Devices - Quick Setup

This short description will help you set up your first device, without going
into too much detail. It is assumed that the software has already been
successfully installed.
1. Start the Administrator application and click the Add Device... button.
The Device Setup Wizard starts.
2. Enter the IP address of the Axis camera/video server.
3. Click Next and enter the administrator password for the device.
4. Click Next to auto-detect the device. If successful, the device type and
MAC address (S/N) will be shown.
5. Click Next and give the device a descriptive name.
6. Click Finish to return to the Administrator. The new device will now
be shown in the Device Manager window.
Devices - Quick Setup
Monitor Manager
Figure 1 - The main Administrator window.
Add Device
