T ools used
T ools used
Used for TD510
• • Phillips screwdriver (Plus tip)
• • Allen key
(Supplied with speaker, used
for speaker angle adjustment)
• • Scissors • • Tape
(Paper tape or similar)
Accessor ies
Accessor ies
CB1 components
1 Spacer
X1
4 Screw(binding M5 x 8)
Have the following tools ready before commencing installation work.
Have the following tools ready before commencing installation work.
150 mm or more
• • Allen key • • Allen key
(Nominal size 3 mm) (Nominal size 1.5 mm)
(For neck holding bolt) (For cover wire)
• • Screw
(For installing bracket to
ceiling)
Check that all of the following accessories are present before installation.
Check that all of the following accessories are present before installation.
Ceiling installation screws are not included.
Ceiling installation screws are not included.
2 Bracket
5 Screw (TD510 for wires)
X4 (binding M4 x 8)
– 2 –
Used for TD508 II
• • Phillips screwdriver (Plus tip)
• • Awl
(or drill)
• • Screw
(For securing drop-prevention
X3 or more wire to ceiling)
3 Wire
X1
6 Screw (TD508 II for wires)
X1 (binding M5 x 8)
90 mm or more
• • Stubby screwdriver
(Plus tip)
X1
X1
X1
