STEP 1: CHANGING THE INPUT HARNESS

1. The Cyclone and Atom ESCs include the Novak Input Plug
System™ to convert the Futaba J style signal harness to be
compatible with Airtronics/Sanwa (AIR), KO, Kyosho (KYO),
and JR/Hitec/AIR Z (JR) receivers. Refer to Figures 1-5
NOTE: It is important that the metal locking tabs do not extend
outside the plastic plug housing.
FIGURE 1 Additional Plugs Included
AIR
Airtronics/Sanwa
4
CYCLONE & ATOM INSTRUCTION MANUAL
KO
KO Propo
FIGURE 2 With a small standard
screwdriver, press on each of the
three metal prongs until the wires
are easy to remove. Remove wires.
KYO
Kyosho
JR/Hitec/AIR Z
JR
Continued
