10 Product and kit listings
The Dimplex solar product range is offered as kit or as individual components. The fol-
lowing listings detail all the kits and the individual components available.
10.1 Dimplex solar kits
The Dimplex solar kits are packaged in such a way that all the required components are
contained in the kit. Optional components are available but are not contained in the
st
nd
standard kits. Furthermore, the kits are structured to allow a 1
fix and 2
fix installa-
tion should the installation be done in stages such as in new build situations.
The cylinders are to be ordered separately as they differ in type, direct and indirect
auxiliary heating, and the size of cylinder relative to the collector area can vary. The
kits are summarised in Figure 59, the cylinders are listed in Figure 60 along side the
individual solar kit components.
Figure 59 – Dimplex solar kits overall view
10.2 Dimplex solar components
For systems larger than 6.6 m² (3 collectors) or should additional components be re-
quired the individual components can be chosen from Figure 60.
