INSTRUCTION MANUAL

E L E C T R I C A C T U A T O R S F O R I N D U S T R I A L P R O C E S S C O N T R O L

MODELS

For actuators manufactured

after 2/24/25.

14-10_

Need help?

Do you have a question about the 14-10 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Beck 14-10 Series

Page 1 MODELS 14-10_ 80-1400-02 Rev. 9.9 INSTRUCTION MANUAL For actuators manufactured after 2/24/25. E L E C T R I C A C T U A T O R S F O R I N D U S T R I A L P R O C E S S C O N T R O L...
Page 2 Beck control of globe valves and other devices 14-100 linear electric actuator manufactured by Harold Beck & Sons, Inc. of Newtown, requiring up to 1,800 lbs (8 010 N) of thrust. Pennsylvania. NOTICE: This manual includes information that will make installation simple, efficient, and trouble-free.
Page 3 80-1400-02, Rev. 9.9 PRODUCT DESCRIPTION Beck Group 14 linear actuators are engineered Valves may also be operated at their individual for precise, reliable operation of globe valves locations with a built-in electric Handswitch. requiring up to 1,800 lbs (8 010 N) of thrust. The B e c k ’...
Page 4 The new stroke displacement is produced by the full demand signal. Standards* CSA Labeled (US & Canada); CE Compliant; UKCA Compliant *NOTE: May not be available with all options and models. For more information, please call Beck at 215-968-4600.
Page 5 80-1400-02, Rev. 9.9 PRODUCT DESCRIPTION Outline Dimensions NOTE: Actuators may be mounted in any orientation. Dimensions in inches & [mm]. "A" "B" "C" Max. Valve Stem Drive Shaft Valve Boss Yoke Nominal Drive Extension (Valve Approx. Travel Range Dia. Range Height Shaft Extension Stem Retracted...
Page 6 80-1400-02, Rev. 9.9 PRODUCT DESCRIPTION Control Options TABLE 2: SUMMARY OF GROUP 14 CONTROL OPTIONS EXTERNAL AUXILIARY MODEL CONTROL INPUT FEEDBACK ESR-5 PART NO.* OUTPUT CPS-5 PART NO.* SWITCH TYPE SIGNAL DEVICE SIGNAL OPTIONS 120 V ac None CPS-5 Direct None Contactless Low Power...
Page 7 After unpacking, the wooden platform may be used to transport the actuator to the installation site. INSTALLATION—MECHANICAL Beck actuators can be furnished with valves mounted as unitized assemblies ready for pipeline installation. CAUTION Working with valves installed in a pipeline can be dangerous.
Page 8 If there is no wiring diagram available, you may obtain a copy from Beck by Valve Installation providing the serial number of your drive. For maximum safety, the Beck actuator body The Beck actuator can be mounted in any should be grounded.
Page 9 80-1400-02, Rev. 9.9 INSTALLATION Wiring The Group 14 actuator is available with four separate control configurations. Typical functional wiring connections for each control option are described in the following paragraphs and diagrams. The wiring diagram specific to each actuator is attached to the inside of the wiring terminal cover. Feedback connections for actuators incorpor ating the Contactless Position Sensor (CPS-5) for control option 6 are described on page10.
Page 10 80-1400-02, Rev. 9.9 INSTALLATION Wiring Option 6, Modulating Direct AC Control with Contactless Position Sensing Customer must supply three wires to directly control the actuator motor direction: One 120 V ac line for Retraction (terminal M), one 120 V ac line for Extension (terminal N), and one neutral (terminal B).
Page 11 V ac line is replaced with Line 1 of the 240 V ac. V ac operation. In all cases, the power neutral is CPS-5 SIGNAL CONNECTIONS Beck Group 14 actuators equipped with the Contactless Position Sensor (CPS-5) are shipped ready for installation. They are engineered to match the mA feedback range in your system.
Page 12 80-1400-02, Rev. 9.9 INSTALLATION Start-Up START-UP INSTRUCTIONS 5. Raise the actuator shaft using the Handswitch until the plug is clear of the seat and there is After the actuator is mounted and its wiring sufficient clearance to make the following connections are made, it is ready to be tested for adjustment.
Page 13 80-1400-02, Rev. 9.9 OPERATION HOUSING SELF-LOCKING MECHANISM (SLM) All models of the Beck Group 14 electric actuator have individual, cast aluminum An integral part of every Group 14 control compartments for the main components: The motor is the self-locking mechanism. This...
Page 14 (CPS-5) for feedback and position indication. HANDSWITCH A local electric Handswitch is provided on POSITION FEEDBACK: Beck actuators to permit operation at the valve, CONTACTLESS POSITION independent of the controller. As a safety SENSOR (CPS-5) feature, the Handswitch is designed so that the...
Page 15 80-1400-02, Rev. 9.9 CALIBRATION Switches SWITCH ADJUSTMENTS Handswitch, and then turn the Handwheel until the mechanical stop is reached. All Group 14 actuators are shipped with All switches are SPDT and are rated at 6 A, 120 end-of-travel limit switches and all auxiliary V ac.
Page 16 80-1400-02, Rev. 9.9 CALIBRATION Switches 13. Close the covers and tighten the terminal Setting travel limit switches, cont’d. cover bolt to 10 Ib-ft (14 N•m). Tighten the 2. Use the electric Handswitch to drive the top cover bolt just enough to compress the control shaft so that the EXT switch cam is O-ring seal.
Page 17 Adjustment of the total actuator stroke within the factory-set travel range is easily The Calibar adjustment is designed to allow accomplished by the use of the Beck Calibar, field changes of the total actuator stroke with the Figure 7. The switches and feedback device are same maximum demand signal applied (e.g., a...
Page 18 80-1400-02, Rev. 9.9 CALIBRATION Changing Direction of Travel CHANGING DIRECTION OF Models 14-106 TRAVEL 1. Open the terminal compartment (1/2" bolt heads) and remove the top cover (15/16" bolt Direction of travel is defined as the direction head). The O-ring seal will remain in the rim of output shaft motion produced by an increasing of the top cover when removed.
Page 19 80-1400-02, Rev. 9.9 CALIBRATION Feedback Signal FEEDBACK SIGNAL 5. Tighten the clamping screw to 5 Ib-in (0.56 N•m) torque. CALIBRATION 6. Operate the actuator between the electrical Feedback signal calibration is necessary limits. Verify the feedback signal is properly to en sure that signal current corresponds to adjusted.
Page 20 80-1400-02, Rev. 9.9 CALIBRATION Feedback Signal CPS-5 Calibration Tools required for calibration: Model 14-106 mA / V dc Multimeter 3/32” Screwdriver These models are equipped with a Contactless 7/64” Hex Wrench Position Sensor (CPS-5) for position sensing and 5/16” Open End Wrench feedback.
Page 21 80-1400-02, Rev. 9.9 Figure 8 TERMINAL BLOCK ZERO POTENTIOMETER (FACTORY SEALED) FERRITE SENSOR (STATOR) SPAN POTENTIOMETER FERRITE ROTOR CLAMP FERRITE SENSOR (ROTOR) Figure 8: CPS-5 Position Sensor CPS MODEL NUMBER CPS - 5 20 - 4400 - 02 TRANSFORMER TERMINALS Figure 9: CPS-5 Tranformer Side...
Page 22 If vibration is present, check the electrical terminal connections and other hardware for tightness. LUBRICATION Periodic lubrication is not required on Beck actuators. However, during major maintenance outages, it is recommended that older actuators should be inspected to ensure that the gearing is not worn or damaged.
Page 23 80-1400-02, Rev. 9.9 MAINTENANCE Component Replacement MOTOR This section covers replacement of many components of the Group 14 drive. Note that The control motor is not field-repairable. some components are not field repairable. Dis assembly of the motor will result in a loss of If it should ever be necessary to replace torque that can only be restored by returning the the output gear, shaft, or output shaft bearings,...
Page 24 80-1400-02, Rev. 9.9 MAINTENANCE Component Replacement LIMIT AND AUXILIARY SELF-LOCKING MECHANISM SWITCHES (SLM) Complete switch assemblies may be replaced. In normal service, the SLM friction surface It is not possible to replace individual switches. To should not require replacement; however, a replace switch assemblies, remove the top cover combination of excessive modulation and load (15/16”...
Page 25 80-1400-02, Rev. 9.9 To install the CPS-5, slide the rotor onto O-RING the control shaft (clamp end toward the limit SHAFT switches). Leave the clamp loose. Assemble FIBER WASHER CPS-5 over the rotor and mounting studs, THREADED BUSHING transformer out and at approximately 4 o’clock. SEAL Secure assembly with three hex nuts.
Page 26 80-1400-02, Rev. 9.9 TROUBLESHOOTING If your unit contains a Stall Protection Module (SPM) refer to publication 80-0017-03, “Troubleshooting”. CONDITIONS POSSIBLE CAUSES CORRECTIONS 1. Actuator runs in only one a. Handswitch failure. a. Check continuity from terminal N to V direction in AUTO and both and M to U with Handswitch in AUTO directions with Handswitch in position.
Page 27 80-1400-02, Rev. 9.9 CONDITIONS POSSIBLE CAUSES CORRECTIONS 9. Actuator travel very non-linear: a. e.g., 4–19 mA change on input a. Wiper and high end of feedback a. Check feedback potentiometer for causes actuator to drive from potentiometer reversed. proper connections. 0% to 30%;...
Page 28 80-1400-02, Rev. 9.9 NOTES...
Page 29 Select the needed spare part(s) from Table parts be stocked for quick availability in the event 4, below. Specify the actuator serial number that service of your Beck actuator is required. (example: 14-106-031891-01-02) provided on The types of parts are listed in Table 4, below.
Page 30 (sold only as complete assembly) Auxiliary terminal strip Top cover with gasket Transformer (w/ fuse, if 240V model) Top cover bolt Top bar Note: To ensure exact replacement parts, include all nameplate data of the Beck actuator with the order.
Page 31 80-1400-02, Rev. 9.9 CONTROL ASSEMBLY AND DRIVE TRAIN...
Page 32 4 to 20 mA 20-4400-02 Industry Std (ISA) 500Ω (Max.) TABLE 9: CPS-5 SIGNAL OUTPUT TERMINAL CONNECTIONS AND LOADING OUTPUT RANGING RESISTOR MAXIMUM RESISTOR SIGNAL RANGE TERMINALS BECK EXTERNAL CONNECTIONS VALUE (–) PART NO. LOAD Models 20-4400-02 4 to 20 mA EE—CC Open 800Ω...
Page 33 80-1400-02, Rev. 9.9 APPENDIX Schematics TYPICAL SCHEMATIC FOR CONTROL OPTION 6 TYPICAL SCHEMATIC FOR CONTROL OPTION 6 W/ STALL PROTECTION MODULE...
Page 34 80-1400-02, Rev. 9.9 INDEX Application reviews .......... 35 Product demonstrations ........35 Applications, typical ........... 3 SLM ..............24 Calibar adjustment ........... 17 Safety precautions ..........7 CPS-5 calibration ..........20 Seal replacement ..........23 CPS-5 functional block diagram ...... 32 Service, how to obtain ........
Page 35 Beck Sales your location. In order to arrange to see a Beck Engineers will work with you to make it easier for actuator in your plant or office, contact Beck’s you to obtain the proper equipment and give you Sales Department.
Page 36 ~ founded 1936 ~ HAROLD BECK & SONS, INC. Made in USA 11 TERRY DRIVE NEWTOWN, PENNSYLVANIA 18940 USA PHONE: 215-968-4600 FAX: 215-860-6383 E-MAIL: sales@haroldbeck.com www.haroldbeck.com 6/25...
