AvantGuard 5
O O w w n n e e r r ' ' s s G G u u i i d d e e

Advertisement

Table of Contents
loading

Related Manuals for Clifford AVANTGUARD 5

Summary of Contents for Clifford AVANTGUARD 5

  • Page 1 AvantGuard 5 O O w w n n e e r r ’ ’ s s G G u u i i d d e e...
  • Page 2 limited lifetime consumer warranty Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or replace with a comparable reconditioned model any Directed unit (hereafter the "unit"), excluding without limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to be defective in workmanship or material under reasonable use during the life- time of the vehicle provided the following conditions are met: the unit was professionally installed and serviced by an authorized Directed dealer;...
  • Page 3 ! ! Please note that this manual was intended for US consumers and therefore includes American phrases or words. trademarks and copyrights Bitwriter ™ , Clifford ® , Code-Hopping ™ , Directed ®...

  • Page 4: Table Of Contents

    contents what is included ... . .3 arming diagnostics ..18 disarming diagnostics ..19 important information ..3 arm/disarm diagnostic chart .
  • Page 5 diesel compatibility ..37 bypass blackjax temporarily . .39 blackjax off warning indicator 40 auto-immobilization feature . . .37 auto-immobilization sequence sensor description section ..41 ..... . .37 507T tilt/motion sensor .

  • Page 6: What Is Included

    In order to maximize the use of this system, please review this owner's guide carefully prior to using your system. You can print additional or replacement copies of this owner’s guide by accessing the Clifford web- site at www.clifford.com. © 2 0 0 3 d i re c t e d e l e c t ro n i c s , i n c .

  • Page 7: System Maintenance

    system maintenance The system requires no specific maintenance. Your transmitter is pow- ered by two miniature 3V lithium batteries that will last approximately one year under normal use. When the batteries weaken, operating range will be reduced and the system will provide a low battery warn- ing chirp indication when disarming.

  • Page 8: Transmitter Configurations

    : : This manual describes the features and accessories that are included with your system along with information about compatible Clifford accessories that are not included. For a list of included acces- sories, please refer to the What Is Included section of this manual.

  • Page 9: Transmitter Functions

    transmitter functions This system uses computer-based code learning to learn the transmit- ter buttons. This makes it possible to assign any transmitter button to any system function. The transmitter initially comes programmed with standard configuration, but may also be customized using the CliffNet Wizard PC program.
  • Page 10 Immediately cease the use of the unit and repair or disconnect the installed remote start module. Clifford will not be held responsible or pay for installation or reinstallation costs. Remote start is controlled by this button.
  • Page 11 Button twice, then Button These buttons enter safe start mode for manual transmission vehicles and activate Autostart mode. Button three times, then Button These buttons adjust the dual-zone omnisensor. Button three times, then Button These buttons adjust the dual-zone radar sensor.

  • Page 12: Arming With Transmitter

    using your system The buttons used in the instructions in this manual correspond to the standard transmitter configuration. If your transmitter has been custom configured, the icons on your transmitter buttons may not correspond to the indicated functions. arming with transmitter You can activate, or arm, the system by pressing on your trans- mitter for one second.

  • Page 13: Disarming

    ally armed at that point. The system arms and the doors lock (if con- nected and programmed for passive locking) at 30 seconds, but the siren will not chirp. The early chirps provide you with a 25-second warning prior to arming. n n o o t t e e : : If any protected entry point (a door or a switch-protected trunk or hood) is open, the system will not passively arm.

  • Page 14: Disarming Without A Transmitter

    Alert. If the siren is active when the system is disarmed you will hear two chirps but the system is not disarmed. (Refer to the Remote Siren Silencing section of this guide.) However, if the alarm completes the full trigger cycle when disarmed you will hear three chirps. disarming without a transmitter This feature allows you to disarm the system without the transmitter should it be lost, damaged, or disabled.

  • Page 15: Transmitter Chirp Muting

    transmitter chirp muting To temporarily turn off the arm or disarm chirps, use transmitter chirp muting. Simply press on the transmitter, and the confirmation chirp(s) will be eliminated for that one operation only. The parking lights will flash to confirm the arm/disarm command. If you want the arm/disarm chirps turned off permanently, please refer to the User- Selectable Features section of this guide.

  • Page 16: Intellistart And Smartwindows

    intellistart and smartwindows sensor bypass When the system sees a command to start the vehicle via the Intellistart, it bypasses all sensors and will continue to bypass these sen- sors until the remote start shuts down. When the system sees a SmartWindows command for up or down operation, the unit will automatically bypass all sensors until the win- dows complete their operation.

  • Page 17: Disarm/Valet Mode

    disarm/valet mode Entering your pin code using the PlainView 2 Valet switch allows you to disarm the system or enter valet mode without using the transmit- ter. In valet mode, the security system will not arm, even with the trans- mitter, but all convenience functions (door locks, trunk release, etc.) will continue to work normally.

  • Page 18: Transmitter Valet Mode

    transmitter valet mode To enter or exit Valet Mode, press twice and then The LED status indicator will light solid when Valet Mode is entered, or will turn off when Valet Mode is exited. one-time auto-arming bypass This will bypass the auto arm feature once only. With the key, turn the ignition on, then off within two seconds.

  • Page 19: Multiple Event Total Recall

    multiple event total recall This will report the last eight system triggers. Press and hold of the PlainView 2 Valet switch. While still holding , arm and disarm the system, then release the button. The LED will start to blink to indicate the most recent trigger and proceed down to the eighth trigger.

  • Page 20: Select Siren Sounds

    Doors are covered by FACT differently; if the alarm is triggered by an open door for three full cycles, the doors will be bypassed until the trig- ger ceases. FACT is programmable. See the Programming Options section of this guide. n n o o t t e e : : Arming and disarming the system does not reset this function! The only way to reset a bypassed zone is for 60 minutes or to turn on the ignition.

  • Page 21: Diagnostics

    diagnostics The microprocessor at the heart of your security system is constantly monitoring all of the switches and sensors that are connected to it. It detects any faulty switches and sensors and prevents them from dis- abling the entire system. The microprocessor will also record and report any triggers that occurred during your absence.

  • Page 22: Disarming Diagnostics

    disarming diagnostics Extra disarm chirps are the Tamper Alert. If three chirps are heard when disarming, the system was triggered in your absence. If three chirps are heard, the LED status indicator will indicate which zone was involved when you turn the ignition on (see the Table of Zones section). The sys- tem will retain this information in its memory.

  • Page 23: Table Of Zones

    table of zones The zone number is the number of LED flashes used by the system to identify a specific input. The standard input assignments are listed below, along with spaces to write in any optional sensors or switches you have had installed. If the Warning Zone response is triggered, the LED will not report it.

  • Page 24: High Frequency

    high frequency Your system transmits and receives at 433 MHz. This provides a cleaner spectrum with less interference and a more stable signal. smart power up II This security system will store its current state to non-volatile memory. If power is lost and then reconnected the system will recall the stored state from memory.

  • Page 25: Programming

    Power Saver when the system is armed: After the system has been armed for 48 hours, the LED will flash at half its nor- mal rate, decreasing the system's current draw. Power Saver in Valet Mode: When the system enters Valet Mode the LED illuminates steadily.

  • Page 26: Tions

    manual programming instructions Be sure to document changes by taking note of all feature changes made in programming mode. To enter the User Selectable Features programming: Ignition on - Turn the ignition to the run position or start the engine. Enter PIN - Enter the factory preset PIN code 2 by pressing on the PlainView 2 Valet switch twice, then once.

  • Page 27: User Selectable Features

    number. n n o o t t e e : : Refer to the Feature Descriptions sections of this guide for impor- tant notes and descriptions of the system features and programming. Exit programming - To exit programming mode turn the igni- tion off or wait 60 seconds without pressing the PlainView 2 Valet switch.

  • Page 28: User Selectable Features Descriptions - Column One

    user selectable features descriptions - column one add new remote (auto learn) Auto-learn new five-button Radar2 remote controls to the system in the standard button configuration. Once you have entered the feature, press on the transmitter until you hear a confirmation chirp. Press again until you hear two chirps indicating the new remote is learned.
  • Page 29 auto unlock - ignition/off Ignition: The doors will automatically unlock as soon as the ignition is turned off. Off: The doors will not automatically unlock when the igni- tion is turned off auto (passive) arm and lock - on/off On: The doors will lock when the system passively arms. This feature only applies when passive arming is programmed on.

  • Page 30: User Selectable Features Descriptions - Column Two

    user selectable features descriptions - column two set pin code This feature allows the setting of the user's personal PIN code. For more information, please refer to the PIN Programming section of this guide. select siren sounds The individual sounds the siren produces during an full trigger alarm can be customized for owner recognition of an alarm trigger.
  • Page 31 Off: There is no entry delay when armed. The system will trigger instantly when a door is opened. reset to default settings All system settings (except PIN and remote programming) in the User Programming grid will be reset to their default fac- tory setting as indicated in bold lettering.

  • Page 32: User Selectable Features Descriptions - Column Three

    user selectable features descriptions - column three The features in this column pertain to programming individual trans- mitter channels in custom configurations. Following is an explanation of the features. arm/disarm only The remote control channel programmed into this feature will arm/dis- arm the system only.
  • Page 33 remote start This feature is only available with IntelliStart connected. The transmitter channel programmed into this feature will activate or shut down the Intellistart remote start system. window control This feature is only available with SmartWindows connected. The transmitter channel programmed into this feature will activate the vent or roll down feature of the SmartWindows system.

  • Page 34: Pin Programming

    pin programming A PIN code can have one to four digits; each digit can be from 0-9. n n o o t t e e : : A PIN code cannot begin with a zero. Programming Procedure Enter the feature location in the installer programming grid. Immediately press and release of the PlainView 2 Valet switch.

  • Page 35: Remote Start

    Activates all preset accessories such as the heater or AC. Monitors RPM and shuts down the engine if problems are detected. Clifford security system remains armed throughout. Automatically bypasses triggered security sensors. Automatically shuts down the engine if the alarm sounds.

  • Page 36: Remote Start Do's And Don'ts

    Auto shutdown after 30 minutes if left unattended. Prevents the starter from engaging if the driver turns the ignition key too far. ShortStop lets you remove the key and arm the alarm for a brief errand while the engine continues to idle. Selectable low temp autostart warm up for very cold weather.

  • Page 37: Remote Start/Engine Shut Down

    DON'T remote start your vehicle or engage Shortstop or Autostart modes in an enclosed area such as a garage or car port. DON'T allow children access to your remote control. DON'T engage remote start or Shortstop or Autostart modes when children or pets are present in the vehicle. DON’T remote start the vehicle when someone is in front or behind the vehicle.

  • Page 38: Shortstop Mode

    Insert your key into the ignition and turn to the run position. Step on the brake, the remote start will turn off and the engine will stay running. You are ready to drive. shortstop mode Shortstop mode is a convenience feature that allows the remote start to keep the engine running while you run a brief errand.

  • Page 39: Low Temperature/Battery Start

    low temperature/battery start Your remote start system can automatically start your vehicle if the inte- rior reaches a pre-programmed low temperature setting or if the bat- tery charge level drops too low. Both these settings can be calibrated and set using the Cliffnet Wizard. It is recommended that you have your installer calibrate and set the start time intervals if you intend to use this feature.

  • Page 40: Diesel Compatibility

    diesel compatibility the system will activate the engine’s glow plugs for the necessary dura- tion before starting via either a timer delay or through a direct connec- tion to your vehicle’s glow plug indicator (may require optional parts or wiring). auto-immobilization feature Auto-immobilization is a feature designed for maximum security;...

  • Page 41: One-Time Valet Feature

    OFF: Valet mode will only be exited by using the valet switch or the remote control. blackjax feature Clifford's exclusive BlackJax feature provides a safe and effective means of recovering your vehicle after a carjacking by monitoring the door input, brakes, and engine speed. Simply get out of the vehicle and let the thief drive away.

  • Page 42: Blackjax Deactivation Sequence

    n n o o t t e e : : If the driver accidently exits the vehicle and triggers the blackjax feature, the siren will sound 5 chirps after 20 seconds. The driver then has 20 seconds to enter the pin code to deactivate the blackjax fea- ture.

  • Page 43: Blackjax Off Warning Indicator

    Siren chirps 1 time as confirmation of BlackJax bypassed. Turn Ignition Off, siren chirps 3 times as confirmation of exit- ing programming. n n o o t t e e : : If ignition remains on after entering PIN code and no action for 10 seconds, unit will automatically exit programming mode without chirps.

  • Page 44: Sensor Description Section

    sensor description section 507T tilt/motion sensor This sensor detects when the vehicle is being raised in an attempt to either remove the wheels/tires or tow the vehicle. This sensor is capa- ble of learning the vehicle’s initial angles of vertical and horizontal incli- nation each time the vehicle is parked.
  • Page 45 Read the following instructions thoroughly for a full understanding of how to properly adjust this sensor. Disarm system Transmit Channel 16. (Press 3 times then 1 time) The LED will turn on and the siren will chirp 1 time. Primary (full trigger) zone adjustment has now been entered.

  • Page 46: Adjusting The Omnisensor

    Press of the remote control to return to Primary zone adjustment and lock in Warn Away zone setting. Siren chirps 2 times Primary zone can now be re-adjusted as described in step 3. Or press again to lock in primary zone setting and exit programming mode.
  • Page 47 1 time). The LED will turn on and the siren will chirp 1 time. Sensor test and adjustment mode is entered. To test Primary (full trigger) zone. Press of the remote control. Siren will chirp 2 times. Hit vehicle. Siren chirps 1 time if hit hard enough to activate sensor. Adjust Primary zone Press of the remote control.
  • Page 48 Adjust Warn-away zone Press Siren chirps 2 times. Sensor adjustment mode is entered. Hit vehicle at the desired level of impact. Sensor adjusts itself to the force of Hit. Siren chirps 1 time as confirmation of adjustment. Press to lock adjustment. Press to re-enter Primary zone adjustment Siren chirps 2 times.

  • Page 49: Glossary Of Terms

    glossary of terms 507T Tilt/Motion sensor: This sensor detects when the vehicle is being raised in an attempt to either remove the wheels/tires or tow the vehi- cle. This sensor is capable of learning the vehicle’s initial angles of ver- tical and horizontal inclination each time the vehicle is parked.
  • Page 50 Proximity Sensor : This is a sensor mounted in the vehicle that is designed to protect the interior and its contents. Siren : Noise generating device usually installed in the engine compart- ment of the vehicle. It is responsible for generating the "chirps" you hear, as well as the six tones you hear while the alarm is triggered.
  • Page 51 security & convenience expansions Here we have listed only some of the many expansion options avail- able. Please contact your dealer for a complete list of all the options available to you. Backup Battery: The 520T keeps the system armed, triggers the alarm and keeps the immobilization circuits active if main battery power is discon- nected.

  • Page 52: Health Check

    Directed Electronics recommends you return to your installing Clifford dealer to have your system checked for correct operation. The first check is due one year after the installation date and at yearly intervals thereafter. n n o o t t e e : : There may be a small charge incurred for this service.
  • Page 53 The company behind this system is Directed Electronics, Inc. Since its inception, Directed has had one purpose, to provide consumers with the finest vehi- ® cle security and car stereo products and accessories available. The recipient of nearly 100 patents and Innovations Awards in the field of advanced electronic technology, Directed is ISO ®...
