BOOK# 091-12-1
INSTRUCTION MANUAL
AUTO CHARGE 12 DV
AUTOMATIC BATTERY CHARGER
MODEL #091-12DV-12
NOTE :
This charger is designed for
vehicles with single batteries
either negative or positive ground
INPUT : 115/230 volt, 50/60 Hz
3 YEAR WARRANTY
.
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796-1221
TEL: in NY 631-567-0314
TOLL FREE: 800-346-0857
FAX: 631-567-5826
Advertisement
Related Manuals for KUSSMAUL 091-12DV
Summary of Contents for KUSSMAUL 091-12DV
- Page 1 This charger is designed for vehicles with single batteries either negative or positive ground INPUT : 115/230 volt, 50/60 Hz 3 YEAR WARRANTY KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796-1221 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
-
Page 2: Installation
INTRODUCTION This manual describes the installation and wiring for the Auto-Charge 12DV Automatic Battery Charger. It is suggested that the installer read The entire instructions to become familiar with the tasks involved before starting. INSTALLATION The installation of the vehicle wiring provides a direct connection between the battery and the Auto-Charge 12DV Automatic Battery Charger. -
Page 3: Installation Wiring Diagram
INSTALLATION WIRING DIAGRAM IMPORTANT: Wire size is for a WIRE SIZE CHART maximum length of 20 feet. If wiring is to be longer, larger wiring is re- CONNECTION ITEM DEFINITION WIRE SIZE quired. Additional information is avail- BATTERY NEGATIVE CHARGING LEAD 14 AWG BAT- NEGATIVE... -
Page 4: Specification & Outline
SPECIFICATION & OUTLINE SPECIFICATIONS: Input: 230/115V 50/60Hz, switch selectable Output Volts: Adjustable, 13.25 volts nominal Output Current: 0-12 amps, D.C., Current Limited Charge Indicator: 0-15 amps Weight: 16 lbs 6.75 AUTO CHARGE 12.00 12.75 4.75 9/32" DIA. 4 HOLES 4.25 OUTLINE DRAWING... - Page 5 SPARE PARTS LIST PART NUMBER DESCRIPTION B091-349 Assembly, Control Board 2480 Transformer, Power SPW405-S Transformer, Power, PC Mount B-511-2 Rectifier Bridge A091-15-017 Sense Resistor Assembly EM 5822 Meter, 0-15 Amp D.C. 2150-A1 Light, Indicator, Neon LM3900 Integ. Circuit, Quad Op Amp IP15WB-1K Potentiometer, trimming, 1K LM7812...
-
Page 6: Warranty
Vehicle Identification Vehicle Owner WARRANTY All product of Kussmaul Electronics Company Inc. are warranted to be free of defects of material or workmanship. Liability is limited to repairing or replacing at our factory, without charge, any material or defects which become apparent in normal use within 3 years from the date the equipment was shipped.
