Wire colours and connection points for connection cables
1 Antenna power supply (Blue)
Connect to the automatic-antenna control terminal of the vehicle.
2 Control power supply (Blue/White)
Connect the control terminal for the external amplifier, etc.
Cellular phone mute Wire (Pink)
3
Connect to the earth output terminal on a mobile phone.
Earth (Black)
4
Connect where good body earthing is available.

Main unit connections

E-LAN terminal (13P)
A
Connect to the E-LAN terminal of the CD changer, etc.
Front line-out terminal
B
Connect to the RCA connector of an external amplifier.
Rear line-out terminal
C
Connect to the RCA connector of an external amplifier.
D
Line-out terminal (Non fader)
This is used for non fader output. It can be used as a sub-woofer terminal if a separate amplifier with
a low bass filter is connected.
E
AUX in terminals (CD8445E only)
Connect if using together with portable audio equipment that is sold separately.
* If the output from the connected equipment is via a mini plug, it will need to be converted to RCA.
- If installing to a vehicle with no ACC position -
Tip
• If installing to a vehicle with no ACC position, be sure to explain the following to the customer when
handing back the vehicle.
"When getting out of the vehicle, be sure to press the [PWR] button on the main unit for 2
seconds or more while the power is still on, and then turn off the power." If they forget to turn off
the power, the battery will be drained.

- Vehicle connections -

Tip
• You will need to purchase the necessary component adapter cable for the vehicle so that the power
supplies can be utilised. (Contact the dealer for further details.)
