FEATURES LISTING

The Cyclone and Atom ESCs are loaded with features, such as:
• Highest motor control frequency (up to 23,400 Hz).
• 256 discrete steps forward & 256 discrete steps braking
for smoothest trigger response available (0.39% per step).
• Adjustable minimum brake that can be set from 0% to
75% with the use of a simple adjustment pot.
• Three different user-selectable profiles to suit the desired
application (off-road, touring sedan, 1/12 scale, oval, etc.)
and ability to store one Custom Profile (created with the
optional Pit Wizard #1035 or ESC Profile Software #1030).
Accessed with the One-Touch Set-Up™ button, these profiles
give racers extreme flexibility and a competitive advantage.
• The Data Link™ allows the ESC to be connected to the
Novak Pit Wizard or ESC Profile Software w/IBM compat. PC.
• Quickest response to change in transmitter signal (fewer
than 500 micro seconds).
• Low-voltage operation enables the ESC's control electron-
ics to work error free down to 2 volts DC.
• Polar Drive Technology™ and HYPERFET III™ transistors
provide smooth throttle control and cool running operation.
This technology also provides improved radio system perfor-
mance by reducing motor-generated radio interference.
• Radio Priority Circuitry™ maintains control of the vehicle
after the battery pack has "dumped," and helps eliminate
servo jitters during heavy-load applications.
• Built-in 6-volt/3-amp BEC (Battery Eliminator Circuit) to
power the radio system and the most power-hungry servos,
without the use of an external receiver battery. The BEC cir-
cuit is fully protected from overloading.
• Low-resistance Solder Posts for quick installation, clean re-
placement, and unlimited positioning of any size power wires.
• Built-in Brake Light Circuitry and Brake Light LED Kit are
included to power two external LEDs, adding realism to
Formula 1 and touring cars. (Cyclone only)
