Package Contents
• All-in-one Mobile Companion
• Ethernet Cable
• Quick Install Guide
Minimum System Requirements
Computer with:
• Window 7®
,Windows Vista®
Windows® XP SP2
5
5
or Mac OS X (v10.7)
• Internet Explorer® v9 or Mozilla® Firefox® v9.0
or Google Chrome (16.0.912.75) or Safari 5
• 20MB Hard Disk Space
• Network Interface Card
Power Input:
• 100-240VAC, 50/60Hz
For Internet Access:
• Cable or DSL Modem for High Speed Internet
Connection
• Subscription to an Internet Service Provider (ISP)
• For Wireless N Performance, an 802.11n adapter
is required
Features
• Multiple Operation Modes, Router/Access Point,
Repeater and Wi-Fi HotSpot Modes to Create
Different Usages
• IEEE 802.11n and 802.11g Compliant
• Mode Selector Switch
• One 10/100 LAN/WAN Port
2
• MAC Support
• Supports Power over USB for Added Convenience
• Supports Secure Wireless Encryption Using WPA
or WPA2
• Wi-Fi Protected Setup (WPS) Push Button
• Dual Active Firewalls - SPI and NAT
(Router Mode only)
• SharePort® Web File Access Support
(Router and Wi-Fi Hotspot Mode Only)
• SharePort® Mobile App for iPhone® and iPad®
(Router and Wi-Fi Hotspot Mode Only)
• QRS Mobile App for iPhone® and iPad®
(Router Mode Only)
• Wall-plug Design for More Convenient Use
• Elegant Design and Compact Size -
Does Not Block Other Outlets
• D-Link One-Touch AP Configuration
• Guest Zone Support
• 24/7 Basic Installation Support
3
• 1-Year Limited Warranty
4
Create a Wi-Fi hotspot for all
Watch videos from a USB drive
5
Wi-Fi Hotspot Mode
Wi-Fi-as-WAN: Create a Wi-Fi Hotspot from a wireless
Internet connection and with NAT for its own network
Internet
Router Mode
1
Internet
Repeater Mode
Internet
DIR-505
All-in-one Mobile Companion
With this product
What you needed before
Travel router
your mobile devices
High-end router with
USB sharing capability
Share your videos and
Online sharing site or DropBox subscription
pictures with friends
(if over 2GB)
Charge your iPhone®
Phone charger
Router / Access Point
Modem
Router / Access Point
iPhone
DIR-505
®
Mobile Companion
iPad
®
USB Drive
(for file sharing)
Laptop
iPhone
DIR-505
®
Mobile Companion
iPad
®
USB Drive
(for file sharing)
Laptop
DIR-505
Mobile Companion
iPhone
®
iPad
®
Laptop
