Minimum Brake Adjustment - NOVAK ATOM AND CYCLONE ESC Manual

STEP 6: Throttle Profile Selection (continued)
FIGURE 14 General Diagram of Minimum Brake, Dead
Band and other parameters.
1 0 0
5 0
2 0
1 0
F u l l
B r a k e

MINIMUM BRAKE ADJUSTMENT

The Cyclone & Atom come with a Minimum Brake
Adjustment feature to give the user control over the starting
value of the brake throw. This adjustment is made with the
ESC's BRAKE pot, using the included adjustment screwdriver.
DO NOT rotate the pot beyond its end stop—this will
damage the pot and void the warranty.
• By turning the BRAKE adjustment pot clockwise
amount of minimum brake is increased to a maximum of
75% of the total brake throw.
• When the BRAKE pot is turned all the way counter-
clockwise
0.39%. This means that the first brake pulse is 0.39% of
the total brake throw.
CYCLONE & ATOM INSTRUCTION MANUAL
256 Discrete Steps
to Full Brake
T R I G G E R
M i n i m u m
B r a k e
[ 2 0 % ]
, the amount of minimum brake is set to
256 Discrete Steps
to Full Throttle
15%
P O S I T I O N
M i n i m u m
D r i v e
[ 1 0 % ]
N e u t r a l
1 0 0
5 0
2 0
1 0
F u l l
T h r o t t l e
, the
