Arrow 5
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARROW 5 and is the answer not in the manual?

Questions and answers

Related Manuals for Clifford ARROW 5

Summary of Contents for Clifford ARROW 5

  • Page 1 Arrow 5 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...

  • Page 3: Limited Lifetime Consumer Warranty

    limited lifetime consumer warranty Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the life- time of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer;...
  • Page 4 ! ! Please note that this manual was intended for US consumers and therefore includes American phrases or words. trademarks and copyrights Bitwriter ™ , Clifford ® , Code-Hopping ™ , DEI ®...

  • Page 5: Table Of Contents

    table of contents transmitter configurations ..2 select siren sounds ...14 what is included ... .3 diagnostics ....15 arming diagnostics .

  • Page 6: Transmitter Configurations

    transmitter configurations Arm/Disarm Button Optional Accessory Accessory Output Channel Button Button...

  • Page 7: What Is Included

    In order to maximize the use of this system, please review this owner's guide carefully prior to using your system. You can print additional or replacement copies of this owner’s guide by accessing the Clifford web- site at www.clifford.com. © 2 0 0 3 d i re c t e d e l e c t ro n i c s , i n c .

  • Page 8: System Maintenance

    system maintenance The system requires no specific maintenance. Your transmitter is pow- ered by a miniature 3V lithium battery that will last approximately one year under normal use. When the battery weakens, operating range will be reduced and the system will provide a low battery warning chirp indi- cation when disarming.

  • Page 9: Transmitter Functions

    transmitter functions This system uses computer-based code learning to learn the transmit- ter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with standard configuration, but may also be customized using the CliffNet Wizard PC program.

  • Page 10: Using Your System

    using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration. If your transmitter has been custom configured, the icons on your transmitter buttons may not correspond to the indicated functions. arming You can activate, or arm, the system by pressing on your trans- mitter for one second.

  • Page 11: Disarming

    not chirp. The early chirps provide you with a 25-second warning prior to arming. n n o o t t e e : : If any protected entry point (a door or a switch-protected trunk or hood) is open, the system will not passively arm. Additionally, each time a protected entry is triggered during the arming countdown, the 30-second countdown starts over.

  • Page 12: Disarming Without A Transmitter

    disarming without a transmitter This feature allows you to disarm the system without the transmitter should it be lost, damaged, or disabled. In order to disarm without a transmitter, you must have the vehicle’s ignition key, know where the PlainView 2 Valet switch is located, and have the PIN code. Be sure to check with the installer for the location of the PlainView 2 Valet switch and instructions for entering the PIN code.

  • Page 13: Transmitter Sensor Disable

    transmitter sensor disable To temporarily disable a sensor input, arm the system, press the simultaneously. The lights will flash four times and all warn away trigger zones three and eight are bypassed. Press the buttons again; the lights flash four times and both warn away and full trigger zones three and eight are bypassed until the system is disarmed.

  • Page 14: Auxiliary Channel Bypass

    auxiliary channel bypass Alarm sensor input zones three and eight will be bypassed while a pulsed or timed auxiliary Output is active. panic mode with smart door locking If you are threatened in or near your vehicle, you can attract attention by triggering the system with your transmitter! Just press two seconds to enter Panic Mode.

  • Page 15: Transmitter Valet Mode

    After the last digit continue to hold three seconds. The LED status indicator will light steadily if you are entering Valet Mode and will turn off if you are exiting Valet Mode. To exit Valet Mode: 1. Turn the ignition on. 2.

  • Page 16: Low Battery Warning

    low battery warning When the transmitter battery is low, the system will generate five quick chirps when disarmed. n n o o t t e e : : The self-powered smart siren will generate a low-pitched tone. instant auto-arming bypass This will bypass the auto arm feature once only.

  • Page 17: False Alarm Control Technology (Fact Ii)

    and proceed down to the eighth trigger. If fewer than eight triggers are stored in memory, the LED will blink continuous- ly until the system is armed/disarmed using the transmitter after recalling the final trigger. For more information, please refer to the Table of Zones section of this guide. false alarm control technology (FACT II) Your system offers FACT , a feature that prevents annoying...

  • Page 18: Select Siren Sounds

    Since this will only occur while the system is armed, there is no need for a siren override key. Unlike other back-up battery sirens that constantly drain the car battery, Clifford’s design draws charging current only when the ignition is on (i.e., engine running). If the internal battery is discharged, the arm/disarm chirps are muted.

  • Page 19: Diagnostics

    diagnostics The microprocessor at the heart of your security system is constantly monitoring all of the switches and sensors that are connected to it. It detects any faulty switches and sensors and prevents them from dis- abling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

  • Page 20: Arm/Disarm Diagnostic Chart

    arm/disarm diagnostic chart Action Chirps Light Flashes Description System armed System armed with hood/ trunk active and bypassed (zones 5 and 6) 2 (5 sec.) 4 2 (5 sec.) 4 System armed with door active and bypassed (zone 4) 2 (10 sec.) 4 2 (10 sec.) 4 System armed with sensor active and bypassed zones...

  • Page 21: Anti-Code Grabbing (Acg)

    anti-code grabbing (ACG) This unit features Anti-Code Grabbing (ACG) with Random Code Encryption. This means the receiver and transmitters each use a math- ematical formula called an algorithm to change their code each time the transmitter is used. This technology has been developed to increase the security of the unit.

  • Page 22: Power Saver Mode

    power saver mode Your system will automatically enter Power Saver Mode while armed or in Valet Mode, after a period of time in which no operation has been performed. This lowers the current draw on the vehicle's battery and prevents the system from draining the battery. Power Saver Mode takes over under the following conditions: Power Saver when the system is armed: After the system has been armed for 48 hours, the LED will flash at half its nor-...

  • Page 23: Programming Options

    programming options Programming options control what your system does during normal operation, and require few or no additional parts. However, some may require additional installation labor. Following is a list of the program settings, with the factory settings in bold: Active arming (only with the transmitter) or passive arming (automatic arming 30-seconds after the last door is closed).

  • Page 24: Manual Programming Instructions

    False Alarm Control Technology (FACT ) on or off: Please refer to the FACT section of this guide for a complete explanation of how FACT operates. If FACT is pro- grammed off, the security system will respond to inputs from any sensor indefinitely.
  • Page 25 Hold/Chirp/Release - After entering the PIN code, press and hold until a chirp is heard and the LED turns on, then release the button. You have now entered the feature selec- tion position of the User Selectable Features grid. Column select - Press the same number of times as the desired column.

  • Page 26: User Selectable Features

    user selectable features * This feature is only available with optional 515C siren. ** This feature is only available with optional IntelliStart connected. *** This feature is only available with optional SmartWindows connected.

  • Page 27: User Selectable Features Descriptions - Column One

    user selectable features descriptions - column one add new remote (auto learn) Auto-learn new three-button cello remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again to complete the learn routine.
  • Page 28 auto unlock - ignition/off Ignition: The doors will automatically unlock as soon as the ignition is turned off. Off: The doors will not automatically unlock when the igni- tion is turned off. passive lock - on/off On: The doors will lock when the system passively arms. This feature only applies when passive arming is programmed on.

  • Page 29: User Selectable Features Descriptions - Column Two

    user selectable features descriptions - column two set pin code This feature allows the setting of the user's personal PIN code. For more information, please refer to the PIN Programming section of this guide. select siren sounds The individual sounds the 515C siren produces during an full trigger alarm can be customized for owner recognition of an alarm trigger.

  • Page 30: User Selectable Features Descriptions - Column Three

    reset to default settings All system settings (except PIN and remote programming) in the User Programming grid will be reset to their default fac- tory setting as indicated in bold lettering. Press on the transmitter; the siren will chirp twice as confirmation.
  • Page 31 accessory output The transmitter channel programmed into this feature will activate the accessory output. silent mode The transmitter channel programmed into this feature will arm/disarm the system, but the siren will not chirp. remote valet The transmitter channel programmed into this feature will make the system enter/exit valet mode.

  • Page 32: Pin Programming

    pin programming A PIN code can have one to four digits; each digit can be from 0-9. n n o o t t e e : : A PIN code cannot begin with a zero. Programming Procedure Enter the feature location in the installer programming grid. Immediately press and release of the PlainView 2 Valet switch.
  • Page 33 PIN Code Confirmation Procedure Begin this procedure within 15 seconds of finishing the programming sequence or the new code will not be set. Turn on the ignition. Enter the new PIN code. Press and hold for three seconds. LED turns on: New PIN code is learned and program- ming is complete.

  • Page 34: Glossary Of Terms

    glossary of terms Control Unit: The "brain" of your system. Usually hidden underneath the dash area of the vehicle. It houses the microprocessor which mon- itors your vehicle and controls all of the system's functions. Normally Open/Normally Closed Immobilizer : An automatic switch con- trolled by the security system which prevents the vehicle’s starter from cranking whenever the system is armed.
  • Page 35 of the siren sounding and parking light flashing for the programmed duration. PlainView 2 Valet Switch : A small two-button switch mounted some- where inside the vehicle. It is used to override the alarm when a trans- mitter is lost or damaged, or to enter or exit Valet mode. Warning Zone Response: Lighter impacts to the vehicle will generate the Warning Zone response.

  • Page 36: Security & Convenience Expansions

    security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Backup Battery: The 520T keeps the system armed, triggers the alarm and keeps the starter interrupt active if main battery power is disconnected.

  • Page 37: Health Check

    Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service.
  • Page 39 © 2 0 0 3 d i re c t e d e l e c t ro n i c s , i n c .
  • Page 40 The company behind this system is Directed Electronics, Inc. Since its inception, Directed ® has had one purpose, to provide consumers with the finest vehi- cle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed ®...
