Page 1: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 INTRODUCTION Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5: Warnings And Cautions
This number also appears on the Automobile Information Disclosure Label affixed to a window on your vehicle. Save this label for a convenient record of your vehicle identification number and optional equipment.
Page 7 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....10 Key-In-Ignition Reminder ....10 Sentry Key —...
Page 8 8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Security Alarm System — If Equipped ..26 To Set The Alarm ..... .27 To Disarm The System .
Page 9: Things To Know Before Starting Your Vehicle
Exhaust System ..... . .75 Safety Checks You Should Make Inside The Vehicle ......76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 9 Safety Checks You Should Make Outside The Vehicle .
Page 10: Things To Know Before Starting Your Vehicle 7
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The double sided keys may be inserted into the locks with either side up. The keys for your new vehicle are enclosed in a plastic bag with a bar code label affixed to the front.
Page 11: Replacement Keys
on the remaining transmitters will work. If the vehicle is moving 5 mph or more, then all the transmitter buttons are disabled for all keys. NOTE: The Sentry Key Immobilizer System is not compatible with remote starting systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 12 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE consists of programming a blank key to the vehicle electronics. A blank key is one which has never been programmed and needs to be cut. NOTE: When having the Sentry Key System serviced, bring all vehicle keys to the dealer.
Page 13: Ignition And Steering Lock
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Changes or modifications not expressly ap- NOTE: proved by the party responsible for compliance could void the user’s authority to operate the equipment. IGNITION AND STEERING LOCK In the LOCK position, the steering and ignition systems are locked to provide anti-theft protection for your ve- hicle.
Page 14: Ignition Accessory Delay Feature
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! The key cannot be turned to LOCK until the selector is in the PARK position. Do not attempt to pull the shift lever out of PARK after the key is in the LOCK position.
Page 15: Door Locks
DOOR LOCKS Manual Door Locks All the doors can be “manually” locked from the inside by pushing down the door lock plunger, located at the rear of the door. Both front doors may be opened from the inside with the door lock plunger in the down or locked position.
Page 16: Power Door Locks
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks Power Door Lock Switches Power Door Lock Switch Operation Vehicles equipped with power door locks can be locked or unlocked from inside by either the use of the door lock switches located on the front doors or by pressing the LOCK or UNLOCK buttons on the Remote Keyless Entry key fob.
Page 17 As a safety feature the doors will not lock when using the door lock switches during the following conditions: • The driver’s door is open while the key is in the ignition. Automatic Door Locks If this feature is enabled, your door locks will lock automatically when the vehicle’s speed exceeds 15 mph (24 km/h).
Page 18 18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE occur only after the vehicle has been shifted into the Park position after the vehicle has been driven (shifted out of Park and all doors closed). This feature will not operate if there is any manual operation of the power door locks (Lock or Unlock).
Page 19: Child Protection Door Lock
Child Protection Door Lock To provide a safer environment for children riding in the rear seat, the rear doors of your vehicle have the child- protection door lock system. Child Lock Location THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 Child Lock Details To use the system, open each rear door and slide the control UP to engage the locks and DOWN to disengage...
Page 20: Remote Keyless Entry
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the child protection locks are engaged. NOTE: After setting the child protection door lock system, always test the door from the inside to make certain it is in the desired position.
Page 21: To Unlock The Doors And Liftgate
NOTE: Your vehicle’s keyfob may have three, four or five buttons (shown), depending on the optional features purchased with your vehicle. This system allows you to lock or unlock the doors and liftgate or activate the panic alarm from distances a minimum of 66 feet (20 meters) using a hand held radio transmitter.
Page 22: To Lock The Doors And Liftgate
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. If the desired programming was not achieved or to reactivate this feature, repeat the above steps. To lock the doors and liftgate: Press and release the LOCK button on the key fob to lock all doors and liftgate.
Page 23: Using The Panic Alarm
Flash Lamps with Lock Programming 1. Press and hold the UNLOCK button on the key fob. 2. After holding the UNLOCK button for four seconds, also press the LOCK button within 6 seconds. A single chime will sound to indicate that this feature has changed.
Page 24: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information This device complies with part 15 of FCC rules and with RS-210 of Industry Canada. Operation is subject to the following conditions: 1. This device may not cause harmful interference. 2.
Page 25 2. Fasten your seat belt (Fastening the seatbelt will cancel any chiming that may confuse you during this program- ming procedure). 3. Place the key into the ignition. 4. Turn the ignition to the ON position ( Do not start the engine ).
Page 26: Battery Replacement
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Battery Replacement The recommended replacement battery is CR2032. 1. If the key fob is equipped with a screw, remove the screw. With the transmitter buttons facing down, use a flat blade to pry the two halves of the transmitter apart. Make sure not to damage the elastomer seal during removal.
Page 27: To Set The Alarm
To Set the Alarm: The alarm will set when you use the power door locks or use the Keyless Entry transmitter to lock the doors. After all the doors are locked and closed the security light in the instrument cluster will flash rapidly to signal that the system is arming.
Page 28: Remote Starting System - If Equipped
Key into the ignition and turning the key to the ON position. REMOTE STARTING SYSTEM — IF EQUIPPED Your Dodge Durango may be equipped with a remote starting system, which will allow the vehicle to be started up to 300 feet away from the vehicle using the remote keyless entry key fob which is part of your ignition key.
Page 29: Liftgate
To enter the vehicle while the engine is running during a remote start, you must first unlock the vehicle using the UNLOCK button on the key fob. After the vehicle is unlocked, you have 60 seconds to enter the vehicle, insert the key in the Ignition and move it to the RUN position, otherwise the engine will cancel remote start and auto- matically turn off.
Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: When the engine is running from a Remote Start (if equipped), the vehicle must first be unlocked by pressing the keyfob UNLOCK button prior to activating the Power Liftgate otherwise the engine will stop auto- matically.
Page 31: Power Liftgate - If Equipped
Power Liftgate — If Equipped The power liftgate may be opened manually or by using the button on the remote keyless entry transmitter. Press the button on the remote keyless entry transmitter twice within five seconds, to open the power liftgate. Once the liftgate is fully open, pressing the button twice within five seconds a second time will close the liftgate.
Page 32 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! During power operation, personal injury or cargo damage may occur. Ensure the liftgate travel path is clear. Make sure the liftgate is closed and latched before driving away. A beeping signal will sound two seconds before the liftgate starts to open or close.
Page 33 (65° C). Be sure to remove any buildup of snow or ice from the liftgate before pressing any of the power liftgate switches. • If the power liftgate encounters multiple obstructions within the same cycle, the system will automatically stop and must be opened or closed manually. •...
Page 34: Windows
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows Power Window Switches Power Window Switches The control on the left front door has up-down switches that give you finger tip control of all four power win- dows. There is a single opening and closing switch on the passenger doors for passenger window control.
Page 35: Auto Down
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 ignition is turned OFF or the driver’s door is opened. This feature can be turned off by your authorized dealer. NOTE: The Power Accessory Delay feature will allow the power windows to operate for ten minutes after the ignition it turned OFF.
Page 36: Occupant Restraints
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, knee bolsters, front airbags for both the driver and front passenger, and if equipped left and right side curtain airbags for the driver and passengers seated next to a window.
Page 37: Lap/Shoulder Belts
of ejection and the risk of injury caused by striking the inside of the vehicle. Everyone in a motor vehicle should be belted at all times. Lap/Shoulder Belts All seating positions in your vehicle have combination lap/shoulder belts. The belt webbing retractor is de- signed to lock during very sudden stops or collisions.
Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of a collision the best.
Page 39 plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to allow the belt to go around your lap. Removing Slack From Belt 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.”...
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 41: Adjustable Upper Shoulder Belt Anchorage
6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 42: Second Row Center Seat Belt
42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in the desired position.
Page 43: Rear 60/40 Seat Third Row Center Three Point Belt - If Equipped
Rear 60/40 Seat Third Row Center Three Point Belt — If Equipped The center three point seat belt for the third row rear seat may be disconnected to allow the 60% seat back to easily fold down. The keyed-buckle latch plate (small latch plate at the end of the belt) can be detached from the keyed seat belt buckle (buckle without a red release button) located on the left inboard side of the third row...
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To reattach the seat belt to the third row center seat, pull the small (keyed buckle) latch plate forward from the headliner slots and insert it into the keyed buckle until there is an audible click. Refer to the previous section for the proper seat belt usage.
Page 45: Seat Belt Pretensioners
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove any slack from the seat belt system in the event of a collision.
Page 46: Enhanced Driver Seat Belt Reminder System (Beltalert)
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Driver Seat Belt Reminder System (BeltAlert) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the Enhanced Warning System (BeltAlert) will alert the driver to buckle their seat belt.
Page 47: Seat Belts And Pregnant Women
buckled. A chime will sound immediately (once the feature has toggled). If during this time the ignition switch is turned out of the ON position or the timer expires, programming mode will be cancelled. 4. Programming mode will be cancelled after the feature has toggled with the seat belt still buckled or if the ignition switch is turned to the lock position or 10 seconds after the feature has toggled.
Page 48: Driver And Right Front Passenger Supplemental Restraint System (Srs)-Airbags
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use the seat belt extender when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 49 the instrument panel, above the glove compartment. The words SRS/AIRBAG are embossed on the airbag covers. NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size.
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger. Window bags also work with seat belts to improve occupant protection.
Page 51 4. If your vehicle has window bags, do not lean against the door or window, airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center.
Page 52 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag System Components The airbag system consists of the following: • Occupant Restraint Controller • Side Remote Acceleration Sensors (If Equipped) • Airbag Warning Light • Driver Airbag • Passenger Airbag •...
Page 53 The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or RUN positions. These include all of the items listed above except the steering wheel and column, and knee bolsters. If the key is in the OFF position, in the ACC position, or not in the ignition, the airbags are not on and will not inflate.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: Children 12 years and under should always ride buckled up in a rear seat in an appropriate child restraint. • The Passenger Airbag Disable (PAD) Indicator Light (an amber light located in the center of the instrument panel) tells the driver and front passenger when the front passenger airbag is turned off.
Page 55 adult passenger is properly seated in the front passen- ger seat. In this case, the air bag is ready to be inflated if a collision requiring an airbag occurs. For almost all properly installed rear facing child re- straints, the PAD indicator light will be illuminated indicating that the front passenger airbag is turned off and will not inflate.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE will cause the system to turn the airbag on. In this case, the OCS has classified the occupant of the seat as an adult. An adult occupant needs to sit in a normal position (with their feet on or near the floor) in order to be properly classified.
Page 57 sensors, a fault will occur which turns on both the PAD Indicator Light and the Airbag Warning Light. Once the lodged object is removed, the fault will be automatically cleared after a short period of time. • The Driver and Passenger Airbag/Inflator Units are located in the center of the steering wheel and the right side of the instrument panel.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The Side Impact SRS Window Bags are designed to activate only in certain side collisions. When the ORC (with side impact option) detects a collision requiring the window bags to inflate, it signals the inflators on the crash side of the vehicle.
Page 59 • Do not replace the seat cover with an aftermarket seat cover. • Do not add a secondary seat cover other than those approved by DaimlerChrysler/Mopar. • At no time should any supplemental restraint system (SRS) component or SRS related component or fas- tener be modified or replaced with any part except those which are approved by DaimlerChrysler/ Mopar.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: A frontal collision that is not severe enough to need airbag protection will not activate the system. This does not mean something is wrong with the airbag system. If you do have a collision which deploys the airbags, any or all of the following may occur: •...
Page 61 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 62: Event Data Recorder (Edr)
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The light flickers or comes on and remains on while driving. NOTE: If the speedometer, tachometer or any engine related gauges are not working, the airbag control mod- ule may also be disabled. The airbags may not be ready to inflate for your protection.
Page 63 may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states. Data of a potentially sensitive nature, such as would identify a particular driver, ve- hicle, or crash, will be treated confidentially. Confidential data will not be disclosed by DaimlerChrysler Corpora- tion to any third party except when: 1.
Page 64: Child Restraint
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Child Restraint Everyone in your vehicle needs to be buckled up all the time - babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 65 LATCH child restraint anchorage system. (See the LATCH - Child Seat Anchorage System section.) • Rearward-facing child seats must NEVER be used in the front seat of a vehicle with a front passenger airbag. An airbag deployment could cause severe injury or death to infants in this position.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If the shoulder belt contacts the face or neck, move the child closer to the center of the vehicle. Never allow a child to put the shoulder belt under an arm. WARNING! •...
Page 67 lap/shoulder belt will tighten the belt. The cinching latch plate will keep the belt tight, however, any seat belt system will loosen with time, so check the belt occasionally and pull it tight if necessary. If the seat belt has a automatic locking retractor, it will have a distinctive label.
Page 68 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE restraints, many child restraint manufacturers offer add-on tether strap kits or retro-fit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle. All three second row seating positions have lower an- chorages that are capable of accommodating LATCH- compatible child seats having flexible, webbing-mounted...
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Installing the LATCH-Compatible Child Restraint System We urge that you carefully follow the directions of the manufacturer when installing your child restraint. Not all child restraint systems will be installed as described here. Again, carefully follow the installation instructions that were provided with the child restraint system.
Page 70 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap. You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 71 WARNING! Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint. Installing Child Restraints Using the Vehicle Seat Belt The second and third row seats have either cinching latch...
Page 72 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Second Row Seat Tether Anchors...
Page 73 Child Restraints in Third Row Seating (If Equipped) The third seating row is not capable of installing child restraints that require the use of a tether strap. There are no tether anchor provisions for the third seating row in your vehicle, the hooks in the rear floor are not designed to withstand the forces that may occur during a crash.
Page 74: Engine Break-In Recommendations
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! An incorrectly anchored tether strap could lead to seat failure and injury to the child. In a collision, the seat could come loose and allow the child to crash into the inside of the vehicle or other passengers, or even be thrown from the vehicle.
Page 75: Safety Tips
A new engine may consume some oil during its first few thousand miles of operation. This is a normal part of the break-in and is not an indication of difficulty. SAFETY TIPS Exhaust System WARNING! Exhaust gases contain carbon monoxide, an ex- tremely toxic gas that by itself is colorless and odorless.
Page 76: Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after an accident if they have been damaged (bent retractor, torn webbing, etc.).
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Fluid Leaks Check the area under vehicle after overnight parking for fuel, water, oil, or other fluid leaks. Also, if gasoline fumes are detected, the cause should be located and corrected.
Page 79: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......84 Inside Day/Night Mirror ....84 Automatic Dimming Mirror —...
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Seats ....... . 111 Front Seat Manual Seat Adjustment .
Page 81 Automatic Headlights — If Equipped ..133 Headlights, Parking Lights, Panel Lights ..134 Illuminated Entry ..... 134 Daytime Running Lights (Canada Only) .
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electronic Brake Control System ... . 146 ABS (Anti-Lock Brake System) ... . 146 BAS (Brake Assist System) –...
Page 83 Canadian Programming/Gate Programming . . 166 Using HomeLink ..... 166 Erasing HomeLink Buttons ....166 Reprogramming a Single HomeLink Button .
Page 84: Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Inside Day/Night Mirror The mirror should be adjusted to center on the view through the rear window. A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Day/Night Mirror Annoying headlight glare can be reduced by moving the small control under the mirror to the night position (toward rear of truck).
Page 85: Outside Mirrors
Automatic Dimming Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight...
Page 86: Electric Remote-Control Mirrors
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Electric Remote-Control Mirrors The controls for the power mirrors are located on the driver’s door trim panel. Remote Control Mirrors Switch Mirror Directions To adjust a mirror, turn the control wand toward the left or right mirror positions indicated.
Page 87: Illuminated Vanity Mirrors - If Equipped
WARNING! Vehicles and other objects seen in the right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the right side mirror.
Page 88: Automatic Dimming Driver's Exterior Mirror - If Equipped
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE that the heating elements are ON. Turning Off the rear window defroster or the ignition will deactivate the heated mirrors. Automatic Dimming Driver’s Exterior Mirror — If Equipped This mirror will automatically adjust for annoying light glare from vehicles behind you.
Page 89 that enables different electronic devices to connect to each other without wires or a docking station, so UCon- nect works no matter where you stow your cellular phone (be it your purse, pocket, or briefcase), as long as your phone is turned on and has been paired to the vehicle’s UConnect™...
Page 90: Operations
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headset Profile), you may not be able to use any UCon- nect™ features. Refer to your cellular service provider or the phone manufacturer for details. The UConnect™ system is fully integrated with the vehicle’s audio system.
Page 91 To complete the pairing process, you will need to refer- ence your cellular phone owner’s manual. One of the following vehicle specific websites may also provide detailed instructions for pairing with the brand of phone that you have: NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect...
Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing. • When prompted, after the voice on beep, say Pair a Phone.
Page 93 Dial by Saying a Number • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Dial. • System will prompt you to say the number you want call. • For example, you can say 234-567-8901. The phone number that you enter must be of valid length and combination.
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Add Names to Your UConnect™ Phonebook NOTE: Adding names to phonebook is recommended when vehicle is not in motion. • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Phonebook New Entry.
Page 95 • You will then be asked for the name of the phonebook entry that you wish to edit. • Next, choose the number designation (home, work, mobile, or pager) that you wish to edit. • When prompted, recite the new phone number for the phonebook entry that you are editing.
Page 96 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After you enter the name, the UConnect™ system will ask you which designation you wish to delete: home, work, mobile or pager. Say the designation you wish to delete. • Note that only the phonebook entry in the current language is deleted.
Page 97: Phone Call Features
Phone Call Features The following features can be accessed through the UConnect™ system if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the UConnect™ system. Check with your cellular service provider for the features that you have.
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE second call is in progress. To go back to the first call, refer to Toggling Between Calls. To combine two calls, refer to Conference Call. Place/Retrieve a Call from Hold To put a call on hold, press the Phone’ button until you hear a single beep which will indicate that the call has been placed on hold.
Page 99: Uconnect™ System Features
Redial • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Redial. • The UConnect™ system will call the last number that was dialed on your cellular phone. Note: this may not be the last number dialed from the UConnect™ sys- tem.
Page 100 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say the name of the language you wish to switch to (English, Espanol, or Francais, if so equipped). • Continue to follow the system prompts to complete language selection.
Page 101 emergency situations when the cell phone has network coverage and stays paired to the UConnect™ system. Towing Assistance If you need towing assistance, • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Towing Assistance.
Page 102 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When calling a number with your UConnect™ system that normally requires you to enter in a touch-tone sequence on your cellular phone keypad, you can push the ’Voice Recognition’ button and say the sequence you wish to enter followed by the word Send.
Page 103 Dialing Using the Cellular Phone Keypad You can dial a phone number with your cellular phone keypad and still use the UConnect™ system (while dialing via the cell phone keypad, the user must exercise caution and take precautionary safety measures). By dialing a number with your paired Bluetooth™...
Page 104: Advanced Phone Connectivity
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Information Service When using AT&T Wireless Service, dialing to phone number #121, you can access voice activated automated system to receive news, weather, stocks, traffic, etc. related information. Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect™...
Page 105 Select another Cellular Phone This feature allows you to select and start using another phone with the UConnect™ system. The phone must have been previously paired to the UConnect™ system that you want to use it with. • Press the ’Phone’ button to begin. •...
Page 106: Things You Should Know About Your Uconnect™ System
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition’ button anytime while the list is being played and say the priority number of the phone you wish to delete. Things You Should Know About Your UConnect™ System Voice Recognition (VR) •...
Page 107 • UConnect™ phonebook name tag recognition rate is optimized for the voice of the person who stored the name in the phonebook. • You can say O (letter O ) for 0 (zero). 800 must be spoken eight-zero-zero. • Even though international dialing for most number combinations is supported, some shortcut dialing number combinations may not be supported.
Page 108 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109...
Page 110 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 111: Seats
North American English Primary Alternate(s) Zero Add location Add new All of them Confirmation prompts Confirmations prompts Delete a name Delete Language Select language List names List all List paired phones List phones Pager Beeper Phone pairing Pairing Phonebook Phone book Return to main menu Return.
Page 112: Front Seats Manual Seat Recliners
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Seat Adjuster WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 113: Manual Lumbar Support Adjustment - If Equipped
WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 114: Way Driver's Power Seat - If Equipped
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To lower the head restraint, depress the release button located at the base of the head restraint and push down on the head restraint. Head Restraint Adjustment 8 - Way Driver’s Power Seat — If Equipped The driver power seat switches are located on the left side of the driver seat lower side trim.
Page 115: Way Passenger's Power Seat - If Equipped
4 - Way Passenger’s Power Seat — If Equipped The front passenger’s power seat switches are located on the right side of the passenger seat lower side trim. The bottom switch controls forward/rearward adjustment. The top switch controls the seatback recline adjustment. NOTE: The 4 - way seat does not have an up/down adjustment.
Page 116 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE passenger to select from two different levels of supple- mental electrical seat heating, or no seat heating to suit their individual comfort requirements. With the ignition switch in the RUN position, depressing the heated seat switch rocker to its momentary High or Low position provides power to the heated seat element and maintains the requested temperature setting.
Page 117: Second Row 40/20/40 Seat - Fold And Tumble
WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion or other physical condition must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.
Page 118 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE be folded into the down position for use as a cargo floor, or the seat can now be tumbled forward to allow access to the rear of the vehicle. To fold the 20% seatback, pull the strap forward to release the seatback.
Page 119 WARNING! Do not drive the vehicle with the outer 40% second row seats in the tumbled position. The outer 40% second row seats are only intended to be tumbled for entry and exit to the third row seat. Failure to follow these instructions could result in personal injury.
Page 120: Third Row Seat Bench - If Equipped
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Third Row Seat Bench — If Equipped To Fold The Seats Folding the third seat occurs in two stages: First the cushion is lifted and moved forward from the pockets at the front of the cushion. The cushion will rest onto the floor directly behind the second row seat.
Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Seat Cushion Movement Up And Forward Rear Seat Folded To Achieve Maximum Cargo Capacity Pull the release handles and strap on the second row seats and fold flat. After folding the third row seat, unsnap the flipper panel on the third row seatback and flip it forward on the backs of the second row seats.
Page 122: Third Row 60/40 Folding - If Equipped
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Before returning the second row 40% seats to their upright position, always snap the third row seat flipper panel(s) back to the third row seat first. NOTE: The seat belt buckles are hinged to fold with the seat back.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Third Row Seat 40% Seatback Folded Down Third Row Seat Features...
Page 124 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Third Row Seat Folded Forward Third Row Seat Return Pull Strap...
Page 125: Driver Memory System - If Equipped
DRIVER MEMORY SYSTEM — IF EQUIPPED Once programmed, the memory buttons 1 and 2 on the driver’s door panel can be used to recall the driver’s seat position, driver’s outside mirror position, adjustable brake and accelerator pedals position, Automatic Tem- perature Control (ATC) temperature and radio station preset settings.
Page 126: Setting Memory Positions And Linking Remote
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Setting Memory Positions and Linking Remote Keyless Entry Transmitter to Memory NOTE: Each time the SET (S) button and a numbered button (1 or 2) are pressed, you erase the memory settings for that button and store new settings. 1.
Page 127: Memory Position Recall
Memory Position Recall NOTE: • The driver’s seat belt must be unbuckled to recall memory positions. • The vehicle must be in Park to recall memory posi- tions. • Not all motors may be moved at one time. Please refer to the 8-way power seat description.
Page 128: Self-Limiting Control
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 3. Within 10 seconds, press and release the UNLOCK button on the Remote Keyless Entry transmitter. To disable another transmitter linked to either memory position, repeat steps 1-3 for each transmitter. NOTE: The capability to link Remote Keyless Entry transmitters to memory is enabled when delivered from the factory.
Page 129: To Open And Close The Hood
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 the seat is positioned rearward enough and no benefit from moving the seat any farther rearward. NOTE: The Easy Exit Easy Entry feature is not enabled when delivered from the factory. The Easy Exit Easy Entry feature may be enabled (or later disabled) by a qualified DaimlerChrysler service representative.
Page 130 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Then push the safety latch lever to the left. It is located between the grille and hood opening right of the center. To prevent possible damage, do not slam the hood to close it. Use a firm downward push at the center front edge of the hood to ensure that both latches engage.
Page 131: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 LIGHTS...
Page 132: Interior Lights
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Interior Lights Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the right side of the switch) is rotated to the second upward detent position, or when the UNLOCK button is pressed on the key fob.
Page 133: Headlight Delay
If the headlights remain on while the ignition is cycled off, the exterior lights will automatically turn off after 8 minutes. If the headlights are turned on and left on for 8 minutes while the ignition is off, the exterior lights will automatically turn off.
Page 134: Headlights, Parking Lights, Panel Lights
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights, Parking Lights, Panel Lights When the headlight switch is rotated to the first position to the right, the parking lights, taillights, side marker lights, license plate light and instrument panel lights are all turned on.
Page 135: Lights-On Reminder
Lights-on Reminder If the headlights, parking lights, or courtesy lights are left On, after the ignition is turned Off, a continuous fast chime will sound when the driver’s door is opened. Fog Lights — If Equipped The foglights are turned ON by placing the headlight rotary control in the parking light, headlight, or Auto UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 position and pressing the fog light button.
Page 136: Turn Signals
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals Move the lever up or down to signal a right-hand or left-hand turn. The arrow on either side of the instrument cluster flashes to indicate the direction of the turn, and proper operation of the front and rear turn signal lights.
Page 137: High Beam / Low Beam Select Switch
High Beam / Low Beam Select Switch Pull the multifunction control lever fully toward the steering wheel to switch the headlights from HIGH or LOW beam. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 Windshield Wipers The wipers and washers are operated by a switch in the multifunction control lever.
Page 138 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE with a variable pause between cycles, desirable. For maximum delay between cycles, rotate the control knob into the upper end of the delay range. The delay interval decreases as you rotate the knob until it enters the LO continual speed position.
Page 139: Windshield Washers
Windshield Washers To use the washer, push in on the washer knob on the end of the multifunction control lever and hold while spray is desired. If the washer knob is depressed while in the delay range, the wiper will operate for several seconds after the washer knob is released.
Page 140: Tilt Steering Column
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE deep snow, sand, or gravel turn the system Off to improve traction. If the vehicle is 4WD, use 4HI position. When the ESP is switched off, the ESP/TCS Indicator light in the instrument cluster comes on.
Page 141: Driver Adjustable Pedals - If Equipped
WARNING! Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped. Be sure it is locked before driving. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 DRIVER ADJUSTABLE PEDALS —...
Page 142: Adjustment
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustment 1. Position the driver seat so that you are at least 10 inches (254 mm) away from the airbag located in the center of the steering wheel. 2. Fasten and adjust the seatbelts. 3.
Page 143: To Activate
To Activate Push the ON/OFF button to the ON position. In the instrument cluster, the word “CRUISE” illuminates when the system is on. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 To Set At A Desired Speed When the vehicle has reached the desired speed, press and release the SET button.
Page 144: To Resume Speed
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Leaving the Speed Control ON when not in use is dangerous. You could accidentally set the system to cause it to go faster than you want. You could lose control and have an accident. Always leave the system OFF when you aren’t using it.
Page 145: To Accelerate For Passing
Functions 3.7L Engage Speed 35 mph (56 km/h) Minimun RESUME Speed 30 mph (50 km/h) ACCEL Increase 2 mph (3km/h) DECEL Decrease 1 mph (2 km/h) Dropout Speed 30 mph (50 km/h) To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed.
Page 146: Electronic Brake Control System
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Speed Control can be dangerous where the system can’t maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control. An accident could be the result. Don’t use Speed Control in heavy traffic or on roads that are winding, icy, snow-covered, or slippery.
Page 147: Bas (Brake Assist System) - If Equipped With Esp
WARNING! • Anti-lock system (ABS) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction afforded. •...
Page 148 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE applies optimum pressure to the brakes. The system applies optimum pressure to the brakes in emergency braking conditions. This can help reduce braking dis- tances. The BAS complements the antilock brake system (ABS). Applying the brakes very quickly results in the best BAS assistance.
Page 149: Tcs (Traction Control System) - If Equipped With Esp
TCS (Traction Control System) – if equipped with This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability.
Page 150: Esp (Electronic Stability Program)
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Many factors, such as vehicle loading, road condi- tions and driving conditions, influence the chance that wheel lift or rollover may occur. • ERM can not prevent all wheel lift or rollovers, especially those that involve leaving the roadway or striking objects or other vehicles.
Page 151 • Understeer - when the vehicle is turning less than appropriate for the steering wheel position. ESP/TCS Indicator Light The ESP/TCS Indicator Light starts to flash as soon as the tires lose traction and the ESP system becomes active. The ESP/TCS Indicator Light also flashes when TCS is active.
Page 152 152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High Range (4WD Models) or 2WD Models This is the normal operating mode for ESP in 4WD high range and in 2WD vehicles. Whenever the vehicle is started or the transfer case (if equipped) is shifted from 4WD low range or neutral back to 4WD high range, the ESP system will be in this mode.
Page 153 situation requiring ESP to be switched to the “Partial Off” mode is overcome, turn ESP on by momentarily depress- ing the “ESP Control Switch”. This may be done with the vehicle is in motion. 4WD Low Range Partial Off This is the normal operating mode for ESP in 4WD low range.
Page 154 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! In the Partial Off mode, the engine torque reduction and stability features are desensitized. Therefore, the enhanced vehicle stability offered by ESP is unavailable. ESP/BAS Warning Lamp and ESP/TCS Indicator Light The malfunction indicator for the ESP is combined with the BAS indicator.
Page 155: Overhead Console
OVERHEAD CONSOLE The overhead console has the following features: • Courtesy Lights • Garage Door Opener — If Equipped • Compass/Temperature Mini-Trip Computer — If Equipped UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 Courtesy/Reading Lights Near the front of the console are two courtesy/reading lights.
Page 156: Compass/Temperature Mini-Trip Computer
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE COMPASS/TEMPERATURE MINI-TRIP COMPUTER This feature allows you to choose between a compass/ temperature display and one of four trip conditions being monitored. US/M Button Use this button to change the display from U.S. to metric measurement units.
Page 157: Global Reset
Global Reset If the RESET button and STEP button are pressed at the same time and held for 3 seconds (you will hear a confirmation beep) and the Global Reset feature will reset the distance to empty (using a default fuel economy value), fuel economy, trip odometer, and elapsed time displays.
Page 158: Average Fuel Economy (Avg Eco)
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Average Fuel Economy (AVG ECO) Shows the average fuel economy since the last reset. This display mode becomes less sensitive to instantaneous changes in fuel consumption as the number of total vehicle miles since the last reset increases. It is suggested that this mode be reset periodically for general operation or when driving conditions change significantly (for example, at the end of a trip or when a trailer is...
Page 159: C/T Button
C/T Button Use this button to select a readout of the outside tem- perature and one of eight compass headings that indicate the direction in which the vehicle is facing. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 Compass/Temperature Display WARNING! Even if the display still reads a few degrees above 32°F ( 0°C), the road surface may be icy, particularly in woods or on bridges.
Page 160: Manual Compass Calibration
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After completing one 360° turn, with the vehicle traveling less than 5 mph (8 km/h), in an area free from large metal or metallic objects, the CAL symbol will turn off and the compass will function normally.
Page 161: Outside Temperature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 To set the variance: Turn the ignition ON and set the display to “Compass/Temperature.” Press and hold the RESET button approximately five seconds. The last vari- ance zone number will be displayed. Press the STEP button to select the new variance zone and press the RESET button to resume normal operation.
Page 162: Garage Door Opener - If Equipped
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED The HomeLink Universal Transceiver replaces up to three remote controls (hand held transmitters) that oper- ate devices such as garage door openers, motorized gates, or home lighting. It triggers these devices at the push of a button.
Page 163: Programming Homelink
WARNING! Vehicle exhaust contains carbon monoxide, a danger- ous gas. Do not run the vehicle’s exhaust while training the transceiver. Exhaust gas can cause seri- ous injury or death. WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate.
Page 164 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Position the end of your hand-held transmitter 1-3 inches (3-8 cm) away from the HomeLink buttons while keeping the indicator light (dots below House Symbol) in view. 3. Simultaneously press and hold both the HomeLink button that you want to train and the hand-held trans- mitter buttons.
Page 165 constantly, programming is complete and your device should activate when the HomeLink button is pressed and released. NOTE: To program the remaining two HomeLink but- tons, begin with Programming step two. Do not repeat step one. If the indicator light blinks rapidly for two seconds and then turns to a constant light, continue with Program- ming steps 6-8 to complete the programming of a rolling code equipped device (most commonly a garage door...
Page 166: Canadian Programming/Gate Programming
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Canadian Programming/Gate Programming Canadian radio-frequency laws require transmitter sig- nals to time-out (or quit) after several seconds of transmission which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U.S.
Page 167: Reprogramming A Single Homelink Button
• Press and hold the two outer HomeLink buttons until the indicator light begins to flash-after 20 seconds. Release both buttons. Do not hold for longer that 30 seconds. HomeLink is now in the train (or learning) mode and can be programmed at any time beginning with Programming - step 2.
Page 168: Power Sunroof - If Equipped
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • This device must accept any interference that may be received including interference that may cause undes- ired operation. NOTE: Changes or modifications not expressly ap- proved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 169: Wind Buffeting
condition until the switch is pushed forward again. To close fully, hold the switch in the forward position until the glass movement has stopped. The sunshade can be opened manually. It will also open as the sunroof opens. The sunshade cannot be closed if the sunroof is open.
Page 170: Sunroof Maintenance
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the rear windows open, open the front and rear windows together to minimize the buffeting. If the buffeting occurs with the sunroof open, adjust the sunroof opening to minimize the buffeting or open any window. Sunroof Maintenance Use only a nonabrasive cleaner and a soft cloth to clean the glass panel.
Page 171: Electrical Outlet Use With Engine Off (Battery Fed Configuration)
Electrical Outlet Use With Engine OFF (Battery Fed Configuration) CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
Page 172: Floor Console
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The fuse block is located in the left side kick panel behind a removable cover near the park brake pedal. A fuse puller is attached to the inside surface of the fuse panel cover to aid in removing fuses, if necessary. FLOOR CONSOLE Floor Console Features The Floor Console between the driver’s and front pas-...
Page 173 The coin slots are located under the instrument panel center stack. Cup Holders The Durango has 8 cupholders. Four are located in the center console, two are located in the second row armrest, and two are located in the left hand quarter panel for UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 third row occupants.
Page 174: Factory Installed Roof Luggage Rack
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE FACTORY INSTALLED ROOF LUGGAGE RACK The load carried on the roof when equipped with a luggage rack must not exceed 68 kg (150 lbs.), and should be uniformly distributed over the cargo area. The side rails between the stantions should be used to tie down cargo.
Page 175 CAUTION! To avoid damage to the roof rack and vehicle, do not exceed the maximum roof rack load capacity. Always distribute heavy loads as evenly as possible and secure the load appropriately. Long loads which extend over the windshield, such as wood panels or surfboards, should be secured to both the front and rear of the vehicle.
Page 176: Cargo Management System-If Equipped
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CARGO MANAGEMENT SYSTEM—IF EQUIPPED The cargo management system consists of a removable cargo liner and removable cargo organizer. Cargo Organizer To open the side cover, pull on the cover latch. To open the organizer base pull on the center latch. To remove the organizer from the vehicle, pull the right hand side of the organizer towards you so that the right pin slides out of the slot in the vehicle.
Page 177: Instrument Panel And Controls
INSTRUMENT PANEL AND CONTROLS CONTENTS Instruments And Controls ....181 Instrument Cluster ..... . 182 Instrument Cluster Description .
Page 178 178 INSTRUMENT PANEL AND CONTROLS Sales Code RAQ – AM/FM/CD (6-Disc) Radio With Optional Satellite Radio, Hands Free Phone, And Vehicle Entertainment Systems (VES) Capabilities ......200 Operating Instructions - Radio Mode .
Page 179 PTY Button Scan ..... 218 PTY Button Seek ..... 219 Satellite Antenna .
Page 180 180 INSTRUMENT PANEL AND CONTROLS Rear Window Features ....237 Rear Window Defrosting ....238 Rear Window Wiper/Washer .
Page 181: Instruments And Controls
INSTRUMENT PANEL AND CONTROLS 181 INSTRUMENTS AND CONTROLS...
Page 182: Instrument Cluster
182 INSTRUMENT PANEL AND CONTROLS Instrument Cluster...
Page 183: Instrument Cluster Description
INSTRUMENT CLUSTER DESCRIPTION 1. Fuel Gage The fuel gauge shows level of fuel in tank when ignition switch is in the ON position. 2. Temperature Gage The temperature gage indicates engine coolant temperature. Any reading within the normal range indicates that the cooling system is operat- ing satisfactorily.
Page 184 184 INSTRUMENT PANEL AND CONTROLS left/right turn signal is left on with the engine RPM vehicle speed greater than 15 mph (24 km/h) for more than one mile. 4. Low Fuel Warning Light This indicator lights when the fuel gauge reads 1/8 of a tank or less.
Page 185 CAUTION! Driving with a hot engine cooling system could damage your vehicle. If the temperature light is on, safely pull over and stop the vehicle. Idle the vehicle in neutral with the air conditioner turned off until the light turns off. If the if the light remains on, turn the engine off immediately, and call for service.
Page 186 186 INSTRUMENT PANEL AND CONTROLS 13. ABS Warning Light This light monitors the Anti-Lock Brake System which is described elsewhere in this manual. This light will come on when the ignition key is turned to the ON position and may stay on for approximately 3 seconds.
Page 187 range (PRND21). If the PRNDL displays only the char- acters PRND21 (no boxes) have the system checked by an authorized dealer. 17. Trip Odometer The trip odometer shows individual trip mileage. To toggle between the odometer and the trip odometer, press the Odometer/Trip Odometer Button.
Page 188 188 INSTRUMENT PANEL AND CONTROLS ESP/TCS Indicator Light also flashes when TCS is active. If the ESP/TCS Indicator Light begins to flash during acceleration, ease up on the accelerator and apply as little throttle as possible. Be sure to adapt your speed and driving to the prevailing road conditions.
Page 189 NOTE: A chime will sound if the vehicle is rolling and a door has been opened. 23. BRAKE System Warning Light The red “BRAKE” warning light will come on when the ignition key is first turned on, and stay on briefly as a bulb check.
Page 190 190 INSTRUMENT PANEL AND CONTROLS driven several miles at speeds greater than 30 mph (48 km/h), see your authorized dealer as soon as possible. NOTE: • The ESP/TCS Indicator Light and the ESP/ BAS Warning Lamp come on momentarily each time the ignition switch is turned ON.
Page 191: Radio Reception Information
27. Airbag Indicator The indicator lights and remains lit for 6 to 8 seconds when the ignition is first turned ON. If the light does not come on when the ignition is first turned on, or the light stays on or comes on while driving, have the airbag system checked by an authorized dealer.
Page 192: Fm Reception
192 INSTRUMENT PANEL AND CONTROLS another. Noise from storms and power lines can also interfere with AM reception. Reducing the treble can reduce some of the noise. FM Reception FM Stereo signals produce better sound quality than AM signals. However, FM signals will only travel approxi- mately 10 to 40 miles (16 to 64 km).
Page 193: Sales Code Ref - Am/Fm/Cd (Single Disc) Radio With Optional Satellite Radio And Hands Free Phone Capability
SALES CODE REF — AM/FM/CD (SINGLE DISC) RADIO WITH OPTIONAL SATELLITE RADIO AND HANDS FREE PHONE CAPABILITY NOTE: The radio sales code is located on the lower right side of your radio faceplate. REF Radio INSTRUMENT PANEL AND CONTROLS 193 Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 194 194 INSTRUMENT PANEL AND CONTROLS Mode Button (Radio Mode) Press the mode button repeatedly to select between the CD player or Satellite Radio (if equipped). SEEK Button (Radio Mode) Press and release the SEEK button to search for the next listenable station in either AM/FM or Satellite (if equipped) mode.
Page 195 Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune/ Audio control. 3. After the hours are adjusted, press the right side Tune/Audio control to set the minutes. The minutes will begin to blink.
Page 196 196 INSTRUMENT PANEL AND CONTROLS Press the rotary TUNE control a fourth time and BAL will be displayed. Turn the TUNE control to the right or left to adjust the sound level from the right or left side speakers. Press the rotary TUNE control a fifth time and FADE will be displayed.
Page 197: Operation Instructions - Cd Mode
Operation Instructions - CD Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Inserting The Compact Disc (Single CD Player) Gently insert one CD into the CD player with the CD label facing up. The CD will automatically be pulled into the CD Player and the CD icon will illuminate on the radio display.
Page 198 198 INSTRUMENT PANEL AND CONTROLS SCAN Button (CD Mode) Press this button to play the first 10 seconds of each track. To stop the scan function, press the button a second time. EJECT Button (CD Mode) Press this button and the disc will unload and move to the entrance for easy removal.
Page 199: Operation Instructions - Auxiliary Mode
Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device such as an MP3 player, cassette player or microphone and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 200: Operating Instructions - Hands Free Phone - If Equipped
200 INSTRUMENT PANEL AND CONTROLS RW/FF (Auxiliary Mode) No function. RND/SET Button (Auxiliary Mode) No function. Mode Button (Auxiliary Mode) Press the mode button repeatedly to select between the CD player or Satellite Radio (if equipped). Operating Instructions - Hands Free Phone — If Equipped Refer to the HANDS FREE PHONE (UConnect™) section of the Owner’s Manual.
Page 201: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping.
Page 202 202 INSTRUMENT PANEL AND CONTROLS will return. Rotating the volume control, turning the radio ON/OFF, or turning OFF the ignition will also return the sound from the speakers NOTE: In Hands Free Phone (if equipped) mode, the MUTE button mutes the microphone. SCAN Button (Radio Mode) Pressing the SCAN button causes the tuner to search for the next listenable station, in either AM, FM or Satellite (if...
Page 203 RW/FF (Radio Mode) Pressing the rewind/fast forward button causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM, FM or Satel- lite (if equipped) frequencies. TUNE Control (Radio Mode) Turn the right side rotary control clockwise to increase or counter-clockwise to decrease the frequency.
Page 204 204 INSTRUMENT PANEL AND CONTROLS turning the TUNE rotary knob within 5 seconds will allow the program format type to be selected. Many radio stations do not currently broadcast PTY information. Toggle the PTY button to select the following format types: 16 Digit-Character Program Type No program type or un-...
Page 205 By pressing the SEEK button when the PTY icon is displayed, the radio will be tuned to the next frequency station with the same selected PTY name. The PTY function only operates when in the FM mode. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
Page 206: Operation Instructions - (Cd Mode For Cd Audio Play)
206 INSTRUMENT PANEL AND CONTROLS Operation Instructions - (CD MODE for CD Audio Play) NOTE: The ignition switch must be in the ON or ACC position to operate the radio. NOTE: Note: This Radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW) compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 207: Load/Eject Button
SEEK Button (CD MODE for CD Audio Play) Press the right side of the SEEK button for the next selection on the CD. Press the left side of the button to return to the beginning of the current selection, or return to the beginning of the previous selection if the CD is within the first 10 seconds of the current selection.
Page 208 208 INSTRUMENT PANEL AND CONTROLS Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc. Press and hold the LOAD/ EJT button for 5 seconds and all CDs will be ejected from the radio. If you have ejected a disc and have not removed it within 15 seconds, it will be reloaded.
Page 209: Notes On Playing Mp3 Files
RND/PTY Button (Random Play Button) (CD MODE for CD Audio Play) Press this button while the CD is playing to activate Random Play. This feature plays the selections on the compact disc in random order to provide an interesting change of pace. Press the SEEK button to move to the next randomly selected track.
Page 210 210 INSTRUMENT PANEL AND CONTROLS • Maximum number of files: 255 • Maximum number of folders: 100 • Maximum number of characters in file/folder names: • Level 1: 12 (including a separator 3-character extension) • Level 2: 31 (including a separator 3-character extension) Multisession disc formats are supported by the radio.
Page 211 MPEG Specifi- Sampling Fre- cation quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 212: Operation Instructions
212 INSTRUMENT PANEL AND CONTROLS Operation Instructions - (CD Mode for MP3 Audio Play) SEEK Button (CD Mode for MP3 Play) Pressing the right side of the SEEK button plays the next MP3 File. Pressing the left side of the SEEK button plays the beginning of the MP3 file.
Page 213 MSG or INFO Button (CD Mode for MP3 Play) Press and MSG or INFO button while playing MP3 disc. The radio scrolls through the following TAG information: Song Title, Artist, File Name, and Folder Name (if avail- able). Press the MSG or INFO button once more to return to elapsed time priority mode.
Page 214: Sales Code Rec - Am/Fm/Cd (6-Disc) Radio With Navigation System
214 INSTRUMENT PANEL AND CONTROLS Operating Instructions - Hands Free Phone (If Equipped) Refer to Hands Free Phone in Section 3 of the Owner’s Manual. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to the Satellite Radio section of the Owner’s Manual.
Page 215: Operating Instructions - Satellite Radio (If Equipped)
menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD changer with MP3 capability. Mapping information for navigation is supplied on a DVD that is loaded into the unit. One map DVD covers all of North America.
Page 216: System Activation
216 INSTRUMENT PANEL AND CONTROLS System Activation NOTE: Your vehicle’s radio must be on and in satellite mode when the activation process takes place. To activate your Sirius Satellite Radio service, call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com.
Page 217: Selecting Satellite Mode In Ref, Raq, And Rak Radios
ESN/SID Access With RAQ and RAK Radios With the ignition switch in the ACCESSORY position and the radio OFF, press the CD Eject and TIME buttons simultaneously for 3 seconds. All twelve ESN/SID num- bers will be displayed. The radio will exit the ESN/SID mode when any other button is pushed, the ignition is turned OFF, or 5 minutes has passed since any button was pushed.
Page 218: Selecting A Channel
218 INSTRUMENT PANEL AND CONTROLS Selecting a Channel Press and release the SEEK or TUNE knob to search for the next channel. Press the top of the button to search up and the bottom of the button to search down. Holding the TUNE button causes the radio to bypass channels until the button is released.
Page 219: Pty Button Seek
one and stop the search. Pressing a pre-set memory button during a music type scan, will call up the memory channel and stop the search. PTY Button SEEK When the desired program is obtained, press the SEEK button within five seconds. The channel will change to the next channel that matches the program type selected.
Page 220: Remote Sound System Controls - If Equipped
220 INSTRUMENT PANEL AND CONTROLS REMOTE SOUND SYSTEM CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. The right hand control is a rocker type switch with a push button in the center.
Page 221: Cd Player
The button located in the center of the left hand control will tune to the next pre-set station that you have programmed in the radio pre-set push-buttons. CD Player Pressing the top of the switch once will go to the next track on the CD.
Page 222: Radio Operation And Cellular Phones
222 INSTRUMENT PANEL AND CONTROLS NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e. scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have theft protection encoding. Try a known good disc before considering disc player service.
Page 223: Air Conditioning Operation
Air Conditioning Operation To turn the air conditioning On or Off perform the following steps: • Position the mode control button to the desired airflow setting. • Set the front blower control to any desired speed. • Press the Snowflake (A/C) button which is located to the right of the temperature control slide.
Page 224: Front Mode Control
224 INSTRUMENT PANEL AND CONTROLS Front Mode Control The mode control allows you to choose from several patterns of air distribution. NOTE: To improve your selection choices, the system allows you to operate at intermediate positions between the major modes. These intermediate positions are iden- tified by the small dots and give an even blend of both modes.
Page 225 NOTE: There is a difference in temperature between the upper and lower outlets for added comfort. The warmer air goes to the floor outlets. This feature gives improved comfort during sunny but cool conditions. Heat (Floor) Outside air flows primarily through the floor out- lets located under the instrument panel.
Page 226: Rear Temperature Control - If Equipped
226 INSTRUMENT PANEL AND CONTROLS Temperature Control The temperature of the air is controlled by a slide located on the top center of the control panel. Move the slide left or right to change the temperature. The blue area of the scale indicates cooler temperatures while the red area indicates warmer temperatures.
Page 227: Rear Window Defrosting And Rear Window Washer/Wiper
mode on the front control will give you air from the outlets in the headliner in the rear. Floor mode in the front will give you floor in the rear. Rear Window Defrosting and Rear Window Washer/Wiper See the “Rear Window Features” section of this book. Automatic Temperature Control (ATC) —...
Page 228: Level Of Automatic Control
228 INSTRUMENT PANEL AND CONTROLS The ATC system uses an infrared sensor located in the overhead console to measure the temperature of the driver. Based on the sensor input, the system will auto- matically control comfort by varying the temperature, fan speed, and mode.
Page 229: Manual Control (Atc)
Manual Control (ATC) You also may choose to customize your comfort by selecting the fan speed and mode manually. Pressing the fan speed button or any mode button places the system into manual operation. While in manual operation there are six fan speeds available and the choice of any mode.
Page 230 230 INSTRUMENT PANEL AND CONTROLS Manual control of Recirculation is possible only in Panel, Floor, and Bi-Level modes. It will not operate in Mix, or Defrost modes. The recirculation symbol will flash three times indicating recirculation is not available in these modes.
Page 231 the A/C snowflake button has not been pressed. This dehumidifies the air to help dry the windshield. Rear Temperature Control (ATC) The “REAR” button cycles through the following modes: Rear Control from Front This allows the driver or passenger to control the rear blower speeds using the FAN +/–...
Page 232: Rear Zone Climate Control - If Equipped
232 INSTRUMENT PANEL AND CONTROLS Rear Zone Climate Control — If Equipped Headliner air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving the air vane knobs on the outlets to one side will shut off the airflow.
Page 233: Rear Rotary Temperature Control
Rear Rotary Blower Control The second row seat occupants have control of the rear blower speed, only when the front control unit is in the “REAR CONTROL” position or CONTROL IN REAR for ATC. The rear blower switch has an “Off” position and a range of blower speeds.
Page 234: Front Unit To Rear Unit Chart
234 INSTRUMENT PANEL AND CONTROLS Front Unit to Rear Unit Chart If the Front Control is Rear Airflow will come selected from Panel Headliner Bi-Level Headliner • Between Bi-Level Floor Bi-Level Floor Floor Floor Defrost Floor Operating Tips Fast Cooldown For a fast cooldown, set the blower fan to the highest setting, set the mode control to the panel fresh position, press the snowflake button to turn on the air condition-...
Page 235 and blower speed to maintain comfort. Interior fogging on the windshield can be quickly removed by selecting the defrost mode. Regular cleaning of the inside of the windows with a non-filming cleaning solution (vinegar and water works very well) will help prevent contaminates (cigarette smoke, perfumes, etc.) from sticking to the windows.
Page 236: Operating Tips Chart
236 INSTRUMENT PANEL AND CONTROLS Operating Tips Chart...
Page 237 REAR WINDOW FEATURES Rear Window Wiper/Washer INSTRUMENT PANEL AND CONTROLS 237 A rotating switch located on the climate control panel turns the rear wiper On or Off. Pressing the rotating switch inward activates the rear window washer. Rotating the switch will enable one of five intermittent delay times for the rear wiper.
Page 238 238 INSTRUMENT PANEL AND CONTROLS If the rear wiper is operating when the ignition is turned off, the wiper will automatically return to the “Park” position. When the vehicle is restarted, the wiper will resume operation. Rear Window Defrosting A push-button type switch is located in the climate control panel.
Page 239: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 242 Automatic Transmission ....242 Normal Starting .
Page 240 240 STARTING AND OPERATING Tire Safety Information ....264 Tire Markings ......264 Tire Identification Number (TIN) .
Page 241 Snowplow ......307 Dodge Durango Models ....307 Recreational Towing (Behind Motorhome, Etc.) .
Page 242: Starting Procedures
242 STARTING AND OPERATING STARTING PROCEDURES Automatic Transmission Start the engine with the selector lever in NEUTRAL or PARK position. Apply the brake before shifting to any driving range. WARNING! Do not attempt to push or tow your vehicle to get it started.
Page 243 If Engine Fails To Start If the engine fails to start after you have followed the Normal Starting procedure, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there while cranking the engine. This should clear any excess fuel in case the engine is flooded.
Page 244: Engine Block Heater - If Equipped
244 STARTING AND OPERATING CAUTION! Long periods of engine idling can cause excessive exhaust temperatures which can damage your ve- hicle. Do not leave your vehicle unattended with the engine running. WARNING! Do not leave children or animals inside parked vehicles in hot weather.
Page 245: Automatic Transmission
AUTOMATIC TRANSMISSION Automatic Transmission The electronic PRNDL on the instrument cluster indicates the transmission gear selected. The selector lever is mounted on the right side of the steering column. To drive, move the selector lever from Park or Neutral to the desired drive position.
Page 246 246 STARTING AND OPERATING WARNING! Never use Park position on an automatic transmis- sion as a substitute for the parking brake. Always apply parking brake fully when parked to guard against vehicle movement and possible injury or damage. WARNING! It is dangerous to shift the selector lever out of “P” or “N”...
Page 247 it also when climbing long grades, and for engine brak- ing when descending moderately steep grades. To pre- vent excessive engine speed do not exceed 45 miles per hour (72 km/h) in this range. “1” First For driving up very steep hills and for engine braking at low speeds 25 mph (40 km/h) or less when going down hill.
Page 248 248 STARTING AND OPERATING If the transmission temperature gets extremely hot, the transmission will automatically select the most desirable gear for operation at this temperature. If the transmission temperature becomes hot enough the TRANS TEMP light may illuminate and the transmission may downshift out of Overdrive until the transmission cools down.
Page 249 equipped) is disabled and 2-3 and 3-4 shift patterns are modified. Shifts into Overdrive (4th gear) are allowed during steady cruise (for improved fuel economy) and automatic closed-throttle downshifts to 3rd gear (for improved braking) will occur during steady braking. The “TOW/HAUL”...
Page 250: Four-Wheel Drive Operation
250 STARTING AND OPERATING cause damage to the transmission. The torque converter will refill within five seconds of shifting from Park into any other gear position. FOUR-WHEEL DRIVE OPERATION NV 144 Transfer Case Operating Information/Precautions The NV 144 is an electric shift transfer case and is operated by the Four-Wheel-Drive (4WD) Control Switch, which is located on the instrument panel.
Page 251 WARNING! Always engage the parking brake when powering down the vehicle if the Service 4WD light is illuminated. Not engaging the parking brake may allow the vehicle to roll which may cause personal injury. NOTE: Do not attempt to make a shift while only the front or rear wheels are spinning.
Page 252: Shifting Procedure - Nv 144 Transfer Case
252 STARTING AND OPERATING Shifting Procedure - NV 144 Transfer Case AWD to 4LOCK or 4LOCK to AWD With the key ON and the engine either OFF or RUN- NING, rotate the transfer case switch, located on the instrument panel to the desired position. NOTE: Delayed shifting out of 4LOCK may be experi- enced due to uneven tire wear, low tire pressure, or excessive vehicle loading.
Page 253: Nv 244 Generation Ii Transfer Case Operating Information / Precautions
If the key is not ON then the shift will not take place and no position indicator lights will be on or flashing. NV 244 Generation II Transfer Case Operating Information / Precautions The NV 244 Generation II is an electric shift transfer case and is operated by the 4WD Control Switch, which is located on the instrument panel.
Page 254 254 STARTING AND OPERATING NOTE: The transfer case Neutral (N) position is to be used for recreational towing only. See Recreational Tow- ing section for specific procedures on shifting into and out of Neutral (N). Transfer Case Position Indicator Lights Transfer case position indicator lights are located on the instrument cluster.
Page 255 When operating your vehicle in 4LO, the engine speed is approximately three times that of the AWD or 4LOCK positions at a given road speed. Take care not to over- speed the engine and do not exceed 40 km/h (25 mph). Proper operation of four-wheel-drive vehicles depends on tires of equal size, type and circumference on each wheel.
Page 256: Shifting Procedure - Nv 244 Generation Ii
256 STARTING AND OPERATING 4LOCK Four-Wheel-Drive LOCK - Locks the transfer case inter- axle differential. Forces front and rear wheels to rotate at the same speed. Additional traction for loose, slippery road surfaces only. Four-Wheel-Drive Low Range - Low speed 4 wheel drive.
Page 257 wheels to complete the shift. There may be a delay up to 13 seconds for the shift to complete after the wheels have stopped spinning. NOTE: Delayed shifting out of the 4LOCK position may be experienced due to uneven tire wear, low tire pressure, or excessive loading.
Page 258: Parking Brake
258 STARTING AND OPERATING NOTE: If any of the requirements to select a new transfer case position have not been met, the transfer case will not shift. The indicator light will flash and the current transfer case position will be maintained. To retry the selection, turn the control knob back to the current position, wait five (5) seconds, and retry the shift.
Page 259 The instrument cluster brake warning light NOTE: indicates only that the parking brake is applied. You must be sure the parking brake is fully applied before leaving the vehicle. When parking on a hill, turn the front wheels toward the curb on a downhill grade and away from the curb on an uphill grade.
Page 260: Brake System
260 STARTING AND OPERATING BRAKE SYSTEM In the event power assist is lost for any reason, (for example, repeated brake applications with the engine off), the brakes will still function. The effort required to brake the vehicle will be significantly increased over that required with the power system operating.
Page 261 At the instant one of the wheels is about to lock up, a slight pulsation can be felt in the brake pedal, indicating that the ABS is in the regulating mode. Keep firm and steady pressure on the brake pedal while experiencing the pulsation.
Page 262: Power Steering
262 STARTING AND OPERATING WARNING! • Anti-lock system (ABS) cannot prevent the natu- ral laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency be- yond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
Page 263 If for some reason, the power assist is interrupted, it will still be possible to steer your vehicle. Under these condi- tions you will observe a substantial increase in steering effort, especially at very low vehicle speeds and during parking maneuvers. NOTE: Increased noise levels at the end of the steering wheel travel are considered normal and does not indicate that there is a problem with the power steering system.
Page 264: Rocking The Vehicle
264 STARTING AND OPERATING ROCKING THE VEHICLE If vehicle becomes stuck in snow, sand, or mud, it can often be moved by a rocking motion. Move the gear selector rhythmically between FIRST and REVERSE, while applying slight pressure to the accelerator. The least amount of accelerator pedal pressure to main- tain the rocking motion without spinning the wheels or racing the engine is most effective.
Page 265 • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation. Example: 215/65R15 96H •...
Page 266 266 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Millimeters (mm)
Page 267 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions.
Page 268: Tire Identification Number (Tin)
268 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire.
Page 269: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 269 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the: 1) number of people that can be carried in the vehicle...
Page 270 270 STARTING AND OPERATING Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the “Tire and Loading Information”...
Page 271 5. Determine the combined weight of luggage and cargo being loaded on the vehicle. That weight may not safely exceed the available cargo and luggage load capacity calculated in Step 4. 6. If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle.
Page 272 272 STARTING AND OPERATING...
Page 273: Tires-General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES—GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 274: Tire Inflation Pressures
274 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Underinflation also increases tire rolling resistance and results in higher fuel consumption.
Page 275 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap–if equipped. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure”.
Page 276: Radial-Ply Tires
276 STARTING AND OPERATING loading may be required for high speed vehicle opera- tion. Refer to original equipment or an authorized tire dealer for recommended safe operating speeds, loading and cold tire inflation pressures. WARNING! High speed driving with your vehicle under maxi- mum load is dangerous.
Page 277: Compact Spare Tire - If Equipped
Compact Spare Tire — If Equipped The compact spare is for temporary emergency use with radial tires. It is engineered to be used on your style vehicle only. Since this tire has limited tread life, the original tire should be repaired (or replaced) and rein- stalled at the first opportunity.
Page 278: Limited Use Spare - If Equipped
278 STARTING AND OPERATING Limited Use Spare — If Equipped The limited use spare tire is for temporary emergency use on your vehicle. This tire is identified by a limited use spare tire warning label located on the limited use spare tire and wheel assembly.
Page 279: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck. And don’t let anyone near a spinning wheel, no matter what the speed.
Page 280: Life Of Tire
280 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.
Page 281: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 282: Supplemental Tire Pressure Information - If Equipped
282 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SUPPLEMENTAL TIRE PRESSURE INFORMATION – IF EQUIPPED A light load vehicle condition is defined as two passen- gers {150 lbs (68 kg) each} plus 200 lbs (91kg) of cargo.
Page 283: Snow Tires
These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires of Durango trucks. NOTE: The use of class “S” chains is permitted on Durangos with P245/70R17 tires. CAUTION! Do not use tire chains on 4x4 Durango trucks equipped with tires other than P245/70R17 tires.
Page 284: Tire Rotation Recommendations
284 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates and tend to develop irregular wear pat- terns.
Page 285: Fuel Requirements
FUEL REQUIREMENTS All engines (except 5.7L engines) are de- signed to meet all emissions regulations and provide excellent fuel economy and performance when using high quality un- leaded “regular” gasoline having an oc- 3.7L/4.7L tane rating of 87. The routine use of pre- Engines mium gasoline is not recommended.
Page 286: Reformulated Gasoline
286 STARTING AND OPERATING and durability for your vehicle. We recommend the use of gasolines that meet the WWFC specifications if they are available. Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as “Reformulated Gasoline.” Reformulated gasolines contain oxygenates, and are spe- cifically blended to reduce vehicle emissions and im- prove air quality.
Page 287: Mmt In Gasoline
MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane. Gasolines blended with MMT provide no performance advantage beyond gasolines of the same octane number without MMT. Gasolines blended with MMT reduce spark plug life and reduce emission system performance.
Page 288 288 STARTING AND OPERATING NOTE: Tighten the gas cap until you hear a “clicking” sound. This is an indication that the gas cap is properly tightened. Make sure that the gas cap is tightened each time the vehicle is refueled. WARNING! A fire may result if gasoline is pumped into a portable container that is inside of a vehicle or on a...
Page 289: Fuel System Cautions
CAUTION! Damage to the fuel system or emission control system could result from using an improper fuel tank filler tube cap (gas cap). A poorly fitting cap could let impurities into the fuel system. WARNING! • Never allow any lit smoking materials near the vehicles while removing the cap or filling the tank.
Page 290: Carbon Monoxide Warnings
290 STARTING AND OPERATING NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you. Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: •...
Page 291: Catalytic Converter
CATALYTIC CONVERTER The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic converter will not require maintenance. However, you must keep the en- gine maintained to assure proper operation and prevent possible damage.
Page 292: Vehicle Loading
292 STARTING AND OPERATING vehicle should be stopped, the engine shut off and the vehicle allowed to cool. Service, including a tune-up to manufacturer’s specifications should be obtained imme- diately. To minimize the possibility of catalyst damage: • Do not shut off the engine or interrupt the ignition when the transmission is in gear and the vehicle is in motion.
Page 293 Rating (GAWR) front and rear, and Vehicle Identification Number (VIN). A Month-Day-Hour (MDH) number is included on this label and shows the Month, Day, and Hour of manufacture. The bar code that appears on the bottom of the label is your Vehicle Identification Number (VIN).
Page 294: Curb Weight
294 STARTING AND OPERATING Inflation Pressure (Cold) This is the cold tire inflation pressure for your vehicle for all loading conditions up to full GAWR. Curb Weight The curb weight of a vehicle is defined as the total weight of the vehicle with all fluids, including vehicle fuel, at full capacity conditions, and with no occupants or cargo loaded into the vehicle.
Page 295 WARNING! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles. This could cause you to lose control. Also, overloading can shorten the life of your vehicle.
Page 296: Trailer Towing
296 STARTING AND OPERATING TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
Page 297 Gross Axle Weight Rating (GAWR) The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR. WARNING! It is important that you do not exceed the maximum front or rear GAWR.
Page 298: Trailer Hitch Classification
298 STARTING AND OPERATING Weight-Distributing Hitch A weight-distributing hitch includes a receiver attached to the tow vehicle, plus a removable hitch head and spring bar assembly that fits into the receiver opening and hook up brackets that connect the spring bars to the trailer frame.
Page 299: Trailer Towing Weights (Maximum Trailer Weight Ratings)
• http:// www.dodge.com/towing. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 300: Towing Requirements
300 STARTING AND OPERATING Never exceed the maximum tongue weight stamped on your bumper or trailer hitch. Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer. • The weight of any other type of cargo or equipment put in or on your vehicle.
Page 301 CAUTION! • Avoid towing a trailer for the first 500 miles (805 km) of vehicle operation. Doing so may damage your vehicle. • During the first 500 miles (805 km) of trailer towing, limit your speed to 50 mph (80 km/h). Perform the maintenance listed in Section 8 of this manual.
Page 302 302 STARTING AND OPERATING • Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners.
Page 303 − Check for signs of tire wear or visible tire damage before towing a trailer. Refer to the Tires–General Information section of this manual on Tread Wear Indicators for the proper inspection procedure. − When replacing tires refer to the Tires–General Infor- mation section of this manual on Replacement Tires for proper tire replacement procedures.
Page 304 304 STARTING AND OPERATING WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 305: Towing Tips
7- Pin Connector Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. STARTING AND OPERATING 305 If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage.
Page 306 306 STARTING AND OPERATING NOTE: Check the automatic transmission fluid level before towing. Towing Tips — Tow/Haul (If Equipped) To reduce potential for automatic transmission overheat- ing, turn the “TOW HAUL OD/OFF” feature ON when driving in hilly areas or shift the transmission to Drive position 2 on more severe grades.
Page 307: Trailer Towing Mirrors - If Equipped
(flipped Out or In). A small blindspot mirror is integrated onto the main mirror surface. SNOWPLOW Dodge Durango Models NOTE: Do not use Dodge Durango Models for snow- plow applications. STARTING AND OPERATING 307 WARNING! Snowplows, winches, and other aftermarket equip- ment should not be added to the front end or your vehicle.
Page 308: Recreational Towing (Behind Motorhome, Etc.)
308 STARTING AND OPERATING WARNING! Attaching a snowplow to this vehicle could ad- versely affect performance of the airbag system in an accident. Do not expect that the airbag will perform as described earlier in this manual RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Recreational Towing 2WD Models Recreational towing of 2WD models is not allowable.
Page 309 WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake. The transfer case Neutral (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move despite the transmission position.
Page 310 310 STARTING AND OPERATING 2. Shut engine OFF. 3. Turn the ignition key to the ON position without starting the engine. 4. Depress brake pedal. 5. Shift automatic transmission to Neutral (N). 6. Using the point of a ballpoint pen or similar object, depress the recessed transfer case Neutral (N) button for 4 seconds.
Page 311 NOTE: The ignition key must be ON for a shift to take place and for the position indicator lights to be operable. If the key is not ON, the shift will not take place and no position indicator lights will be on or flashing. CAUTION! Damage to the transmission may occur if the trans- mission is shifted into Park (P) with the transfer case...
Page 312: Traction
312 STARTING AND OPERATING NOTE: Items 1 through 5 are requirements that must be met prior to depressing the Neutral (N) selection button, and must continue to be met until 1 second elapses and the shift has been completed. If any of these requirements are not met prior to depress- ing the Neutral (N) button or are no longer met during the 1 second time, then all of the position indicator lights will flash continuously until all requirements are met or...
Page 313: Equipment Identification Plate
STARTING AND OPERATING 313 2. Slow down if road has standing water or puddles. 3. Replace tires when tread wear indicators first become visible. 4. Keep tires properly inflated. 5. Maintain sufficient distance between your vehicle and the car in front to avoid a collision in a sudden stop. EQUIPMENT IDENTIFICATION PLATE The equipment Identification Plate is located on the hood inner surface.
Page 315: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....316 Adding Fuel ......316 Changing A Flat Tire .
Page 316: Hazard Warning Flasher
316 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The flasher switch is on the top of the steering column, just behind the steering wheel. Press the flasher switch and all front and rear directional signals will flash intermittently. Press the switch a second time to turn off the emergency flashers.
Page 317: Changing A Flat Tire
WARNING! • Never allow any lit smoking materials near the vehicles while removing the cap or filling the tank. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is in a vehicle or on a truck bed.
Page 318 318 WHAT TO DO IN EMERGENCIES WARNING! The jack is designed as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes, unless suitable supports are placed under the vehicle as a safety measure. The vehicle should be jacked on a firm level surface only.
Page 319: Removing The Spare Tire
Removing The Spare Tire The spare tire on the Dodge Durango is located under- neath the vehicle in the rear. Remove the spare tire before attempting to jack the truck. 1. Remove the rubber plug from the floor in the cargo area.
Page 320: Tire Changing Procedure
320 WHAT TO DO IN EMERGENCIES It is recommended that you stow the flat or spare to avoid tangling the loose cable. CAUTION! The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and can damage the winch.
Page 321 Preparations Park the vehicle on a firm level surface, avoiding ice or slippery areas. Set the parking brake and place the gear selector in PARK (automatic transmission). On Four Wheel Drive vehicles, shift the transfer case to the “4L” position. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 322 322 WHAT TO DO IN EMERGENCIES (prior to inboard transition. Operate the jack using the jack drive tube and the wheel wrench - the tube exten- sion, may be used but is not required. Front Jacking Location When changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube.
Page 323 Rear Right Jacking Location Before raising the wheel off the ground, make sure that the jack will not damage surrounding truck parts and adjust the jack position as required. 4. By rotating the wheel wrench clockwise, raise the vehicle until the wheel just clears the surface. WHAT TO DO IN EMERGENCIES 323 WARNING! Raising the vehicle higher than necessary can make...
Page 324 324 WHAT TO DO IN EMERGENCIES WARNING! A loose tire or jack thrown forward in a collision or hard stop could injure someone in the vehicle. Always stow the jack, tools and the extra tire and wheel in the places provided. 7.
Page 325: Jump Starting
To Stow The Flat Or Spare Turn the wheel so that the valve stem is down. Slide the wheel retainer through the center of the wheel and position it properly across the wheel opening. For convenience in checking the spare tire inflation, stow with the valve stem toward the rear of the vehicle.
Page 326 326 WHAT TO DO IN EMERGENCIES Check the Battery Test Indicator (if equipped). If a light or bright colored dot is visible in the indicator (if equipped), DO NOT jump-start the battery. If the indicator (if equipped) is dark or shows a green dot, proceed as follows: 1.
Page 327: Emergency Tow Hooks - If Equipped
WARNING! Do not connect the cable to the negative post of the discharge battery. The resulting electrical spark could cause the battery to explode. During cold weather when temperatures are below freezing point, electrolyte in a discharged battery may freeze. Do not attempt jump starting because the battery could rupture or explode.
Page 328: Towing A Disabled Vehicle
328 WHAT TO DO IN EMERGENCIES WARNING! Chains are not recommended for freeing a stuck vehicle. Chains may break, causing serious injury or death. WARNING! Stand clear of vehicles when pulling with tow hooks. Tow straps and chains may break, causing serious injury.
Page 329: Four-Wheel Drive Vehicles
Four-Wheel Drive Vehicles The manufacturer recommends towing with all wheels OFF the ground. Acceptable methods are to tow the vehicle on a flatbed or with one end of the vehicle raised and the opposite end on a towing dolly. Two-Wheel Drive Vehicles Provided that the transmission is operable, tow with the transmission in Neutral and the ignition key in the OFF position along with the front wheels raised and the rear...
Page 331: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment 3.7L V6 ....334 Engine Compartment 4.7L V-8 ....335 Engine Compartment 5.7L HEMI V-8 .
Page 332 332 MAINTAINING YOUR VEHICLE Catalytic Converter ....347 Maintenance-Free Battery ....348 Air Conditioner Maintenance .
Page 333 Bulb Replacement ..... . 377 Headlights/Parking/Turn Signal ..377 Rear Side Marker, Tail Lights, Turn Signals And Backup Lights —...
Page 334: Engine Compartment 3.7L V6
334 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 3.7L V6...
Page 335: Engine Compartment 4.7L V-8
MAINTAINING YOUR VEHICLE 335 ENGINE COMPARTMENT 4.7L V-8...
Page 336: Engine Compartment 5.7L Hemi V-8
336 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 5.7L HEMI V-8...
Page 337: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 338: Emissions Inspection And Maintenance Programs
338 MAINTAINING YOUR VEHICLE cap until a clicking sound is heard. This is an indication that the gas cap is properly tightened. Press the odometer reset button to turn the message off. If the problem persists, the message will appear the next time the vehicle is started.
Page 339: Replacement Parts
3. As soon as you turn your key to the ON position, you will see your MIL symbol come on as part of a normal bulb check. 4. Approximately 15 seconds later, one of two things will happen: a. The MIL light will blink for approximately 5 sec- onds and then remain on until the first engine crank or the key is turned off.
Page 340: Dealer Service
340 MAINTAINING YOUR VEHICLE DEALER SERVICE Your dealer has the qualified service personnel, special tools and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 341 1. Position the vehicle on a level surface. 2. Turn Off the engine and allow approximately 5 min- utes for the oil to settle to the bottom of the crankcase. 3. Remove the engine oil level indicator (dipstick). 4. Wipe the engine oil level indicator (dipstick) clean. 5.
Page 342 342 MAINTAINING YOUR VEHICLE Frequency Of Oil Change Road conditions and your style of driving affect the interval at which your oil should be changed. Check the following to determine if ANY apply to you: • Day or night temperatures are below 32°F (0°C). •...
Page 343 periodically. Make sure that these units are always clean. This will tend to reduce to a minimum the amount of abrasive material that may enter the engine. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacture only recommends engine oils that are API certified and meet the requirements of DaimlerChrysler Material Standard MS-6395.
Page 344: Engine Oil Filter
344 MAINTAINING YOUR VEHICLE For information on engine oil filler cap location, see the Engine Compartment illustration in this section. Lubricants which do not have both, the engine oil certi- fication mark and the correct SAE viscosity grade num- ber should not be used. Synthetic Engine Oils There are a number of engine oils being promoted as either synthetic or semi-synthetic.
Page 345: Drive Belts - Check Condition And Tensioner
Drive Belts — Check Condition and Tensioner Belt tension is controlled by means of an automatic tensioner. No belt tension adjustments are required. However, belt and belt tensioner condition should be inspected at the specified intervals, and replaced if re- quired.
Page 346: Ignition Cables
346 MAINTAINING YOUR VEHICLE Ignition Cables Replace the ignition cables (5.7L engines only) at the mileage interval shown in the maintenance charts. Engine Air Cleaner Filter Under normal driving conditions, replace the air filter at the intervals shown on Schedule “A”. If, however, you drive the vehicle frequently under dusty or severe con- ditions, the filter element should be inspected periodi- cally and replaced if necessary at the intervals shown on...
Page 347: Catalytic Converter
Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 348: Maintenance-Free Battery
Maintenance-Free Battery All Dodge trucks are equipped with maintenance-free batteries. You will never have to add water, nor is periodic maintenance required.
Page 349: Air Conditioner Maintenance
WARNING! Battery posts, terminals, and related accessories con- tain lead and lead compounds. Always wash hands after handling the battery. To determine the battery charge, check the battery test indicator (if equipped) on top of the battery. Refer to the illustration.
Page 350: Power Steering - Fluid Check
350 MAINTAINING YOUR VEHICLE WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Section 3 of the Warranty Information book for further warranty information.
Page 351: Front Suspension Ball Joints
WARNING! Fluid level should be checked on a level surface and with the engine off to prevent injury from moving parts and to insure accurate fluid level reading. Do not overfill. Use only manufacturers recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 352: Windshield Wiper Blades
352 MAINTAINING YOUR VEHICLE attention should also be given to hood latching compo- nents to insure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated. The external lock cylinders should be lubricated twice a year, preferably in the fall and spring.
Page 353: Exhaust System
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. After the engine has warmed, operate the defroster for a few minutes to reduce the possibility of smearing or freezing the fluid on the cold windshield.
Page 354: Cooling System
354 MAINTAINING YOUR VEHICLE WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, fol- low the preceding safety tips. Cooling System Inspection Check engine coolant (antifreeze) protection every 12...
Page 355 WARNING! You or others can be badly burned by hot coolant or steam from your radiator. If you see or hear steam coming from under the hood don’t open the hood until the radiator has had time to cool. If you open the hood and see steam or hot coolant escaping from the radiator, don’t touch anything.
Page 356 356 MAINTAINING YOUR VEHICLE Recommended Engine Coolant This vehicle has been factory filled with an Ethylene Glycol based engine coolant with long life corrosion inhibitors (called HOAT, for Hybrid Organic Additive Technology). Follow the “Maintenance Schedule” for the recommended coolant change intervals. Refer to Fluids, Lubricants and Genuine Parts for correct fluid type.
Page 357 Adding Coolant When adding coolant, or refilling the system, a minimum solution of 50% recommended HOAT ethylene glycol engine coolant (antifreeze) and distilled water should be used. Use higher concentrations (not to exceed 70%) if temperatures below 34°F ( 37°C) are anticipated. Use only high purity water such as distilled or deionized water when mixing the water/engine coolant solution.
Page 358 358 MAINTAINING YOUR VEHICLE WARNING! The warning words “DO NOT OPEN HOT” on the coolant pressure cap are a safety precaution. Heat causes pressure to build up in the cooling system. To prevent scalding or injury, do not remove the pres- sure cap when the system is hot or under pressure.
Page 359: Emission Related Components
D. Maintain coolant concentration at 50% HOAT ethyl- ene glycol engine coolant (minimum) and distilled water for proper corrosion protection of your engine. E. Make sure that the radiator and coolant bottle over- flow hoses are not kinked or obstructed. F.
Page 360: Brake System
360 MAINTAINING YOUR VEHICLE You are urged to use only the manufacturer’s specified hoses and clamps, or their equivalent in material and specification, in any fuel system servicing. It is manda- tory to replace all clamps that have been loosened or removed during service.
Page 361 WARNING! Use of brake fluid that may have a lower initial boiling point, or is unidentified, as to specifications may result in sudden brake failure during hard prolonged braking. You could have an accident. WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching on fire.
Page 362: Automatic Transmission
362 MAINTAINING YOUR VEHICLE WARNING! Worn brake hoses can burst and cause brake failure. You could have an accident. If you see any sign of cracking, scuffing, or worn spots, have the brake hoses replaced immediately. Automatic Transmission Fluid Level Check Check the fluid level while the transmission is at normal operating temperature 180°F (82°C).
Page 363 a minimum of two (2) minutes for the oil to fully drain into the transmission before rechecking the fluid level. NOTE: If it is necessary to check the transmission below the operating temperature, the fluid level should be between the two “COLD” (lower) holes on the dipstick with the fluid at approximately 70°F ( 21°C) (room temperature).
Page 364: Transfer Case
364 MAINTAINING YOUR VEHICLE CAUTION! Using a transmission fluid other than the manufac- turers recommended fluid may cause deterioration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than the manufacturers recommended fluid will result in more frequent fluid and filter changes.
Page 365: Axles
Axles Refer to Fluids, Lubricants and Genuine Parts for correct fluid type. The manufacturer does not recommend regularly sched- uled oil changes for axles in vehicles whose operation is classified as normal truck service. NOTE: The presence of water in the gear lubricant will result in corrosion and possible failure of differential components.
Page 366: Appearance Care And Protection From Corrosion
366 MAINTAINING YOUR VEHICLE There are two groups identified, those for wheel bearings (Letter “G”) and those for chassis (Letter “L”) lubrication. Perfor- mance categories within these groups result in dual letter each group. The letter des- ignations shown in the ex- ample are the highest quality level available and when combined as shown can be used for chassis lubrication.
Page 367 The most common causes are: • Road salt, dirt and moisture accumulation. • Stone and gravel impact. • Insects, tree sap and tar. • Salt in the air near seacoast localities. • Atmospheric fallout/industrial pollutants. Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using a mild car wash soap, and rinse the panels completely with clear water.
Page 368 368 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to an accident or similar cause which destroys the paint and protective coating have your vehicle repaired as soon as possible.
Page 369 Your leather upholstery can be best preserved by regular cleaning with a damp soft cloth. Small particles of dirt can act as an abrasive and damage the leather upholstery and should be removed promptly with a damp cloth. Stubborn soils can be removed easily with a soft cloth and Mopar Total Clean.
Page 370: Power Distribution Center (Fuse/Relay)
370 MAINTAINING YOUR VEHICLE 1. Clean with a wet soft rag. A mild soap solution may be used, but do not use high alcohol content or abrasive cleaners. If soap is used, wipe clean with a clean damp rag. 2. Dry with a soft tissue. Seat Belt Maintenance Do not bleach, dye or clean the belts with chemical solvents or abrasive cleaners.
Page 371: Fuse Block
FUSE BLOCK CAUTION! When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it suggests a problem in the circuit that must be corrected.
Page 372 372 MAINTAINING YOUR VEHICLE Fuse Block Cavity Mini Fuse/Color Instrument Cluster Battery 15 Amp Blue Occupant Classification 10 Amp Red Module (OCM) Battery Feed Ignition Run/Start for Con- troller (NGC), Integrated 10 Amp Red Power Module (IPM), AC Relay and Fuel Pump Relay Door Node and Non- 10 Amp Red Memory Power Mirror...
Page 373: Underhood Fuses (Power Distribution Center)
Cavity Mini Fuse/Color Description 10 Amp Red Heated Mirrors 20 Amp Yellow Cluster Battery Feed Ignition Run HVAC 10 Amp Red Module/Heated Rear Glass (EBL) Relay 10 Amp Red ABS Module Ignition Run Battery Feed Blue Tooth, Compass/Trip Computer 15 Amp Blue (CMTC), Sentry Key Diag- nostics Reconfigurable Power Out-...
Page 374 374 MAINTAINING YOUR VEHICLE Cartridge Cavity Mini Fuse Fuse / Relay 40 Amp Green 30 Amp Pink 40 Amp Green 50 Amp Red 10 Amp Red Spare 20 Amp Yellow Fuel Pump 20 Amp Yellow NGC Spare 20 Amp Yellow ABS Batt 20 Amp Yellow NGC Batt 20 Amp Yellow Trailer Tow 15 Amp Blue...
Page 375: Underhood Fuses (Integrated Power Module)
Underhood Fuses (Integrated Power Module) Cartridge Cavity Mini Fuse Fuse / Relay Relay Relay Relay Relay Relay Relay Relay 10 Amp Red 10 Amp Red 10 Amp Red Cartridge Cavity Fuse / Relay Description Relay Wiper On/Off Wiper Hi/Lo Horn Rly Rear Wiper Lt T-Tow Stop/Turn Rly...
Page 376: Replacement Light Bulbs
376 MAINTAINING YOUR VEHICLE Cartridge Cavity Mini Fuse Fuse / Relay Relay Relay Relay 30 Amp Green 30 Amp Green REPLACEMENT LIGHT BULBS Description Rad Fan Lo LIGHT BULBS — Interior Dome Light ......WL212–2 Ft Fog Lamps Liftgate Lamp .
Page 377: Bulb Replacement
BULB REPLACEMENT Headlights/Parking/Turn Signal 1. Remove the two bolts attaching the headlight to the inner fender panel. MAINTAINING YOUR VEHICLE 377 2. Remove one nut that attaches the headlight to the inner fender panel. Access to the nut is possible by removing the fender panel access door which is located in the wheel liner.
Page 378: Rear Side Marker, Tail Lights, Turn Signals And Backup Lights - Replacement
378 MAINTAINING YOUR VEHICLE 6. Twist and remove socket from lamp. 7. Remove bulb from socket and replace. NOTE: These are Halogen bulbs. Take care not to touch the bulb with your fingers. Body oils from your fingers could cause excessive heat build-up which reduces bulb life.
Page 379 MAINTAINING YOUR VEHICLE 379 2. Rotate the light to the outboard side of the vehicle and remove.
Page 380 380 MAINTAINING YOUR VEHICLE 3. Unlock and remove electrical connector. 4. Remove the three screws holding the bulb strip to the back of the tail lamp.
Page 381 MAINTAINING YOUR VEHICLE 381 5. Remove the bulb strip from the tail light lens. 6. Remove bulbs from bulb strip by pulling the bulb straight out.
Page 382: License Lights
382 MAINTAINING YOUR VEHICLE License Lights 1. Remove the two screws securing the lens to the liftgate.
Page 383: Center High-Mounted Stoplight
2. Rotate the socket 1/4 turn counterclockwise. 3. Pull bulb from socket. MAINTAINING YOUR VEHICLE 383 Center High-Mounted Stoplight 1. Remove two screws securing stoplight housing assem- bly to the liftgate.
Page 384: Fog Lights
384 MAINTAINING YOUR VEHICLE 2. Turn socket 1/4 counterclockwise and free from hous- ing. 3. Pull bulb straight from socket to remove. Fog Lights 1. Rotate bulb and connector 1/4 turn counterclockwise. 2. Pull bulb off of connector. NOTE: For foglights ensure that the takeout push- fasteners are relocated back in their positions;...
Page 385: Fluids And Capacities
FLUIDS AND CAPACITIES Fuel 3.7L/4.7L, 87 Octane 5.7L, 89 Octane Engine Oil (with filter) 3.7L, SAE 5W-30, API Certified 4.7L, SAE 5W-30, API Certified 5.7L, SAE 5W-20, API Certified Cooling System (includes 2.1 Qts./2L for coolant bottle 3.7L without Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 3.7L with Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 4.7L without Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula) 4.7L with Rear Heat (Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula)
Page 386: Fluids, Lubricants And Genuine Parts
386 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant 3.7/4.7L Engine Oil 5.7L Engine Oil Engine Oil Filter Spark Plugs Fuel Selection 3.7L/4.7L Fuel Selection 5.7L Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent.
Page 387: Chassis
Chassis Component Automatic Transmission Transfer Case Front Axle Rear Axle Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts. Mopar ATF+4, Automatic Transmission Fluid. Mopar ATF+4, Automatic Transmission Fluid. SAE 75W-90 Multipurpose Type, GL-5 Gear Lubricant or equivalent. SAE 75W-140 Synthetic Gear Lubricant or equivalent.
Page 389 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..390 Emissions Testing ..... . . 390 Maintenance Schedules .
Page 390: Emission Control System Maintenance
390 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type on the following pages must be done at the times or mileages specified to assure the continued proper func- tioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 391: Maintenance Schedules
MAINTENANCE SCHEDULES There are two maintenance schedules that show the required service for your vehicle. First is Schedule “B”. It is for vehicles that are operated under the conditions that are listed below and at the beginning of the schedule. •...
Page 392 392 MAINTENANCE SCHEDULES Use the schedule that best describes your driving condi- tions. Where time and mileage are listed, follow the interval that occurs first. NOTE: Under no circumstances should oil change in- tervals exceed 6000 miles (10 000 km) or 6 months whichever comes first.
Page 393 Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant reservoir, brake master cylinder, and transmission and add as needed. •...
Page 394: Schedule "B
394 SCHEDULE “B” Schedule “B” Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. • Day or night temperatures are below 32° F (0° C). • Stop and go driving. • Extensive engine idling. •...
Page 395 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect engine air cleaner filter, replace if neces- sary.
Page 396 396 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Check transfer case fluid level (4X4). Inspect brake linings.
Page 397 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 398 398 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 399 Miles (Kilometers) Inspect auto tension drive belt and replace if re- quired. Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your ve- hicle is used for police, taxi, fleet, or frequent trailer towing. Drain and refill automatic transmission fluid and change main sump filter (4.7L/5.7L only).
Page 400 400 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 401 Miles (Kilometers ) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Change rear axle fluid. Change front axle fluid (4X4). Check transfer case fluid level (4X4). Inspect brake linings.
Page 402 402 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Flush and replace engine coolant, if not replaced at 60 months.
Page 403 Miles (Kilometers) Change engine oil and engine oil filter, or at 3 months whichever comes first. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Change rear axle fluid. Change front axle fluid (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if necessary.
Page 404 404 SCHEDULE “B” Miles (Kilometers) Drain and refill transfer case fluid (4X4). Drain and refill automatic transmission fluid, change filter (3.7L). This applies only if your vehicle is used for police, taxi, fleet, or fre- quent trailer towing. Drain and refill automatic transmission fluid and change main sump filter and spin-on cooler return filter if equipped.
Page 405: Schedule "A
Schedule “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Check transfer case fluid level (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace as neces- sary.
Page 406 406 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Check transfer case fluid level (4X4). Flush and replace engine coolant at 60 months, if not replaced at 102,000 miles (170 000 km).
Page 407 Miles (Kilometers) [Months] Inspect engine air cleaner filter, replace if necessary. Replace spark plugs. Inspect PCV valve, replace as necessary. * Inspect and replace ignition cables if neces- sary (5.7L only). Inspect auto tension drive belt and replace if required. 36,000 42,000 48,000...
Page 408 408 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Check transfer case fluid level (4X4). Inspect brake linings. Inspect engine air cleaner filter, replace if neces- sary.
Page 409 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Drain and refill tranfer case fluid (4X4). Flush and replace engine coolant, if not replaced at 60 months. Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km).
Page 410: Vehicle Storage
410 SCHEDULE “A” Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 411: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......412 Prepare For The Appointment .
Page 412 We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to your selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 413 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 414 414 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 415 WARRANTY INFORMATION (U.S. Vehicles Only) See the Warranty Information Booklet for the terms and provisions of DaimlerChrysler’s warranties applicable to this vehicle. MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best.
Page 416 416 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 417 IF YOU NEED CONSUMER ASSISTANCE 417 Call Toll Free at: • 1–800–890–4038 (U.S.) • 1–800–387–1143 (Canada) Visit us on the World Wide Web at: • www.techauthority.daimlerchrysler.com • www.daimlerchrysler.ca/manuals...
Page 419 INDEX...
Page 420 420 INDEX ABS (Anti-Lock Brake System) ... . 186,260 Adding Fuel ......287,316 Air Cleaner, Engine (Engine Air Cleaner Filter) .
Page 421 Ball Joints ......351 Battery ....... 348 Charging .
Page 422 422 INDEX Cargo Organizer ..... . . 176 Cargo Organizer ......176 Cargo (Vehicle Loading) .
Page 423 Points to Remember ....358 Radiator Cap ......357 Selection of Coolant (Antifreeze) .
Page 424 424 INDEX Jacking ......320 Overheating ......357 Tow Hooks .
Page 425 Engine Oil Disposal ....344 Flashers Hazard Warning ..... . . 316 Turn Signal .
Page 426 426 INDEX Gasoline, Reformulated ....286 Gauges Coolant Temperature ....183 Fuel .
Page 427 Lock ....... . 13 Illuminated Entry ......14 Infant Restraint .
Page 428 428 INDEX Bulb Replacement ....376,377 Center Mounted Stop ....383 Courtesy/Reading .
Page 429 Lower Anchors and Tether for CHildren (LATCH) ......67 Lubricating Oil ......365 Lubrication, Body .
Page 430 430 INDEX Change Interval ..... . . 342 Dipstick ......340 Disposal .
Page 431 Sunroof ......168 Windows ......34 Power Steering Fluid .
Page 432 432 INDEX Replacement Parts ..... . . 339 Replacement Tires ..... . . 280 Reporting Safety Defects .
Page 433 Sentry Key Programming ....12 Service and Maintenance ... . . 340,390,391 Service Assistance .
Page 434 434 INDEX Stuck, Freeing ......264 Sun Roof ......168 Supplemental Tire Pressure Information .
Page 435 Spare Tire ......319 Spinning ......278 Tread Wear Indicators .
Page 436 436 INDEX Transmitter Programming (Remote Keyless Entry) ....24 Tread Wear Indicators ....279 Trip Computer .
Page 437 Windshield Wiper Blades ....352 Windshield Wipers ..... . . 137 Wiper Blade Replacement .
Page 438 NOTES...
Page 439 NOTES...
Page 440 NOTES...
