NextBase CLICK 10 Instruction Manual

Click 10
''
10.1 DELUXE PORTABLE DVD PLAYER

SPECIFICATIONS

10.1 digital TFT screen with resolution 800RGB(W) x 480(H) ''
Click & Go: intelligent car mounting system, just slip the player
into the mount and the movie will play automatically
Deluxe design with metal-like front and leather back
Built-in battery (7.4V/3200mAh) allows up to 2.5-hour use
Easy on-top buttons (9 keys)
Slim top loading DVD loader
Include 3-in-1 card slot for SD /MMC /MS /MS-Pro and USB host
Support S-video input /output, CVBS input /output, earphone
output, and DC 12V output
Can connect TV, Game console via iX connector
2 slim built-in stereo speakers (1W)
2-channel IR transmitter
Multi-language OSD: English, German, French, Spanish, Italian,
and Swedish
DVB-T module (optional)

PARAMETERS

Power Supply

Power input: DC 12V/1.5A
Battery: built-in battery (7.4V/3200mAh)

Dimension and Weight

Dimension: 246mm (W) x 170mm (H) x 30mm (L)
Weight: 1100g

ACCESSORIES

AC-DC adapter
Remote control
Earphone
AV cable
(via iX connector)
Instruction manual
Quick start
Carrying bag
Info@next-base.com www.next-base.com
