- Page 1 Air conditioner Installation manual AC***BNJPKG • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this Installation manual carefully and retain it for future reference.
- Page 2 Contents Safety Information Safety Information Installation Procedure Installation Procedure Step 1 Checking and preparing accessories Step 2 Choosing the installation location Step 3 Installing the indoor unit Step 4 Purging inert gas from the indoor unit Step 5 Connecting the assembly pipes to the refrigerant pipes Step 6 Cutting and flaring the pipes Step 7 Performing the gas leak test Step 8 Insulating the refrigerant pipes...
- Page 3 Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest version, visit www.samsung.com. Notices and notes To make you aware of safety messages and highlighted information, we use the following notices and notes throughout this...
- Page 4 • This manual explains how to install an indoor unit with equipped. a split system with two SAMSUNG units. The use of • Do not use means to accelerate the defrost operation or other types of units with different control systems may to clean, other than those recommended by Samsung.
- Page 5 • Do not install the product in a ship or a vehicle (such • Be sure not to perform power cable modification, as a campervan). Salt, vibration or other environmental extension wiring, and multiple wire connection. factor may cause the product malfunction, electric –...
- Page 6 Installation Procedure Step 1 Checking and preparing Step 2 Choosing the installation accessories location The following accessories are supplied with the indoor Installation location requirements unit. The type and quantity may differ, depending on the specifications. • There must be no obstacles near the air inlet and outlet.
- Page 7 Indoor unit installation requirement 11.2 12.3 • This unit has to be installed as floor type only. 13.4 • There must be no obstacles near the air inlet and outlet. 14.6 • Select a convenient location that permits the air to 15.8 reach every corner of the area to be cooled.
- Page 8 Installation Procedure Indoor unit dimensions AC026BNJPKG,AC035BNJPKG (Unit: mm) Name Description Liquid pipe connection Ø6.35 (1/4") Gas pipe connection Ø9.52 (3/8") Drainpipe connection ID : Ø12 ; OD : Ø18 Power supply connection 0.75~1.5mm², 3wires • Length of pipes and difference in height: see the outdoor unit installation manual •...
- Page 9 Step 3 Installing the unit 4 The body front should be opened to connect pipes. Remove the 4 screws on the front of the unit and then pull 1 When you install the indoor with side-pipe connection, the lower section of the unit out as shown below. please make space more than 300mm from the wall.
- Page 10 Installation Procedure Step 5 Connecting the assembly pipes 7 Hanging the indoor unit on the Bracket Hanger, then fix the Indoor Unit by using 4 Screws. to the refrigerant pipes • Case 1. Installing on the floor: You must secure the unit There are two refrigerant pipes of different diameters : to the wall using 4 screws to ensure that the unit does not fall.
- Page 11 Step 6 Cutting and flaring the pipes 2 Use insulation that is thick enough to cover the refrigerant pipe to prevent condensate water on the outside of pipe and 1 Make sure that you have the required tools available. (pipe to ensure system efficiency.
- Page 12 Installation Procedure Step 8 Insulating the refrigerant pipes 5 Check that the flaring is correct, referring to the illustrations below for examples of incorrect flaring. Once you have checked that there are no leaks in the system, you can insulate the piping and hose. 1 To avoid condensation problems, place Acrylonitrile Butadien Rubber separately around each refrigerant pipe.
- Page 13 Step 9 Installing the drain hose and Select the insulation of the refrigerant pipe. • Insulate the gas side and liquid side pipe, noting the drain pipe insulation thickness that must differ according to the When installing the drain hose for the indoor unit, check if pipe size.
- Page 14 Installation Procedure Step 11 Connecting the power and 6-ways for drain hose and drain pipe connection communication cables CAUTION • Always remember to connect the refrigerant pipes before performing the electric connections. When disconnecting the system, always disconnect the electric cables before disconnecting the refrigerant pipes.
- Page 15 Step 12 Optional: Extending the power Indoor power supply cable Max/ Power supply Indoor power cable Min(V) Prepare the following tools. Tools Spec Shape ±10% 220 to 240V, 50 Hz 0.75 mm²↑, 3 wires Crimping pliers MH-14 Communication cable 0.75 mm²↑, 2 wires Connection sleeve 20xØ6.5 (mm)
- Page 16 Installation Procedure 3 Insert both sides of core wire of the power cable into the CAUTION connection sleeve. • Make sure that the connection parts are not exposed to • Method 1: Push the core wire into the sleeve from both outside.
- Page 17 Step 13 Optional : Setting the Emergency Temperature Output (ETO) function Emergency Temperature Output (ETO) function (for the multi system, this function is not supported.) CAUTION • In order to deploy the ETO function, the MIM-B14, an external contact interface module, must be installed in each indoor unit.
- Page 18 Installation Procedure [Sub] [Main] ETO operation specifications 1 Main indoor unit – Based on the external contact control settings, the main indoor unit decides whether to generate output when an error (indoor unit stop) occurs. – Based on the ETO settings, the main indoor unit decides whether to generate output according to the temperature and time conditions.
- Page 19 3. Set SEG8 for the Install option (02 mode) to '8'. (Refer to "step15. Setting the indoor unit addresses and the installation options ") NOTE • The External Floating switch is not sold separately by Samsung. • External Control (MIM-B14) and External Floating switch cannot be connected simultaneously. Only either of them can be connected at a time.
- Page 20 Installation Procedure Step 15 Setting the indoor unit addresses and the installation options • Set the indoor unit address and installation option with a wireless remote controller. Options and address can also be modified using wired controllers or service software. You cannot set both the indoor unit addresses and the 2 Set the option values.
- Page 21 Take the steps presented in the following table: Option setting Status 1 Setting SEG2, SEG3 option Press Low Fan button to enter SEG2 value. Press High Fan button to enter SEG3 value. Each time you press the button, will be selected in rotation. SEG2 SEG3 2 Setting Cool mode...
- Page 22 Installation Procedure Option setting Status 10 Setting Auto mode Press Mode button to be changed to Auto mode in the OFF status. 11 Setting SEG14, SEG15 option Press Low Fan button to enter SEG14 value. Press High Fan button to enter SEG15 value. Each time you press the button, will be selected in rotation.
- Page 23 Check whether the option values that you have set are correct by pressing the button repeatedly. [SEG2, SEG3] [SEG4, SEG5] [SEG6, SEG8] [SEG9, SEG10] [SEG11, SEG12] [SEG14, SEG15] [SEG16, SEG17] [SEG18, SEG20] [SEG21, SEG22] [SEG23, SEG24] 4 Save the option values into the indoor unit: Press the button with the direction of remote control for set.
- Page 24 Installation Procedure Setting the indoor unit addresses Option No. for an indoor unit address: 0AXXXX-1XXXXX-2XXXXX-3XXXXX Before installing an indoor unit, be sure to set an address for the indoor unit by taking the following steps: 1 Make sure that the power is supplied to the indoor unit. If the indoor unit is not plugged in, it must include a power supply. 2 Set an address for each indoor unit using the remote control, according to your air conditioning system plan, by referring to the following table and by following the steps in Common steps for setting the addresses and options on page 20.
- Page 25 Example) If you want to set as "MAIN: 3, CHANNEL: 1, RMC: B", SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 assign option codes except SEG 1, 7 which are page options. Setting the installation options in a batch Installation option No.
- Page 26 Installation Procedure Option SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 Function Page Use of drain pump Indication Details Indication Details Reserved Reserved Reserved Reserved Indication Disuse and details Use external drain pump Option SEG13 SEG14 SEG15 SEG16 SEG17 SEG18 Setting the output of Maximum filter usage Function Page...
- Page 27 Changing the addresses and options individually Example) If you want to set as "MAIN : 3, CHANNEL : 1, RMC : B", Option SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 The tens’ digit of an The unit digit of an The option mode Explanation PAGE MODE...
- Page 28 Troubleshooting Troubleshooting • If an error occurs during the operation, one or more LED flickers and the operation is stopped except the LED. • If you re-operate the air conditioner, it operates normally at first, then detect an error again. LED Display Abnormal condition Error code...
- Page 29 English...
