54 Using the CMDB interface

Resource data entry tab settings page

Resource data entry tab settings page

Items in the resource association type page (continued)
Table 9-8
Item
Maximum Cardinality
Enable Editing From
The Resource Data Entry Tab Settings page lets you edit the order of the resource
display page tabs.
A value is assigned to each tab. The order of the tabs from left to right is
determined by the lowest assigned value to the highest value. If two or more tabs
have the same value, which is the default except for the summary, comment, and
general tabs, the order of those tabs is determined alphabetically. To change the
value that is assigned to a tab, click the Edit button that is associated with the tab.
In the dialog that opens, enter a value and click OK.
Description
Specifies the maximum number of relationships that can be
established between the child and parents. If you do not want to
limit the number of relationships, select the Unlimited check
box.
Specifies the mechanism style that is used to select an associated
resource.
The options are as follows:
Computer Type Association Picker
Contract Assigned User Picker
Generic Picker
Hierarchy Picker (for hierarchal parent resource types)
Hierarchy Picker Showing Children (for hierarchal parent
resource types)
Asset List
List
Resource Association Picker for Asset
Resource Tree Picker for Asset
Software Purchase Association
Selecting the checkbox with the same name as the resource
association type allows a reverse resource association to be
created between two resources. Example: Selecting the User
checkbox for the Owners resource association lets you create an
association from a user (parent) to an asset (child). Unless you
select this box you can create associations only from a child
resource to a parent resource.
