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap (gas cap). •...
Page 311: Loose Fuel Filler Cap Message
310 STARTING AND OPERATING • When the fuel nozzle “clicks” or shuts off, the fuel tank is full. Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap”...
Page 312: Gross Vehicle Weight Rating (Gvwr)
• Gross Axle Weight Rating (GAWR) rear • Vehicle Identification Number (VIN) • Type of Vehicle • Month Day and Hour of Manufacture (MDH) The bar code allows a computer scanner to read the VIN. Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle.
Page 313: Overloading
312 STARTING AND OPERATING Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory service as long as you do not exceed the GVWR and the front and rear GAWR. The best way to figure out the total weight of your vehicle is to weigh it when it is fully loaded and ready for operation.
Page 314: Recreational Towing (Behind Motorhome, Etc.)
RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Recreational towing is allowed ONLY if the driveshaft is removed. Towing with the rear wheels on the ground while the driveshaft is connected can result in severe transmission damage. WARNING! If the driveshaft is removed, the vehicle can roll even if the transmission is in PARK, which could cause serious injury or death.
Page 316: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....316 If Your Engine Overheats ....316 TIREFIT Kit .
Page 317: Hazard Warning Flasher
316 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located in the switch bank near the bottom center of the instrument panel. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 318: Tirefit Kit
CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116 °C) or greater pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range 200– 230°F (93–110°C).
Page 319: Tirefit Storage
318 WHAT TO DO IN EMERGENCIES This kit will provide a temporary tire seal, allowing you to drive your vehicle up to 100 miles (160 km) with a maximum speed of 55 mph (88 km/hr). TIREFIT Storage The TIREFIT kit is located in the trunk. TIREFIT Location TIREFIT Kit Components and Operation 1.
Page 320: Tirefit Usage Precautions
5. Power Plug and Cable 6. Air Pump Hose (Black) 7. Sealant Hose (Clear with Yellow Cap) 8. Accessory Storage Compartment Using the Mode Select Knob and Hoses Selecting Air Mode Turn the Mode Select knob (4) to this position for air pump operation only.
Page 321 320 WHAT TO DO IN EMERGENCIES the vehicle or tire and wheel components. Once the sealant dries, it can easily be peeled off and properly discarded. • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the TIREFIT kit.
Page 322 WARNING! (Continued) − If you are unsure of the condition of the tire or the wheel. • Keep TIREFIT away from open flame or heat source. • A loose TIREFIT kit thrown forward in a collision or hard stop could endanger the occupants of the vehicle.
Page 323: Sealing A Tire With Tirefit
322 WHAT TO DO IN EMERGENCIES Sealing a Tire with TIREFIT (A) Whenever You Stop to Use TIREFIT: 1. Pull over to a safe location and turn ON the vehicle’s Hazard Warning flashers. 2. Verify that the valve stem (on the wheel with the deflated tire) is in a position that is near to the ground.
Page 324 (C) Injecting TIREFIT Sealant into the deflated tire: • Always start the engine before turning ON the TIRE- FIT kit. NOTE: Manual transmission vehicles must have the parking brake engaged and the shifter in NEUTRAL. • After pressing the Power Button (3), the sealant (white fluid) will flow from the Sealant Bottle (1) through the Sealant Hose (7) and into the tire.
Page 325 324 WHAT TO DO IN EMERGENCIES If the sealant (white fluid) does flow through the clear Sealant Hose (7): 1. Continue to operate pump until sealant is no longer flowing through hose (typically takes 30 - 70 seconds). As the sealant flows through hose (7), the pressure gauge (2) can read as high as 70 psi (5 Bar).
Page 326 CAUTION! • The metal end fitting from Power Plug and Cable (5) may get hot after use, so should be handled carefully. • Failure to reinstall the Yellow Cap on the fitting at the end of the Clear Sealant Hose (7) can result in sealant contacting your skin, clothing, and the vehicle’s interior.
Page 327 326 WHAT TO DO IN EMERGENCIES If tire pressure is less than 19 psi (1.3 Bar) , the tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance. If the tire pressure is 19 psi (1.3 bar) or higher: 1.
Page 328: Jump-Starting Procedures
4. Clean any remaining sealant from the TIREFIT hous- ing. 5. Position the new Sealant Bottle (1) to the housing so that the Clear Sealant Hose (7) aligns with the hose slot in the front of the housing and the alignment keys on the bottom of the bottle align with the alignment slots in the housing.
Page 329: Preparations For Jump-Start
328 WHAT TO DO IN EMERGENCIES WARNING! When temperatures are below the freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump-starting because the battery could rup- ture or explode and cause personal injury. Battery temperature must be brought above freezing point before attempting a jump-start.
Page 330: Jump-Starting Procedure
WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be injured by moving fan blades. • Remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact.
Page 331 330 WHAT TO DO IN EMERGENCIES CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle. 1. Connect the positive (+) end of the jumper cable to the remote positive (+) post of the discharged vehicle.
Page 332: Freeing A Stuck Vehicle
8. Disconnect the opposite end of the positive (+) jumper cable from the positive (+) post of the booster battery. 9. Disconnect the positive (+) end of the jumper cable from the remote positive (+) post of the discharged vehicle. If frequent jump-starting is required to start your vehicle you should have the battery and charging system in- spected at your authorized dealer.
Page 333: Towing A Disabled Vehicle
332 WHAT TO DO IN EMERGENCIES CAUTION! • When “rocking” a stuck vehicle by moving be- tween “1st” and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Revving the engine or spinning the wheels too fast may lead to transmission overheating and failure.
Page 334: Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground)
Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) Flat towing of vehicles is permitted within the following limitations: With The Key Fob Your vehicle may be towed under the following condi- tions: • The shift lever must be in NEUTRAL •...
Page 335: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
334 WHAT TO DO IN EMERGENCIES CAUTION! • Do not attempt to tow this vehicle from the front with sling-type towing equipment. Damage to the front fascia will result. • If the transmission is not operative or if the vehicle is to be towed more than 15 miles (24 km) or faster than 30 mph (48 kph), then the only approved method of towing is with a flatbed truck.
Page 336 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 6.1L ... . . 338 Onboard Diagnostic System — OBD II ..339 Loose Fuel Filler Cap ....339 Emissions Inspection And Maintenance Programs .
Page 337 336 MAINTAINING YOUR VEHICLE Brake System ..... . . 359 Clutch Hydraulic System (Manual Transmission) – If Equipped ..361 Manual Transmission –...
Page 338 Center High-Mounted Stop Lamp (CHMSL) ..... 381 License Lamp ..... . . 381 Fluid Capacities .
Page 339: Engine Compartment - 6.1L
338 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 6.1L 1 — Remote Jump Start (Positive Battery Post) 2 — Integrated Power Module 3 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Access Cover 5 — Engine Coolant Reservoir 6 — Power Steering Fluid Reservoir 7 —...
Page 340: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 341: Emissions Inspection And Maintenance Programs
340 MAINTAINING YOUR VEHICLE Trip Odometer button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the MIL. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...
Page 342: Replacement Parts
5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition key or start the engine. This means that the vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 343: Dealer Service
342 MAINTAINING YOUR VEHICLE DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these service manuals before attempting any procedure yourself.
Page 344: Engine Oil
CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
Page 345 344 MAINTAINING YOUR VEHICLE NOTE: Under no circumstances should oil change intervals exceed 6,000 miles (10 000 km) or six months, whichever occurs first. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the requirements of Chrysler Material Standard MS-10725 and are approved to MB 229.3 or MB 229.5 (will be listed...
Page 346: Engine Oil Filter
environment. Contact your authorized dealer, service station, or governmental agency for advice on how and where used oil and oil filters can be safely discarded in your area. Engine Oil Filter The engine oil filter should be replaced at every engine oil change.
Page 347: Maintenance-Free Battery
346 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter Selection The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be used to assure most efficient service. MOPAR engine air cleaner filters are a high quality filter and are recommended.
Page 348 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 349: Air Conditioner Maintenance
348 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test.
Page 350: Body Lubrication
Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 351: Adding Washer Fluid
350 MAINTAINING YOUR VEHICLE Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades. Always use washer fluid when using the wipers to remove salt or dirt from a dry windshield. Avoid using the wiper blades to remove frost or ice from the windshield.
Page 352: Exhaust System
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 353 352 MAINTAINING YOUR VEHICLE CAUTION! The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effective- ness of the catalyst as an emissions control device and may seriously reduce engine performance and cause serious damage to the engine. Under normal operating conditions, the catalytic con- verter will not require maintenance.
Page 354 WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
Page 355: Cooling System
354 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position (OFF position for Keyless Go™). The fan is temperature controlled and can start at any time the ignition switch is in the ON position (RUN position for Keyless Go™).
Page 356 drain from the coolant recovery bottle. DO NOT RE- MOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. Cooling System – Drain, Flush, and Refill If the solution is dirty or contains a considerable amount of sediment, clean and flush with a reliable cooling system cleaner.
Page 357 356 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to five years or 102,000 miles (170 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
Page 358 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated.
Page 359 358 MAINTAINING YOUR VEHICLE When additional coolant is needed to maintain the proper level, it should be added to the coolant bottle. Do not overfill. Points to Remember NOTE: When the vehicle is stopped after a few miles (kilometers) of operation, you may observe vapor coming from the front of the engine compartment.
Page 360: Brake System
• Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install ONLY the correct type thermostat. Other designs may result in unsatisfactory coolant performance, poor gas mileage, and increased emissions. Brake System In order to assure brake system performance, all brake system components should be inspected periodically.
Page 361 360 MAINTAINING YOUR VEHICLE Use only manufacturer’s recommended brake fluid. Re- fer to “Fluids, Lubricants, and Genuine Parts” in “Main- taining Your Vehicle” for further information. WARNING! • Use only manufacturer’s recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts”...
Page 362: Clutch Hydraulic System (Manual Transmission) - If Equipped
WARNING! (Continued) • Do not allow petroleum based fluid to contami- nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure. This could result in an accident. Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter or moisture.
Page 363 362 MAINTAINING YOUR VEHICLE If you notice fluid loss or gear shift malfunction, have your authorized dealer check the transmission fluid level. CAUTION! • Using a transmission fluid other than the manu- facturer’s recommended fluid may cause deterio- ration in transmission shift quality and/or torque converter shudder.
Page 364: Rear Axle
Parts” in “Maintaining Your Vehicle” for further informa- tion. It is important that the transmission fluid be main- tained at the prescribed level using the recommended fluid. No chemical flushes should be used in any trans- mission; only the approved lubricant may be used. Special Additives Automatic Transmission Fluid (ATF) is an engineered product and its performance may be impaired by supple-...
Page 365: Appearance Care And Protection From Corrosion
364 MAINTAINING YOUR VEHICLE Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and chemicals that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 366 • Use a high quality cleaner wax, such as MOPAR Cleaner Wax or equivalent to remove road film, stains and to protect your paint finish. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 367 366 MAINTAINING YOUR VEHICLE • Use MOPAR Touch Up Paint or equivalent on scratches as soon as possible. Your authorized dealer has touch up paint to match the color of your vehicle. Wheel and Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome-plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
Page 368 Interior Care Use MOPAR Fabric Cleaner or equivalent to clean fabric upholstery and MOPAR Carpet Cleaner or equivalent for carpeting. Interior Trim should be cleaned starting with a damp cloth, or MOPAR Satin Select or equivalent. Do not use harsh cleaners or Armor All . Use MOPAR Total Clean or equivalent to clean vinyl upholstery.
Page 369 368 MAINTAINING YOUR VEHICLE Do not use abrasive cleaning components, solvents, steel wool or other aggressive material to clean the lenses. Glass Surfaces All glass surfaces should be cleaned on a regular basis with MOPAR Glass Cleaner or any commercial household-type glass cleaner.
Page 370: Fuses
NOTE: The cupholder cannot be removed. FUSES Integrated Power Module (IPM) The Integrated Power Module (IPM) is located in the engine compartment. This module contains fuses and relays. Integrated Power Module MAINTAINING YOUR VEHICLE 369 CAUTION! • When installing the integrated power module cover, it is important to ensure the cover is prop- erly positioned and fully latched.
Page 371 370 MAINTAINING YOUR VEHICLE Cav- Cartridge Mini- Description Fuse Fuse — 15 Amp Washer Motor Blue — 25 Amp Powertrain Control Natural Module (PCM) — 25 Amp Ignition Run/Start Natural — 25 Amp EGR Solenoid/ Natural Alternator — — — —...
Page 372: Rear Power Distribution Center
MAINTAINING YOUR VEHICLE 371 Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Access Panel...
Page 373 372 MAINTAINING YOUR VEHICLE CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 374 Cav- Cartridge Mini- Description Fuse Fuse — 20 Amp Fuel Pump Yellow — 15 Amp Sub Amp – If Equipped Blue — 15 Amp Diagnostic Link Connec- Blue tor (DLC)/Wireless Con- trol Module (WCM)/ Wireless Ignition Node (WIN) — 20 Amp Power Outlet Yellow —...
Page 375 374 MAINTAINING YOUR VEHICLE Cav- Cartridge Mini- Description Fuse Fuse — — — — — — — 10 Amp Occupant Restraint Controller (ORC) — 10 Amp Ignition Run, AC Heater Control/Occupant Re- straint Controller (ORC) — 5 Amp Cluster/Electronic Stabil- Orange ity Program (ESP)/ Powertrain Control Mod-...
Page 376: Vehicle Storage
Cav- Cartridge Mini- Description Fuse Fuse — 5 Amp Auto Inside Rearview Orange Mirror/Heated Seats – If Equipped/Switch Bank — — — 30 Amp — Front Blower Motor Pink 30 Amp — Rear Window Defroster Pink 20 Amp — Amplifier/Sunroof – Blue If Equipped * Cavities 11, 12, and 13 contain self-resetting fuses...
Page 377: Replacement Bulbs
376 MAINTAINING YOUR VEHICLE REPLACEMENT BULBS LIGHT BULBS – Interior Rear Courtesy/Reading Lamps ... . . W5W Rear Compartment (Trunk) Lamp ... . . 562 Overhead Console Reading Lamps .
Page 378: Bulb Replacement
BULB REPLACEMENT Low Beam Headlamp, High Beam Headlamp, Park/Turn Lamp — Models with Halogen Headlamps — If Equipped See your authorized dealer for bulb replacement. Low Beam Headlamp, High Beam Headlamp, and Park/Turn Lamp — Models with High Intensity Discharge (HID) Headlamps — If Equipped HID Headlamps The headlamps are a type of high voltage discharge tube.
Page 379: Front/Rear Side Marker Lamp
378 MAINTAINING YOUR VEHICLE Front/Rear Side Marker Lamp 1. Remove the front/rear side marker. Use a fiber stick or similar tool to gently pry the lamp on the outboard side to disengage the clip. NOTE: • If a screwdriver is used, make sure a soft material is placed between the vehicle body and tool so not to scratch the paint.
Page 380 3. Remove the fasteners from the back of the tail lamp assembly. 4. Pull back the trunk liner. 5. Remove the remaining fasteners from the back of the tail lamp assembly. MAINTAINING YOUR VEHICLE 379 6. Pull the tail lamp assembly clear from the vehicle to access the bulbs.
Page 381 380 MAINTAINING YOUR VEHICLE 8. Disconnect the electrical connector. 9. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the tail lamp assembly. 10. Disconnect the bulb from the socket assembly and install the replacement bulb. 11.
Page 382: Center Tail/Backup Lamp
Center Tail/Backup Lamp See your authorized dealer for bulb replacement. Center High-Mounted Stop Lamp (CHMSL) The CHMSL uses LED lamps that are not serviceable separately. The CHMSL must be replaced as an assembly, see your authorized dealer. License Lamp 1. Remove the screws securing the lamp to the rear fascia.
Page 383 382 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 6.1 Liter Engine (SAE 5W-40, API Certified) Cooling System * 6.1 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level. U.S.
Page 384 FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. For best performance and maximum protection under all types of operat- ing conditions, the manufacturer only recommends full synthetic engine oils that meet the requirements of Chrysler Material Standard MS-10725 and are approved to MB 229.3 or MB 229.5.
Page 385 384 MAINTAINING YOUR VEHICLE Chassis Component Manual Transmission – If Equipped MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Automatic Transmission – If Equipped Brake Master Cylinder Power Steering Reservoir Rear Axle Fluid, Lubricant, or Genuine Part ATF+4 product. MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product.
Page 386 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance Maintenance Schedule ....386 Required Maintenance Intervals ..388 .
Page 387 386 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type, must be done at the times or mileages specified to ensure the continued proper functioning of the Emission Control System. These, and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 388 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicle’s oil if it has been six months since your last oil change, even if the oil change indicator message is NOT illuminated.
Page 389 388 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery, and clean and tighten the terminals as required. • Check the fluid levels of the coolant reservoir, brake master cylinder, and power steering, and add as needed.
Page 390 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule ❏...
Page 391: Service Schedule
390 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule ❏...
Page 392 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
Page 393 392 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer Date...
Page 394 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. ❏...
Page 395 394 MAINTENANCE SCHEDULES 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule ❏...
Page 396 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule ❏...
Page 397 396 MAINTENANCE SCHEDULES 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule ❏...
Page 398 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Inspect and replace the PCV Valve if necessary.* ❏ Inspect the rear axle fluid. ❏...
Page 399 398 MAINTENANCE SCHEDULES 102,000 Miles (170,000 km) or 102 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the spark plugs. ❏ Flush and replace the engine coolant if not done at 60 months. Odometer Reading Repair Order # Dealer Code...
Page 400 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏...
Page 401 400 MAINTENANCE SCHEDULES 126,000 Miles (210,000 km) or 126 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Inspect the rear axle fluid. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule ❏...
Page 402 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer MAINTENANCE SCHEDULES 401...
Page 403 402 MAINTENANCE SCHEDULES 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ If you are using your vehicle in dusty or off-road conditions, inspect the engine air cleaner filter, and replace if necessary. ❏...
Page 404 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Adjust parking brake on vehicles equipped with four-wheel disc brakes. Odometer Reading Date Repair Order #...
Page 405 404 MAINTENANCE SCHEDULES * This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 406: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......407 Prepare For The Appointment .
Page 407 406 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......413 Treadwear ......413 Traction Grades .
Page 408: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 409: Chrysler Llc Customer Center
408 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 410: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 411: Warranty Information (U.s. Vehicles Only)
410 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service contract that is not the manufacturer’s Service Contract. It is not responsible for any service contract other than the manufacturer’s Service Contract. If you purchased a service contract that is not a manufacturer’s Service Contract, and you require service after the manufactur- er’s New Vehicle Limited Warranty expires, please refer...
Page 412: Mopar Parts
MOPAR PARTS MOPAR fluids, lubricants, parts, and accessories are available from an authorized dealer. They are recom- mended for your vehicle in order to help keep the vehicle operating at its best. REPORTING SAFETY DEFECTS In The 50 United States And Washington, D.C. If you believe that your vehicle has a defect that could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety...
Page 413: Publication Order Forms
412 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 414: Department Of Transportation Uniform Tire
Call toll free at: • 1–800–890–4038 (U.S.) • 1–800–387–1143 (Canada) Visit us on the Worldwide Web at: • www.techauthority.com DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 415: Temperature Grades
414 IF YOU NEED CONSUMER ASSISTANCE WARNING! The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics. Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory...
Page 416 INDEX...
Page 417 416 INDEX About Your Brakes ....264,267 ABS (Anti-Lock Brake System) ... . 267,271 Adding Engine Coolant (Antifreeze) .
Page 418 Automatic Headlights ....124 Automatic Transaxle Special Additives ..... . 363 Automatic Transmission .
Page 419 418 INDEX Bulbs, Light ......72,376 Calibration, Compass ..... 180 Capacities, Fluid .
Page 420 Console, Floor ......150 Console, Overhead ..... . . 136 Contract, Service .
Page 421 420 INDEX Door Locks ......28 Door Locks, Automatic ....30 Door Opener, Garage .
Page 422 Oil ......343,382,383 Oil Change Interval ....343 Oil Filler Cap .
Page 423 422 INDEX Fluids ....... . 383 Fluids, Lubricants and Genuine Parts ..383 Fog Lights .
Page 424 GVWR ....... 311 Hands-Free Phone (Uconnect™) ....81 Hazard Driving Through Flowing, Rising, or Shallow Standing Water .
Page 425 424 INDEX Instrument Cluster ....157,158 Instrument Panel and Controls ....156 Instrument Panel Lens Cleaning .
Page 426 Brake Warning ..... 164,267 Bulb Replacement ....376,377 Center Mounted Stop .
Page 427 426 INDEX Tire Pressure Monitoring (TPMS) ..165,298 Traction Control ..... . . 279 Turn Signal .
Page 428 Heated ......79 Outside ......77 Vanity .
Page 429 428 INDEX Overheating, Engine ..... . 316 Owner’s Manual (Operator Manual) ..4,412 Paint Care .
Page 430 Rear Window Defroster ....152 Rear Window Features ....152 Recreational Towing .
Page 431 430 INDEX Child Restraint ....59,60,61,66 Extender ......45 Front Seat .
Page 432 Side Window Demisters (Defrosters) ..230 Signals, Turn ..... . 72,126,160 Slippery Surfaces, Driving On .
Page 433 432 INDEX Tachometer ......158 Telescoping Steering Column ....132 Temperature Gauge, Engine Coolant .
Page 434 Recreational ......313 Towing Assistance ......96 Towing Vehicle Behind a Motor Home .
Page 435 434 INDEX Vehicle Storage ..... . . 230,375 Vehicle Theft Alarm (Security Alarm) ..17 Viscosity, Engine Oil .
Page 436 Chrysler Group LLC 10D492-126-AB Printed in U.S.A. 2nd Edition...
