Configuring Monitors and the Layout

Once the software has been configured for your cameras and video
servers, you should then set up the screen layout for the Monitor
application, and specify where each camera should be displayed on the
screen.
Important!
Adding a camera in the Monitor Manager is a required step to enable the display of
the camera in the Monitor application. If a camera is not configured for display here,
it will not appear in the Monitor application.
In the Administrator, click the Monitor Manager button.
The Monitor Manager provides the following options:
Select how many monitors (i.e. camera windows) to display
Layout Size -
on the screen. A maximum of 16 windows can be displayed. Select from
1x1, 2x2, 3x3 or 4x4.
The Administrator Application
Figure 4 - The Monitor Manager window.
