AUTO CHARGE ODY
AUTOMATIC BATTERY CHARGER
MODEL #091-128-12E-40-115
for ODYSSEY AGM BATTERIES
This charger is calibrated to the
ODYSSEY requirementof 14.7 volts
in the bulk/absorption range and 13.6
DO NOT USE TO CHARGE A
NORMAL FLOODED LEAD ACID
KUSSMAUL ELECTRONICS CO., INC
170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796
TEL: in NY 631-567-0314
INSTRUCTION MANUAL
CAUTION
volts in the float mode
BATTERY
3 YEAR WARRANTY
TOLL FREE: 800-346-0857
FILE: IM_091-128-12E-40-115
Rev B., 2-16-2006
q
FAX: 631-567-5826
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 091-128-12E-40-115 and is the answer not in the manual?

Questions and answers

Summary of Contents for KUSSMAUL 091-128-12E-40-115

  • Page 1 13.6 volts in the float mode DO NOT USE TO CHARGE A NORMAL FLOODED LEAD ACID BATTERY 3 YEAR WARRANTY KUSSMAUL ELECTRONICS CO., INC 170 CHERRY AVE., WEST SAYVILLE, N.Y. 11796 TEL: in NY 631-567-0314 TOLL FREE: 800-346-0857 FAX: 631-567-5826...
  • Page 2: Battery Charger Features

    INTRODUCTION The AUTO CHARGEd ODY charger, Model 091-128-12E-40-115 is a compact, com- pletely automatic single channel battery charger designed specifically for periodic charg- ing of ODYSSEY PC series and AGM Batteries. Of rugged construction, the charger is made to withstand the shock and vibration encountered in vehicle mounted equipment.
  • Page 3: Principles Of Operation

    PRINCIPLES OF OPERATION A three-step lead acid battery charger operates in the three stages described below: 1) A discharged battery is recharged at a constant current (bulk charge) until its volt- age reaches an overcharge level of 2.45 volts per cell. At this time the charger will switch to Finish Charge.
  • Page 4 THREE STAGE CHARGING CURVE Model: 091-128-12E-40-115 ABSORPTION STAGE 14.70VDC BATTERY CURRENT 13.60VDC I Limit=40.0A FLOAT STAGE 8.0 Hours BATTERY VOLTAGE Voltage Increasing Voltage Constant Voltage Constant Current Constant Current Decreasing Full Charge Maintained TIME STAGE I STAGE III STAGE II...
  • Page 6: Specifications

    Specifications Model: 091-128-12E-40-115 Input Power: 115VAC, 60Hz, 10Amps Input Over Current Protection: Fuse; 15Amp, Slow-Blow Output Power: 12 to 14.7VDC, 40Amperes Current Limited Charge Indicator: 50Amperes Mode Indicators: Battery Fault; Red TimeOut: Red Bulk Charge: Yellow Finish Charge: Yellow Battery Charged: Green Recommended Battery Size: Odyssey, AGM Series "PC", 150 to 300 AH...
  • Page 9: Warranty

    Kussmaul Electronics Company, Inc. shall have no liability for dam- ages of any kind to associated equipment arising from the installation and /or use of the Kussmaul Electronics Company, Inc. products. The pur- chaser, by the acceptance of the equipment, assumes all liability for any damages which may result from its installation, use or misuse, by the purchaser, his or its employes or others.
