USB Port
Connect a USB storage device
Reset Button
Restore settings
Internet Port
Plug your Internet cable in here
WPS Push Button
Securely connect to wireless network
Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic and network overhead, lower actual data throughput rate.
1
2 The attached devices must have CAT5 or above Ethernet cable.
3 24/7 Basic Installation Support is available only in the USA for the first 30 days from date of original purchase.
1-Year Limited Warranty available only in the USA and Canada.
4
Computer must adhere to Microsoft's recommended System Requirements.
5
All references to speed and range are for comparison purposes only. Product specifications, size and shape are subject to change without notice, and actual product appearance may differ from that depicted herein.
DIR-505 QRS App
For more information
U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | dlink.ca
© 2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, mydlink and the D-Link RoHS logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries.
Other trademarks or registered trademarks are the property of their respective owners. Visit www.dlink.com for more details.
Updated 3/7 /12
Mode Switch
Switch between
Router/ AP, Repeater and
Wi-Fi Hotspot Mode
SharePort™
Mobile App
DIR-505 All-in-one Mobile Companion
Technical Specifications
Standards
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.3
• IEEE 802.3u
Wireless Modes
• Wi-Fi Hotspot Mode
• Router/AP Mode
• Repeater Mode
(USB sharing capability disabled)
Wireless Frequency Range
• 2.4 GHz to 2.4835 GHz
Antennas
• Internal Antenna
Security
• Wi-Fi Protected Access (WPA/WPA2)
• WPS™ (PBC)
Advanced Features
• SharePort™ Mobile app for iOS
• Quick Router Setup app for iOS
• VPN pass through
• Guest Zone Support
• UPnP™ Support
• Web File Access Support
• Wi-Fi WMM Quality of Service
Advanced Firewall Features
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI)
• MAC Address Filtering
• DMZ Support
Device Management
• Web UI
Diagnostic LEDs
• Power/WPS
Operating Temperature
• 32 to 104 ˚F (0 to 40 ˚C)
Operating Humidity
• 0% to 90% non-condensing
Certifications
• CE
• Wi-Fi Certified
• FCC
• IC
Dimensions
• 2.68" x 1.65" x 2"
(68 x 42 x 51 mm )
Weight
• 0.23 lb (104.3 grams)
Warranty
• 1-Year Limited Warranty
4
