42XR4 Installation Guide
42" Plasma Display
Contents:
Product Description and Notes
Ventilation Requirements
Display Dimensions
Front, Top & Bottom
Rear
Left & Right Side
Display Dimensions w/Optional Speakers and Stand
Dimensions w/Optional Wall Mount
Dimensions w/Optional Ceiling Mount
Connections
Control Codes

Product Description

Type:
Plasma Display
Resolution:
1024x768
Aspect Ratio:
16:9
Color Correction: Bonded Color Filter
Notes
This document is intended to be used as a reference guide to supply useful information for a design or installation. It is not intended to
be a step-by step procedure for installation.
Any ceilings or walls must be strong enough to support the display and the installation must be in accordance with any local
building codes. All mounts should make secure contact to wood studs.
4:3 sources can be displayed on the 16:9 screen in either normal aspect ratio with bars on the left or right, or stretched horizontally to
fill the screen using the menus (see "Aspect Modes" in menus and user manual).
Distances are in inches, for millimeters multiply by 25.4.
Distances may vary ±5%.
Maximum Tilt Angles
Below is the maximum angle that the display can be tilted
Landscape 30°
www.necvisualsystems.com
Page 1
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10
Screen Surface: Anti-Reflective
Dimensions:
Weight:
FCC:
Max Tilt
NEC Solutions (America), Inc.
Visual Systems Division
40"(W) x 24"(H) x 3.9"(D)
59.5 lbs
Class B
PX-42XR4
Rev 1.3
Page 1 of 10

Advertisement

Table of Contents
loading

  Related Manuals for NEC PlasmaSync 42XR4

  Summary of Contents for NEC PlasmaSync 42XR4

  • Page 1: Product Description

    Distances are in inches, for millimeters multiply by 25.4. Distances may vary ±5%. Maximum Tilt Angles Below is the maximum angle that the display can be tilted Landscape 30° www.necvisualsystems.com NEC Solutions (America), Inc. Page 1 Page 2 Page 3 Page 4 Page 5...
  • Page 2 NOTE: The ventilation space should not be covered or closed off at the front of the opening. If for some reason the opening needs to be covered, other means of ventilation will need to be incorporated into the design. Contact NEC for design review and recommendations.
  • Page 3: Display Dimensions

    Control Buttons 0.79 0.74 1.72 0.81 3.89 4.79 11.3 www.necvisualsystems.com 40.2 12.28 AC Inlet 17.61 NEC Solutions (America), Inc. Visual Systems Division Ventilation Openings 1.86 2.74 IR Receiver 14.61 Power Button Speaker Terminal PX-42XR4 Rev 1.3 Page 3 of 10...
  • Page 4 42XR4 Installation Guide 42” Plasma Display Display dimensions (cont.) 4 - M8*14 Max for Speaker 9.71 4 - M4*10 Max for PC www.necvisualsystems.com NEC Solutions (America), Inc. 37.56 20.87 17.52 20.87 PX-42XR4 Visual Systems Division Rev 1.3 8 - M4*16 Max...
  • Page 5 42XR4 Installation Guide 42” Plasma Display Display dimensions (cont.) 0.50 www.necvisualsystems.com NEC Solutions (America), Inc. Visual Systems Division 0.60 1.59 3.86 PX-42XR4 Rev 1.3 Page 5 of 10...
  • Page 6 42XR4 Installation Guide 42” Plasma Display Dimensions with optional speakers and stand 0.02 www.necvisualsystems.com 4.72 26.93 47.0 Optional Speakers 0.02 NEC Solutions (America), Inc. Visual Systems Division 3.86 0.24 3.62 11.06 PX-42XR4 Rev 1.3 2.05 Page 6 of 10...
  • Page 7 42XR4 Installation Guide 42” Plasma Display Dimensions with optional Wall Mount Kit (4250WMK) www.necvisualsystems.com 20.87 AC IN NEC Solutions (America), Inc. Visual Systems Division Rev 1.3 2.98 6.70 8.73 4.31 PX-42XR4 Page 7 of 10...
  • Page 8 42XR4 Installation Guide 42” Plasma Display Dimensions with optional Ceiling Mount Kit (4250CMK) www.necvisualsystems.com Note: Optional Accessories not included with 4250CMK 20.87 AC IN NEC Solutions (America), Inc. Visual Systems Division 4.57 8.30 PX-42XR4 Page 8 of 10 Rev 1.3...
  • Page 9 42XR4 Installation Guide 42” Plasma Display Connections www.necvisualsystems.com Located at bottom of display NEC Solutions (America), Inc. Visual Systems Division Rev 1.3 Power Switch Ext. Speaker Connections Control Panel AC Inlet PX-42XR4 Page 9 of 10...
  • Page 10: Control Codes

    BRIGHT SCREEN MODE: STADIUM ZOOM NORMAL ANAMORPHIC (FULL) 2.35:1 AUTO PICTURE CINEMA MODE NOTE: Contact your NEC rep for codes not listed. NOTE: Use a cross/reverse/null modem cable. Cable Connection Communication Protocol: Interface: RS-232C Communication: Asynchronous Baud Rate: 9600 bps...
