Enter the IP address, netmask, default router IP address, and optional VLAN identifier (a valid
Step 5
VLAN identifier or 0 for an untagged VLAN) for the management interface.
The VLAN identifier should be set to match the switch interface configuration.
Note
Enter the IP address of the default DHCP server that will supply IP addresses to clients, the
Step 6
controller's management interface, and optionally the service-port interface.
The management interface is the default interface for in-band management of the
Note
controller and connectivity to enterprise services such as AAA servers.
Enter the IP address of the controller's AP-manager interface.
Step 7
Note The AP-manager interface is used for Layer 3 communications between the controller
and lightweight access points. It must have a unique IP address and is usually
configured on the same VLAN or IP subnet as the management interface, but this is
not a requirement.
If the AP-manager interface is on the same subnet as the management interface, the
Note
AP-manager interface uses the same DHCP server IP address as the management
interface.
Step 8 Enter the IP address of the controller's virtual interface, which will be used by all controller
Layer 3 security and mobility managers. You should enter a fictitious, unassigned IP address,
such as 1.1.1.1.
The virtual interface is used to support mobility management, DHCP relay, and
Note
embedded Layer 3 security such as guest web authentication and VPN termination.
All controllers within a mobility group must be configured with the same virtual
interface IP address.
If desired, enter the name of the mobility group/RF group to which you want the controller
Step 9
to belong.
