Setting the gray level for the sides of the screen

Use this procedure to set the gray level for the parts on the
screen on which nothing is displayed when the screen is
set to the 4:3 size.
Example: Adjusting the "GRAY LEVEL"
Press the PROCEED button on the remote control to
display the MAIN MENU on the screen, then...
1. Use the L and M buttons to select "FUNCTION", then
press the PROCEED button.
The "FUNCTION" screen appears.
2. Use the L and M buttons to select "GRAY LEVEL".
F U N C T I O N
OSM
OSM ADJ.
POWER MGT
GRAY LEVEL
CINEMA MODE
RGB3 ADJ.
LONG LIFE
RESET
SEL.
ADJ.
3. To adjust the "GRAY LEVEL"...
Use the
and
buttons to adjust the GRAY LEVEL.
F U N C T I O N
OSM
OSM ADJ.
POWER MGT
GRAY LEVEL
CINEMA MODE
RGB3 ADJ.
LONG LIFE
RESET
SEL.
ADJ.
4. Once the setting is completed ...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once
more.
Information
GRAY LEVEL
This adjusts the brightness of the black (the gray level)
for the sides of the screen.
The standard is 0 (black). The level can be adjusted
from 0 to 15. The factory setting is 3 (dark gray).
Restoring the factory default settings
Select "RESET" under the function menu. Note that
this also restores other settings to the factory defaults.
: ON
: 1
: OFF
:
3
: ON
: 1
EXIT
RETURN
: ON
: 1
: OFF
:
9
: ON
: 1
EXIT
RETURN
E-29

Setting the picture to suit the movie

The film image is automatically discriminated and
projected in an image mode suited to the picture.
[NTSC, PAL, PAL60, 480I (60Hz), 525I (60Hz), 576I
(50Hz), 625I (50Hz), 1035I (50Hz), 1080I (60Hz) only]
Example: Setting the "CINEMA MODE" to "OFF"
Press the PROCEED button on the remote control unit to
display the MAIN MENU on the screen, then...
1. Use the L and M buttons to select "FUNCTION", then
press the PROCEED button.
The "FUNCTION" screen appears.
2. Use the L and M buttons to select "CINEMA MODE".
F U N C T I O N
OSM
OSM ADJ.
POWER MGT
GRAY LEVEL
CINEMA MODE
RGB3 ADJ.
LONG LIFE
RESET
SEL.
ADJ.
3. To set the CINEMA MODE to "OFF" ...
Use the
and
buttons to select "OFF".
The mode switches as follows each time the
button is pressed:
→ ON ↔ OFF ←
F U N C T I O N
OSM
OSM ADJ.
POWER MGT
GRAY LEVEL
CINEMA MODE
RGB3 ADJ.
LONG LIFE
RESET
SEL.
ADJ.
4. Once the setting is completed ...
Press the EXIT button to return to the main menu.
To delete the main menu, press the EXIT button once
more.
Information
CINEMA MODE
ON ................... Automatic discrimination of the
image and projection in cinema mode.
OFF ................... Cinema mode does not function.
Restoring the factory default settings
Select "RESET" under the function menu. Note that
this also restores other settings to the factory defaults.
: ON
: 1
: OFF
: 3
:
ON
: 1
EXIT
RETURN
or
: ON
: 1
: OFF
: 3
:
OFF
: 1
EXIT
RETURN
