- Page 1 DIAMOND OW / IW series DIAMOND OW-2 DIAMOND IW-2 DIAMOND OW-1 DIAMOND IW-1 User Manual BRITAIN'S MOST FAMOUS LOUDSPEAKERS...
- Page 2 Important Safety Information Before installing this product read all these instructions! This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Before making any connections, switch all the units in your system off...
- Page 3 Welcome to Wharfedale ! Destined to become the reference home entertainment speaker system, the OW/IW series offers transparency and neutrality that surpasses far larger, more costly systems. More compact than any speaker capable of rendering such clarity and pinpoint detail, the ultra-smooth OW series ensure unsurpassed, effortless realism even in very large rooms.
- Page 4 The hanging method DIAMOND OW-1 Installation: Fit the rubber feet supplied to cushion the speaker against the wall. Mark the positions for the mounting screws using the template provided. It is recommended to use 100mm 3.9’’ a spirit level to align the screws correctly. Note: After fitting screws to the wall, position the speaker carefully so the screws line up with the keyhole slots in the brackets.
- Page 5 Setting Up a Home Theatre System Placement Front and Effects Channels: The front loudspeakers are placed on either side of the television screen, 2 to 3 metres apart. We recommend placing the rear effects speakers in a high position, behind the listener's head. The front faces of the centre and surround loudspeakers should also be in line as far as possible.
- Page 6 Troubleshooting Before investigating a problem, always switch off the system at mains. If your system is not working properly please work through this checklist before returning the unit to your dealer. Symptom Possible Cause No Sound System not switched on; Speaker cables shorting terminals out; Wrong source selected Sound lacks bass content Subwoofer not switched on Lack of bass reproduction...
- Page 7 Warranty Coverage Your loudspeakers have been constructed to the highest standards. From top grade furniture construction and finish to carefully designed and selected acoustic components, Wharfedale speakers are built to provide a lifetime of sonic pleasure. We hope you will derive many years of good service from our products.
- Page 8 Exclusions The following items are excluded from the Wharfedale warranty: - Normal wear and tear and cosmetic damage (including but not limited to any wear from reasonable use, environmental deterioration or neglect) - Products on which the serial number has been removed, altered or otherwise made illegible. - Products not purchased from an authorised Wharfedale dealer.
- Page 9 Repairs All repairs will be carried out by the appointed distributor (or locally appointed service centre). Repairs handled or processed without authorisation or approval of the appointed representative will be excluded from this limited warranty. Please note, Wharfedale is not able to supply parts or replacement items to any other entity than the official distributor or authorised service centre.
- Page 10 Specifications Model DIAMOND OW-1 DIAMOND OW-2 General description 2-way ‘on wall’ loudspeaker 2-way ‘on wall’ loudspeaker Enclosure type closed-box closed-box Transducer complement 2-way 2-way Bass driver 6.5" ( 150mm) advanced PP Cone x2 6.5" (150mm) advanced PP Cone Midrange driver Treble driver 1"...
