TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6 INTRODUCTION 5...
Page 7: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Locking Doors With A Key .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sound Horn With Remote Key Lock ..21 Flash Lights With Remote Key Lock/Unlock . . 22 Using The Panic Alarm ....22 Programming Additional Transmitters .
Page 12 Seat Belt Pretensioners — If Equipped ..48 Supplemental Rear Impact Active Head Restraints (AHR) ..... . 48 Enhanced Seat Belt Use Reminder System (BeltAlert ) .
Page 13: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The authorized dealer that sold you your new vehicle has the key code numbers for your vehicle locks. These numbers can be used to order duplicate keys. Ask your authorized dealer for these numbers and keep them in a safe place.
Page 14 Ignition Switch Positions 1 — LOCK 3 — ON 2 — ACC (ACCESSORY) 4 — START NOTE: If you try to remove the key before you place the shift lever in PARK, the key may become trapped tem- porarily in the ignition switch cylinder. If this occurs, rotate the key to the right slightly, then remove the key as THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 described.
Page 15: Locking Doors With A Key
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! An unlocked car is an invitation to thieves. Always remove the key from the ignition and lock all the doors when leaving the vehicle unattended. Locking Doors With A Key You can insert the key with either side up. To lock the door, turn the key to the right.
Page 16: Replacement Keys
seconds for a bulb check. If the light remains on after the bulb check, it indicates that there is a problem with the electronics. In addition, if the Vehicle Security Light begins to flash after the bulb check, it indicates that someone used an invalid key to try to start the engine.
Page 17: Customer Key Programming
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE procedure. This procedure consists of programming a blank key to the vehicle electronics. A blank key is one that has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle keys with you to an authorized dealer.
Page 18: General Information
Repeat this procedure to program up to eight keys. If you do not have a programmed Sentry Key , contact your authorized dealer for details. NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory.
Page 19: To Set The Security Alarm
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Set The Security Alarm 1. Remove the key from the ignition switch and get out of the vehicle. 2. Lock the door using either the power door LOCK switch or the Remote Keyless Entry (RKE) transmitter and close all doors.
Page 20: To Unlock The Doors And Liftgate
Three Button RKE Transmitter NOTE: The line of transmission must not be blocked with metal objects. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 To Unlock The Doors And Liftgate Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors and liftgate.
Page 21: Illuminated Approach - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the following steps: 1. Press and hold the LOCK button on a programmed RKE transmitter for at least 4 seconds, but no longer than 10 seconds.
Page 22: To Lock The Doors And Liftgate
To Lock The Doors And Liftgate Press and release the LOCK button on the RKE transmit- ter to lock all doors and liftgate. The turn signal lights will flash and the horn will chirp to acknowledge the signal. Sound Horn With Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter.
Page 23: Flash Lights With Remote Key Lock/Unlock
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lights With Remote Key Lock/Unlock This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- ter. This feature can be turned on or turned off. To change the current setting, proceed as follows: •...
Page 24: Programming Additional Transmitters
The Panic Alarm will stay on for three minutes unless you turn it off by pressing the PANIC button a second time or if the vehicle speed is 5 mph (8 km/h) or greater. NOTE: When you turn off the Panic Alarm by pressing the PANIC button a second time, you may have to be closer to the vehicle due to the radio frequency noises of the system.
Page 25: Transmitter Battery Replacement
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transmitter Battery Replacement NOTE: Perchlorate Material – special handling may apply. “www.dtsc.ca.gov/hazardouswaste/ perchlorate.” The recommended replacement battery is CR2032. 1. If the RKE transmitter is equipped with a screw, remove the screw. With the RKE transmitter buttons facing down, use a flat blade to pry the two halves of the RKE transmitter apart.
Page 26: Remote Starting System - If Equipped
NOTE: If the RKE transmitter is equipped with a screw, reinstall and tighten the screw until snug. REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conve- niently from outside the vehicle while still maintaining security.
Page 27 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Enter Remote Start Press and release the REMOTE START button on the RKE transmitter twice, within five sec- onds. The parking lights will flash and the horn will chirp twice (if programmed). Then, the engine will start and the vehicle will remain in the Remote Start mode for a 15-minute cycle.
Page 28: Door Locks
To Exit Remote Start Mode and Drive the Vehicle Before the end of the 15-minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm (if equipped). Then, insert the key into the ignition switch and turn the switch to the ON position.
Page 29: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • When leaving the vehicle, always remove the key from the ignition lock and lock your vehicle. Do not leave unattended children in the vehicle or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe per- sonal injuries and death.
Page 30 Automatic Door Locks — If Equipped The doors will lock automatically on vehicles with power door locks if all of the following conditions are met: 1. The Auto Lock feature is enabled. 2. The transmission is in gear. 3. All doors are closed. 4.
Page 31 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: • If you do not hear the chime it means that the system did not enter the programming mode and you will need to repeat the procedure.
Page 32: Child-Protection Door Lock System (Rear Doors) - If Equipped
3. ‘Within 30 seconds, press the power door UNLOCK switch to unlock the doors. 4. A single chime will indicate the completion of the programming. 5. Repeat these steps if you want to return this feature to its previous setting. NOTE: •...
Page 33: Power Windows - If Equipped
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child-Protection Door Lock Function WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged.
Page 34: Auto-Down
• For vehicles equipped with the EVIC, the power window switches will remain active for up to 10 min- utes after the ignition switch is turned to the LOCK position. Opening either front door will cancel this feature. The time for this feature is programmable. Refer to “Electronic Vehicle Information Center (EVIC)/Personal Settings (Customer-Programmable Features)”...
Page 35: Window Lockout Switch
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window Lockout Switch The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window LOCKOUT switch.
Page 36 Liftgate Handle NOTE: • In the event of a power malfunction, or the RKE transmitter is inoperative, insert the key into the liftgate lock cylinder and turn it to the right (manual lock models only). Using the liftgate handle, pull the liftgate open with one fluid motion.
Page 37: Occupant Restraints
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Gas props support the liftgate in the open position. However, because the gas pressure drops with tempera- ture, it may be necessary to assist the props when opening the liftgate in cold weather. OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems:...
Page 38 If you will be carrying children too small for adult-sized seat belts, the seat belts or the Lower Anchors and Tether for CHildren (LATCH) feature also can be used to hold infant and child restraint systems. For more information on LATCH, see Lower Anchors and Tether for CHildren (LATCH).
Page 39: Lap/Shoulder Belts
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle.
Page 40 WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in a collision much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instructions to wear your seat belt safely and to keep your pas- sengers safe, too.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Inserting Latch Plate into Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 42 WARNING! (Continued) • A belt that is worn under your arm is very danger- ous. Your body could strike the inside surfaces of the vehicle in a collision, increasing head and neck injury. A belt worn under the arm can cause internal injuries.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen.
Page 44: Adjustable Upper Shoulder Belt Anchorage
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 Adjustable Upper Shoulder Belt Anchorage In the front seat, the shoulder belt can be adjusted upward or downward to position the belt away from your neck. Push the anchorage button to release the anchorage, and move it up or down to the position that fits you best.
Page 45: Second Row Center Lap/Shoulder Belt Operating Instructions
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you will prefer a higher position. When you release the anchorage, try to move it down to make sure that it is locked in position.
Page 46 3. Route the shoulder belt to the inside of the right head restraint. Routing the Rear Center Shoulder Belt 4. When the belt is long enough to fit, insert the mini- latch plate into the mini-buckle until you hear a “click.” THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 5.
Page 47 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 7. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, pull on the lap belt.
Page 48: Lap/Shoulder Belt Untwisting Procedure
10. To disengage the mini-latch from the mini-buckle for storage, insert the regular latch plate into the black button on the top of the mini-buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully.
Page 49: Seat Belt Pretensioners - If Equipped
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Use The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 50 How the Active Head Restraints (AHR) Work The Occupant Restraint Controller (ORC) determines whether the severity, or type of rear impact, will require the Active Head Restraints (AHR) to deploy. If a rear impact requires deployment, both the driver and front passenger seat AHRs will be deployed.
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head restraints are placed in their proper positions in order to minimize the risk of neck injury in the event of an accident.
Page 52 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism. 1 — Downward Movement 2 — Rearward Movement THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 3 — Final Downward Movement To Engage Locking Mecha- nism...
Page 53: Enhanced Seat Belt Use Reminder System (Beltalert )
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. AHR In Reset Position NOTE: • If you have difficulties or problems resetting the head restraints, see an authorized dealer.
Page 54: Seat Belt Extender
BeltAlert Programming BeltAlert can be enabled or disabled by your authorized dealer or by performing the following procedure: NOTE: The following steps must occur within the first 60 seconds of the ignition switch being turned to the ON or START position. Chrysler Group LLC does not recom- mend deactivating BeltAlert .
Page 55: Seat Belts And Pregnant Women
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 56 Airbag and Knee Bolster Location 1 — Driver and Passenger Air- 3 — Knee Bolster bags 2 — Driver Knee Airbag NOTE: These airbags are certified to the new Federal regulations for Advanced Airbags. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The Advanced Front Airbags have a multistage inflator design.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag System Components The Advanced Airbag system consists of the following: • Occupant Restraint Controller (ORC) • Front and Side Impact Sensors — If Equipped • Airbag Warning Light • Driver Front Airbag •...
Page 58: Advanced Front Airbag Features
Advanced Front Airbag Features The Advanced Front Airbag system has multistage driver and front passenger airbags. This system provides output appropriate to the severity and type of collision as determined by the Occupant Restraint Controller (ORC), which may receive information from the front impact sensors.
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Airbags — If Equipped Supplemental seat-mounted side airbags provide en- hanced protection and work together with supplemental Side Airbag Inflatable Curtains (SABIC) to help protect an occupant during a side impact. The supplemental side seat airbag is marked with an airbag label sewn into the outboard side of the seat.
Page 60 Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped SABIC airbags may offer side-impact and vehicle rollover protection to front and rear seat outboard occupants in addition to that provided by the body structure. Each airbag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side-impact head injuries.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Airbag covers may not be obvious in the interior trim; but they will open during airbag deployment. The system includes side impact sensors adjacent to both front and rear seat occupants that are calibrated to deploy the SABIC airbags during impacts that require airbag occupant protection.
Page 62 Here are some simple steps you can take to minimize the risk of harm from a deploying airbag: 1. Children 12 years old and younger should always ride buckled up in a rear seat. WARNING! Infants in rear facing child restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag.
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Do not lean against the door. If your vehicle has side airbags, and deployment occurs, the side airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center.
Page 64: Airbag Deployment Sensors And Controls
Airbag Deployment Sensors and Controls Occupant Restraint Controller (ORC) The ORC is part of a Federally regulated safety system required for this vehicle. The ORC determines if deployment of the front and/or side airbags in a frontal or side collision is required. Based on the impact sensors signals, a central electronic ORC deploys the Advanced Front Airbags, Supplemental Driver Side Knee Airbag, SABIC airbags —...
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The ORC monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON position. If the key is in the OFF position, in the ACC position, or not in the ignition, the airbag system is not on and the airbags will not inflate.
Page 66 the Advanced Front Airbags. Different airbag inflation rates are possible, based on the collision type and sever- ity. The steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as the bags inflate to their full size. The bags fully inflate in about 50 to 70 milliseconds.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Based on the severity and type of collision, the side airbag inflator on the crash side of the vehicle may be triggered, releasing a quantity of non-toxic gas. The inflating side airbag exits through the seat seam into the space between the occupant and the door.
Page 68 events. Additional sensors in the ORC determine the level of airbag deployment and provide verification. Enhanced Accident Response System In the event of an impact causing airbag deployment, if the communication network remains intact, and the power remains intact, depending on the nature of the event the ORC will determine whether to have the Enhanced Accident Response System perform the follow- ing functions:...
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • As the airbags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the non-toxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat.
Page 70 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 71: Event Data Recorder (Edr)
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. While the airbag system is designed to be mainte- nance free, if any of the following occurs, have an authorized dealer service the system immediately.
Page 72 2. Under certain circumstances, EDR data may not be recorded (e.g., loss of battery power). In conjunction with other data gathered during a com- plete accident investigation, the electronic data may be used by Chrysler Group LLC and others to learn more about the possible causes of crashes and associated injuries in order to assess and improve vehicle perfor- mance.
Page 73: Child Restraints
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Requested by police under a legal warrant. 4. Otherwise required by law. Data parameters that are recorded: • Diagnostic trouble code(s) and warning light status for electronically-controlled safety systems, including the airbag system •...
Page 74 Infants and Child Restraints There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Always check the child seat owner’s manual to ensure you have the correct seat for your child.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE in the vehicle by the lap/shoulder belt or the LATCH child restraint anchorage system. Refer to LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren) . • The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
Page 76 that you can install the child restraint in the vehicle where you will use it, before you buy it. • The restraint must be appropriate for your child’s weight and height. Check the label on the restraint for weight and height limits. •...
Page 77 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary. • In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint.
Page 78 Automatic Locking Retractor (ALR) To operate the switchable retractor, pull the belt from the retractor until there is enough to allow you to pass through the child restraint and slide the latch plate into the buckle. Then pull on the belt until it is completely extended from the retractor.
Page 79 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH-compatible child seats having flexible, webbing- mounted lower attachments. Child seats with fixed lower attachments must be installed in the outboard positions only. Regardless of the specific type of lower attachment, NEVER install LATCH-compatible child seats such that two seats share a common lower anchorage.
Page 80 provide add-on tether strap kits for some of their older products. Tether anchorage kits are also available for most older vehicles. Because the lower anchorages are to be introduced to passenger carrying vehicles over a period of years, child restraint systems having attachments for those anchor- ages will continue to have features for installation in vehicles using the lap or lap/shoulder belt.
Page 81 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In general, you will first loosen the adjusters on the lower and tether straps so that you can more easily attach the hook or connector to the lower and tether anchorages. The tether strap should be routed over the center of the head restraint and attached to the tether anchor on the rear of the seat back.
Page 82: Engine Break-In Recommendations
WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor position directly behind the child seat to secure a child restraint top tether strap. Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or could injure a passenger during panic braking or in a collision.
Page 83: Safety Tips
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not inter- preted as an indication of difficulty. SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO...
Page 84: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 85: Safety Checks You Should Make Inside The Vehicle
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside the Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays, and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Front seat belt assemblies must be replaced after a collision.
Page 86 WARNING! Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious per- sonal injury. • Always make sure that floor mats are properly attached to the floor mat fasteners. • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the...
Page 87: Periodic Safety Checks You Should Make Outside The Vehicle
86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 88: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......91 Inside Day/Night Mirror ....91 Automatic Dimming Mirror —...
Page 89 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command System Operation ..123 Commands ......125 Voice Training .
Page 90 Windshield Wipers And Washers ..147 Windshield Wiper Operation ... . 147 Intermittent Wiper System ....148 Windshield Washers .
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pinch Protect Override ....163 Venting Sunroof — Express ... . . 163 Sunshade Operation .
Page 92: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical mirror adjustment. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of vehicle).
Page 93: Automatic Dimming Mirror - If Equipped
92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 94: Power Mirrors - If Equipped
WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in this convex mirror.
Page 95: Heated Mirrors - If Equipped
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To adjust a mirror, turn the control wand toward the left or right mirror positions indicated. Tilt the control wand in the direction you want the mirror to move. When finished adjusting the mirror, turn the control to the center position to prevent accidentally moving a mirror.
Page 96: Vanity Mirrors - If Equipped
Uconnect™ Phone. NOTE: The Uconnect™ Phone requires a cellular phone equipped with the Bluetooth Hands-Free Profile, Ver- sion 0.96 or higher. See the Uconnect™ website for supported phones. For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect...
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • www.jeep.com/uconnect • or call 1–877–855–8400 Uconnect™ Phone allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation.
Page 98: Operation
Voice Command Button Actual button location may vary with the ra- dio. The individual buttons are described in the “Operation” section. The Uconnect™ Phone can be used with any Hands-Free Profile certified Bluetooth cellular phone. See the Uconnect™ website for supported phones. If your cellu- lar phone supports a different profile (e.g., Headset Profile) you may not be able to use any Uconnect™...
Page 99 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command when you are asked for it. For example, you can use the combined form voice com- mand Phonebook New Entry, or you can break the combined form command into two voice commands:...
Page 100 The following are general phone to Uconnect™ Phone pairing instructions: • Press the button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing. • When prompted, after the beep, say Pair a Phone and follow the audible prompts.
Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will prompt you to say the number you want to call. • For example, you can say 234-567-8901 . • The Uconnect™ Phone will confirm the phone number and then dial. The number will appear in the display of certain radios.
Page 102 • When prompted, enter the number designation (e.g., Home, Work, Mobile, or Pager ). This will allow you to store multiple numbers for each phonebook entry, if desired. • When prompted, recite the phone number for the phonebook entry that you are adding. After you are finished adding an entry into the phone- book, you will be given the opportunity to add more phone numbers to the current entry or to return to the...
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Depending on the maximum number of entries down- loaded, there may be a short delay before the latest downloaded names can be used. Until then, if avail- able, the previous downloaded phonebook is available for use.
Page 104 first disconnect or drop the Bluetooth connection to the Uconnect™ Phone, and then send the address book entry via Bluetooth . Please see your phone Owner’s Manual for specific instructions on how to drop the Bluetooth connection. • If the phonebook entry is longer than 24 characters, it will only use the first 24 characters.
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete Uconnect™ Phonebook Entry NOTE: Editing phonebook entries is recommended when the vehicle is not in motion. • Press the button to begin. • After the Ready prompt and the following beep, say Phonebook Delete.
Page 106: Phone Call Features
• Note that only the phonebook in the current language is deleted. • Automatic downloaded phonebook entries cannot be deleted or edited. List All Names in the Uconnect™ Phonebook • Press the button to begin. • After the Ready prompt and the following beep, say Phonebook List Names.
Page 107 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE call, press and hold the button until you hear a single beep, indicating that the incoming call was rejected. Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cellular phone.
Page 108 Conference Call When two calls are in progress (one active and one on hold), press and hold the button until you hear a double beep indicating that the two calls have been joined into one conference call. Three-Way Calling To initiate three-way calling, press the while a call is in progress, and make a second phone call, as described under Making a Second Call While Current Call is in Progress.
Page 109: Uconnect™ Phone Features
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Call continuation is the progression of a phone call on the Uconnect™ Phone after the vehicle ignition key has been switched to OFF. Call continuation functionality avail- able on the vehicle can be any one of three types: •...
Page 110 Emergency Assistance If you are in an emergency and the cellular phone is reachable: • Pick up the phone and manually dial the emergency number for your area. If the phone is not reachable and the Uconnect™ Phone is operational, you may reach the emergency number as follows: •...
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Towing Assistance If you need towing assistance: • Press the button to begin. • After the Ready prompt and the following beep, say Towing Assistance. NOTE: • The towing assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14- 3454 for Mexico City and 1-800-712-3040 for outside...
Page 112 When calling a number with your Uconnect™ Phone that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can press the button and say the sequence you wish to enter, followed by the word Send. For example, if required to enter your PIN followed with a pound, (3 7 4 6 #), you can press the button and say, 3 7 4 6 # Send.
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts ON/OFF Turning confirmation prompts off will stop the system from confirming your choices (e.g., the Uconnect™ Phone will not repeat a phone number before you dial it). • Press the button to begin.
Page 114: Advanced Phone Connectivity
Mute/Un-Mute (Mute OFF) When you mute the Uconnect™ Phone, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the Uconnect™ Phone: •...
Page 115 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When prompted, say List Phones. • The Uconnect™ Phone will play the phone names of all paired cellular phones in order from the highest to the lowest priority. To “select” or “delete” a paired phone being announced, press the say “Select”...
Page 116: Things You Should Know About Your Uconnect™ Phone
Things You Should Know About Your Uconnect™ Phone Uconnect™ Phone Tutorial To hear a brief tutorial of the system features, press the button and say “Uconnect™ Tutorial.” Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers, the Uconnect™ Phone Voice Training feature may be used.
Page 117 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Speak normally, without pausing, just as you would speak to a person sitting a few feet/meters away from you. • Make sure that no one other than you is speaking during a Voice Command period. •...
Page 118 • In a convertible vehicle, system performance may be compromised with the convertible top down. Phone Far End Audio Performance • Audio quality is maximized under: • low-to-medium blower setting, • low-to-medium vehicle speed, • low road noise, • smooth road surface, •...
Page 119 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119...
Page 121 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 122 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 123 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 124: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 125 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the Voice Command for the beep, and say your command.
Page 126: Commands
Commands The Voice Command system understands two types of commands. Universal commands are available at all times. Local commands are available if the supported radio mode is active. Changing the Volume 1. Start a dialogue by pressing the Voice Command button.
Page 127 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band, say “FM” or “Radio FM”. In this mode, you may say the following commands: • “Frequency” (to change the frequency) • “Next Station” (to select the next station) •...
Page 128 Memo To switch to the voice recorder mode, say “Memo”. In this mode, you may say the following commands: • “New Memo” (to record a new memo) — During the recording, you may press the Voice Command button to stop recording. You proceed by saying one of the following commands: −...
Page 129: Voice Training
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Keep in mind that you have to press the Voice Command button first and wait for the beep before speaking the “Barge In” commands. Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers the Uconnect™...
Page 130: Manual Front Seat Adjustment
Manual Front Seat Adjustment The adjusting bar is at the front of the seats, near the floor. Pull the bar up to move the seat to the desired position. Using body pressure, move forward and rear- ward on the seat to be sure the seat adjusters have latched.
Page 131: Manual Seat Height Adjustment - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Seat Height Adjustment — If Equipped The driver’s seat height can be raised or lowered by using the handle on the outboard side of the seat to adjust the driving position. Seat Height Adjustment Manual Lumbar —...
Page 132: Driver's Seatback Recline
Driver’s Seatback Recline To recline: 1. Lean forward before lifting the handle, then lean back to the desired position and release the handle. 2. Lift the handle to return the seatback to an upright position. Reclining Seat UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 133: Six-Way Power Seats - If Equipped
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Six-Way Power Seats — If Equipped The power seat switch is located on the outboard side of the seat near the floor. Use the switch to move the seat up, down, forward, rearward, or to tilt the seat. Power Seat Switch WARNING! Adjusting a seat while the vehicle is moving is...
Page 134: Heated Seats - If Equipped
Heated Seats — If Equipped This feature heats the front driver and passenger seats. The heaters provide the same heat level for both cushion and back. The controls for the front heated seats are located on the center instrument panel area. After turning the ignition ON, you can choose from High, Low, or Off heat settings.
Page 135: Fold-Flat Front Passenger Seat
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.
Page 136: Adjusting Active Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Adjusting Active Head Restraints Active Head Restraints can reduce the risk of injury in the event of a rear impact. The Active Head Restraint should be adjusted so the top of the head restraint is located above the top of your ear.
Page 137 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To raise the head restraint, pull upward on the head restraint (on some models, you may need to press the push button). To lower the head restraint, press the push button, located at the base of the head restraint, and push downward on the head restraint.
Page 138 Active Head Restraint (Tilted) NOTE: • The head restraints should only be removed by quali- fied technicians, for service purposes only. If either of the head restraints require removal, see your autho- rized dealer. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 •...
Page 139: Folding Rear Seat
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Do not place items over the top of the Active Head Restraint, such as coats, seat covers or portable DVD players. These items may interfere with the operation of the Active Head Restraint in the event of an accident and could result in serious injury or death.
Page 140: Reclining Rear Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 Reclining Rear Seat — If Equipped For additional comfort, pull the strap forward just enough to release the seatback latch. Rear Seats Folded Flat Reclining Rear Seat Strap Then push the seatback to a reclined position, approxi- mately 35 degrees maximum, and release the strap.
Page 141: To Open And Close The Hood
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed. •...
Page 142 2. Move the safety catch located under the front edge of the hood, near the center and raise the hood. Safety Catch Lift the hood prop rod, clipped to the right side (left side when standing in front of hood) of the engine compart- ment, to secure the hood in the open position.
Page 143: Lights
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Multifunction Lever The multifunction lever controls the operation of the headlights, parking lights, turn signals, headlight beam selection, instrument panel light dimming, interior lights, the passing lights and fog lights. The multifunction lever is located on the left side of the steering column.
Page 144: Lights-On Reminder
Lights-on Reminder If the headlights or parking lights are on after the ignition is turned OFF, a chime will sound to alert the driver when the driver’s door is opened. Fog Lights — If Equipped The front fog light switch is on the multifunction lever.
Page 145: Turn Signals
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals Move the multifunction lever up or down and the arrows on each side of the instrument cluster flash to show proper operation of the front and rear turn signal lights. Turn Signal Control NOTE: If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb.
Page 146: Instrument Panel Dimmer
Instrument Panel Dimmer Rotate the center portion of the lever to the extreme bottom position to fully dim the instrument panel lights and prevent the interior lights from illuminating when a door is opened. Rotate the center portion of the lever up to increase the brightness of the instrument panel lights when the park- ing lights or headlights are on.
Page 147: Map/Reading Lights
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE than the normal lamp operation. The high beam head- lights will come on as Daytime Running Lights (DRL), which is at a lower intensity than the normal high beams. The DRL’s will come on whenever the ignition is ON, the engine is running, the headlight switch is off, the parking brake is off, the turn signal is off, and the shift lever is in any position except for PARK.
Page 148: Windshield Wipers And Washers
WINDSHIELD WIPERS AND WASHERS The windshield wiper/washer control lever is located on the right side of the steering column. The front wipers are operated by rotating a switch, located on the end of the lever. For information on the rear wiper/washer, refer to “Rear Window Fea- tures”...
Page 149: Intermittent Wiper System
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Intermittent Wiper System Use the intermittent wiper when weather conditions make a single wiping cycle, with a variable pause be- tween cycles, desirable. Select the delay interval by turning the end of the lever. Rotate the end of the lever upward (clockwise) to decrease the delay time and downward (counterclockwise) to increase the delay time.
Page 150: Mist Feature
Mist Feature Push down on the control lever to activate a single wipe to clear the windshield of road mist or spray from a passing vehicle. As long as the lever is held down, the wipers will continue to operate. Mist Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 CAUTION!
Page 151: Tilt Steering Column
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT STEERING COLUMN This feature allows you to tilt the steering column upward or downward. The tilt control lever is located on the left-side of the steering column, below the turn signal controls Tilt Steering Control Push down on the lever to unlock the column.
Page 152: Electronic Speed Control - If Equipped
ELECTRONIC SPEED CONTROL — IF EQUIPPED When engaged, Electronic Speed Control takes over the accelerator operation at speeds greater than 25 mph (40 km/h). The Electronic Speed Control lever is located on the right side of the steering wheel. Electronic Speed Control Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 NOTE: In order to ensure proper operation, the Elec- tronic Speed Control System has been designed to shut...
Page 153: To Set A Desired Speed
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have an accident. Always leave the Electronic Speed Control system off when you are not using it.
Page 154: Manual Transaxle
RESUME ACCEL position, the set speed will continue to increase until the lever is released, then the new set speed will be established. Tapping RESUME ACCEL once will result in a 1 mph (1.6 km/h) speed increase. Each time the Electronic Speed Control lever is tapped, speed increases, so that tapping the lever three times will increase speed by 3 mph (4.8 km/h), etc.
Page 155: To Accelerate For Passing
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Accelerate for Passing Press the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. Using Electronic Speed Control On Hills NOTE: The Electronic Speed Control system maintains speed, up and down hills.
Page 156 The HomeLink buttons that are located in the headliner or sun visor designate the three different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 WARNING! •...
Page 157: Programming Homelink
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for 20 seconds until the red indicator flashes.
Page 158 • After training a HomeLink channel, if the garage door does not operate with HomeLink and the ga- rage door opener was manufactured after 1995, the garage door opener may have a rolling code. If so, proceed to the heading “Programming A Rolling Code System.”...
Page 159: Gate Operator/Canadian Programming
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Firmly press and release the LEARN or TRAINING button. The name and color of the button may vary by manufacturer. NOTE: You have 30 seconds in which to initiate the next step after the LEARN button has been pressed. 7.
Page 160: Using Homelink
successfully accepted the frequency signal. The indica- tor light will flash slowly and then rapidly when fully trained. If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ” earlier in this section. Using HomeLink To operate, press and release the programmed HomeLink button.
Page 161: Troubleshooting Tips
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the LEARN button on the Garage Door Opener to complete the training for a Rolling Code.
Page 162: Power Sunroof - If Equipped
POWER SUNROOF — IF EQUIPPED The power sunroof switch is located in the reading light. Power Sunroof Switch UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 WARNING! • Never leave children in a vehicle with the key in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.
Page 163: Opening The Sunroof
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening the Sunroof Manual Mode To open the sunroof, press and hold the switch rearward to full open. Any release of the switch will stop the movement and the sunroof will remain in a partial open condition until the switch is pushed and held rearward again.
Page 164: Pinch Protect Override
Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing, press the switch forward and hold for two seconds after the reversal occurs. This allows the sunroof to move towards the close position. NOTE: Pinch protection is disabled while the switch is pressed.
Page 165: Ignition Off Operation
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ignition Off Operation The sunroof will also operate up to 45 seconds after the ignition has been turned OFF. The sunroof operation will be canceled if either of the front doors are opened during the 45 second time period.
Page 166 NOTE: • To ensure proper operation, a MOPAR element must be used. • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.
Page 167: Power Inverter - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER INVERTER — IF EQUIPPED A 115 Volt (150 Watt) AC power inverter is located on the rear of the center console for added convenience. This outlet can power cellular phones, electronics and other low power devices requiring power up to 150 Watts.
Page 168 WARNING! To avoid serious injury or death: • Do not use a three-prong adaptor. • Do not insert any objects into the receptacles. • Do not touch with wet hands. • Close the lid when not in use. • If this outlet is mishandled, it may cause an electric shock and failure.
Page 169: Cupholders
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CUPHOLDERS Your vehicle is equipped with four cupholders. There are two cupholders located in the front. Front Cupholders There are two cupholders behind the center console for rear passengers. Rear Cupholders...
Page 170: Storage
STORAGE Glove Compartment And Storage Bin The glove compartment storage bin is located on the passenger side of the instrument panel. Glove Compartment Storage Bin UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Upper Instrument Panel Storage A storage compartment is located on the center of the instrument.
Page 171: Door Storage - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open the storage compartment, push down on the button. The lid will open automatically. Push down on the lid to close it. Opened Storage Compartment Door Storage — If Equipped The interior door panels are equipped with lower storage areas.
Page 172: Chillzone Beverage Cooler Storage Compartment - If Equipped
CHILLZONE BEVERAGE COOLER STORAGE COMPARTMENT — IF EQUIPPED The upper storage bin door swings upward to present the contents of the long shallow bin that can store items out of sight. Beneath this bin is the glove compartment. The large glove compartment door swings downward and features two levels of storage.
Page 173: Console Features
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Inside the Chill Zone is a vent which, when opened, allows either air conditioned or fresh air to flow into the Chill Zone compartment. Depending on ambient tem- perature and A/C setting, the compartment can keep beverages cool.
Page 174 To open the upper storage compartment, push inward on the upper handle to unlatch the upper lid and lift the lid open. Upper Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 To open the lower storage compartment, lift upward on the lower handle to unlatch the lower storage compart- ment and lift the lid open.
Page 175: Cargo Area Features
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not operate this vehicle with a console compart- ment lid in the open position. Cellular phones, music players, and other handheld electronic devices should be stowed while driving. Use of these devices while driving can cause an accident due to distrac- tion, resulting in death or injury.
Page 176: Cargo Cover
To operate the flashlight, press the switch once for high, twice for low, and a third time to return to off. Three-Press Switch Cargo Cover The cargo area trim panels include two notches for mounting the available tonneau cover that accommo- dates the reclining rear seat.
Page 177 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Using the handle, pull the cover toward you and guide the rear cover posts into the guides located on both sides of the rear trim panel. Cargo Cover Guides WARNING! In an accident a cargo cover loose in the vehicle could cause injury.
Page 178: Removable Load Floor
Removable Load Floor The cargo area contains a removable load floor. Rear Cargo Area Cargo Tie-Down Loops There are two D-rings installed in the cargo area for securing cargo. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 WARNING! • Cargo tie-down loops are not safe anchors for a child seat tether strap.
Page 179: Fold Down Speakers - If Equipped
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Place as much cargo as possible in front of the rear axle. Too much weight or improperly placed weight over or behind the rear axle can cause the rear of the vehicle to sway. •...
Page 180: Rear Window Defroster
Rear Wiper/Washer Control Rotate the center portion of the lever upward to the “On” position to activate the rear wiper. NOTE: The rear wiper operates in an intermittent mode only. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Rotate the center portion of the lever past the first detent to activate that rear washer.
Page 181 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE turns off after approximately 10 minutes. For an addi- tional five minutes of operation, press the button a second time. NOTE: To prevent excessive battery drain, use the rear window defroster only when the engine is operating. CAUTION! Failure to follow these cautions can cause damage to the heating elements:...
Page 182: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....185 Instrument Cluster – Base ....186 Instrument Cluster –...
Page 183 182 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (Disc Mode For CD And MP3/WMA Audio Play, DVD-Video) . . . 222 Notes On Playing MP3/WMA Files ..224 List Button (Disc Mode For MP3/WMA Play) ....226 Info Button (Disc Mode For MP3/WMA Play) .
Page 184 Notes On Playing MP3 Files ... . 250 List Button (CD Mode For MP3 Play) ..253 Info Button (CD Mode For MP3 Play) ..253 Universal Consumer Interface (UCI) —...
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Sound System Controls — If Equipped......265 Radio Operation ..... 266 CD Player .
Page 186: Instrument Panel Features
INSTRUMENT PANEL FEATURES 1 — Air Outlet 2 — Instrument Cluster 3 — Radio 4 — Passenger Airbag UNDERSTANDING YOUR INSTRUMENT PANEL 185 5 — Lower Glove Compartment/Beverage Cooler – If Equipped 6 — Climate Controls 7 — Heated Seat Switches – If Equipped 8 —...
Page 187: Instrument Cluster - Base
186 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER – BASE...
Page 188: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 187 INSTRUMENT CLUSTER – PREMIUM...
Page 189: Instrument Cluster Descriptions
188 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Temperature Gauge The temperature gauge shows engine coolant tempera- ture. Any reading within the normal range indicates that the engine cooling system is operating satisfactorily. The gauge pointer will likely indicate a higher tempera- ture when driving in hot weather, up mountain grades, or when towing a trailer.
Page 190 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer- ship for service if your vehicle overheats. If you decide to look under the hood yourself, see “Main- taining Your Vehicle”.
Page 191 190 UNDERSTANDING YOUR INSTRUMENT PANEL If jump starting is required, refer to “Jump Starting Procedures” in “What To Do In Emergencies”. 7. Airbag Warning Light This light turns on and remains on for seven seconds as a bulb check when the ignition switch is first turned ON.
Page 192 Further overheating will cause the temperature gauge to pass H , the indicator will continuously flash and a continuous chime will occur until the engine is allowed to cool. If the light turns on while driving, safely pull over and stop the vehicle.
Page 193 192 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: The light may flash momentarily during sharp cornering maneuvers, which change fluid level condi- tions. The vehicle should have service performed, and the brake fluid level checked. If brake failure is indicated, immediate repair is neces- sary.
Page 194 13. Shift Lever Indicator The Shift Lever Indicator is self-contained within the instrument cluster. It displays the gear position of the automatic transmission. 14. Odometer / Trip Odometer Display Area This display indicates the total distance the vehicle has been driven. NOTE: U.S.
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If the vehicle is equipped with the optional Electronic Vehicle Information Center (EVIC) in the in- strument cluster, all warnings including “door” and “gATE” and “Oil Change Required” will only be dis- played in the EVIC display. For additional information, refer to “Electronic Vehicle Information Center (EVIC) —...
Page 196 damaged, a “noFUSE” message will display in the odom- eter display area. For further information on fuses and fuse locations refer to “Fuses” in “Maintaining Your Vehicle”. CHAngE OIL Your vehicle is equipped with an engine oil change indicator system. The “CHAngE OIL” message will flash in the instrument cluster odometer for approximately 12 seconds after a single chime has sounded to indicate the next scheduled oil change interval.
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL 16. Trip/Odometer Display Reset Button Press this button to change the display from odometer to either of the two trip odometer settings. Trip A or Trip B will appear when in the trip odometer mode. Push in and hold the button for two seconds to reset the trip odometer to 0 miles (0 km).
Page 198 20. Turn Signal Indicators The arrow will flash with the exterior turn signal when the turn signal lever is operated. If the vehicle electronics sense that the vehicle has traveled about 1 mile (1.6 km) with the turn signals on, a continuous chime will sound to alert you to turn the signals off.
Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL • Each time the ignition is turned ON, the ESC system will be ON even if it was turned off previously. • The ESC system will make buzzing or clicking sounds when it is active. This is normal; the sounds will stop when ESC becomes inactive following the maneuver that caused the ESC activation.
Page 200 maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 201 200 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system, called OBD, that monitors engine and automatic transmission con- trol systems. The light will illuminate when the key is in the ON position, before engine start.
Page 202 26. Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, it indicates that the Anti-Lock portion of the brake system is not functioning and that service is required.
Page 203: Electronic Vehicle Information Center (Evic) - If Equipped
202 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! Continued operation with the Transmission Tem- perature Warning Light illuminated could cause the fluid to boil over, come in contact with hot engine or exhaust components causing a fire that may result in personal injury. 28.
Page 204 Electronic Vehicle Information Center (EVIC) The EVIC consists of the following: • System Status • Vehicle information warning message displays • Personal settings (Customer-Programmable Features) UNDERSTANDING YOUR INSTRUMENT PANEL 203 • Compass heading • Outside temperature display • Trip computer functions •...
Page 205: Oil Change Required - If Equipped
204 UNDERSTANDING YOUR INSTRUMENT PANEL • Right Rear Turn Signal Light Out (with a single chime) • RKE Battery Low (with a single chime) • Personal Settings Not Available – vehicle not in park (automatic transmission) or vehicle is in motion (manual transmission).
Page 206: Evic Functions
1. Turn the ignition switch to the ON position (do not start the engine). 2. Fully depress the accelerator pedal slowly three times within 10 seconds. 3. Turn the ignition switch to the OFF/LOCK position. NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset.
Page 207: Compass/Temperature/Audio
206 UNDERSTANDING YOUR INSTRUMENT PANEL • Distance To Empty (DTE) • Elapsed Time • Tire Pressure Monitor (TPM) • Personal Settings To Reset The Display Pressing and holding the EVIC button once will clear the function currently being displayed. Reset will only occur if a resettable function is currently being displayed.
Page 208: Distance To Empty (Dte)
Distance To Empty (DTE) Shows the estimated distance that can be travelled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level.
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL Use the EVIC button to display one of the following choices: Language When in this display you may select different languages for all display nomenclature, including the trip functions. Pressing the EVIC button while in this display selects English, Espanol, or Francais depending on availability.
Page 210 Sound Horn with Remote Key Lock When ON is selected, a short horn sound will occur when the RKE transmitter LOCK button is pressed. This feature may be selected with or without the Flash Lights with Remote Key Lock feature. Press and hold the EVIC button when in this display until “ON”...
Page 211 210 UNDERSTANDING YOUR INSTRUMENT PANEL Confirmation of Voice Commands — If Equipped When ON is selected all voice commands from the Uconnect™ system are confirmed. Press and hold the EVIC button when in this display until “ON” or “OFF” appears to make your selection. Illuminated Approach When this feature is selected the headlights will activate and remain on for up to 90 seconds when the doors are...
Page 212 NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To ensure compass accu- racy, the compass variance should be properly set accord- ing to the variance map for the zone where the vehicle will be driven.
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL press and release (less than one second) the EVIC button several times until “Compass Variance” is highlighted. The “Compass Variance” message and the current vari- ance zone number will be displayed. To change the zone, press and hold (longer than two seconds) the EVIC button to increment the variance one step.
Page 214: Media Center 230 (Req) - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)
4. Using a long button press (more than one second) press the EVIC button, this will place the Compass in calibration mode. The CAL indicator will come on con- tinuously in the EVIC display to indicate that the com- pass is now in the calibration mode, and that the vehicle can now be driven to calibrate.
Page 215: Operating Instructions - Radio Mode
214 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Press the ON/VOLUME control knob a second time to turn off the radio.
Page 216 Phone Button Uconnect™ Phone — If Equipped Press this button to operate the Uconnect™ Phone feature (if equipped). Refer to “Uconnect™ Phone” in “Under- standing The Features Of Your Vehicle”. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Uconnect”...
Page 217 216 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in AM, FM or Satellite (if equipped) frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 218 or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected. Many radio stations do not currently broadcast Music Type information. Toggle the MUSIC TYPE button to select the following format types: Program Type 16-Digit Character Display No program type...
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode.
Page 220 • Angle – Repeatedly pressing SELECT will change the viewing angle if supported by the DVD disc (if equipped). NOTE: • The available selections for each of the above entries varies depending upon the disc. • These selections can only be made while playing a DVD.
Page 221 220 UNDERSTANDING YOUR INSTRUMENT PANEL Audio Language — If Equipped Selecting this item allows you to choose a default audio language (effective only if the language is supported by the disc). You can select a language not listed by scrolling down and selecting other.
Page 222 a disc is loaded, changes will not be effective. Also, the defaults are effective only if the disc supports the customer-preferred settings. AM and FM Buttons Press the buttons to select AM or FM mode. SET Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET button.
Page 223 222 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (DISC MODE for CD and MP3/WMA Audio Play, DVD-VIDEO) The radio DVD player and many DVD discs are coded by geographic region. These region codes must match in order for the disc to play. If the region code for the DVD disc does not match the region code for the radio DVD player, it will not play the disc.
Page 224 Eject Button — Ejecting Compact Disc(s) Press the EJECT button and the pushbutton with the corresponding number (1-6) where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 225: Notes On Playing Mp3/Wma Files
224 UNDERSTANDING YOUR INSTRUMENT PANEL Notes On Playing MP3/WMA Files The radio can play MP3/WMA files; however, acceptable MP3/WMA file recording media and formats are limited. When writing MP3/WMA files, pay attention to the following restrictions. Supported Media (Disc Types) The MP3/WMA file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3,WMA, DVD Video, DVD-R, DVD-RW, DVD+R, DVD+RW, and CDDA+MP3.
Page 226 If a disc contains multi-formats, such as CD audio and MP3/WMA tracks, the radio will only play the MP3/ WMA tracks on that disc. Supported MP3/WMA File Formats The radio will recognize only files with the *.MP3/WMA extension as MP3/WMA files. Non-MP3/WMA files named with the *.MP3/WMA extension may cause play- back problems.
Page 227: List Button (Disc Mode For Mp3/Wma Play)
226 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3/WMA Files When a medium containing MP3/WMA data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3/WMA files.
Page 228 Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3/WMA player, cassette player, or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 229 228 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Voice Command System (If Equipped) For the radio, refer to “Voice Command” in “Understand- ing The Features Of Your Vehicle”. For Uconnect™ “Voice Command,” refer to “Uconnect™ Phone” in “Understanding The Features Of Your Vehicle”.
Page 230: Media Center 730N/430 (Rer/Ren/Rbz) - Am/Fm Stereo Radio And Cd/Dvd/Hdd/ Nav - If Equipped
DTS™ DTS™ and DTS™ 2.0 are trademarks of Digital The- ater Systems, Inc. MEDIA CENTER 730N/430 (RER/REN/RBZ) — AM/FM STEREO RADIO AND CD/DVD/HDD/NAV — IF EQUIPPED NOTE: The sales code is located on the lower right side of the unit’s faceplate. The REN, RER and RBZ radios contain a CD/DVD player, USB port, and a 30-gigabyte hard drive (HDD).
Page 231 230 UNDERSTANDING YOUR INSTRUMENT PANEL 3. To move the hour forward, touch the screen where the word “Hour” with the arrow pointing upward is dis- played. To move the hour backward, touch the screen where the word “Hour” with the arrow pointing down- ward is displayed.
Page 232: Clock Setting Procedure - Rer/Ren Radio
Changing the Time Zone 1. Turn on the radio. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen.
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL displayed. To move the minute backward, touch the screen where the word “Min” with the arrow pointing downward is displayed. 6. To save the new time setting, touch the screen where the word “Save” is displayed. Changing Daylight Savings Time When selected, this feature will display the time of day in daylight savings time.
Page 234: Media Center 130 (Res) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
3. Touch the screen where “User Clock” is displayed, the clock setting menu will appear on the screen. 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen. 5.
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction, without stopping.
Page 236 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 237: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
236 UNDERSTANDING YOUR INSTRUMENT PANEL SET/RND Button — To Set the Pushbutton Memory When you are receiving a station that you wish to commit to pushbutton memory, press the SET/RND button. The symbol SET 1 will now show in the display window.
Page 238 • This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks. Inserting Compact Disc(s) Gently insert one CD into the CD player with the CD label facing up.
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 240: Notes On Playing Mp3 Files
Notes on Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions. Supported Media (Disc Types) The MP3 file recording media supported by the radio are CDDA, CD-R, CD-RW, MP3, and CDDA+MP3.
Page 241 240 UNDERSTANDING YOUR INSTRUMENT PANEL Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times. Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files.
Page 242: Operation Instructions - Auxiliary Mode
Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: •...
Page 243: Media Center 130 (Res/Rsc) - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack) And Sirius Radio
242 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (RES/RSC) — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) AND SIRIUS RADIO NOTE: The radio sales code is located on the lower right side of the radio faceplate. RES/RSC Radio Operating Instructions —...
Page 244 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 245 244 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change.
Page 246 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
Page 247 246 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: 16-Digit Character Program Type No program type or undefined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies Program Type Personality Display Public...
Page 248 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 249: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
248 UNDERSTANDING YOUR INSTRUMENT PANEL display window. Each button can be set for SET 1 and SET 2 in both AM and FM. This allows a total of 12 AM and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice.
Page 250 If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the track number, and index time in minutes and seconds.
Page 251: Notes On Playing Mp3 Files
250 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or...
Page 252 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 253 252 UNDERSTANDING YOUR INSTRUMENT PANEL Supported MP3 File Formats The radio will recognize only files with the *.MP3 exten- sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems. The radio is designed to recognize the file as an invalid MP3 and will not play the file.
Page 254: List Button (Cd Mode For Mp3 Play)
Loading times for playback of MP3 files may be affected by the following: • Media - CD-RW media may take longer to load than CD-R media • Medium formats - Multisession discs may take longer to load than non-multisession discs •...
Page 255: Universal Consumer Interface (Uci) - If Equipped
254 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3 player or cassette player and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 256: Connecting The Ipod
This feature allows an iPod to be plugged into the vehicle’s sound system through a 16–pin connector, using the provided interface cable. UCI supports Mini, 4G, Photo, Nano, 5G iPod iPhone devices. Some iPod software versions may not fully support the UCI features. Please visit Apple’s website for software updates.
Page 257: Using This Feature
256 UNDERSTANDING YOUR INSTRUMENT PANEL Using This Feature By using the provided connection cable to connect an iPod to the vehicle’s UCI 16–pin connector port: • The iPod audio can be played on the vehicle’s sound system, providing metadata (artist, track title, album, etc.) information on the radio display.
Page 258 • Jump backward in the current track by pressing and holding the << RW button. Holding the << RW button long enough will jump to the beginning of the current track. • Jump forward in the current track by pressing and holding the FF >>...
Page 259: List Or Browse Mode
258 UNDERSTANDING YOUR INSTRUMENT PANEL • RND button (available on sales code RES radio only): Pressing this button toggles between Shuffle ON and Shuffle OFF modes for the iPod . If the RND icon is showing on the radio display, then the shuffle mode is List Or Browse Mode During Play mode, pressing any of the buttons described below, will bring up List mode.
Page 260 • Pressing a PRESET button will display the current list on the top line and the first item in that list on the second line. • To Exit List mode without selecting a track, press the same PRESET button again to go back to Play mode.
Page 261: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Req/Rer/Res/Reu/Rbz Radios Only)
260 UNDERSTANDING YOUR INSTRUMENT PANEL Uconnect™ Multimedia (SATELLITE RADIO) — IF EQUIPPED (REN/REQ/RER/RES/REU/RBZ RADIOS ONLY) Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast. The subscription service provider is Sirius Satellite Radio. This service offers over 130 channels of music, sports, news, entertainment, and programming for chil- dren, directly from its satellites and broadcasting studios.
Page 262: Selecting Uconnect™ Multimedia (Satellite) Mode
Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. ESN/SID Access With REN/RER/RBZ Radios While in SAT mode, press the MENU button on the radio faceplate.
Page 263: Operating Instructions - Uconnect™ Multimedia (Satellite) Mode
262 UNDERSTANDING YOUR INSTRUMENT PANEL • Dense tree coverage may interrupt reception in the form of short audio mutes. • Driving under wide bridges or along tall buildings can cause intermittent reception. • Placing objects over or too close to the antenna can cause signal blockage.
Page 264 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows. TUNE Control (Rotary) Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the channel. MUSIC TYPE Button —...
Page 265: Operating Instructions - Uconnect™ Phone (If Equipped)
264 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 266: Operating Instructions - Video Entertainment System (Ves)™ (If Equipped)
Operating Instructions — Video Entertainment System (VES)™ (If Equipped) Refer to separate “Video Entertainment System (VES)™ Guide.” REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches.
Page 267: Radio Operation
266 UNDERSTANDING YOUR INSTRUMENT PANEL The button located in the center of the right-hand control will switch modes to Radio or CD. The left-hand control is a rocker type switch with a pushbutton in the center. The function of the left-hand control is different depending on which mode you are in.
Page 268: Radio Operation And Cellular Phones
3. Do not apply paper or tape to the disc; avoid scratch- ing the disc. 4. Do not use solvents such as benzene, thinner, cleaners, or anti-static sprays. 5. Store the disc in its case after playing. 6. Do not expose the disc to direct sunlight. 7.
Page 269: Manual Heating And Air Conditioning
268 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Heating and Air Conditioning The Manual Temperature Controls consist of a series of outer rotary dials and inner push knobs. Blower Control Rotate this control to regulate the amount of air forced through the ven- tilation system in any mode.
Page 270 Temperature Control Rotate this control to regulate the tem- perature of the air inside the passenger compartment. Rotating the dial left into the blue area of the scale indicates cooler temperatures while rotating right into the red area indicates warmer temperatures. NOTE: If your air conditioning performance seems lower than expected, check the front of the A/C con-...
Page 271 270 UNDERSTANDING YOUR INSTRUMENT PANEL Bi-Level Air is directed through the panel and floor outlets. NOTE: For all settings except full cold or full hot, there is a difference in temperature between the upper and lower outlets. The warmer air flows to the floor outlets. This feature gives improved comfort during sunny but cool conditions.
Page 272 NOTE: • Continuous use of the recirculation mode may make the inside air stuffy and window fogging may occur. Extended use of this mode is not recommended. • The use of the recirculation mode in cold or damp weather will cause windows to fog on the inside, because of moisture buildup inside the vehicle.
Page 273: Automatic Temperature Control (Atc) - If Equipped
272 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control (ATC) — If Equipped The Automatic Temperature Control system automati- cally maintains the climate in the cabin of the vehicle at the comfort levels desired by the driver and passenger. Automatic Temperature Control Automatic Operation Operation of the system is quite simple.
Page 274 The recommended setting for maximum comfort for the average person is 72°F (22°C); however, this may vary. NOTE: • The temperature setting can be adjusted at anytime without affecting automatic operation. • Pressing the Air Conditioning Control button while in AUTO mode will cause the LED in the control button to flash three times and then turn off.
Page 275 274 UNDERSTANDING YOUR INSTRUMENT PANEL...
Page 276 The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Panel Air is directed through the outlets in the instrument panel. These outlets can be adjusted to direct airflow. The center instrument panel outlets can be NOTE: aimed so that they are directed toward the rear seat...
Page 277 276 UNDERSTANDING YOUR INSTRUMENT PANEL • Air Conditioner Control Press this button to turn on the air conditioning during manual operation only. When the air conditioning is turned on, cool dehumidified air will flow through the outlets selected with the Mode control dial. Press this but- ton a second time to turn OFF the air conditioning.
Page 278: Operating Tips
defrost/floor mode. Attempting to use the recircula- tion while in these modes will cause the LED in the control button to blink and then turn off. • Most of the time, when in Automatic Operation, you can temporarily put the system into Recirculation Mode by pressing the Recirculation button.
Page 279 278 UNDERSTANDING YOUR INSTRUMENT PANEL Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower settings. This will ensure adequate system lubrication to minimize the possibility of compressor damage when the system is started again.
Page 280 UNDERSTANDING YOUR INSTRUMENT PANEL 279 A/C Air Filter — If Equipped The A/C Filter prevents most dust and pollen from entering the cabin. The filter acts on air coming from outside the vehicle and recirculated air within the pas- senger compartment. Refer to “Maintenance Procedures” in “Maintaining Your Vehicle”...
Page 281 280 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 282 STARTING AND OPERATING CONTENTS Starting Procedures ....285 Manual Transmission – If Equipped ..285 Automatic Transmission –...
Page 283 282 STARTING AND OPERATING AutoStick — If Equipped ....294 Operation ......294 General Information .
Page 284 Tires — General Information ... . . 323 Tire Pressure ..... . . 323 Tire Inflation Pressures .
Page 285 284 STARTING AND OPERATING Adding Fuel ......346 Fuel Filler Cap (Gas Cap) ....346 Loose Fuel Filler Cap Message .
Page 286: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured.
Page 287: Normal Starting
286 STARTING AND OPERATING Do not press the accelerator. Turn the ignition switch to the START position and release it as soon as the starter engages. The starter motor will continue to run, and it will disengage automatically when the engine is running. If the engine fails to start, the starter will disengage automatically in 10 seconds.
Page 288: If Engine Fails To Start
If Engine Fails to Start If the engine fails to start after you have followed the “Normal Starting” or “Extreme Cold Weather” proce- dures, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there. Crank the engine for no more than 15 seconds.
Page 289: Manual Transmission - If Equipped
288 STARTING AND OPERATING WARNING! Remember to disconnect the cord before driving. Damage to the 110-115 Volt electrical cord could cause electrocution. MANUAL TRANSMISSION — IF EQUIPPED Five–Speed Manual Transmission WARNING! You or others could be injured if you leave the vehicle unattended without having the parking brake fully applied.
Page 290: Recommended Shift Speeds
Use each gear in numerical order, do not skip a gear. Be sure the transmission is in first gear, (not third), when starting from a standing position. Damage to the clutch can result from starting in third gear. For most city driving, you will find it easier to use only the lower gears.
Page 291: Automatic Transmission - If Equipped
290 STARTING AND OPERATING CAUTION! If you skip more than one gear while downshifting or downshift at too high a vehicle speed, you could damage the engine, transmission, or clutch. To maintain a safe speed and prolong brake life, shift down to second or first gear when descending a steep grade.
Page 292: Brake/Transmission Interlock System
Shift Lever NOTE: You MUST press and hold the brake pedal down while shifting out of PARK. STARTING AND OPERATING 291 WARNING! It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed.
Page 293: Automatic Transmission Ignition Interlock System
292 STARTING AND OPERATING NOTE: If a malfunction occurs, the transmission will not shift out of PARK. Battery power is required to release the brake/transmission interlock system. There is a removable plug in the right side of the shifter housing that allows you to insert your finger to override the system.
Page 294 WARNING! • Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the vehicle into PARK, remove the key from the ignition, and apply the parking brake.
Page 295: Autostick - If Equipped
294 STARTING AND OPERATING CAUTION! Before moving the shift lever out of PARK, you must turn the ignition from LOCK to ON so the steering wheel and shift lever are released. Otherwise, dam- age to the steering column or shift lever could result. You must also press the brake pedal.
Page 296: General Information
AutoStick operation is activated in the DRIVE position by moving the shift lever side-to-side. Moving the shift lever to the (+) side will activate AutoStick and shift up to the next higher manual ratio, unless you are already operating in or near Overdrive, in which case sixth gear ratio will be selected.
Page 297: Driving On Slippery Surfaces
296 STARTING AND OPERATING • If the system detects powertrain overheating, the transmission will revert to the automatic shift mode and remain in that mode until the powertrain cools off. • If the system detects a problem, it will disable the AutoStick mode and the transmission will return to the automatic mode until the problem is corrected.
Page 298: Driving Through Water
2. Slow down if the road has standing water or puddles. 3. Replace the tires when tread wear indicators first become visible. 4. Keep the tires properly inflated. 5. Maintain enough distance between your vehicle and the vehicle in front of you to avoid a collision in a sudden stop.
Page 299 298 STARTING AND OPERATING CAUTION! • Always check the depth of the standing water before driving through it. Never drive through standing water that is deeper than the bottom of the tire rims mounted on the vehicle. • Determine the condition of the road or the path that is under water and if there are any obstacles in the way before driving through the standing wa- ter.
Page 300: Power Steering
WARNING! • Driving through standing water limits your vehi- cle’s traction capabilities. Do not exceed 5 mph (8 km/h) when driving through standing water. • Driving through standing water limits your vehi- cle’s braking capabilities, which increases stop- ping distances. Therefore, after driving through standing water, drive slowly and lightly press on the brake pedal several times to dry the brakes.
Page 301: Power Steering Fluid Check
300 STARTING AND OPERATING system. This noise should be considered normal, and it does not in any way damage the steering system. WARNING! Continued operation with reduced power steering assist could pose a safety risk to yourself and others. Service should be obtained as soon as possible. CAUTION! Prolonged operation of the steering system at the end of the steering wheel travel will increase the steering...
Page 302: Parking Brake
If necessary, add fluid to restore to the proper indicated level. With a clean cloth, wipe any spilled fluid from all surfaces. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied.
Page 303 302 STARTING AND OPERATING NOTE: • When the parking brake is applied and the automatic transmission is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound to alert the driver. Fully release the parking brake before attempting to move the vehicle.
Page 304: Brake System
CAUTION! If the “Brake Warning Light” remains on with the parking brake released, a brake system malfunction is indicated. Have the brake system serviced by an authorized dealer immediately. BRAKE SYSTEM Your vehicle is equipped with power assisted brakes as standard equipment.
Page 305: Anti-Lock Brake System (Abs)
304 STARTING AND OPERATING WARNING! Driving a vehicle with the “Brake Warning Light” on is dangerous. A significant decrease in braking per- formance or vehicle stability during braking may occur. It will take you longer to stop the vehicle or will make your vehicle harder to control.
Page 306 WARNING! (Continued) • The capabilities of an ABS-equipped vehicle must never be exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of others. The “ABS Warning Light” monitors the ABS System. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds.
Page 307: Electronic Brake Control System
306 STARTING AND OPERATING You may also experience the following when the brake system goes into anti-lock mode: • the ABS motor running (it may continue to run for a short time after the stop) • the clicking sound of solenoid valves •...
Page 308: Starting And Operating 307
(HSA), and Electronic Stability Control (ESC). All sys- tems work together to enhance vehicle stability and control in various driving conditions and are commonly referred to as ESC. Anti-Lock Brake System (ABS) This system aids the driver in maintaining vehicle control under adverse braking conditions.
Page 309: Traction Control System (Tcs)
308 STARTING AND OPERATING WARNING! (Continued) • The BAS cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplan- ing. Only a safe, attentive, and skillful driver can prevent accidents. • The capabilities of a BAS-equipped vehicle must never be exploited in a reckless or dangerous manner which could jeopardize the user’s safety or the safety of others.
Page 310 HSA Activation Criteria The following criteria must be met in order for HSA to activate: • Vehicle must be stopped. • Vehicle must be on a 7% grade or greater hill. • Gear selection matches vehicle uphill direction (i.e., vehicle facing uphill is in forward gear; vehicle back- ing uphill is in REVERSE gear).
Page 311: Electronic Stability Control (Esc)
310 STARTING AND OPERATING 5. Release the clutch pedal. 6. Rotate the steering wheel one-half turn to the left. 7. Press the “ESC Off” switch (located in the lower switch bank below the climate controls) four times within 20 seconds. The “ESC Off Indicator Light” should turn on and turn off two times.
Page 312 ESC Off Indicator Light The “ESC Off Indicator Light” (located in the instrument cluster) starts to flash as soon as the tires lose traction and the ESC system becomes active. The “ESC Off Indicator Light” also flashes when TCS is active. If the “ESC Off Indicator Light”...
Page 313 312 STARTING AND OPERATING several ignition cycles, and the vehicle has been driven several miles (kilometers) at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible to have the problem diagnosed and corrected. NOTE: •...
Page 314: Tire Safety Information
NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, it may be desirable to switch to the “Partial Off” mode by pressing the “ESC Off” switch. Once the situa- tion requiring ESC to be switched to the “Partial Off”...
Page 315 314 STARTING AND OPERATING NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 316 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%)
Page 317 316 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 318: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. DOT = Department of Transportation —...
Page 319: Tire Terminology And Definitions
318 STARTING AND OPERATING Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 320: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire Placard Location STARTING AND OPERATING 319 Tire and Loading Information Placard Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 321 320 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 322 available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4.
Page 323 322 STARTING AND OPERATING...
Page 324: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 325: Tire Inflation Pressures
324 STARTING AND OPERATING WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure.
Page 326 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure.”...
Page 327: Tire Pressures For High Speed Operation
326 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 328: Tire Spinning
WARNING! • Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h). • Temporary-use spare tires have limited tread life. When the tread is worn to the tread wear indica- tors, the temporary use spare tire needs to be replaced.
Page 329: Tread Wear Indicators
328 STARTING AND OPERATING WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 30 mph (48 km/h) or for more than 30 seconds continuously when you are stuck, and do not let anyone near a spinning wheel, no matter what the...
Page 330: Life Of Tire
Life of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure.
Page 331 330 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 332: Tire Chains
TIRE CHAINS Due to limited clearance, tire chains are not recom- mended. CAUTION! Damage to the vehicle may result if tire chains are used. SNOW TIRES Some areas of the country require the use of snow tires during Winter. Standard tires are of the all-season type and satisfy this requirement as indicated by the M+S designation on the tire sidewall.
Page 333: Tire Pressure Monitoring System (Tpms)
332 STARTING AND OPERATING Refer to “Maintenance Schedule” for the proper mainte- nance intervals. More frequent rotation is permissible if desired. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed. The suggested rotation method is shown in the following diagram.
Page 334 The TPMS will warn the driver of a low tire pressure if the tire pressure falls below the low-pressure warning limit for any reason, including low temperature effects, or natural pressure loss through the tire. The TPMS will continue to warn the driver of low tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above the recommended cold placard pressure.
Page 335 334 STARTING AND OPERATING CAUTION! • The TPMS has been optimized for the original equipment tires and wheels. TPMS pressures and warnings have been established for the tire size equipped on your vehicle. Undesirable system operation or sensor damage may result when us- ing replacement equipment that is not of the same size, type, and/or style.
Page 336: Base System
• Seasonal temperature changes will affect tire pressure, and the TPMS will monitor the actual tire pressure in the tire. Base System This is the TPMS warning indicator located in the instrument cluster. The TPMS uses wireless technology with wheel rim mounted electronic sensors to monitor tire pressure lev- els.
Page 337 336 STARTING AND OPERATING Check TPMS Warnings The Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and remain on solid when a system fault is detected. The system fault will also sound a chime. If the ignition key is cycled, this sequence will repeat providing the system fault still exists.
Page 338: Premium System - If Equipped
4. For each subsequent ignition key cycle, a chime will sound and the Tire Pressure Monitoring Telltale Light will flash on and off for 75 seconds and then remain on solid. 5. Once you repair or replace the original road tire and reinstall it on the vehicle in place of the compact spare tire, the TPMS will update automatically and the Tire Pressure Monitoring Telltale Light will turn OFF, as long...
Page 339 338 STARTING AND OPERATING • Various Tire Pressure Monitoring System Messages, which display in the Electronic Vehicle Information Center (EVIC) • Yellow Tire Pressure Monitoring Telltale Light Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Light will illumi- nate in the instrument cluster and an audible chime will be activated when one or more of the four active road tire pressures are low.
Page 340 graphic display of the pressure value(s) will stop flash- ing, and the Tire Pressure Monitoring Light will extin- guish once the updated tire pressure(s) have been re- ceived. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) to receive this information.
Page 341 340 STARTING AND OPERATING will be displayed instead of dashes. A system fault can occur with any of the following scenarios: 1. Jamming due to electronic devices or driving next to facilities emitting the same radio frequencies as the TPM sensors.
Page 342: General Information
5. Once you repair or replace the original road tire and reinstall it on the vehicle in place of the compact spare tire, the TPMS will update automatically and the Tire Pressure Monitoring Telltale Light will turn OFF, as long as no tire pressure is below the low-pressure warning limit in any of the four active road tires.
Page 343: Reformulated Gasoline
342 STARTING AND OPERATING Poor quality gasoline can cause problems such as hard starting, stalling and hesitations. If you experience these symptoms, try another brand of gasoline (with the ap- propriate octane rating for your engine) before consider- ing service for the vehicle. Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as “Reformulated Gasoline.”...
Page 344: E85 Usage In Non-Flex Fuel Vehicles
E85 Usage In Non-Flex Fuel Vehicles Non-FFV vehicles are compatible with gasoline contain- ing 10% ethanol (E10). Gasoline with higher ethanol content may void the vehicle’s warranty. If a Non-FFV vehicle is inadvertently fueled with E85 fuel, the engine will have some or all of these symptoms: •...
Page 345: Materials Added To Fuel
344 STARTING AND OPERATING It is even more important to look for gasoline without MMT in Canada, because MMT can be used at levels higher than those allowed in the United States. MMT is prohibited in Federal and California reformu- lated gasoline.
Page 346: Carbon Monoxide Warnings
CAUTION! (Continued) • The use of fuel additives, which are now being sold as octane enhancers, is not recommended. Most of these products contain high concentra- tions of Methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives is not the responsibility of the manufacturer.
Page 347: Adding Fuel
346 STARTING AND OPERATING WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. •...
Page 348 CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel tank filler cap (gas cap). A poorly fitting cap could let impurities into the fuel system. • A poorly fitting gas cap may cause the “Malfunc- tion Indicator Light (MIL)”...
Page 349: Loose Fuel Filler Cap Message
348 STARTING AND OPERATING Loose Fuel Filler Cap Message If the vehicle diagnostic system determines that the fuel filler cap is loose or improperly installed, a “gASCAP” message will be displayed in the Odometer/Trip Odom- eter in the instrument cluster. Refer to “Instrument Cluster Description”...
Page 350 Gross Vehicle Weight Rating (GVWR) The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, and cargo. The total load must be limited so that you do not exceed the GVWR. Tire Size The tire size on the Vehicle Certification Label represents the actual tire size on your vehicle.
Page 351: Trailer Towing
350 STARTING AND OPERATING Overloading can cause potential safety hazards and shorten useful service life. Heavier suspension compo- nents do not necessarily increase the vehicle’s GVWR. Loading To load your vehicle properly, first figure out its empty weight. Store heavier items down low and be sure you distribute their weight as evenly as possible.
Page 352 Gross Trailer Weight (GTW) The GTW is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or tem- porary) loaded in or on the trailer in its loaded and ready for operation condition. The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale.
Page 353: Installing A Trailer Hitch
352 STARTING AND OPERATING that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling. Weight-Carrying Hitch A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or some other connecting point of the truck.
Page 354: Trailer Hitch Classification
WARNING! Do not operate the vehicle without a properly se- cured tire and jack assembly. Any loose items may be thrown forward in a collision or hard stop and strike occupants, causing serious or fatal injury. Trailer Hitch Classification The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition.
Page 355: Trailer Towing Weights (Maximum Trailer Weight Ratings)
354 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area 2.0L Auto/Man 22 sq ft (2.04 sq m) 2.4L Auto/Man 22 sq ft (2.04 sq m) 2.4L Auto/Man with 32 sq ft (3.0 sq m) Trailer Tow Prep Pack-...
Page 356: Trailer And Tongue Weight
Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the GTW on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely from side-to-side which will cause loss of con- trol of vehicle and trailer.
Page 357: Towing Requirements
356 STARTING AND OPERATING NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the “Tire and Loading Information Placard”...
Page 358 WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: • Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 359 358 STARTING AND OPERATING WARNING! (Continued) 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (this requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements –...
Page 360 actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. − Trailer brakes are recommended for trailers over 1,000 lbs (450 kg) and required for trailers in excess of 2,000 lbs (907 kg).
Page 361 360 STARTING AND OPERATING Towing Requirements – Trailer Lights and Wiring Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four-pin and seven-pin wiring harness.
Page 362: Towing Tips
Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 — Left Stop/Turn 3 — Right Stop/Turn 7 — Running Lamps 4 — Electric Brakes STARTING AND OPERATING 361 Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic.
Page 363: Recreational Towing (Behind Motorhome, Etc.)
362 STARTING AND OPERATING Cooling System To reduce potential for engine and transmission over- heating, take the following actions: − City Driving When stopped for short periods of time, shift the trans- mission into NEUTRAL and increase the engine idle speed.
Page 364 NOTE: Vehicles equipped with manual transmissions may be recreationally towed (flat towed) at any legal highway speed, for any distance, if the manual transmis- sion is in NEUTRAL and the ignition key is in the ACC position. CAUTION! • Do not flat tow any vehicle equipped with a automatic transmission.
Page 366 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....366 If Your Engine Overheats ....366 Automatic Transaxle Overheating .
Page 367: Hazard Warning Flasher
366 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the instrument panel, below the radio. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 368: What To Do In Emergencies 367
CAUTION! Driving with a hot cooling system could damage your vehicle. If the pointer rises to the H (red) mark, the instrument cluster will sound a chime. When safe, pull over and stop the vehicle with the engine at idle. Turn off the air conditioning and wait until the pointer drops back into the normal range.
Page 369: Automatic Transaxle Overheating
368 WHAT TO DO IN EMERGENCIES AUTOMATIC TRANSAXLE OVERHEATING During sustained high speed driving or trailer towing up long grades on hot days, the automatic transaxle oil may become too hot. If this happens, the transmission overheat in- dicator light will come on, and the vehicle will slow slightly until the automatic transaxle cools down enough to allow a return to the requested speed.
Page 370: Jack Location
Jack Location The jack and jack-handle are stowed under the load floor in the cargo area. Spare Tire and Jack Stowage Spare Tire Stowage The compact spare tire is stowed under the rear load floor in the cargo area. WHAT TO DO IN EMERGENCIES 369 Spare Tire Removal Lift up the load floor cover and remove the hold down.
Page 371: Jacking Instructions
370 WHAT TO DO IN EMERGENCIES 5. Turn on the Hazard Warning flasher. 6. Block both the front and rear of the wheel diagonally opposite the jacking position. For example, if changing the right front tire, block the left rear wheel.
Page 372 WARNING! (Continued) • If working on or near a roadway, be extremely careful of motor traffic. • To assure that spare tires, flat or inflated, are securely stowed, spares must be stowed with the valve stem facing the ground. • Turn on the Hazard Warning flasher. Jack Warning Label 1.
Page 373 372 WHAT TO DO IN EMERGENCIES CAUTION! Do not attempt to raise the vehicle by jacking on locations other than those indicated in Step 3. 3. There are two front jacking locations and two rear jacking locations on each side of the body. The front locations are outlined by two triangular cutouts, the rear ones by two rectangular cutouts.
Page 374 WARNING! To avoid possible personal injury, handle the wheel covers with care to avoid contact with any sharp edges. NOTE: The wheel cover is held on the wheel by the wheel nuts. When reinstalling the original wheel, prop- erly align the wheel cover to the valve stem, place the wheel cover onto the wheel, then install the wheel nuts.
Page 375: Jump-Starting Procedures
374 WHAT TO DO IN EMERGENCIES WARNING! A loose tire thrown forward in a collision or hard stop could injure the occupants in the vehicle. Have the deflated (flat) tire repaired or replaced immedi- ately. 11. Check the tire pressure as soon as possible. Correct the tire pressure as required.
Page 376: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 375 Preparations for Jump-Start The battery in your vehicle is located in the front of the engine compartment below the air intake duct. To access the battery remove the air intake duct by turning the two finger screws, located on the radiator support.
Page 377: Jump-Starting Procedure
376 WHAT TO DO IN EMERGENCIES WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be injured by moving fan blades. • Remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact.
Page 378 CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle. 1. Connect the positive (+) end of the jumper cable to the positive (+) post of the discharged vehicle. 2.
Page 379: Freeing A Stuck Vehicle
378 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper cable from the positive (+) post of the booster battery. 9. Disconnect the positive (+) end of the jumper cable from the positive (+) post of the discharged vehicle. 10.
Page 380: Towing A Disabled Vehicle
CAUTION! (Continued) • Revving the engine or spinning the wheels too fast may lead to transmission overheating and failure. It can also damage the tires. Do not spin the wheels above 30 mph (48 km/h) while in gear (no transmission shifting occurring). WARNING! Fast spinning tires can be dangerous.
Page 381 380 WHAT TO DO IN EMERGENCIES Manual Transaxle • Front Wheel Drive (FWD) or All Wheel Drive (AWD) vehicles can be flat towed (all four wheels on the ground) with the transmission in NEUTRAL. • FWD vehicles can be towed with the front wheels elevated.
Page 382: Without The Ignition Key
WHAT TO DO IN EMERGENCIES 381 Without The Ignition Key Special care must be taken when the vehicle is towed with the ignition in the LOCK position. A dolly should be used under the front wheels if the rear wheels are raised. Proper towing equipment is necessary to prevent dam- age to the vehicle.
Page 384 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 2.0L ... . . 385 Engine Compartment — 2.4L ... . . 386 Onboard Diagnostic System —...
Page 385 384 MAINTAINING YOUR VEHICLE Cooling System ..... 401 Brake System ..... . . 407 Automatic Transmission (CVT) –...
Page 386: Engine Compartment - 2.0L
ENGINE COMPARTMENT — 2.0L 1 — Washer Fluid Reservoir 2 — Power Steering Fluid Reservoir 3 — Engine Oil Fill 4 — Air Cleaner Filter 5 — Brake Fluid Reservoir MAINTAINING YOUR VEHICLE 385 6 — Integrated Power Module 7 — Battery (Under Cover) 8 —...
Page 387: 386 Maintaining Your Vehicle
386 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 2.4L 1 — Washer Fluid Reservoir 2 — Power Steering Fluid Reservoir 3 — Engine Oil Fill 4 — Brake Fluid Reservoir 5 — Integrated Power Module 6 — Battery (Under Cover) 7 — Air Cleaner Filter 8 —...
Page 388: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated Onboard Diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 389: Emissions Inspection And Maintenance Programs
388 MAINTAINING YOUR VEHICLE persists, the message will appear the next time the vehicle is started. This might indicate a damaged cap. If the problem is detected twice in a row, the system will turn on the MIL. Resolving the problem will turn the MIL light off.
Page 390: Replacement Parts
4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 391: Maintenance Procedures
390 MAINTAINING YOUR VEHICLE your vehicle. Refer to these Service Manuals before attempting any procedure yourself. NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle.
Page 392: Engine Oil
CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
Page 393 392 MAINTAINING YOUR VEHICLE CAUTION! Do not overfill the engine. Overfilling the engine as indicated by the range markings, as described above, on the engine oil dipstick will cause oil aeration, which can lead to loss of oil pressure and an increase in oil temperature.
Page 394 Engine Oil Viscosity (SAE Grade) SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature starting and vehicle fuel economy. Your engine oil filler cap also states the recommended engine oil viscosity grade for your engine. Lubricants which do not have both the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used.
Page 395: Engine Oil Filter
394 MAINTAINING YOUR VEHICLE station, or governmental agency for advice on how and where used oil and oil filters can be safely discarded in your area. Engine Oil Filter The engine oil filter should be replaced with a new filter at every engine oil change.
Page 396: Maintenance-Free Battery
Maintenance-Free Battery Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- tenance required. WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing.
Page 397: Air Conditioner Maintenance
396 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked posi- tive (+) and negative (-) and are identified on the battery case.
Page 398: Body Lubrication
WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Warranty Information Book, located on the DVD, for further warranty information.
Page 399: Windshield Wiper Blades
398 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated. The external lock cylinders should be lubricated twice a year, preferably in the Fall and Spring. Apply a small amount of a high quality lubricant, such as MOPAR Lock Cylinder Lubricant or equivalent directly into the lock cylinder.
Page 400: Exhaust System
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 401 400 MAINTAINING YOUR VEHICLE CAUTION! • The catalytic converter requires the use of un- leaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emissions con- trol device and may seriously reduce engine per- formance and cause serious damage to the engine. •...
Page 402: Cooling System
To minimize the possibility of catalytic converter dam- age: • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in motion. • Do not try to start the engine by pushing or towing the vehicle.
Page 403 402 MAINTAINING YOUR VEHICLE Coolant Checks Check engine coolant (antifreeze) protection every 12 months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or rusty in appearance, the system should be drained, flushed and refilled with fresh engine coolant (anti- freeze).
Page 404 CAUTION! • Mixing of engine coolant (antifreeze) other than specified Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion pro- tection. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emer- gency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
Page 405 404 MAINTAINING YOUR VEHICLE When adding engine coolant (antifreeze), a minimum solution of 50% recommended MOPAR Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology), or equivalent, in water should be used. Use higher concentrations (not to exceed 70%) if temperatures below 34°F ( 37°C) are antici- pated.
Page 406 WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add engine coolant (antifreeze) when the engine is overheated. Do not loosen or remove the cap to cool an overheated engine. Heat causes pressure to build up in the cooling system.
Page 407 406 MAINTAINING YOUR VEHICLE long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month. When additional engine coolant (antifreeze) is needed to maintain the proper level, it should be added to the coolant bottle.
Page 408: Brake System
• Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean. • Do not change the thermostat for Summer or Winter operation. If replacement is ever necessary, install ONLY the correct type thermostat.
Page 409 408 MAINTAINING YOUR VEHICLE when the pads are replaced. However, low fluid level may be caused by a leak and a checkup may be needed. NOTE: If your vehicle is equipped with a manual transmission , the brake fluid reservoir supplies fluid to both the brake system and the clutch release system.
Page 410 WARNING! (Continued) • To avoid contamination from foreign matter or moisture, use only new brake fluid or fluid that has been in a tightly closed container. Keep the master cylinder reservoir cap secured at all times. Brake fluid in a open container absorbs moisture from the air resulting in a lower boiling point.
Page 411: Automatic Transmission (Cvt) - If Equipped
410 MAINTAINING YOUR VEHICLE Automatic Transmission (CVT) – If Equipped Selection Of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor- mance. Use only the manufacturer’s recommended trans- mission fluid which has been formulated with special metal to metal friction coefficient additives to provide the proper steel belt traction on the drive and driven pulleys.
Page 412: Manual Transmission - If Equipped
Special Additives Do not add any materials (other than leak detection dyes) to Continuously Variable Transmission (CVT) Fluid (CVTF+4 ). CVTF+4 is an engineered product and its performance may be impaired by supplemental additives. Manual Transmission – If Equipped Lubricant Selection Use only the manufacturers recommended transmission fluid.
Page 413 412 MAINTAINING YOUR VEHICLE hot or cold weather and other extreme conditions will have an adverse effect on paint, metal trim, and under- body protection. The following maintenance recommendations will enable you to obtain maximum benefit from the corrosion resistance built into your vehicle. What Causes Corrosion? Corrosion is the result of deterioration or removal of paint and protective coatings from your vehicle.
Page 414 CAUTION! • Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces. • Use of power washers exceeding 1,200 psi (8 274 kPa) can result in damage or removal of paint and decals.
Page 415 414 MAINTAINING YOUR VEHICLE Wheel And Wheel Trim Care All wheels and wheel trim, especially aluminum and chrome-plated wheels, should be cleaned regularly with a mild soap and water to prevent corrosion. To remove heavy soil, use MOPAR Wheel Cleaner or select a nonabrasive, non-acidic cleaner.
Page 416 Your leather upholstery can be best preserved by regular cleaning with a damp, soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and MOPAR Total Clean or equivalent.
Page 417 416 MAINTAINING YOUR VEHICLE Glass Surfaces All glass surfaces should be cleaned on a regular basis with MOPAR Glass Cleaner or any commercial household-type glass cleaner. Never use an abrasive type cleaner. Use caution when cleaning the inside rear win- dow equipped with electric defrosters or the right rear quarter window equipped with the radio antenna.
Page 418: Fuses
Seat Belt Maintenance Do not bleach, dye or clean the seat belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the seat belts need cleaning, use a mild soap solution or lukewarm water.
Page 419 418 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse Empty 15 Amp Lt Blue 10 Amp 10 Amp 20 Amp Yellow 10 Amp 30 Amp Green 30 Amp Green Description Cavity Cartridge Empty AWD/4WD ECU Feed CHMSL Brake Switch Feed Ignition Switch Feed/ Trailer Tow IOD Sw/Pwr Mir/...
Page 420 Cavity Cartridge Mini- Fuse Fuse 15 Amp IGN Run/Acc Dome Lt Blue Lamp/Sunroof/Rear Wiper Motor/ACC Inverter 10 Amp IOD Feed Mod-Wcm 40 Amp ASD Relay Contact Green PWR Feed 20 Amp PWR Amp 1 & Amp Yellow 2 Feed 15 Amp IOD Feed Radio Lt Blue 10 Amp...
Page 421 420 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Fuse Fuse 10 Amp 30 Amp Pink 10 Amp 30 Amp Pink 40 Amp Green 30 Amp Pink 25 Amp Natural Description • When installing the IPM cover, it is important to Headlamp Washer ensure the cover is properly positioned and fully Relay Control –...
Page 422: Vehicle Storage
VEHICLE STORAGE If you will not be using your vehicle for more than 21 days, you may want to take steps to preserve your battery. • Disengage the mini-fuse in the Power Distribution Center labeled IOD (Ignition Off-Draw). • Disconnect the negative cable from the battery. REPLACEMENT BULBS All the inside bulbs are brass or glass wedge base.
Page 423: Rear Tail, Turn Signal, And Backup Lamps
422 MAINTAINING YOUR VEHICLE Rear Tail, Turn Signal, and Backup Lamps 1. Remove the two push-pins from the tail lamp housing. 2. Grasp the tail lamp and pull firmly to disengage the lamp from the aperture panel.
Page 424 MAINTAINING YOUR VEHICLE 423 3. Twist and remove socket from the lamp. 4. Remove the bulb from the socket and replace.
Page 425: License Lamps
424 MAINTAINING YOUR VEHICLE License Lamps 2. Rotate the socket 1/4 turn counterclockwise. 1. Use a screw driver to gently pry against the side of the snap tab to remove the lamp from the liftgate.
Page 426: Center High-Mounted Stoplamp
MAINTAINING YOUR VEHICLE 425 3. Pull the bulb from the socket. Center High-Mounted Stoplamp The lamp is an LED assembly. See your authorized dealer for replacement.
Page 427: Fluid Capacities
426 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 2.0L and 2.4L Engine (SAE 5W-20, API Certified) Cooling System * 2.0L and 2.4L Engine (MOPAR Engine Coolant/Antifreeze 5 Year/100,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level. U.S.
Page 428: Fluids, Lubricants, And Genuine Parts
FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 429: Chassis
428 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission (CVT) – If Equipped Manual Transmission – If Equipped MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR CVTF + 4 ATF+4 product.
Page 430: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..430 Maintenance Schedule ....430 Required Maintenance Intervals ..432...
Page 431 430 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 432 oil if it has been six months since your last oil change and even if the oil change indicator message is NOT illuminated. • Change your engine oil more often if you drive your vehicle off-road for an extended period of time. •...
Page 433 432 MAINTENANCE SCHEDULES • Check all lights and other electrical items for correct operation. At Each Oil Change • Change the engine oil filter. • Inspect the brake hoses and lines. • Check the manual transmission fluid level. CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
Page 434 6,000 Miles (10,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 12,000 Miles (20,000 km) or 12 Months Maintenance Service Schedule ❏...
Page 435: Service Schedule
434 MAINTENANCE SCHEDULES 18,000 Miles (30,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 24,000 Miles (40,000 km) or 24 Months Maintenance Service Schedule ❏...
Page 436 30,000 Miles (50,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs. ❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
Page 437 436 MAINTENANCE SCHEDULES 42,000 Miles (70,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 48,000 Miles (80,000 km) or 48 Months Maintenance Service Schedule ❏...
Page 438 54,000 Miles (90,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 60,000 Miles (100,000 km) or 60 Months Maintenance Service Schedule ❏...
Page 439 438 MAINTENANCE SCHEDULES 66,000 Miles (110,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 72,000 Miles (120,000 km) or 72 Months Maintenance Service Schedule ❏...
Page 440 78,000 Miles (130,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 84,000 Miles (140,000 km) or 84 Months Maintenance Service Schedule ❏...
Page 441 440 MAINTENANCE SCHEDULES 90,000 Miles (150,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs. ❏ Inspect and replace PCV valve if necessary.
Page 442 102,000 Miles (170,000 km) or 102 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Flush and replace the engine coolant. ❏ Flush and replace the engine coolant if not done at 60 months. Odometer Reading Date Repair Order #...
Page 443 442 MAINTENANCE SCHEDULES 114,000 Miles (190,000 km) or 114 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 120,000 Miles (200,000 km) or 120 Months Maintenance Service Schedule ❏...
Page 444 126,000 Miles (210,000 km) or 126 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer 132,000 Miles (220,000 km) or 132 Months Maintenance Service Schedule ❏...
Page 445 444 MAINTENANCE SCHEDULES 138,000 Miles (230,000 km) or 138 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. Odometer Reading Repair Order # Dealer Code Signature Authorized Chrysler Dealer 144,000 Miles (240,000 km) or 144 Months Maintenance Service Schedule ❏...
Page 446 150,000 Miles (250,000 km) or 150 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate tires. ❏ Replace the engine air cleaner filter. ❏ Replace the spark plugs. ❏ Adjust the parking brake on vehicles equipped with four-wheel disc brakes.
Page 448 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle......449 Prepare For The Appointment .
Page 449 448 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....453 Department Of Transportation Uniform Tire Quality Grades ......454 Treadwear .
Page 450: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 451: 450 If You Need Consumer Assistance
450 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 452: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 453: Warranty Information
452 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 454: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 455: Quality Grades
454 IF YOU NEED CONSUMER ASSISTANCE vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts. • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 456: Traction Grades
in each category is shown on the sidewall of the tires on your vehicle. All passenger car tires must conform to Federal safety requirements in addition to these grades. Treadwear The Treadwear grade is a comparative rating, based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 457 456 IF YOU NEED CONSUMER ASSISTANCE grade C corresponds to a level of performance, which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A repre- sent higher levels of performance on the laboratory test wheel, than the minimum required by law.
Page 458: Index
INDEX...
Page 459 458 INDEX ABS (Anti-Lock Brake System) ....304 Adding Engine Coolant (Antifreeze) ..403 Adding Fuel ......346 Adding Washer Fluid .
Page 460 Overheating ......368 Selection Of Lubricant ....410 Shifting .
Page 461 460 INDEX Cargo Light ......174 Cargo Load Floor ......177 Cargo Tie-Downs .
Page 462 Disposal of Used Coolant ....405 Drain, Flush, and Refill ....402 Inspection .
Page 463 462 INDEX Traction Control System ....308 Electronic Speed Control (Cruise Control) Electronic Stability Program (ESP) ... . 310 Electronic Vehicle Information Center (EVIC) .
Page 464 Flat Tire Stowage ......373 Flooded Engine Starting ....287 Fluid, Brake .
Page 465 464 INDEX Gauges Coolant Temperature ....188 Fuel ....... 189 Odometer .
Page 466 Ignition Key Removal ..... 12 Immobilizer (Sentry Key) ....14 Infant Restraint .
Page 467 466 INDEX Alarm ......197 Anti-Lock ......201 Back-Up .
Page 468 Lubrication, Body ..... . . 397 Lumbar Support ......130 Maintenance Free Battery .
Page 469 468 INDEX Change Interval ..... . . 392 Checking ......391 Disposal .
Page 470 Radial Ply Tires ......326 Radio Operation ......267 Radio, Satellite (Uconnect studios) .
Page 471 470 INDEX Schedule, Maintenance ....430 Seat Belt Maintenance ....417 Seat Belt Reminder .
Page 472 Slippery Surfaces, Driving On ....296 Snow Chains (Tire Chains) ....331 Snow Tires .
Page 473 472 INDEX Tie Down Hooks, Cargo ....177 Tilt Steering Column ..... 150 Tire and Loading Information Placard .
Page 474 Towing Assistance ..... . . 110 Traction ......296 Trailer Towing .
Page 475 474 INDEX Vehicle Identification Number (VIN) ... . 6 Vehicle Loading ....320,348,350 Vehicle Modifications/Alterations .
Page 476 Chrysler Group LLC 10PM491-126-AB Printed in U.S.A. 2nd Edition...

Dodge 2010 Caliber Owner's Manual

Caliber

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

Quick Links

Chapters

Related Manuals for Dodge 2010 Caliber

Summary of Contents for Dodge 2010 Caliber
