Page 1: Table Of Contents
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 3 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 4: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer oriented documents. You are urged to read these publications carefully.
Page 5: Van Conversions/Campers
This number also appears on the Automobile Information Disclosure Label affixed to a window on your vehicle. Save this label for a convenient record of your vehicle identification number and optional equipment.
Page 6: Vehicle Modifications / Alterations
6 INTRODUCTION NOTE: It is illegal to remove the VIN plate. VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 7 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....10 Key-In-Ignition Reminder ....10 Sentry Key —...
Page 8 8 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Security Alarm System — If Equipped ..20 Rearming Of The System ....20 To Set The Alarm .
Page 9 Safety Tips ......68 Transporting Passengers ....68 Lock Your Vehicle .
Page 10: 10 Things To Know Before Starting Your Vehicle
10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The double sided keys may be inserted into the locks with either side up. The keys for your new vehicle are enclosed in a plastic bag with a bar code label affixed to the front.
Page 11 The Security Light , located in the instrument cluster, will illuminate for about 3 seconds when the ignition switch is first turned to the ON position. If the vehicle electronics do not receive a valid signal from the ignition key, the Security Light will flash continuously to signal that the vehicle has been immobilized.
Page 12 12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Insert the second valid key and switch the ignition to the ON position within 15 seconds. After 10 seconds the Security Light will begin to flash. Turn the ignition back to the OFF position and remove the second key. 3.
Page 13: Ignition And Steering Lock - If Equipped
IGNITION AND STEERING LOCK — IF EQUIPPED Manual Transmissions Depress and hold the release button located between the ignition switch and the instrument panel. Turn the igni- tion key to LOCK and remove the key. Manual Transmissions THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 DOOR KEY The same key used to start the vehicle is also used to unlock the doors.
Page 14 14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! When leaving the vehicle always remove the key from the ignition lock, and lock your vehicle. Do not leave children unattended in the vehicle, or with access to an unlocked vehicle. Unsupervised use of vehicle equipment may cause severe personal inju- ries and death.
Page 15 Automatic Door Locks If this feature is enabled, your door locks will lock automatically when the vehicle’s speed exceeds 15 mph. This feature is enabled when your vehicle is shipped from the assembly plant and can be disabled by using the following procedure: 1.
Page 16: Remote Keyless Entry - If Equipped
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY — IF EQUIPPED Three Button Transmitter This system allows you to lock or unlock the doors from distances up to about 23 feet (7 meters) using a hand held radio transmitter.
Page 17: To Lock The Doors
5. This will enable you to unlock all doors on the first press of the UNLOCK button. To lock the doors: Press and release the LOCK button on the transmitter to lock all doors. If the ignition is OFF, when the doors are locked, the parking lights will flash on once and the horn will chirp once.
Page 18: Using The Panic Alarm
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. To reactivate this feature, repeat the above steps. Using the Panic Alarm To activate the Panic mode while the ignition is OFF press and release the PANIC button on the transmitter once. When the Panic mode is activated, the interior lights will illuminate, the headlamps and parking lights will flash, and the horn will sound.
Page 19: Transmitter Battery Service
2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios. Transmitter Battery Service Transmitter Battery Replacement The recommended replacement battery is a 3V lithium 2016 cell. This transmitter requires two batteries. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 NOTE: Do not touch the battery terminals that are on the back housing or the printed circuit board.
Page 20: Security Alarm System - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SECURITY ALARM SYSTEM — IF EQUIPPED This system monitors the vehicle doors and ignition for unauthorized operation. When the alarm is activated, the system provides both audible and visual signals. For the first 3 minutes the horn will sound and the headlights and security telltale will flash repeatedly.
Page 21: Windows
horn will sound three times when you unlock the doors and the security lamp will flash for 30 seconds. Check the vehicle for tampering. The Security system will also disarm, if the vehicle is started with a programmed Sentry Key. If an unpro- grammed Sentry Key is used to start a vehicle, the engine will run for 2 seconds and then the security alarm will be initiated.
Page 22 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Window Switches The control on the left front door panel has up-down switches that give you fingertip control of all power windows. There is a single opening and closing switch on the front passenger door for passenger window control.
Page 23: Power Sliding Rear Window-If Equipped
Window Lockout Switch (4 Door Models Only) The window lockout switch on the driver’s door allows you to disable the window control on the other doors. To disable the window controls on the other doors, press the window lock button. To enable the window controls, press the window control button again.
Page 24: Sliding Rear Window
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Sliding Rear Window A locking device in the center of the window helps to prevent entry from the rear of the vehicle. Squeeze the lock to release the window. WIND BUFFETING Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears.
Page 25: Lap/Shoulder Belts
WARNING! In a collision, you and your passengers can suffer much greater injuries if you are not properly buck- led up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle.
Page 26 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat belts.
Page 27 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. Latch Plate 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 plate and pull out the belt.
Page 28 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • A belt buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal injuries. Always buckle your belt into the buckle nearest you. •...
Page 29 WARNING! • A lap belt worn too high can increase the risk of internal injury in a collision. The belt forces won’t be at the strong hip and pelvic bones, but across your abdomen. Always wear the lap belt as low as pos- sible and keep it snug.
Page 30 30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Standard Cab Front Center Three Point Belt 1. The front center seat belt on the Standard Cab may be disconnected to open up utilization of the storage areas behind the front seats. The black latch plate can be detached from the black keyed seat belt buckle located on the inboard side of the passenger seat.
Page 31 WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in a collision.
Page 32: Adjustable Upper Shoulder Belt Anchorage
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In Use Position WARNING! If the black latch and buckle are not connected when the seat belt is used by an occupant, the seat belt will not restrain you properly. Adjustable Upper Shoulder Belt Anchorage In the front row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck.
Page 33: Automatic Locking Retractors (Alr) Mode - If Equipped
Adjusting Upper Shoulder Belt As a guide, if you are shorter than average, you will prefer a lower position, and if you are taller than average, you’ll prefer a higher position. When you release the anchorage, try to move it up or down to make sure that it is locked in position.
Page 34: Center Lap Belts
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. How To Disengage The Automatic Locking Mode Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic lock- ing mode and activate the vehicle sensitive (emergency)
Page 35: Enhanced Seat Belt Reminder System (Beltalert)
NOTE: These devices are not a substitute for proper seat belt placement by the occupant. The seat belt still must be worn snugly and positioned properly. The pretensioners are triggered by the airbag control module. Like the airbags, the pretensioners are single use items.
Page 36: Seat Belts And Pregnant Women
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Within 60 seconds of turning the ignition switch to the ON position, unbuckle and then re-buckle the driver’s seat belt at least three times within 10 seconds, ending with the seat belt buckled. NOTE: Watch for the Seat Belt Warning Light to turn on while unbuckling and off while re-buckling the seat belt.
Page 37: Driver And Right Front Passenger Supplemental Restraint System (Srs)-Airbags
WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use the seat belt extender when the lap belt is not long enough when it is worn low and snug, and in the recommended seating positions.
Page 38 38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The front airbags are certified to the Federal regulations that allow less forceful deployment. The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity and occupant size.
Page 39 Along with the seat belts, front airbags work with the instrument panel knee bolsters to provide improved protection for the driver and front passenger. Window bags also work with seat belts to improve occupant protection. The seat belts are designed to protect you in many types of collisions.
Page 40 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. If your vehicle has window bags, do not lean against the door or window, airbags will inflate forcefully into the space between you and the door. 5. If the airbag system in this vehicle needs to be modified to accommodate a disabled person, contact the Customer Center.
Page 41 Air Bag System Components The airbag system consists of the following: • Occupant Restraint Controller • Side Remote Acceleration Sensors (If Equipped) • Airbag Warning Light • Driver Airbag • Passenger Airbag • Window Bags above Side Windows (If Equipped) •...
Page 42 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How the Airbag System Works • The Occupant Restraint Controller (ORC) determines if a frontal collision is severe enough to require the airbags to inflate. The front airbag inflators are de- signed to provide different rates of airbag inflation from direction provided by the ORC.
Page 43 • If your vehicle is equipped with an Occupant Classi- fication System (OCS), the sun visor air bag warning label will have the phrase even with advanced air bags on it. The OCS will instruct the ORC to either suppress the deployment of the front passenger airbag or reduce the force of a deploying passenger airbag, in the unlikely event that a rear-facing infant seat is in the front passenger seat.
Page 44 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE For almost all properly installed rear facing child re- straints, the PAD indicator light (If Equipped) will be illuminated indicating that the front passenger airbag is turned off and will not inflate. If the PAD indicator light is not illuminated, DO NOT assume the air bag is turned off and move the child restraint to the second row of seats.
Page 45 on the seat will also be sensed. The weight of an adult will cause the system to turn the airbag on. In this case, the OCS has classified the occupant of the seat as an adult. An adult occupant needs to sit in a normal position (with their feet on or near the floor) in order to be properly classified.
Page 46 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE airbag is turned off until the fault is cleared. If an object is lodged under the seat and interferes with operation of the weight sensors, a fault will occur which turns on both the PAD Indicator Light (If Equipped) and the Airbag Warning Light.
Page 47 • Your vehicle has four Weight Sensors (If Equipped) located between the seat and the floor pan. The weight sensors measure applied weight and transfers that information to the OCM. • The Side Impact SRS Window Bags are designed to activate only in certain side collisions.
Page 48 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Do not use prior or future model year seat covers not designated for the specific model being repaired. Al- ways use the correct seat cover specified for the vehicle. • Do not replace the seat cover with an aftermarket seat cover.
Page 49 Passenger Airbag On/Off Switch – (Standard Cab Vehicles Only) THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 The passenger front airbag is to be turned off only if the passenger: • is an infant (less than 1 year old) who must ride in the front seat because there is no rear seat, because the rear seat is too small for a rear-facing infant restraint or because the infant has a medical condition which...
Page 50 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Whenever an airbag is turned off, even a lap/ shoulder belted passenger may hit their head, neck, or chest on the dashboard (instrument panel) or windshield in a crash. This may result in serious injury or death.
Page 51 If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor.
Page 52: Enhanced Accident Response System
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper right side of the instrument panel.
Page 53: Event Data Recorder (Edr)
• The light remains on or flickers after the 6 to 8 second interval. • The light flickers or comes on and remains on while driving. NOTE: If the speedometer, tachometer or any engine related gauges are not working, the airbag control mod- ule may also be disabled.
Page 54 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE provided to the custodial entity upon request. General data that does not identify particular vehicles or crashes may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states.
Page 55: Child Restraint
Child Restraint Everyone in your vehicle needs to be buckled up all the time — babies and children, too. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.
Page 56 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants and Small Children There are different sizes and types of restraints for children from newborn size to the child almost large enough for an adult safety belt. Use the restraint that is correct for your child: •...
Page 57 • The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seat back, they should use a belt-positioning-booster seat.
Page 58 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards.
Page 59 • If the belt still can’t be tightened, or if pulling and pushing on the restraint loosens the belt, disconnect the latch plate from the buckle, turn the buckle around, and insert the latch plate into the buckle again. If you still can’t make the child restraint secure, try a different seating position.
Page 60 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Identification dots are located above the standard cab front seat lower anchorages as a guide for locating lower anchors. NOTE: For children riding in the front seat of a Stan- dard Cab model refer to the “Passenger Airbag On/Off Switch”...
Page 61 Child restraint systems having attachments designed to connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection to the seatback tether anchorage have been available for some time. In fact, many child restraint manufacturers will provide add-on tether strap kits for some of their older products.
Page 62 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing the Child Restraint System WARNING! Do not install child restraint systems equipped with LATCH attachments in the center position of a Quad Cab model rear seat. The LATCH anchorages in this seat are designed for the two outboard seating posi- tions only.
Page 63 WARNING! Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint. Child Restraint Tether Anchor Child restraints having tether straps and hooks for con- nection to tether anchors have been available for some...
Page 64 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. Lift the cover (if so equipped), and attach the hook to the square opening in the sheet metal. 3. Install the child restraint and remove the slack in the tether strap according to the manufacturer’s instructions. Regular Cab Tether Strap Mounting Multiple Child Restraint Installation Sequence - (Quad Cab Rear Seats)
Page 65 5. Place a child restraint on the center rear seat and adjust the tether strap so that it will reach under the head restraint to the tether anchor directly behind the seat and to the anchor directly behind the right seat. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 6.
Page 66 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Quad Cab Tether Strap Mounting...
Page 67: Engine Break-In Recommendations
Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seat back should use the lap/shoulder belt in a rear seat. •...
Page 68: Safety Tips
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Check the engine oil level at every fuel fill. NOTE: A new engine will consume some oil during the first few thousand miles of operation. This should be considered as a normal part of the break-in and not interpreted as a sign of difficulty.
Page 69: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases contain carbon monoxide, a poten- tially toxic gas that by itself is colorless and odorless. To avoid inhaling these gases, the following precau- tions should be observed: • Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 70: Vehicle
70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Safety Checks You Should Make Inside The Vehicle Seat Belts Inspect the belt system periodically, checking for cuts, frays and loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after an accident if they have been damaged (bent retractor, torn webbing, etc.) or if the front airbags have deployed.
Page 71 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Hands–Free Communication (UConnect™) — If Equipped ......76 Operations .
Page 72 72 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlamp Delay ..... . 108 Headlights, Parking Lights, Panel Lights ..108 Daytime Running Lights (Canada Only And Fleet Vehicles) .
Page 73 US/M Button ......121 Reset Button ......121 Global Reset .
Page 74 74 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Venting Sunroof - Express ....135 Sunshade Operation ....135 Wind Buffeting .
Page 75 Tonneau Cover Removal — If Equipped ..152 Mirrors ......157 Automatic Dimming Mirror—...
Page 76: 76 Understanding The Features Of Your Vehicle
76 UNDERSTANDING THE FEATURES OF YOUR VEHICLE HANDS–FREE COMMUNICATION (UConnect™) — IF EQUIPPED UConnect™ is a voice-activated, hands-free, in- vehicle communications system. UConnect™ allows you to dial a phone number with your cellular phone using simple voice commands (e.g., Call” “Mike” ”Work or Dial” “248-555-1212 ).
Page 77: Operations
access the system. The diagram below shows the mirror with the appropriate buttons. Individual button behavior is discussed in the Operation section. UConnect™ Switches The UConnect™ system can be used with any Hands- Free Profile certified Bluetooth™ cellular phone. See www.chrysler.com/uconnect for supported phones.
Page 78 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Prior to giving a voice command, one must wait for the voice on beep, which follows the Ready prompt or another prompt. • For certain operations, compound commands can be used. For example, instead of saying Setup and then Phone Pairing, the following compound command can be said: Setup Phone Pairing.
Page 79 NOTE: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect The following are general phone to UConnect™ System pairing instructions: • Press the ’Phone’ button to begin.
Page 80 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • For identification purposes, you will be prompted to give the UConnect™ system a name for your cellular phone. Each cellular phone that is paired should be given a unique phone name. • You will then be asked to give your cellular phone a priority level between 1 and 7, 1 being the highest priority.
Page 81 Call by Saying a Name • Press the “Phone” button to begin. • After the Ready prompt and the following beep, say Call. • System will prompt you to say the name of the person you want call. • After the Ready prompt and the following beep, say the name of the person you want to call.
Page 82 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you are finished adding an entry into the phone- book, you will be given the opportunity to add more phone numbers to the current entry or to return to the main menu. The UConnect™...
Page 83 Delete Entries in the UConnect™ Phonebook NOTE: Editing phonebook entries is recommended when vehicle is not in motion. • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Phonebook Delete. • After you enter the Phonebook Delete menu, you will then be asked for the name of the entry that you wish to delete.
Page 84: Phone Call Features
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After confirmation, the phonebook entries will be deleted. List All Names in the UConnect™ Phonebook • Press the ’Phone’ button to begin. • After the Ready prompt and the following beep, say Phonebook List Names.
Page 85 Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cell phone.
Page 86 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Conference Call When two calls are in progress (one active and one on hold), press and hold the ’Phone’ button until you hear a double beep indicating that the two calls have been joined into one conference call.
Page 87: Uconnect™ System Features
• After ignition key is switched to off, a call can continue on the UConnect™ system for certain duration, after which the call is automatically transferred from the UConnect™ system to the mobile phone. • An active call is automatically transferred to the mobile phone after ignition key is switched to off.
Page 88 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say Emergency and the UConnect™ system will instruct the paired cellular phone to call the emergency num- ber. This feature is only supported in the USA. NOTE: The emergency number dialed is based on the Country where the vehicle is purchased (911 for USA and Canada and 060 for Mexico).
Page 89 Paging To learn how to page, refer to section Working with Automated Systems. Paging works properly except for pagers of certain companies which time-out a little too soon to work properly with the UConnect™ system. Voice Mail Calling To learn how to access your voice mail, refer to section Working with Automated Systems.
Page 90 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turning Confirmation Prompts On/Off Turning confirmation prompts off will stop the system from confirming your choices (e.g. the UConnect™ sys- tem will not repeat a phone number before you dial it). • Press the ’Phone’ button to begin. •...
Page 91: Advanced Phone Connectivity
Mute/Un-mute (Mute off) When you mute the UConnect™ system, you will still be able to hear the conversation coming from the other party, but the other party will not be able to hear you. In order to mute the UConnect™ system: •...
Page 92 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you would like to connect or disconnect the Blue- tooth™ connection between a UConnect™ paired cellular phone and the UConnect™ system, follow the instruction described in your cellular phone user’s manual. List Paired Cellular Phone Names •...
Page 93: Things You Should Know About Your Uconnect™ System
• The selected phone will be used for the next phone call. If the selected phone is not available, the UCon- nect™ system will return to using the highest priority phone present in or near (approximately with in 30 feet) the vehicle. Delete UConnect™...
Page 94 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • low road noise, • smooth road surface, • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some.
Page 95 • smooth road surface, • fully closed windows, and • dry weather condition. • Operation from driver seat. • Performance, such as, audio clarity, echo. and loud- ness to a large degree, rely on the phone and network, and not the UConnect™ system. •...
Page 96 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97...
Page 98 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 99: Seats
North American English Primary Alternate(s) Zero Add location Add new All of them Confirmation prompts Confirmations prompts Delete a name Delete Language Select language List names List all List paired phones List phones Pager Beeper Phone pairing Pairing Phonebook Phone book Return to main menu Return.
Page 100: 40-20-40 Front Seat
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust any seat only while the vehicle is parked.
Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 The power seat controls are on the outboard side of the front seat cushions. One switch controls the seat move- ment. The six-way switch can be moved forward or back- wards to get the most comfortable position. The same switch can be moved up and down to control seat height or to change the seat angle by tilting it up or down.
Page 102: Manual Passenger Seat
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Passenger Seat Passenger Side Manual The passenger seat is adjustable forward or backward and is equipped with a back recliner. Manual Seatback Recline The recliner handle is on the outside of the seat cushion. Pull up on the handle, as shown, to release the seat back and adjust for comfort.
Page 103: Adjustable Head Restraints
WARNING! You can be seriously, even fatally, injured riding in a seat with the seatback reclined. Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. If you ride in this position, the shoulder harness will no longer be restraining you.
Page 104: Heated Seats - If Equipped
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped The heated seat switches are located in the instrument panel under the climate controls. Heated Seat Switches Each heated seat switch has two settings (HI and LOW). Press the switch once to obtain High heat level, then press the switch again to obtain Low heat level.
Page 105: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD To open the hood, two latches must be released. First pull the hood release lever located below the steering wheel at the base of the instrument panel. Once the hood is released you must reach into the opening beneath the center of the grille and push up the latch to release the safety catch before raising the hood.
Page 106: Lights
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS WARNING! If the hood is not fully latched, it could fly up when the vehicle is moving and block your forward vision. Be sure all hood latches are latched fully before driving. Headlight Switch Location...
Page 107: Interior Lights
Interior Lights Dimmer Control Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the right side of the switch) is rotated to the upward detent position, or if equipped, when the UN- LOCK button is pressed on the key fob.When a door is UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 open and the interior lights are on, rotating the dimmer...
Page 108: Battery Saver
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Battery Saver To protect the life of your vehicle’s battery, Load Shed- ding is provided for both the interior and exterior lights. If the ignition is off and any door is left ajar for 10 minutes or the dimmer control is rotated upwards for 10 minutes, the interior lights will automatically turn off.
Page 109: Daytime Running Lights (Canada Only And Fleet Vehicles)
Light Switch Rotation Your vehicle is equipped with plastic headlight lenses that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth.
Page 110: Lights-On Reminder
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-on Reminder If the headlights, parking lights, or cargo lights are left on, after the ignition is turned off, a chime will sound when the driver’s door is opened. Fog Lights — If Equipped The foglights are turned ON by placing the head- light rotary control in the parking light or head- light position and pushing in the headlight rotary...
Page 111: Multifunction Control Lever
MULTIFUNCTION CONTROL LEVER The multifunction control lever is located on the left side of the steering column. Turn Signals Move the lever up or down to signal a right-hand or left-hand turn. The arrow on either side of the instrument cluster flashes to indicate the direction of the turn, and proper operation of the front and rear turn signal lights.
Page 112: High Beam / Low Beam Select Switch
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High Beam / Low Beam Select Switch Pull the multifunction control lever fully toward the steering wheel to switch the headlights from HIGH or LOW beam. High Beam / Low Beam Windshield Wipers Windshield Wiper / Washer Switch The wipers and washers are operated by a switch in the multifunction control lever.
Page 113 Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle, with a variable pause between cycles, desirable. For maximum delay between cycles, rotate the control knob into the upper end of the delay range. The delay interval decreases as you rotate the knob until it enters the LO continual speed position.
Page 114: Windshield Washers
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers To use the washer, push in on the washer knob on the end of the multifunction control lever and hold while spray is desired. If the washer knob is depressed while in the delay range, the wiper will operate for several seconds after the washer knob is released.
Page 115: Driver Adjustable Pedals
WARNING! Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering col- umn, you could lose control of the vehicle and have an accident. Adjust the column only while the ve- hicle is stopped. Be sure it is locked before driving. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 DRIVER ADJUSTABLE PEDALS Adjustable Pedals Switch...
Page 116: Adjustment
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjustment 1. Position the driver seat so that you are at least 10 inches (254 mm) away from the airbag located in the center of the steering wheel. 2. Fasten and adjust the seatbelts. 3.
Page 117: Electronic Speed Control
ELECTRONIC SPEED CONTROL When engaged, this device takes over accelerator opera- tion at speeds greater than 35 mph (56 km/h). The controls are mounted on the steering wheel. Speed Control Switches UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 To Activate Push the ON/OFF button to the ON position.
Page 118: To Resume Speed
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Leaving the Speed Control ON when not in use is dangerous. You could accidentally set the system to cause it to go faster than you want. You could lose control and have an accident. Always leave the system OFF when you aren’t using it.
Page 119: Overhead Console
for your specific engine), the speed control will automati- cally disengage. If this happens, you can push down on the accelerator pedal to maintain the desired speed. Vehicles equipped with a 6–speed-manual transmission should be operated in 5th gear or lower under the above conditions.
Page 120: Courtesy/Reading Lights
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Courtesy/Reading Lights In the middle of the console are two courtesy/reading lights. Both lights illuminate as courtesy lights when a door is opened, when the dimmer control is rotated to the courtesy light position (fully upward position), or when the UNLOCK button is pressed on the Remote Keyless Entry transmitter, if so equipped.
Page 121: Us/M Button
US/M Button Use this button to change the display from U.S. to metric measurement units. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 RESET Button Use this button to reset the following displays to zero: Average Fuel Economy Trip Odometer Elapsed time...
Page 122: Global Reset
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Global Reset If the RESET button is pressed twice within 2 seconds while in any of the 3 resettable displays (AVG ECO, ODO, ET), the Global Reset will reset all 3 displays. Step Button Use this button to choose or cycle through the four trip conditions.
Page 123: Trip Odometer (Odo)
When the DTE value is less than 30 miles estimated driving distance, the DTE display will change to an alternating test display of “LO” and “FUEL”. This dis- play will continue until the vehicle runs out of fuel. Adding a significant amount of fuel to the vehicle will turn off the “LO FUEL”...
Page 124: C/T Button
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE C/T Button Use this button to select a readout of the outside tem- perature and one of eight compass headings that indicate the direction in which the vehicle is facing. WARNING! Even if the display still reads a few degrees above 32°F ( 0°C), the road surface may be icy, particularly in woods or on bridges.
Page 125: Manual Compass Calibration
Manual Compass Calibration NOTE: To ensure proper compass calibration, make sure the compass variance is properly set before manu- ally calibrating the compass. If the compass appears erratic and the CAL symbol does not appear, you must manually put the compass into the “Calibration”...
Page 126: Outside Temperature
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The default for the compass variance is zone 8. To set the variance: Turn the ignition ON and set the display to “Compass/Temperature.” Press and hold the RESET button approximately five seconds. The last vari- ance zone number will be displayed.
Page 127: Garage Door Opener
GARAGE DOOR OPENER The HomeLink Universal Transceiver replaces up to three remote controls (hand held transmitters) that oper- ate devices such as garage door openers, motorized gates, or home lighting. It triggers these devices at the push of a button. The Universal Transceiver operates off your vehicle’s battery and charging system;...
Page 128: Programming Homelink
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! A moving garage door can cause injury to people and pets in the path of the door. People or pets could be seriously or fatally injured. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 129 WARNING! Vehicle exhaust contains carbon monoxide, a danger- ous gas. Do not run the vehicle’s exhaust while training the transceiver. Exhaust gas can cause seri- ous injury or death. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver.
Page 130 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Some gate operators and garage door openers may require you to replace this Programming Step 3 with procedures noted in the Gate Operator/Canadian Pro- gramming section. 4. The HomeLink indicator light will flash slowly and then rapidly after HomeLink successfully receives the frequency signal from the hand-held transmitter.
Page 131: Canadian Programming/Gate Programming
and, depending on the brand of the garage door opener (or other rolling code equipped device), repeat this sequence a third time to complete the programming. HomeLink should now activate your rolling code equipped device. NOTE: To program the remaining two HomeLink but- tons, begin with Programming step two.
Page 132: Erasing Homelink Buttons
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE etc.). For convenience, the hand-held transmitter of the device may also be used at any time. In the event that there are still programming difficulties or questions, contact HomeLink at: www.homelink.com or 1-800-355- 3515.
Page 133: Power Sunroof - If Equipped
This device complies with part 15 of FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference that may be received including interference that may cause undes- ired operation.
Page 134: Open Sunroof - Express Mode
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Never leave children in a vehicle, with the keys in the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch. Such entrapment may result in serious injury or death.
Page 135: Closing Sunroof - Express
Closing Sunroof - Express Press the switch forward and release, and the sunroof will close automatically from any position. The sunroof will close fully and stop automatically. This is called Express Close. During Express Close operation, any movement of the switch will stop the sunroof. Pinch Protect Feature This feature will detect an obstruction in the opening of the sunroof during Express Close operation.
Page 136: Wind Buffeting
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions.
Page 137 All accessories connected to this outlet should be re- moved or turned OFF when the vehicle is not in use to protect the battery against discharge. There is an additional Pop-Up Power Outlet in the center console ahead of the shifter lever. This outlet is powered only when the ignition switch is in the On or Accessories position.
Page 138: Cigar Lighter And Ash Receiver
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER Cigar Lighter and Ash Receiver (vehicles equipped with a manual transmission) On vehicles equipped with a manual transmission, the ash receiver is opened and closed by pushing on the front surface of the receiver and then allowing the receiver to open.
Page 139: Cupholders
NOTE: As a child safety precaution, the lighter only operates with the ignition switch ON. It heats when pushed in and pops out automatically when ready for use. To preserve the heating element, do not hold the lighter in the heating position. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 CUPHOLDERS Front Instrument Panel Cupholders (40–20–40...
Page 140 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To secure the cup, place the cup to be held into one of the cup wells and then push the cupholder arm toward the cup until it is held stable. Cup Holders Automatic Transmission Cup Holder Door Handle...
Page 141: Front Instrument Panel Cupholders (Bucket Seats) - Automatic Transmission
Front Instrument Panel Cupholders (Bucket Seats) — Automatic Transmission If your new Ram truck is equipped with bucket seats there are three cup holders located on the front of the center console. Cup Holders Bucket Seat UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 Front Cupholders —...
Page 142: Storage
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Center Storage Compartment The center portion of the seat folds down to provide an armrest with unique storage compartments under the lid. Push the button on the front of the armrest to raise the cover.
Page 143: Center Storage Compartment (Bucket Seats)- If Equipped
Center Storage Compartment (Bucket Seats)— If Equipped Center Storage Compartment Push the upper button on the front of the armrest to raise the upper cover. Inside is a power outlet (if equipped), a cut out for a cell phone charger cord, removable coin holder (if equipped), and a divider to configure the UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 storage area into separate compartments.
Page 144: Storage And Seats
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e. cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent engine starting.
Page 145: Fold Flat Load Floor - If Equipped
There is also storage behind the seat. This storage area contains the 10 inch subwoofer. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 FOLD FLAT LOAD FLOOR — IF EQUIPPED Fold Flat Load Floor — If Equipped Quad Cab models with a 60/40 rear seat, may be equipped with a folding steel load floor under the right rear seat.
Page 146 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not operate the vehicle with loose items stored on the load floor. While driving or in an accident you may experience, abrupt stopping, rapid acceleration, or sharp turns. Loose objects stored on the load floor may move around with force and strike occupants, resulting in serious or fatal injury.
Page 147 Load Floor In Open Position 3. Reverse the procedure to store the load floor. Positioning the Load Floor for Storage Access Under the Seat 1. Lift the 60/40 seat cushion(s) to the upward position. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 2.
Page 148 148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not drive with the load floor in the up position. When stopping fast or in an accident, the load floor could move to the down position causing serious injury. Rear Seat Storage Location 4.
Page 149: Pickup Box
PICKUP BOX Pickup Box Features The pickup box on your new Ram has many features designed for utility and convenience. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 NOTE: If you are installing a toolbox to the front of the pickup box, you must use Mopar available from your dealer.
Page 150: Slide-In Campers
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Care should always be exercised when operating a vehicle with unrestrained cargo. Vehicle speeds may need to be reduced. Severe turns or rough roads may cause shifting or bouncing of the cargo that may result in vehicle damage.
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Raise the right side of the tailgate until the right side pivot clears the hanger bracket. Slide the entire tailgate to the right to free the left side pivot. Remove the tailgate from the vehicle entirely. Do not carry the tailgate loose in the truck pickup box.
Page 152: Tonneau Cover Removal - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TONNEAU COVER REMOVAL — IF EQUIPPED NOTE: This procedure requires a minimum of two (2) people to complete. 1. Lower the tailgate. Lowering The Tailgate 2. Pull the handle, located at the center rear of the underside of the cover, to release the latches and lift the cover to the up position.
Page 153 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 3. Remove the right and left attach bolts from front hinges. Pulling The Latch Release Handle Left Hinge And Attach Bolt...
Page 154 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Move the two, already in open position, latches at rear corner of the cover into the closed position. Placing The Rear Latches In Closed Position 5. While supporting the cover, release both gas prop rods using the quick disconnects Quick Disconnect(s)
Page 155 6. Swing the gas prop rods into the storage clips, on the cover. Prop Rod Stowage Clip UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 7. Lower the rear of cover with the latches in the closed position onto strikers to create space for hands to lift cover.
Page 156 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 8. Lift the cover straight up and the carry cover towards the rear of the vehicle Lifting Cover Up Carrying Cover Toward The Rear Of the Vehicle Reverse the procedure for installation. NOTE: Insert the locator pins on the front hinges into the front locator pin holes, on the top edge of the bed.
Page 157: Mirrors
MIRRORS Automatic Dimming Mirror— If Equipped This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light in the button will indicate when the dimming feature is activated.
Page 158: Exterior Mirrors Folding Feature
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Vehicles and other objects seen in a right side convex mirror will look smaller and farther away than they really are. Relying too much on your right side convex mirror could cause you to collide with an- other vehicle or other object.
Page 159: Electric Rear Window Defroster And Heated
Power Mirror Switches Set the top switch to the left or right for the left or right mirror, and set it to the center off position to prevent accidentally moving a mirror when you are finished adjusting the mirror. To adjust a mirror, select left or right with the top switch, and press one of the four arrows for the direction you want the mirror to move.
Page 161 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instruments And Controls ....163 Instrument Cluster ..... . 164 Instrument Cluster Description .
Page 162 162 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (CD Mode For MP3 Audio Play) ..185 Load/Eject Button (CD Mode For MP3 Play) . . 185 Video Entertainment System (Sales Code XRV) — If Equipped .
Page 163: Understanding Your Instrument Panel 163
UNDERSTANDING YOUR INSTRUMENT PANEL 163 INSTRUMENTS AND CONTROLS...
Page 164: Instrument Cluster
164 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER...
Page 165: Instrument Cluster Description
INSTRUMENT CLUSTER DESCRIPTION 1. Check Gages This light illuminates when the Voltmeter, Engine Oil Pressure or Engine Coolant Temperature gages indicate a reading either too high or too low. Examine the gages carefully, and follow the instructions above for each indicated problem. NOTE: When the ignition switch is turned to OFF, the Fuel Gage, Voltmeter, Oil Pressure and Engine Coolant Temperature gages may not show accurate readings.
Page 166 166 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Do not operate the engine with the tachometer pointer at high rpm for extended periods. Engine damage may occur. 5. Airbag Indicator Light The indicator lights and remains lit for 6 to 8 seconds when the ignition is first turned on.
Page 167 NOTE: If the gauge pointer moves to either extreme of the gauge, the “Check Gages” indicator will illuminate and a single chime will sound. 10. TOW HAUL The TOW HAUL button is located at the end of the gear shift lever. This light will illuminate when the TOW HAUL button is pushed once.
Page 168 168 UNDERSTANDING YOUR INSTRUMENT PANEL 12. Security The light will flash rapidly for approximately 16 seconds when the vehicle theft alarm is arming. The light will flash at a slower rate after the alarm is set. The security light will also come on for about two seconds when the ignition is first turned ON.
Page 169 15. Check Gages Light This light is part of an onboard diagnostic system which monitors the emissions and engine control system. If the vehicle is ready for emissions testing the light will come on when the ignition is first turned on and remain on, as a bulb check, until the engine is started.
Page 170 170 UNDERSTANDING YOUR INSTRUMENT PANEL If the light remains on when the parking brake is released, it indicates a possible brake hydraulic system malfunction. In this case, the light will remain on until the cause is corrected. If brake failure is indicated, immediate repair is necessary and continued operation of the vehicle in this condition is dangerous.
Page 171 as 4-wheel-drive operation (e.g. off- road operation). If this light comes on, stop the vehicle and run the engine at idle or faster, with the transmission in NEUTRAL until the light goes off. 21. Low Washer Fluid Light This light comes on when the washer fluid level falls below approximately 1/4 full.
Page 172: Electronic Digital Clock
172 UNDERSTANDING YOUR INSTRUMENT PANEL 25. Door Ajar The Door Ajar light will illuminate when any door is opened. When the ignition is ON the Door Ajar light will stay illuminated until the open door is closed. When the ignition is OFF the Door Ajar light will stay illuminated until the open door is closed or the battery saver feature automatically turns the light off.
Page 173: Clock Setting Procedure
Clock Setting Procedure 1. Press and hold the time button until the hours blink. 2. Adjust the hours by turning the right side Tune / Audio control. 3. After the hours are adjusted, press the right side Tune / Audio control to set the minutes. 4.
Page 174: Operating Instructions - Satellite Radio (If Equipped)
174 UNDERSTANDING YOUR INSTRUMENT PANEL Satellite Navigation Radio with CD Player with MP3 Capability (REC) - combines a Global-Positioning System-based navigation system with an integrated color screen to provide maps, turn identification, selection menus and instructions for selecting a variety of destina- tions and routes, AM/FM stereo radio and six-disc CD changer with MP3 capability.
Page 175: Operating Instructions - Radio Mode
Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Press the ON/VOL control to turn the radio ON. Press the ON/VOL a second time to turn OFF the radio. Electronic Volume Control The electronic volume control turns continuously (360 degrees) in either direction without stopping.
Page 176 176 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: In Hands Free Phone (if equipped) mode, the MUTE button mutes the microphone. SCAN Button (Radio Mode) Pressing the SCAN button causes the tuner to search for the next listenable station, in either AM, FM or Satellite (if equipped) frequencies, pausing for 5 seconds at each listenable station before continuing to the next.
Page 177 TUNE Control (Radio Mode) Turn the right side rotary control clockwise to increase or counter-clockwise to decrease the frequency. AM/FM Button (Radio Mode) Press the button to select AM or FM Modes. Setting the Tone, Balance, and Fade Press the rotary TUNE control and BASS will display. Turn the TUNE control to the right or left to increase or decrease the Bass tones.
Page 178 178 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the PTY button to select the following format types: 16 Digit-Character Dis- Program Type No program type or un- defined Adult Hits Alert Alert Classical Classic Rock College Country Emergency Test Foreign Language Foreign_Language Information Jazz News...
Page 179 By pressing the SEEK button when the PTY icon is displayed, the radio will be tuned to the next frequency station with the same selected PTY name. The PTY function only operates when in the FM mode. If a preset button is activated while in the PTY (Program Type) mode, the PTY mode will be exited and the radio will tune to the preset station.
Page 180: Operation Instructions - (Cd Mode For Cd Audio Play)
180 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - (CD MODE for CD Audio Play) NOTE: The ignition switch must be in the ON or ACC position to operate the radio. NOTE: Note: This Radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW) compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 181: (Cd Mode For Cd Audio Play)
MUTE Button (CD MODE for CD Audio Play) Press the MUTE button to cancel the sound from the speakers. MUTE will be displayed. Press the MUTE button a second time and the sound from the speakers will return. Rotating the volume control, turning the radio ON/OFF, or turning OFF the ignition will also return the sound from the speakers.
Page 182 182 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within 15 seconds, it will be reloaded. If the CD is not removed, the radio will continue to play the non-removed CD. If the CD is removed and there are other CD’s in the radio, the radio will play the next CD after a 2 minute timeout.
Page 183: Notes On Playing Mp3 Files
Press the SEEK button to move to the next randomly selected track. Press and hold the FF button to fast forward through the tracks. Release the FF button to stop the fast forward feature. Press the RND button a second time to stop Random Play.
Page 184 184 UNDERSTANDING YOUR INSTRUMENT PANEL Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs.
Page 185: Operation Instructions
Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files. Loading times for playback of MP3 files may be affected by the following: •...
Page 186 186 UNDERSTANDING YOUR INSTRUMENT PANEL LOAD / EJECT - Eject Press the LOAD/ EJECT button and the push- button with the corresponding number where the CD was loaded and the disc will unload and move to the entrance for easy removal. Radio display will show EJECTING DISC when the disc is being ejected and prompt the user to remove the disc.
Page 187: Video Entertainment System (Sales Code Xrv) - If Equipped
AM/FM Button (CD Mode for MP3 Play) Switches back to Radio mode. RND/ PTY Button (CD Mode for MP3 Play) Pressing this button plays files randomly. SET/DIR Button (CD Mode for MP3 Play) Press the SET/DIR Button to display folders, when playing an MP3 discs that have a file/folder structure.
Page 188: Remote Sound System Controls
188 UNDERSTANDING YOUR INSTRUMENT PANEL REMOTE SOUND SYSTEM CONTROLS The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. The right hand control is a rocker type switch with a button in the center.
Page 189: Cd Player
CD Player Pressing the top of the switch once will go to the next track on the CD. Pressing the bottom of the switch once will go to the beginning of the current track or to the beginning of the previous track if it is within one second after the current track begins to play.
Page 190: Radio Operation And Cellular Phones
190 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the operation of a cellular phone in your vehicle can cause erratic or noisy perfor- mance from your radio. This condition may be lessened or eliminated by relocating the cellular phone antenna. This condition is not harmful to the radio.
Page 191: Air Conditioning And Heating Operation
Dual Zone Control Head UNDERSTANDING YOUR INSTRUMENT PANEL 191 Air Conditioning and Heating Operation To turn on the Air Conditioning, set the fan control at any speed and press the snowflake button located on the control panel. Conditioned air will be directed through the outlets selected by the mode control.
Page 192: Recirculation Pushbutton
192 UNDERSTANDING YOUR INSTRUMENT PANEL Recirculation Pushbutton Pushing the Recirculation button al- lows interior air to recirculate continu- ously in any position except defrost and defrost/floor mode for rapid cool down of the interior. See “Fast Cooldown” later in this section. Mode Control The mode control allows you to choose from several patterns of air...
Page 193: Heat
Heat Outside air flows primarily through the floor out- lets located under the instrument panel. Outside air flows in equal proportions through the floor and defroster outlets. Defrost Outside air is primarily directed to the windshield through the defroster outlets located at the base of the windshield and side window demist outlets.
Page 194: Dual Zone Temperature Control
194 UNDERSTANDING YOUR INSTRUMENT PANEL Dual Zone Temperature Control Dual Zone Temperature Control Use this control to regulate the temperature of the air inside the passenger compartment. This is accomplished by having separate temperature control slides for both the driver and front passenger. The blue area of the scale indicates cooler temperatures while the red area indicates warmer temperatures.
Page 195 pushbutton. When a comfortable condition has been reached, choose a mode position and adjust the tempera- ture control slide and blower speed as necessary to maintain comfort. For high humidity conditions it may be necessary to remain in the Recirculation mode to maintain comfort.
Page 196 196 UNDERSTANDING YOUR INSTRUMENT PANEL When using the air conditioner in extremely heavy traffic in hot weather especially when towing a trailer, addi- tional engine cooling may be required. If this situation is encountered, operate the transmission in a lower gear to increase engine RPM, coolant flow and fan speed.
Page 197: Operating Tips Chart
UNDERSTANDING YOUR INSTRUMENT PANEL 197 Operating Tips Chart...
Page 199 STARTING AND OPERATING CONTENTS Ignition/Starter Switch ....202 Lock ......202 Off .
Page 200 200 STARTING AND OPERATING Four-Wheel Anti-Lock Brake System (ABS) . . . 216 Power Steering ......218 Tire Safety Information .
Page 201 Snowplow ......262 Dodge SRT-10 Models ....262 Traction .
Page 202: 202 Starting And Operating
202 STARTING AND OPERATING IGNITION/STARTER SWITCH LOCK Engages the steering wheel lock (if equipped) when the steering wheel is turned. Unlocks the steering wheel (if equipped with locking wheel). This is the normal running position. Allows the electrical accessories to be used when the engine is not running.
Page 203: Starting Procedures
STARTING PROCEDURES The starter should not be operated for more than 15- second intervals. Waiting a few seconds between such intervals will protect the starter from overheating. Manual Transmission Apply the parking brake, place the gearshift control lever in NEUTRAL and depress the clutch pedal to the floor before starting the vehicle.
Page 204: If Engine Fails To Start
204 STARTING AND OPERATING instrument panel and release when the engine starts. If the engine fails to start within 10 seconds, turn the key to the OFF position, wait 5 seconds, then repeat the normal starting procedure. If Engine Fails To Start If the engine fails to start after you have followed the normal starting procedure, it may be flooded.
Page 205: After Starting
After Starting The idle speed is automatically controlled and will de- crease as the engine warms up. CAUTION! Long periods of engine idling, especially at high engine speeds can cause excessive exhaust tempera- tures which can damage your vehicle. Do not leave your vehicle unattended with the engine running.
Page 206 206 STARTING AND OPERATING “P” Park This gear position supplements the parking brake by locking the transmission. The engine can be started in this range. Never use Park while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range.
Page 207 WARNING! It is dangerous to shift the selector lever out of “P” or “N” if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in re- verse.
Page 208 208 STARTING AND OPERATING NOTE: Do not exceed maximum engine speed. “1” First Use this position for driving up very steep hills and for engine braking at low speeds (20 mph [32 km/h] or less) when going downhill. NOTE: Do not exceed a maximum engine speed of 5500 rpm.
Page 209 • the engine coolant has reached normal operating tem- perature; • vehicle speed is above approximately 30 mph (48 km/h); • the “TOW/HAUL” switch has not been activated; • transmission has reached normal operating tempera- ture. The transmission will downshift from Overdrive to Drive if the accelerator pedal is fully depressed at vehicle speeds above approximately 35 mph (56 km/h).
Page 210 210 STARTING AND OPERATING occurs, press the “TOW/HAUL” button. This will im- prove performance and reduce the potential for transmis- sion overheating or failure due to excessive shifting. The “TOW/HAUL” light will illuminate in the instru- ment cluster to indicate when the switch has been activated.
Page 211: Manual Transmission - 6-Speed
Manual Transmission — 6-Speed NOTE: The parking brake should be engaged before leaving the vehicle, especially on an incline. This model is equipped with a clutch interlocking igni- tion system. The clutch pedal must be fully depressed to start the vehicle. Fully depress the clutch pedal before shifting gears.
Page 212 212 STARTING AND OPERATING You should use low gear when starting from a standing position if under a heavy load. To shift into Reverse, come to a complete stop. Depress the clutch and pause briefly to allow the gear train to stop.
Page 213: Limited-Slip Differential
CAUTION! When descending a hill, be very careful to downshift one gear at a time to prevent overspeeding the engine which can cause valve damage. LIMITED-SLIP DIFFERENTIAL The limited-slip differential provides additional traction on snow, ice, mud, sand and gravel, particularly when there is a difference between the traction characteristics of the surface under the right and left rear wheels.
Page 214: Parking Brake
214 STARTING AND OPERATING PARKING BRAKE The foot operated parking brake is positioned below the lower left corner of the instrument panel. To release the parking brake, pull the parking brake release handle. NOTE: The instrument cluster red brake warning light will come on and flash to indicate that the parking brake is applied.
Page 215: Brake System
WARNING! • Always fully apply the parking brake when leaving your vehicle, or it may roll and cause damage or injury. Also be certain to leave a manual transmis- sion in Reverse or first gear. Failure to do so may allow the vehicle to roll and cause damage or injury.
Page 216: Brake Noise
216 STARTING AND OPERATING Brake Noise During normal operation of the brake system certain noises may be present from time to time. Occasional groan or squeal noises may occur during normal operation of the brake system which may not be indica- tive of a problem.
Page 217 WARNING! Pumping of the anti-lock brakes will diminish their effectiveness and may lead to an accident. Pumping makes the stopping distance longer. Just press firmly on your brake pedal when you need to slow down or stop. STARTING AND OPERATING 217 WARNING! •...
Page 218: Power Steering
218 STARTING AND OPERATING POWER STEERING Your power steering system will provide mechanical steering capability if power assist is lost. If for any reason the hydraulic pressure is interrupted, it will still be possible to steer your vehicle. Under these conditions you will experience a substantial increase in steering effort.
Page 219 • European Metric tire sizing is based on European design standards. Tires designed to this standard have the tire size molded into the sidewall beginning with the section width. The letter P is absent from this tire size designation. Example: 215/65R15 96H •...
Page 220 220 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary Spare tire 31 = Overall Diameter in Inches (in) 215 = Section Width in Milimeters (mm)
Page 221 Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry. H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions. —The maximum speed corresponding to the Speed Symbol should only be achieved un- der specified operating conditions.
Page 222: Tire Identification Number (Tin)
222 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire however the date code may only be on one side. Tires with white sidewalls will have the full TIN including date code located on the white sidewall side of the tire.
Page 223: Tire Loading And Tire Pressure
Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side “B” pillar. Tire Placard Location STARTING AND OPERATING 223 Tire and Loading Information Placard Tire and Loading Information This placard tells you important information about the:...
Page 224 224 STARTING AND OPERATING 3) the tire size designed for your vehicle 4) the cold tire inflation pressures for the front, rear and spare tires. Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size and cold tire inflation pressures specified on the Tire and Loading...
Page 225 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1400 lbs. and there will be five 150 lb. passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lb. (since 5 x 150 = 750, and 1400 –...
Page 226 226 STARTING AND OPERATING...
Page 227: Tires-General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES—GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 228: Tire Inflation Pressures
228 STARTING AND OPERATING 2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Underinflation also increases tire rolling resistance and results in higher fuel consumption.
Page 229 CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap–if equipped. This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem. Inflation pressures specified on the placard are always “cold tire inflation pressure”.
Page 230: Radial-Ply Tires
230 STARTING AND OPERATING Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 231: Compact Spare Tire - If Equipped
Compact Spare Tire — If Equipped The compact spare is for temporary emergency use with radial tires. It is engineered to be used on your style vehicle only. Since this tire has limited tread life, the original tire should be repaired (or replaced) and rein- stalled at the first opportunity.
Page 232: Limited Use Spare - If Equipped
232 STARTING AND OPERATING Limited Use Spare — If Equipped The limited use spare tire is for temporary emergency use on your vehicle. This tire is identified by a limited use spare tire warning label located on the limited use spare tire and wheel assembly.
Page 233: Tread Wear Indicators
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure someone. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck. And don’t let anyone near a spinning wheel, no matter what the speed.
Page 234: Life Of Tire
234 STARTING AND OPERATING Life of Tire The service life of a tire is dependent upon varying factors including but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread.
Page 235: Alignment And Balance
WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combina- tions of unapproved tires and wheels may change suspension dimensions and performance charac- teristics, resulting in changes to steering, han- dling, and braking of your vehicle.
Page 236: Supplemental Tire Pressure Information
236 STARTING AND OPERATING Improper alignment will not cause vehicle vibration. Vibration may be a result of tire and wheel out-of- balance. Proper balancing will reduce vibration and avoid tire cupping and spotty wear. SUPPLEMENTAL TIRE PRESSURE INFORMATION A light load vehicle condition is defined as two passen- gers {150 lbs (68 kg) each} plus 200 lbs (91kg) of cargo.
Page 237: Snow Tires
These cautions apply to all chain traction devices, includ- ing link and cable (radial) chains. Tire chain use is permitted only on the rear tires of SRT–10 Models. NOTE: The use of class “S” chains is permitted on SRT– 10 Models with the use of 17 x 8 steel wheels (part number 52113265AC) available from your authorized dealer.
Page 238: Tire Rotation Recommendations
238 STARTING AND OPERATING TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, driving, and braking functions. For these reasons, they wear at unequal rates, and develop irregular wear patterns. These effects can be reduced by timely rotation of tires.
Page 239: Fuel Requirements
If you experience these symptoms, try another brand of “regular” gasoline be- fore considering service for the vehicle. Over 40 automobile manufacturers around the world have issued and endorsed consistent gasoline specifica- tions (the World Wide Fuel Charter, WWFC) to define...
Page 240: Gasoline/Oxygenate Blends
240 STARTING AND OPERATING Gasoline/Oxygenate Blends Some fuel suppliers blend unleaded gasoline with mate- rials called oxygenates such as 10% alcohol, MTBE, ETBE or TAME. Oxygenates are required in some areas of the country during the winter months to reduce carbon monoxide emissions.
Page 241: Sulfur In Gasoline
Sulfur In Gasoline Your vehicle may have been designed to meet California low emission standards on clean burning, low sulfur, California gasoline. Gasoline sold outside of California is allowed to have higher sulfur levels that may affect the performance of your vehicle’s catalytic converter. This may cause the Malfunction Indicator Light or Service Engine Soon Light to illuminate.
Page 242: Carbon Monoxide Warnings
242 STARTING AND OPERATING some light smoke, your engine may be out of tune or malfunctioning and may require immediate service. Contact your dealer for service assistance. • When pulling a heavy load or driving a fully loaded vehicle when the humidity is low and the temperature is high, use a premium unleaded fuel to help prevent spark knock.
Page 243: Adding Fuel
the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. ADDING FUEL NOTE: The fuel tank filler tube is about 2 inches (50 mm) down from the opening. If fuel is poured from a portable container, the container should have a flexible nozzle long enough to extend into the fuel filler tube.
Page 244: Catalytic Converter
244 STARTING AND OPERATING CAUTION! Damage to the fuel system or emission control system could result from using an improper fuel tank filler tube cap (gas cap). A poorly fitting cap could let impurities into the fuel system. WARNING! • Never allow any lit smoking materials near the vehicles while removing the cap or filling the tank.
Page 245 CAUTION! Damage to the catalytic converter can result if your vehicle is not kept in proper operating condition. In the event of engine malfunction, particularly involv- ing engine misfire or other apparent loss of perfor- mance, have your vehicle serviced promptly. Contin- ued operation of your vehicle with a severe malfunction could cause the converter to overheat, resulting in possible damage to the converter and...
Page 246: Vehicle Loading
246 STARTING AND OPERATING VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration Regulations, your vehicle has a certification label affixed to the driver’s side door or pillar. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 247 Tire Size The tire size on the Label represents the actual tire size on your vehicle. Replacement tires must be equal to the load capacity of this tire size. Rim Size This is the rim size that is appropriate for the tire size listed.
Page 248 248 STARTING AND OPERATING Improper weight distributions can have an adverse effect on the way your vehicle steers and handles and the way the brakes operate. CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles.
Page 249: Trailer Towing
STARTING AND OPERATING 249 Gross Vehicle Weight Rating (GVWR) 6500 LBS. TRAILER TOWING In this section you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer carefully re- view this information to tow your load as efficiently and safely as possible.
Page 250 250 STARTING AND OPERATING Gross Trailer Weight (GTW) The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its loaded and ready for operation condition. The recom- mended way to measure GTW is to put your fully loaded trailer on a vehicle scale.
Page 251 Frontal Area The maximum height and maximum width of the front of a trailer. Trailer Sway Control The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Page 252: Trailer Hitch Classification
252 STARTING AND OPERATING Trailer Hitch Classification The rear bumper is intended to tow trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package.
Page 253: Trailer Towing Weights
• http:// www.dodge.com/towing. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 254: Towing Requirements
254 STARTING AND OPERATING • The weight of any other type of cargo or equipment put in or on your vehicle. • The weight of the driver and all passengers. NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or dealer-installed options, must be considered as part of the total load on your vehicle.
Page 255 WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 256 256 STARTING AND OPERATING • Total weight must be distributed between the tow vehicle and the trailer such that the following four ratings are not exceeded: 1. GVWR 2. GTW 3. GAWR 4. Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight).
Page 257 Towing Requirements — Trailer Brakes − Do not interconnect the hydraulic brake system or vacuum system of your vehicle with that of the trailer. This could cause inadequate braking and possible personal injury. − An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes.
Page 258 258 STARTING AND OPERATING WARNING! Do not connect trailer brakes to your vehicle’s hy- draulic brake lines. It can overload your brake sys- tem and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping dis- tance.
Page 259: Towing Tips
7- Pin Connector Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic. STARTING AND OPERATING 259 If using a manual transmission vehicle for trailer towing, all starts must be in FIRST gear to avoid excessive clutch slippage.
Page 260 260 STARTING AND OPERATING NOTE: Check the automatic transmission fluid level before towing. Towing Tips — Tow/Haul (If Equipped) To reduce potential for automatic transmission overheat- ing, turn the “TOW HAUL” feature ON when driving in hilly areas or shift the transmission to Drive position 2 on more severe grades.
Page 261: Trailer Towing Mirrors - If Equipped
Trailer Towing Mirrors — If Equipped These mirrors are designed with an adjustable mirror head to provide a greater vision range when towing extra-wide loads. To change position inboard or out- board, the mirror head should be rotated (flipped Out or In).
Page 262: Snowplow
262 STARTING AND OPERATING Trailer Towing Position SNOWPLOW Dodge SRT-10 Models NOTE: DO NOT use Dodge SRT- 10 Models for snowplow applications. WARNING! Snowplows, winches, and other aftermarket equip- ment should not be added to the front end or your vehicle.
Page 263: Traction
CAUTION! Using this vehicle for snowplow applications can cause damage to the vehicle. WARNING! Attaching a snowplow to this vehicle could ad- versely affect performance of the airbag system in an accident. Do not expect that the airbag will perform as described earlier in this manual STARTING AND OPERATING 263 TRACTION...
Page 264: Equipment Identification Plate
264 STARTING AND OPERATING EQUIPMENT IDENTIFICATION PLATE The equipment Identification Plate is located on the hood inner surface. The following information about your vehicle is dis- played on this plate: Model, Wheelbase, Vehicle Identifi- cation Number, Truck Order Number, and code numbers with descriptions of all production and special equip- ment on the truck as shipped from the factory.
Page 265 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Lights ....266 Adding Fuel ......267 Jack Location .
Page 266: 266 What To Do In Emergencies
266 WHAT TO DO IN EMERGENCIES HAZARD WARNING LIGHTS The Hazard Warning switch is mounted on the top of the steering column as shown in the illustration. Hazard Light Warning Switch To engage the Hazard Warning lights, depress the button on the top of the steering column.
Page 267: Adding Fuel
ADDING FUEL The fuel tank filler tube has a restriction about 2 inches (50 mm) inside the opening. If using a portable fuel container, it should have a flexible nozzle long enough to reach past the restriction. WARNING! A fire may result if gasoline is pumped into a portable container that is in a vehicle or on a truck bed.
Page 268: Jack Location
268 WHAT TO DO IN EMERGENCIES JACK LOCATION Removal Jack Cover The jack and jack tools are stored under the front passenger seat. Lift the tab and slide the plactic cover forward for access. Jack Wing Bolt Remove the jack and tools by removing the wing bolt and sliding the assembly from under the seat.
Page 269 WARNING! The jack is designed to use as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes, unless suitable sup- ports are placed under the vehicle as a safety mea- sure.
Page 270: Reinstalling The Scissors-Type Jack And Tools (Srt-10 Models)
270 WHAT TO DO IN EMERGENCIES Reinstalling The Scissors-Type Jack And Tools (SRT–10 Models) 1. Lower the jack all the way down by turning the jack turn-screw until the jack is snug. 2. Position the jack and tool bag (unrolled). Make sure the lug wrench is under the jack near the jack turn-screw.
Page 271 WHAT TO DO IN EMERGENCIES 271 3. Fold the flap and roll the jack tool kit into a cylindrical package (in direction of arrows), and tie to the jack using the tie straps. Tying Bag to Jack with Straps Folding Flap and Rolling Bag...
Page 272 272 WHAT TO DO IN EMERGENCIES 4. Place the jack and tools in the storage position holding the jack by the jack turn-screw, slip the jack and tools under seat so that the bottom slot engages into the fastener on the floor and then secure to the floor pan using the wing bolt.
Page 273: Changing A Flat Tire
CHANGING A FLAT TIRE Removing The Spare Tire Remove the spare tire before attempting to jack the truck. Attach the wheel wrench to the jack extension tube. Insert the tube through the access hole between the lower tailgate and the top of the bumper and into the winch mechanism tube.
Page 274: Tire Changing Procedure
274 WHAT TO DO IN EMERGENCIES Tire Changing Procedure WARNING! Getting under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never get any part of your body under a vehicle that is on a jack. Never start or run the engine while the vehicle is on a jack.
Page 275 • Turn on the Hazard Warning Flasher. • Block both the front and rear of the wheel diagonally oppo- site the jacking position. For example, if the right front wheel is being changed, block the left rear wheel. • Passengers should not remain in the vehicle when the vehicle is being jacked.
Page 276 276 WHAT TO DO IN EMERGENCIES 1. Remove the spare wheel, jack, and tools from storage. 2. Using the wheel wrench, loosen, but do not remove, the wheel nuts by turning them counterclockwise one turn while the wheel is still on the ground. 3.
Page 277 • When changing a rear wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle between the spring and the shock absorber with the drive tubes extending to the rear. •...
Page 278 278 WHAT TO DO IN EMERGENCIES 6. Using the wheel wrench, finish tightening the nuts using a crisscross pattern. Correct nut tightness is 90–110 ft. lbs. (125–150 N·m). If in doubt about the correct tightness, have them checked with a torque wrench by your dealer or at a service station.
Page 279: Hoisting
Disc Type Nut Stud Size Torque Wheels Ft. Lbs. Cone 1/2-20 90-110 To Stow The Flat Or Spare Turn the wheel so that the valve stem is down. Slide the wheel retainer through the center of the wheel and position it properly across the wheel opening. For convenience in checking the spare tire inflation, stow with the valve stem toward the rear of the vehicle.
Page 280: Jump-Starting
280 WHAT TO DO IN EMERGENCIES JUMP-STARTING You should not try to start your vehicle by pushing or towing. Vehicles equipped with an automatic transmis- sion cannot be started this way and pushing or towing a vehicle equipped with a manual transmission may over- heat and damage the catalytic converter.
Page 281 2. Park the booster vehicle within cable reach but with- out letting the vehicles touch. Set the parking brake on both vehicles, place the automatic transmission in Park or the manual transmission in Neutral, and turn the ignition OFF. 3. Turn off the heater, radio, and all unnecessary electri- cal loads.
Page 282 282 WHAT TO DO IN EMERGENCIES 5. Connect the other cable, first to the negative terminal of the booster battery and then to the engine of the vehicle with the discharged battery. Make sure you have a good contact on the engine. WARNING! •...
Page 283: Freeing A Stuck Vehicle
FREEING A STUCK VEHICLE If vehicle becomes stuck in snow, sand, or mud, it can often be moved by a rocking motion. Move the gear selector rhythmically between FIRST and REVERSE, while applying slight pressure to the accelerator. In general, the least amount of accelerator pedal pressure to maintain the rocking motion without spinning the wheels or racing the engine is most effective.
Page 285 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment— 8.3L ....288 Onboard Diagnostic System (OBD II) ..289 Emissions Inspection And Maintenance Programs .
Page 286 286 MAINTAINING YOUR VEHICLE Front Suspension Ball Joints ....302 Steering Linkage — Inspection ... . 303 Body Lubrication .
Page 287 Center High-Mounted Stoplight With Cargo Light ......331 Cab Top Clearance Lights — If Equipped ..332 Tailgate ID Lights (Dual Rear Wheels) .
Page 288: 288 Maintaining Your Vehicle
288 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT— 8.3L...
Page 289: Onboard Diagnostic System (Obd Ii)
ONBOARD DIAGNOSTIC SYSTEM (OBD II) Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions and engine control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emissions well within current government regulations.
Page 290 290 MAINTAINING YOUR VEHICLE For states which have an I/M (Inspection and Maintenance) requirement, this check verifies the following: the MIL (Malfunction Indicator Lamp) is functioning and is not on when the engine is running, and that the OBD (On Board Diagnostic) system is ready for testing.
Page 291: Dealer Service
b. The MIL light will remain fully illuminated until the first engine crank or the key is turned off. This means that your vehicle’s OBD system is ready and you can proceed to the I/M station. If your OBD system is not ready, you should see your dealer or repair facility.
Page 292: Replacement Parts
292 MAINTAINING YOUR VEHICLE WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the proper equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic.
Page 293 Checking the oil while the vehicle is on level ground will improve the accuracy of the oil level readings. Maintain the oil level between the ADD and SAFE markings on the dipstick. Adding one quart of oil when the reading is at the ADD mark will result in a SAFE reading on these engines.
Page 294: Maintenance Schedules
294 MAINTAINING YOUR VEHICLE • More than 50% of your driving is at sustained high speeds during hot weather, above 32°C (90°F) • Taxi, Police or delivery service (commercial service) • Off-road or desert operation • If equipped for and operating with E-85 (ethanol) fuel.
Page 295 Engine Oil Identification (API) Symbol There is a symbol to aid you in selecting the proper engine oil. This symbol means that the oil has been certified by the American Petroleum Institute (API). We only recommend synthetic API Certified engine oils, such as Mo- bil 1 , that meet the requirements of Material Standard MS-10725.
Page 296: Engine Oil Filter
296 MAINTAINING YOUR VEHICLE Materials Added to Engine Oil Do not add any materials (other than leak detection dyes) to engine oil. Engine oil is an engineered product and it’s performance may be impaired by supplemental addi- tives. Disposing of Used Engine Oil And Oil Filters Care should be taken in disposing of used engine oil and oil filters from your vehicle.
Page 297: Spark Plugs
Spark Plugs Spark plugs must fire properly to assure engine perfor- mance and emission control. New plugs should be in- stalled at the specified mileage. The entire set should be replaced if there is any malfunction due to a faulty spark plug, malfunctioning spark plugs can damage the cata- lytic converter.
Page 298: Catalytic Converter
298 MAINTAINING YOUR VEHICLE Catalytic Converter The catalytic converter requires the use of unleaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emission control device. Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is im- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage.
Page 299 WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your ex- haust system. Do not park or operate your vehicle in areas where your exhaust system can contact any- thing that can burn.
Page 300: Crankcase Emission Control System
300 MAINTAINING YOUR VEHICLE Crankcase Emission Control System Proper operation of this system depends on freedom from plugging due to deposits. As vehicle mileage builds up, the Crankcase Ventilation Valve orifice may accumu- late deposits. If a valve is not working properly, replace it with a new orifice.
Page 301: Air Conditioner
CAUTION! It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked (+) positive and negative (-) and identified on the battery case. Also, if a “fast charger”...
Page 302: Power Steering - Fluid Check
302 MAINTAINING YOUR VEHICLE Refrigerant Recovery And Recycling The air conditioning system of your vehicle contains R-134a, a refrigerant that does not deplete the ozone layer in the upper atmosphere. The manufacturer recommends that air conditioning service be done by facilities using refrigerant recycling and recovery equipment that meets SAE standard J1991.
Page 303: Steering Linkage - Inspection
The ball joints originally supplied with the vehicle are permanently lubricated at the factory and do not require service. However, if the seals on the ball joints are damaged, the joints should be replaced. Serviceable replacement ball joints are available. Front suspension ball joints should be replaced only by a qualified service technician using tools specially de- signed for this purpose.
Page 304: Windshield Wiper Blades
304 MAINTAINING YOUR VEHICLE Windshield Wiper Blades The rubber edges of the wiper blades and the windshield should be cleaned periodically with a sponge or soft cloth and a mild nonabrasive cleaner. This will remove accu- mulations of salt or road film. Operation of the wipers on dry glass for long periods may cause deterioration of the wiper blades.
Page 305: Exhaust System
Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system. Whenever a change is noticed in the sound of the exhaust system, when exhaust fumes can be detected inside the vehicle, or when the underside or rear of the vehicle is damaged, have a competent mechanic inspect the com- plete exhaust system and adjacent body areas for broken,...
Page 306: Cooling System
306 MAINTAINING YOUR VEHICLE Cooling System Cooling System Maintenance At the intervals shown in the Maintenance Schedules Section of the manual, the system should be drained, flushed and filled. Inspection Check engine coolant (antifreeze) protection every 12 months (before the onset of freezing weather, where applicable).
Page 307 WARNING! Never add coolant to the radiator when the engine is overheated. Do not loosen or remove pressure cap to cool an overheated engine! The coolant is under pressure and severe scalding could result. Drain, Flush And Refill At intervals shown on the Maintenance Schedules, the system should be drained, flushed and refilled.
Page 308 308 MAINTAINING YOUR VEHICLE NOTE: Failure to follow the antifreeze concentration and replacement recommendations, or failure to use antifreeze formulated to prevent corrosion of all cooling system metals, may result in radiator plugging, overheat- ing, or cooling system leaks such as in core hole plugs. WARNING! Never add coolant to the radiator when the engine is overheated.
Page 309: Hoses And Vacuum/Vapor Harnesses
Disposal Of Used Engine Coolant Used ethylene glycol based engine coolant is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community. Do not store ethylene glycol-based engine coolant in open containers or allow it to remain in puddles on the ground.
Page 310: Brake System
310 MAINTAINING YOUR VEHICLE Insure nylon tubing in these areas has not melted or collapsed. Inspect all hose connections such as clamps and cou- plings to make sure they are secure and no leaks are present. Components should be replaced immediately if there is any evidence of wear or damage that could cause failure.
Page 311: Clutch Hydraulic System
WARNING! Overfilling the brake fluid reservoir can result in spilling brake fluid on hot engine parts and the brake fluid catching fire. Use only brake fluid that has been in a tightly closed container to avoid contamination from foreign matter or moisture.
Page 312: Propeller Shaft Universal Joints
312 MAINTAINING YOUR VEHICLE Propeller Shaft Universal Joints Cross Type (No fittings) — Relubrication of this type of universal joint is not required. The seals should be inspected for external leaks or damage. If external leaks or damage is evident, the universal joint should be replaced.
Page 313: Manual Transmission
Manual Transmission Lubricant Selection Refer to the Fluids, Lubricants and Genuine Parts section for correct fluid type. CAUTION! Using a transmission fluid other than the manufac- turer’s recommended fluid may cause deterioration in transmission shift quality. Refer to the Fluids, Lubricants and Genuine Parts section for correct fluid type.
Page 314 314 MAINTAINING YOUR VEHICLE Procedure For Checking Fluid Level To properly check the automatic transmission fluid level, the following procedure must be used: 1. The vehicle must be on level ground. 2. The engine should be running at curb idle speed for a minimum of 60 seconds.
Page 315 CAUTION! Using a transmission fluid other than the manufac- turers recommended fluid may cause deterioration in transmission shift quality and/or torque converter shudder. Using a transmission fluid other than the manufacturers recommended fluid will result in more frequent fluid and filter changes. Refer to Fluids, Lubricants and Genuine Parts for correct fluid type.
Page 316: Front Wheel Bearings
316 MAINTAINING YOUR VEHICLE Front Wheel Bearings Front wheel bearings for all Dodge Ram Trucks are sealed-for-life. They do not require greasing or seal replacement. In some instances, these bearings will “purge” excess grease and the bearing will look slightly wet.
Page 317: Appearance Care And Protection From Corrosion
Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and those that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 318 318 MAINTAINING YOUR VEHICLE • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish. CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder, which will scratch metal and painted surfaces.
Page 319 • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well packaged and sealed. • If a lot of driving is done on gravel roads, consider mud or stone shields behind each wheel. •...
Page 320 320 MAINTAINING YOUR VEHICLE Glass Surfaces All glass surfaces should be cleaned on a regular basis with any commercial household-type glass cleaner. Never use an abrasive type cleaner. Use caution when cleaning inside rear windows equipped with electric defrosters or windshields equipped with a windshield wiper de-icer.
Page 321: Integrated Power Module
INTEGRATED POWER MODULE Integrated Power Module Your vehicle is equipped with a fuse and relay center located in the engine compartment near the battery. Located on the underside of the cover is a label that identifies each component. MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description...
Page 322 322 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 30 Amp Off Road Module Pink Power 5 Amp Trx-Off Rd Pkg Sen Orange (Gas Engine Only) 10 Amp IOD-CNN/Radio/ Under Hood Lamp/ WCM/SDARS/HFM 30 Amp Electric Brake Pink 25 Amp Power-Battery Natural RWAL/ABS Module...
Page 323 Cavity Cartridge Mini Description Fuse Fuse 20 Amp Subwoofer Amplifier Blue 10 Amp Power Mirror 20 Amp Brake Switch/ Yellow CHMSL/Stop Lamp 40 Amp Power Seats Green 10 Amp Power Run/Start- NCC/WCM/ABS/ RWAL 10 Amp Switches/EC Mirror/ Smart Bar 15 Amp Spare Blue 10 Amp...
Page 324: Vehicle Storage
324 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 10 Amp Sunroof/Seatbelt Ten- sioner 20 Amp Cigar Lighter Yellow 25 Amp Spare Natural 30 Amp Diesel PCM (Diesel Pink Only) 1. Disconnect the battery negative (-) cable before remov- ing the cover. 2.
Page 325: Replacement Light Bulbs
REPLACEMENT LIGHT BULBS LIGHT BULBS — Inside Overhead Console Lights ....TS 212-2 Dome Light......7679 All of the inside bulbs are brass or glass wedge base.
Page 326 326 MAINTAINING YOUR VEHICLE 1. Open the hood 2. Remove the two (2) bolts from the front of the head- light housing. Front Headlight Housing Bolts 3. Remove the plug from the inner fender well and remove through Inner Fender Plug access hole.
Page 327 Rear Headlight Housing Nut Access 4. Pull the housing out from the fender to allow room to disconnect the electrical connectors. MAINTAINING YOUR VEHICLE NOTE: For easier removal, pull the headlight assembly straight forward, applying the greatest amount of force to the outer edge of the headlight assembly.
Page 328 328 MAINTAINING YOUR VEHICLE Bulb Removal 5. Unlock and pull connector straight from the base of the headlight halogen bulb. 6. Twist connector on turn signal/park light bulb and remove connector and bulb from housing. 7. Remove housing from vehicle with headlight halogen bulb in housing.
Page 329: Tail, Stop, Turn And Backup Lights
Tail, Stop, Turn and Backup Lights 1. Remove the two (2) screws that pass through the bed sheetmetal. MAINTAINING YOUR VEHICLE 2. Pull the housing straight out from the body, with a quick motion, to separate the housing from the body. If not pulled straight, locators may be damaged.
Page 330 330 MAINTAINING YOUR VEHICLE 3. Push the red lock slide in on the connector and remove the housing from the vehicle. 4. Remove the four (4) screws from the bulb strip in the housing. 5. Pull the appropriate bulb straight from the bulb strip. •...
Page 331: Center High-Mounted Stoplight With Cargo Light
7. While holding the taillight firmly in place, fasten the top screw first. Center High-Mounted Stoplight With Cargo Light 1. Remove the two (2) screws holding the housing/lens to the body as shown. MAINTAINING YOUR VEHICLE 2. Separate the connector holding the housing and wir- ing harness to the body.
Page 332: Cab Top Clearance Lights - If Equipped
332 MAINTAINING YOUR VEHICLE 4. Pull desired bulb straight from the socket. • Outside Bulbs: Cargo Lamps • Inside Bulb: Center High Mount Stop Lamp 5. Reverse procedure for installation of bulbs and hous- ing. Cab Top Clearance Lights — If Equipped 1.
Page 333 MAINTAINING YOUR VEHICLE 2. Rotate the socket ⁄ turn and pull it from the light 3. Pull the bulb straight from it’s socket and replace. assembly.
Page 334: Tailgate Id Lights (Dual Rear Wheels)
334 MAINTAINING YOUR VEHICLE Tailgate ID Lights (Dual Rear Wheels) 1. Remove the two screws and housing and access the bulb sockets from the rear.
Page 335: Side Marker Lights (Dual Rear Wheels)
2. Turn socket ⁄ turn counterclockwise to access the bulb. 3. Pull bulb straight out from socket. 4. Reverse procedure for installation of bulbs and hous- ing. MAINTAINING YOUR VEHICLE Side Marker Lights (Dual Rear Wheels) 1. Push rearward on the side marker light assembly. 2.
Page 336: Fog Lights
336 MAINTAINING YOUR VEHICLE 5. Reverse procedure for installation of bulbs and hous- ing. Fog Lights 1. Reach under the vehicle, unlock and twist connector counterclockwise ⁄ turn and remove connector and bulb from housing. 2. Pull bulb straight from the connector. 3.
Page 337: Fluid Capacities
FLUID CAPACITIES Fuel SRT-10 - Standard Cab Models SRT-10 - Quad Cab Models Engine Oil (with filter) 8.3L (SAE 0W-40 MS-10725) Cooling System 8.3L MAINTAINING YOUR VEHICLE U.S. Metric 26 gal. 34 gal. 129L 10 qts. 9.5 L 20 qts.
Page 338: Fluids, Lubricants And Genuine Parts
338 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil Engine Oil Filter Spark Plugs Fuel Selection Fluids, Lubricants and Genuine Parts Mopar Antifreeze/Coolant 5 Year/102,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) P/N 05066386AA or equivalent. We only recommend synthetic engine oils, such as Mobil 1 , that are API Certified and meet the requirements of Material Standard MS-10725.
Page 339: Chassis
Chassis Component Manual Transmission Fluid Automatic Transmission Fluid Clutch Linkage Limited-Slip Rear Axle Brake Master Cylinder Power Steering Reservoir Fluids, Lubricants and Genuine Parts. Mopar Synthetic Manual Transmission Lubricant 75W/85W (Castrol Syn- torq LT 75W/85W) Mopar ATF+4, Automatic Transmission Fluid. Multipurpose Grease, NLGI Grade 2 E.P.
Page 341 MAINTENANCE SCHEDULES CONTENTS Emission Control System Maintenance ..342 Maintenance Schedules ....342 Schedule “B” ......345 Schedule “A”...
Page 342: Emission Control System Maintenance
342 MAINTENANCE SCHEDULES EMISSION CONTROL SYSTEM MAINTENANCE The “Scheduled” maintenance services, listed in bold type in this section (Section 8) must be done at the times or mileages specified to assure the continued proper functioning of the emission control system. These, and all other maintenance services included in this manual, should be done to provide best vehicle performance and reliability.
Page 343 • Taxi, police, or delivery service (commercial service). • Off-road or desert operation. • If equipped for and operating with E-85 (ethanol) fuel. NOTE: If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule “B”...
Page 344 344 MAINTENANCE SCHEDULES At Each Stop for Fuel • Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accu- racy of the oil level reading.
Page 345: Schedule "B" 345
Schedule “B” Follow schedule “B” if you usually operate your vehicle under one or more of the following conditions. • Day or night temperatures are below 32° F (0° C). • Stop and go driving. • Extensive engine idling. • Driving in dusty conditions. •...
Page 346 346 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 347 Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Drain and refill manual transmission fluid. Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 348 348 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Drain and refill manual transmission fluid. Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 349 Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 350 350 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Drain and refill manual transmission fluid. Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 351 Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Re- place filter and adjust bands.* Drain and refill manual transmission fluid. Rotate tires. Check spare tire for proper pressure and correct stowage.
Page 352 352 SCHEDULE “B” Miles (Kilometers) Change engine oil and engine oil filter at interval shown or 3 months, whichever comes first. Rotate tires. Check spare tire for proper pressure and correct stowage. Flush and replace engine coolant, if not replaced at 60 months.
Page 353 Miles (Kilometers) Change engine oil and engine oil filter at in- terval shown or 3 months, whichever comes first. Drain and refill automatic transmission fluid. Replace filter and adjust bands.* Drain and refill automatic transmission fluid. Replace filter and adjust bands. Drain and refill manual transmission fluid.
Page 354 354 SCHEDULE “B” Miles (Kilometers) Replace ignition cables. Inspect and replace, if necessary, the PCV valve.** Inspect auto tension drive belt and replace if required. Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km).
Page 355: Schedule "A
Schedule “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Inspect brake linings. Replace engine air cleaner filter. Replace spark plugs. 6,000 12,000 18,000 (10 000) (20 000) (30 000) [12] [18]...
Page 356 356 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Flush and replace engine coolant at 60 months, if not replaced at 102,000 miles (170 000 km).
Page 357 Miles (Kilometers) [Months] Change engine oil and engine oil filter. Drain and refill automatic transmission fluid. Replace filter and adjust bands. Rotate tires. Check spare tire for proper pressure and cor- rect stowage. Inspect brake linings. Replace engine air cleaner filter. Replace spark plugs.
Page 358 358 SCHEDULE “A” Miles (Kilometers) [Months] Change engine oil and engine oil filter. Rotate tires. Check spare tire for proper pressure and correct stowage. Flush and replace engine coolant, if not done at 60 mos. Flush and replace engine coolant at 120 months, if not replaced at 102,000 miles (170 000 km).
Page 359 ** This maintenance is recommended by the manufac- turer to the owner, but not required to maintain the emissions warranty. Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all re- ceipts. SCHEDULE “A” 359 WARNING! You can be badly injured working on or around a motor vehicle.
Page 361: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......362 Prepare For The Appointment .
Page 362 We want you to be happy with our products and services. Warranty service must be done by an authorized Chrysler, Dodge, or Jeep dealer. We strongly recommend that you take your vehicle to you selling dealer. They know you and your vehicle best, and are most concerned that you get prompt and high quality service.
Page 363 technicians, special tools, and the latest information to assure your vehicle is fixed correctly and in a timely manner. This is why you should always talk to your dealer’s service manager first. Most matters can be resolved with this process. •...
Page 364 364 IF YOU NEED CONSUMER ASSISTANCE Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its Customer Center. Any hearing or speech impaired customer who has access to a TDD or a conventional teletypewriter (TTY) in the United States can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 365 WARRANTY INFORMATION (U.S. Vehicles Only) See the Warranty Information Booklet for the terms and provisions of DaimlerChrysler’s warranties applicable to this vehicle. MOPAR PARTS Mopar fluids, lubricants, parts, and accessories are available from your dealer. They will help you keep your vehicle operating at its best.
Page 366 366 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 367 • Owner’s Manuals. These manuals have been prepared with the assistance of service and engineering specialists to acquaint you with specific Chrysler group vehicles. Included are starting, operating, emergency and maintenance pro- cedures as well as specifications, capabilities and safety tips. IF YOU NEED CONSUMER ASSISTANCE 367 Call Toll Free at: •...
Page 369 INDEX...
Page 370 370 INDEX Adding Fuel ......243,267 Additives, Fuel ......241 Air Cleaner, Engine (Engine Air Cleaner Filter) .
Page 371 B-Pillar Location ......223 Brake Fluid ......339 Brake System .
Page 372 372 INDEX Climate Control ......190 Clock ......172,176 Clutch .
Page 373 Door Ajar ......172 Door Locks ......13 Door Opener, Garage .
Page 374 374 INDEX Filters Air Cleaner ......297 Engine Fuel ......297 Engine Oil .
Page 375 Tachometer ......165 Voltmeter ......165 Gear Ranges .
Page 376 376 INDEX Intermittent Wipers ..... . 113 Introduction ......4 Jack Location .
Page 377 Intensity Control ..... . . 107 Interior ......107,120 Lights On Reminder .
Page 378 378 INDEX Trailer Towing ......261 Modifications/Alterations, Vehicle ... . . 6 Mopar Parts .
Page 379 Pickup Box ......149 Placard, Tire and Loading Information ..223 Power Distribution Center .
Page 380 380 INDEX Safety Information, Tire ....218 Safety Tips ......68 Satellite Radio .
Page 381 Snow Plow ......262 Snow Tires ......237 Spare Tire .
Page 382 382 INDEX Compact Spare ......231 General Information ....227 High Speed .
Page 383 Fluid ....... 339 Maintenance ......313 Manual .
Page 384 384 INDEX Fluid ......112,304 Windshield Wiper Blades ....304 Windshield Wipers .
