DIXON INDUSTRIES. INC. A
BLOUNT COMPANY AIRPORT
INDUSTRIAL PARK
PO BOX 1569
COFFEYVILLE KS 67337 0945
316 251 2000
FAX 316 251 4117
TECHNICAL DATA
ZTR Model 312
IMPORTANT - READ OPERATOR'S MANUAL BEFORE OPERATING OR MAKING ADJUSTMENTS
SEAT ADJUSTMENT
1. Pull or lift body retention latch P/N 3934
from transaxle backing plate, raise
and push body and seat assembly
forward.
2. Loosen four seat adjustment knobs P/
N 1849 and slide seat forward or
backward to desired position.
3. Re-tighten seat adjustment knobs P/N
1849. DO NOT operate mower without
seat adjustment knobs properly
tightened.
4. Close upper body and push retention
latch. P/N 3934 over transaxle backing
plate.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 312 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dixon 312

  • Page 1 DIXON INDUSTRIES. INC. A BLOUNT COMPANY AIRPORT INDUSTRIAL PARK PO BOX 1569 COFFEYVILLE KS 67337 0945 316 251 2000 FAX 316 251 4117 TECHNICAL DATA ZTR Model 312 IMPORTANT - READ OPERATOR'S MANUAL BEFORE OPERATING OR MAKING ADJUSTMENTS SEAT ADJUSTMENT 1.
  • Page 2 REMOVING THE BODY 1. The 312 has a two-piece polyethylene body. The upper body can be folded forward to expose the transaxle. In some cases, it may be necessary to remove the upper body to service the transaxle. 2. To remove upper body, remove two bolts P/N 3093 from the front of upper body hinge located on the brake shaft P/N 9283.
  • Page 3 2. Disengage mower deck and start engine. With the operator In the normal seated position. , engage mower deck and remove weight from seat. The engine should stop. If the engine does not stop when operator rises from seat, return the mower to an Authorized Dixon dealer for adjustment or repair.
  • Page 4 312 BODY ASSEMBLY...
  • Page 6 312 CHASSIS ASSEMBLY...
  • Page 7 312 TRANSAXLE ASSEMBLY...
  • Page 8 312 MOWER DECK ASSEMBLY 30'...
  • Page 9 312 WIRING ASSEMBLY...
