INSTALLATION MANUAL
• • Be sure to read this installation manual thoroughly prior to installation.
• • If installation methods or non-standard parts not specified in this installation manual are used, accidents or injury
may result.
• • Specialized techniques and expertise are required in order to install the speaker that this product is installed to.
Be sure to ask a qualified technician to carry out installation work.
• • Installation of the speaker should always be carried out by two or more people.
Be sure to keep this manual after the installation for later reference.
To the installing technician:
After all installation and connection work has been completed, please give this installation manual to the customer.
The installation screws used for installing the bracket and wires to the ceiling are not provided as accessories with
this product. (Bracket installation hole diameter: 7 mm)
Contents
Contents
CEILING BRACKET
INSTALLATION MANUAL: 090003-2883B700
2
2
3
3
4
4
Advertisement
Related Manuals for Eclipse CB1
Summary of Contents for Eclipse CB1
-
Page 1: Table Of Contents
CEILING BRACKET INSTALLATION MANUAL: 090003-2883B700 INSTALLATION MANUAL • • Be sure to read this installation manual thoroughly prior to installation. • • If installation methods or non-standard parts not specified in this installation manual are used, accidents or injury may result. •... -
Page 2: Tools Used
Check that all of the following accessories are present before installation. Accessor Check that all of the following accessories are present before installation. Accessor Ceiling installation screws are not included. Ceiling installation screws are not included. CB1 components Spacer Bracket Wire Screw(binding M5 x 8) 5 Screw (TD510 for wires) -
Page 3: For Your Safety In Using This Product
or y our saf ety in using this product or y our saf ety in using this product The following WARNING and CAUTION signs are used throughout this manual as well as on the product. These signs alert the installer and users of important safety information to avoid risk of injury and damages to the product. Please become familiar with these symbols and their associated information before proceeding to the assembly instructions of this manual. -
Page 4: When Performing The Installation
When perf ming the installation When perf ming the installation Leave enough 5 3/4 in. (134 mm) (TD508 II ) space. 8 in. (202 mm) (TD510) Speaker wire (for diameter of 7 mm or more) Speaker wire (for diameter of less than 7 mm) Spacer Ceiling Bracket... - Page 5 – Installation – Remove the screws from the bottom of the speaker base. Screw X4 Speaker base The screws which are removed will not be used. Give them to the customer to keep safely. Speaker Remove the base cover. Speaker Remove the hexagon head screw which is used for securing the base cover drop-prevention wire from the Base cover...
-
Page 6: Adjusting The Angle
For the TD508 II Screwdriver Install the wire to the speaker. Screw Install the speaker to the speaker base. (For TD508 II only) Wire Caution • • TD508 II speakers only: Use the screw (binding M5 x 8) that is included with the bracket as the screw marked For the TD510 •... - Page 7 Set the speaker to the desired angle. Joint • • When adjusting the angle of the speaker, align the mark at the base of the speaker with the index Align with the marks on the speaker. If the mark is not aligned with index marks the index marks when adjusting the angle of the Speaker base...
- Page 8 Peel off the backing paper from the double-sided tape on the spacer, and attach the spacer to the bracket. Speaker installation position Install the bracket at the speaker installation position using the screws (sold separately). Bracket Caution Spacer Spacer Bracket •...
- Page 9 Connect the speaker wires to the speaker. Speaker wire (for diameter of 7 mm or more) Speaker wire • • If the speaker wires are routed through the bracket and speaker neck, they will not easily visible from outside which will improve the outer appearance of the speaker.
- Page 10 Securely install the speaker to the bracket by using the Bracket stubby screwdriver to tighten the screws. Caution • • The speaker can be adjusted to within 10° on each side by loosening the screws. • • When adjusting the direction of the speaker, only loosen the screws.
- Page 11 Install the base cover drop-prevention wire to the speaker base by carrying out step in reverse. Drop-prevention wire Hexagon head screw Drop-prevention wire Base cover Speaker Install the base cover to the speaker base. Speaker base Base cover Speaker – 11 –...
- Page 12 – Template for determining bracket installation position – Front of speaker (standard position) Route the speaker wires before installing the spacer and the bracket to the ceiling. Front of speaker (standard position) Use an awl or similar tool to mark the positions of the bracket installation screws on the ceiling.
