- Page 1 OWNER'S MANUAL Model: Thank you for choosing LUXE Bidet. This manual contains important information regarding your unit. Before operating the unit, please read this manual thoroughly, and retain it for future reference.
- Page 3 LUXEBeret TABLE OF CONTENTS PRODUCT INFORMATION Product Features page 1 Why LUXE Bidet? . page 2 Specifications . page 3 Product Dimensions . page 3 Parts List page 4 PRODUCT INSTALLATION Before Installation . page 5 Installation page 7 PRODUCT...
- Page 4 PRODUCT INFORMATION PRODUCT FEATURES Dual Nozzle Design The LUXE Bidet Neo 320 is equipped with dual nozzles for rear and frontal wash. The frontal or feminine wash gentler than the rear spray. It can be useful for monthly cycles and is highly...
- Page 5 PRODUCT INFORMATION LUXE BIDET? Protects & Restores Forests Bidets axe zero trees. Help protect our forests! EasyOn Your Skin Water cleans better and more gently than paper. Saves the Septic System With bidets, septic tanks would need to be emptied much less. Good Bottom Line...
- Page 6 PRODUCT INFORMATION SPECIFICATIONS UPC: 895063002814 (blue), 850625005139 (white) Retail Size: 17.6 x 7.1 x 4" Retail Package Weight: 2.39 lbs Connection Type: Cold and Hot water Water Control: Chrome-plated lever Mode Selection Control: Chrome-plated dial Nozzles: Dual-nozzle Bidet Body Material: ABS resin, plastic bidet inlet Parts Material: 7/8"...
- Page 7 PRODUCT INFORMATION PARTS LIST Circular Adjustment Plates (2) Bidet Attachment with Rubber Gaskets (2) SKU Code: NeoAd}u5tmentPlare Rubber Washer 7/8" Note:The7/8" Plastic connection sometimes Metal Body 1/2" referred to as Connections 15/16"but 3/8" theyarethe same Size. 7/8" Hot Water T-adapter Hybrid Cold Water T-adapter (3/8"...
- Page 8 If you have extremely high water pressure, the stream of water coming out of the bidet may feel too strong. We would recommend installing a LUXE Bidet@ Metal T-adapter with Shut-off Valve which can be purchased at www.LuxeBidet.com (see discount below).
- Page 9 (as pictured below), NOT at the cold water supply valve coming from the wall. Toilet Tank If you do not have access to the fill valve under the Toilet Tank Fill Valve toilet tank, contact LUXE Bidet Customer Support at Cold Water T-adapte 858-360-7780 or customercare@luxebidet.com alternative installation options.
- Page 10 Step 3 - Mount Your LUXE Bidet on the Toilet Place the bidet attachment on the toilet. The adjustment plates will need to line up with the holes on the toilet bowl.
- Page 11 PRODUCT INSTALLATION INSTALLATION (cont.) Step 5 - Disconnect the Water Supply Hose Make sure you have turned off the toilet tank water supply and flushed the toilet to empty the toilet tank if you have not done so already. Place a towel or bucket underneath toilet tank connection to catch any residual water, then disconnect the water supply hose from the toilet tank.
- Page 12 PRODUCT INSTALLATION INSTALLATION (cont.) Step 9 - Turn off the Sink Hot Water Supply Turn off the sink hot water supply (located underneath or near the sink) to stop the flow of water (most valves will need to be turned clock-wise). Step 9 Step 10 - Disconnect the Sink Hot Water Supply Hose Make sure you have turned...
- Page 13 Toilet Tank Water Supply supply. Sink Hot Water Supply Step 14 Congratulations! You are ready to use the LUXE Bidet for the first time. Gently turn the water pressure control knob to reach your desired spray pressure. ASSEMBLED UNIT Toilet...
- Page 14 PRODUCT OPERATION TROUBLESHOOTING Problem Possible Causes Possible Solutions 1. The toilet seat has outer After installing the bidet, 1. f the extra space is 1" or less, install toilet seat bumpers toilet seat does hinge tabs. (available on luxebidet.com). rest flat on the toilet...
- Page 15 PRODUCT OPERATION TROUBLESHOOTING (cont.) Problem Possible Causes Possible Solutions The toilet tank is filling The water supply valve Turn the water supply slower than normal after may not be fully opened. valve clockwise to allow installing the bidet. more water to flow to the toilet.
- Page 16 PRODUCT OPERATION TROUBLESHOOTING (cont.) Problem Possible Causes Possible Solutions Some toilet seat bolts toilet seat bolts Install longer bolts from not properly affix to the shorter than required to toilet seat manufacturer toilet after installing the accommodate bidet. accommodate extra bidet.
- Page 17 PRODUCT OPERATION Do the nozzle(s) always stay out when not in use? The nozzle is retractable and only comes out when the water is turned on. What kind of material is the bidet body made from? LUXE Bidets are made from very strong (yet light and flexible) plastic.
- Page 18 Therefore, the owner hereby releases the manufacturer and sellers of LUXE Bidet from any and all claims for bodily and property damage resulting from such conditions.
- Page 19 Yes, we have hot water metal braided hoses available for purchase online on our LUXE Bidet Accessories page that can be used to connect the Neo 250 and Neo 320 to the hot water. This hose is 1/4" where...
- Page 20 CONTACT CONTACT If you have any questions or comments, please contact our customer care at any time and we will be able to assist you further. Thank you for choosing LUXE Bidet@. Website: www.LuxeBidet.com Email: customercare@luxebidet.com Phone: 858-360-7780 Fax: 858-876-1559 LUXE Bidet HQ 7770 Regents Rd.
- Page 21 MEMO...
- Page 22 MEMO...
- Page 24 Ver. 22.03.01 Website: www.LuxeBidet.com Email: customercare@luxebidet.com Phone: 858-360-7780 Fax: 858-876-1559 LUXE Bidet HQ 7770 Regents Rd. 113-632 San Diego, CA 92122 United States 0 2Go Products,...
