Summary of Features
GRQ3121 (1U, single channel, one input, two outputs)
GRQ3122 (2U, dual channel, one input & output per channel)
GRQ3121-S (1U, blank front panel slave, single channel, one input, two outputs)
GRQ3122-S (1U, blank front panel slave, dual channel, one input & output per channel)
GRQ2 Remote for Windows
(maximum of 2 COM ports)
•
All front panel controls are analog-style; signal path is digital
•
"Tweek-n-Peek" feature: Front panel adjustments of all parameters are shown in LED display screen
•
24-bit A/D and D/A conversion, 32-bit processing
•
20 to 20 KHz Frequency Response
•
+18 dBV Maximum Signal Input & Output
•
Floating Point SHARC Processor
•
>110 dB dynamic range
Each channel provides (now with fully independent processing on 1x2 units):
•
31-band graphic EQ, with ± 6 or 12 dB range (selectable)
•
Crossover: Bessel, Butterworth, and Linkwitz Reily filters; slopes to 48 dB/octave (Software only)
•
High Cut Filter (3KHz to 20KHz) and Low Cut Filter (20 Hz to 1KHz)
•
FBX Feedback Exterminator: up to 12 Filters, with Setup Mode (Auto Setup Mode via remote control)
•
Parametric Filters: up to 12 filters, numeric or graphic control (Software only)
•
Compressor/Limiter, with controls for ratio, threshold, and gain (attack, release, and knee adjustable
with remote)
•
Digital Delay, with up to 1 second delay, adjustable in 20 microsecond increments
•
Bypass: dedicated switches for FBX, EQ, and Delay with built in LED indicators
•
LED Segmented Indicators: FBX Filters, Level, Gain Reduction
•
LED Point Indicators: FBX Setup, Remote, EQ Range
•
LED Character Display: Delay setting, EQ fader boost/cut, High Cut Filter setting Low Cut Filter setting,
Compressor Ratio, Threshold, Gain, and Staus Messages.
Back Panel:
•
XLR & 1/4" TRS inputs & outputs
•
RS-232 Serial input & output (additional serial input on the slave front panels)
•
Remote switching (8-position contact closure switch; allows switch selection of all 20 stored Graphi-
Q2 presets)
Graphi-Q2 Remote Software Features:
All front panel controls, plus more, including:
•
FBX filter depth & width adjustments; switchable to parametric filters (depth, width & frequency
adjustments)
•
Graphic EQ filter width adjustments
•
Password protection
•
View & edit frequency response curves
•
20 user-defined stored presets
•
Control and link up to 8 Graphi-Q2s (16 channels of audio) per COM port (1 or 2 ports can be used)
•
Future-proof FREE Flash RAM upgrade capability: upgrade your firmware and software from the Sabine
website (www.Sabine.com)!
Operating Guide Version 1: for Sabine Graphi-Q2s with:
•
GRQ2 Firmware Version 2.20
•
GRQ2 Remote Software Version 5.0
TM
Software included with every unit; runs up to 8 Graphi-Q2s per COM port
S
F
UMMARY OF
EATURES
1
B1-GRQ-2-OpGuide-v1-050125.pmd
