Eclipse AVN8826 Installation Manual page 5

Wire colours and connection points for connection cables
Antenna power supply (Blue)
1
Connect to the automatic-antenna control terminal of the vehicle.
Control power supply (Blue/White)
2
Connect the control terminal for the external amplifier, etc.
Vehicle speed pulse signal wire (Purple/White)
3
Connect to the vehicle speed pulse signal terminal.
Parking brake signal wire (Red/White)
4
Connect to the parking brake signal terminal.
5 Reverse signal Wire (Green)
Connect the reverse signal output of the vehicle to this terminal.
6 Navi mute Wire (Brown)
Connect to the NAVI-MUTE terminal of a DCU105 or similar device (sold separately).
Cellular phone mute Wire (Pink)
7
Connect to the earth output terminal on a mobile phone.
H/A mute Wire (Light Green)
8
Connect to the DVD-MUTE terminal of a DCU105 or similar device (sold separately).
Earth (Black)
9
Connect where good body earthing is available.
A NAVI-VOICE output terminal
Connect to the NAVI-VOICE input terminal of an external device such as a DCU105 (sold
separately).
B Digital output terminal
Connect to the DIGITAL input terminal of an external device such as a DCU105 (sold separately).
C VTR input terminals
Connect the output cable of external video equipment such as a VTR.
Yellow : Video signal
D VTR output terminals
Connect to the monitor with video input.
Yellow : Video signal
Back-eye camera external input terminal (4P)
E
Used with the Eclipse back-eye camera (sold separately).
F
E-LAN terminal (13P)
Connect to the E-LAN terminal of the CD changer, etc.
- Vehicle connections -
Tip
• • You will need to purchase the necessary component adapter cable for the vehicle so that the power supplies can
be utilised. (Contact the dealer for further details.)
• • Be sure to wrap the connection cables with plastic tape to insulate them.
White : Audio (left) signal
White : Audio (left) signal
- 5 -
and and
2 3
Red : Audio (right) signal
Red : Audio (right) signal
4
