SINGLE
Technical
Data Book
SINGLE PAC for Europe
(R410A, 50/60Hz, HP)
Model : AC***BNPDKH/EU (Indoor Unit)
AC***BXPD*H/EU (Outdoor Unit)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC BNPDKH/EU Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung AC BNPDKH/EU Series

Summary of Contents for Samsung AC BNPDKH/EU Series

  • Page 1 SINGLE Technical Data Book SINGLE PAC for Europe (R410A, 50/60Hz, HP) Model : AC***BNPDKH/EU (Indoor Unit) AC***BXPD*H/EU (Outdoor Unit)
  • Page 2 History Version Modification Date Remark Ver.1.0 Release Single PAC TDB for Europe 22. 06 03...
  • Page 3 Nomenclature Model Name Buyer (5) Product Notation (1) Classification (6) Fearure (2) Capacity Deluxe x 1/10 kW (3 digits) (3) Version (7) Rating Voltage 2022 1Ф, 220V, 60Hz 3Ф, 380V, 60Hz 1Ф, 220~240V, 50/60Hz 3Ф, 380~415V, 50/60Hz (8) Mode (4) Product Type Cooling Only Indoor Unit Outdoor Unit...

  • Page 4: Features And Benefits

    Features & Benefits Long Distance Air Flow Full HD Filter (MAX60%) The full high density filter collects up to 60% of dust. As a result of the horizontal and vertical flaps that move independently of one another, a greater diversity of air- Auto shutter flow is available depending upon your needs: direct air flow in one direction, long-range cooling, broad left-right...

  • Page 5: Table Of Contents

    Contents 1. Line up 2. Specification 3. Summary Table 4. Capacity Table 5. Dimensional Drawing 6. Center of Gravity 7. Electrical Wiring Diagram 8. Sound Data 9. Temperature and air flow distribution 10. Operation Range 11. Piping Diagram 12. Capacity Correction 13.

  • Page 6: Line Up

    1. Line up Indoor unit Model Type 10.0kW 14.0kW Indoor Outdoor Unit Model Type 10.0kW 14.0kW 1Phase 3Phase...

  • Page 7: Specification

    2. Specification IndoorUnit AC100BNPDKH/EU AC140BNPDKH/EU Model Name OutdoorUnit AC100BXPDKH/EU AC140BXPDNH/EU Mode Heat Pump Heat Pump 2.60/10.00/12.30 4.50/13.40/16.70 Cooling (Min/Std/Max) Btu/h 8,900/34,100/42,000 15,300/45,700/57,000 Performance Capacity 2.80/11.20/14.00 3.90/15.50/20.00 Heating (Min/Std/Max) Btu/h 9,500/38,200/47,800 13,300/52,800/68,200 Cooling 0.62/3.50/5.40 0.93/4.32/6.00 (Min/Std/Max) Power Input Heating 0.54/3.39/4.50 0.70/4.50/6.60 (Min/Std/Max) Cooling 3.2/15.3/23.2...
  • Page 8 2. Specification IndoorUnit AC100BNPDKH/EU AC140BNPDKH/EU Model Name OutdoorUnit AC100BXPDKH/EU AC140BXPDNH/EU Power Supply Ø, #, V, Hz 1,2,220-240,50/60 3,4,380-415,50/60 Type F&T F&T Heat Material Exchanger Tube Fin Treatment Green Hydrophile Green Hydrophile Model Name UG8T300FUBJU UG5TK1450FJX Type Twin BLDC Rotary Twin BLDC Rotary Compressor Output 2.82...

  • Page 9: Summary Table

    3. Summary Table Performance characteristics Capacity Airflow Sound Pressure Sound Power Model Code Weight Cooling Heating Speed (CMM) Level(dBA) Level(dBA) (kg) (kW) Max. 12.30 14.00 High 29.0 AC100BNPDKH/EU 43.0 Std. 10.00 11.20 25.0 Min. 2.60 2.80 23.0 Max. 16.70 20.00 35.0 High AC140BNPDKH/EU...

  • Page 10: Capacity Table

    4. Capacity Table AC100BNPDKH/EU + AC100BXPDKH/EU Cooling TC : TotalCapacity,SHC : SensibleHeat Capacity,PI : PowerInput IndoorTemperature(℃, DB/ WB) 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Outdoor Temp.
  • Page 11 4. Capacity Table AC140BNPDKH/EU + AC140BXPDNH/EU Cooling TC : TotalCapacity,SHC : SensibleHeat Capacity,PI : PowerInput IndoorTemperature(℃,DB/ WB) 20 / 14 22 / 16 25 / 18 27 / 19 28 / 20 30 / 22 32 / 24 Outdoor Temp. (℃, DB) 13.09 9.95 3.09 13.78 10.26 3.15 14.36 10.57 3.21 14.80 10.90 3.28 15.10 10.79 3.31 15.85 10.68 3.35 16.64 10.47 3.41 12.71 9.67 3.19 13.38 9.97 3.26 13.94 10.28 3.32 14.37 10.59 3.39 14.66 10.49 3.42 15.39 10.38 3.46 16.16 10.18 3.53...

  • Page 12: Dimensional Drawing

    5. Dimensional Drawing Indoor unit AC100BNPDKH/EU, AC140BNPDKH/EU Unit: mm[inches] Description Name AC100BNPDKH/EU AC140BNPDKH/EU Liquid pipe connection 9.52 (3/8") 9.52 (3/8") Gas pipe connection 15.88 (5/8") 15.88 (5/8") Drain pipe connection Power supply & Communication wiring conduit...
  • Page 13 5. Dimensional Drawing Outdoor unit AC100BXPDKH/EU Unit: mm[inches] Name Description Liquid pipe connection Ø9.52 (3/8) Gas pipe connection Ø15.88 (5/8) Piping intake knockout hole Front / Side / Rear / Bottom Power wiring conduit Front / Side / Rear / Ø34 (1-3/8) Communication wiring conduit Front / Side / Rear / Ø22 (7/8) Drain hole...
  • Page 14 5. Dimensional Drawing Outdoor unit AC140BXPDNH/EU Unit: mm[inches] Name Description Liquid pipe connection Ø9.52 (3/8) Gas pipe connection Ø15.88 (5/8) Piping intake knockout hole Front / Side / Rear / Bottom Power wiring conduit Front / Side / Rear / Ø34 (1-3/8) Communication wiring conduit Front / Side / Rear / Ø22 (7/8) Drain hole...

  • Page 15: Center Of Gravity

    6. Center of Gravity Indoor unit AC100BNPDKH/EU, AC140BNPDKH/EU Unit: mm[inches] [24-1/8] [15-11/16] 306.5 [7-13/16] [12-1/16]...
  • Page 16 6. Center of Gravity Outdoor unit AC100BXPDKH/EU Unit: mm[inches] AC140BXPDNH/EU Unit: mm[inches]...

  • Page 17: Electrical Wiring Diagram

    7. Electrical Wiring Diagram Indoor unit AC100BNPDKH/EU, AC140BNPDKH/EU Print circuit board(MAIN) U/D STEP MOTOR Up/Down Louver stepping motor ASSY PCB MAIN ASSY PCB POWER Print circuit board(POWER) L/R SETP MOTOR Left/Rigth Louver stepping motor ASSY PCB DISPLAY Print circuit board(DISPLAY) M-BLDC BLDC Motor ROOM(10K)
  • Page 18 7. Electrical Wiring Diagram Outdoor unit AC100BXPDKH/EU MAIN PCB Printed circuit board(MAIN) Electronics Expansion Valve DIS-TH(200K) Thermistor DISCHARGE INVERTER PCB Printed circuit board(INVERTER) M-BLDC BLDC Motor OUT-TH(10K) Thermistor AMBIENT Printed circuit board(EMI) OLT-TH(200K) Thermistor OLP COND-TH(10K) Thermistor CONDENSOR NOTE • This wiring diagram applies only to the outdoor Unit. •...
  • Page 19 7. Electrical Wiring Diagram Outdoor unit AC140BXPDNH/EU MAIN PCB Printed circuit board(MAIN) Electronics Expansion Valve DIS-TH(200K) Thermistor DISCHARGE INVERTER PCB Printed circuit board(INVERTER) M-BLDC BLDC Motor OUT-TH(10K) Thermistor AMBIENT Printed circuit board(EMI) OLT-TH(200K) Thermistor OLP COND-TH(10K) Thermistor CONDENSOR NOTE • This wiring diagram applies only to the outdoor Unit. •...

  • Page 20: Sound Data

    8. Sound Data Indoor unit Sound Pressure level Unit: dB(A) Model High AC100BNPDKH/EU AC140BNPDKH/TK Microphone • NR Curve 1) AC100BNPDKH/EU 2) AC140BNPDKH/EU NR 70 NR 70 NR 65 NR 65 High High NR 60 NR 60 NR 55 NR 55 NR 50 NR 50 NR 45...
  • Page 21 8. Sound Data Outdoor unit Sound Pressure level Unit: dB(A) Model Cooling Heatng AC100BXPDKH/EU Microphone Microphone AC140BXPDNH/EU 1.5m 1.5m Front Front • NR Curve 1) AC100BXPDKH/EU 2) AC140BXPDNH/EU NR 70 NR 70 Cool Cool NR 65 NR 65 Heat Heat NR 60 NR 60 NR 55...

  • Page 22: Sound Power Level

    8. Sound Data Indoor unit Sound Power level NOTE Unit: dB(A) Model Power • Specifications may be subject to change without prior notice - Sound power level is an absolute value that a sound source AC100BNPDKH/EU generates. AC140BNPDKH/EU - dBA = A-weighted sound power level. - Reference power : 1pW.
  • Page 23 8. Sound Data Outdoor unit Sound Power level NOTE Unit: dB(A) Model Power • Specifications may be subject to change without prior notice - Sound power level is an absolute value that a sound source AC100BXPDKH/EU generates. AC140BXPDNH/EU - dBA = A-weighted sound power level. - Reference power : 1pW.

  • Page 24: Temperature And Airflow Distribution

    9. Temperature and airflow distribution AC100BNPDKH/EU (1) Cooling air velocity distribution (2) Cooling temperature distribution (3) Heating air velocity distribution (4) Heating temperature distribution...
  • Page 25 9. Temperature and airflow distribution AC140BNPDKH/EU (1) Cooling air velocity distribution (2) Cooling temperature distribution (3) Heating air velocity distribution (4) Heating temperature distribution...

  • Page 26: Operation Range

    10. Operation Range AC***BNPDKH/EU + AC***BXPD*H/EU Mode Indoor Temperature Outdoor Temperature Indoor humidity Cooling 18°C to 32°C -15℃ to 50℃ 80% or less Drying 18°C to 32°C -15℃ to 50℃ 80% or less Heating -20℃ to 24℃ 30°C or less...

  • Page 27: Piping Diagram

    11. Piping Diagram AC100BNPDKH/EU OUTDOOR UNIT INDOOR UNIT Thermistor- Heat Exchanger (T_II) Service Valve- Heat Exchanger - Pipe Indoor unit (SV_G) (HX_ID) Thermistor- Indoor Room (T_IR) Outdoor Fan Motor (OFM) Electronic Expansion Valve- Main Indoor Fan Motor (E_M) (IFM) Heat Exchanger - Service Thermistor- Thermistor-...
  • Page 28 11. Piping Diagram AC140BNPDNH/EU OUTDOOR UNIT INDOOR UNIT Thermistor- Heat Exchanger (T_II) Service Valve- Heat Exchanger - Gas Pipe Indoor unit (SV_G) (HX_ID) Thermistor- Indoor Room (T_IR) Outdoor Fan Motor1 (OFM1) Outdoor Fan Motor2 (OFM2) Electronic Expansion Valve- Main Indoor Fan Motor (E_M) (IFM) Heat Exchanger -...

  • Page 29: Capacity Correction

    12. Capacity Correction AC100BNPDKH/EU + AC100BXPDKH/EU Cooling Pipe Length (m) 0.92 0.90 0.88 0.87 0.85 0.93 0.92 0.90 0.88 0.87 0.85 0.95 0.93 0.92 0.90 0.88 0.87 0.85 0.97 0.95 0.93 0.92 0.90 0.88 0.87 0.85 0.98 0.97 0.95 0.93 0.92 0.90 0.88...
  • Page 30 12. Capacity Correction AC140BNPDKH/EU + AC140BXPDNH/EU Cooling Pipe Length (m) 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72 0.92 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72 0.94 0.92 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72 0.96 0.94 0.92 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72 0.98 0.96 0.94 0.92 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72 0.98 0.96 0.94 0.92 0.90 0.88 0.86 0.84 0.82 0.80 0.78 0.76 0.74 0.72...

  • Page 31: Installation

    13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Choosing the installation location Determine the installation location considering the following conditions and obtain the user approval. Indoor unit • Install the unit where the pipes and cables can be easily connected to the outdoor unit. •...
  • Page 32 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Strong wind Rooftop • When installing the outdoor unit near the seashore, make sure that it is not directly exposed to sea breeze. If you cannot find an adequate place, a protection wall should be constructed. Install the outdoor unit at a place (such as near a building) where it can be protected from sea breeze.
  • Page 33 Check the condition of the product periodically. – Check the installation site every 3 months and perform anti-corrosion treatment such as R-Pro supplied by SAMSUNG (Code: MOK-220SA) or commercial water repellent grease and wax, etc., based on the product condition.

  • Page 34: When Installing More Than 1 Outdoor Unit

    13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU When installing more than 1 outdoor unit (Unit: mm) 1500 or 600 or 3000 or 3000 or 300 or more more more more more 300 or more 600 or 300 or 600 or 600 or more more more...
  • Page 35 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU CAUTION • Always remember to connect the refrigerant pipes before performing the electric connections. When disconnecting the system, always disconnect the electric cables before disconnecting the refrigerant pipes. Always remember to connect the air conditioner to the grounding system before performing the electric •...
  • Page 36 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU AC140BNPDKH (3-phase) V1/V2 Connector Indoor Unit 1(L) 2(N) F1 Communication DC 12V Cable clamp F1/F2 Wi-Fi Kit Connection Outdoor Unit 1(L) 2(N)L1(R) L2(S) L Cable tie Communication Indoor power Main power cable cable cable NOTE •...
  • Page 37 13. Installation AC***BNPDKH/EU+ AC***BXPD*H/EU CAUTION • Use rated cables or products only, with heat resistance over 105°C, as well as properly rated switches or fuses in the cabinet panel. • Make sure that the cables connected do not produce sparks around the auxiliary power switch or that they are not installed in a place subject to high temperature.

  • Page 38: Connecting The Cables

    13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Solderless ring Cable tie terminal Thin cable Thick cable When connecting two cables to a ring terminal, separate the ring terminal up or down to prevent it from getting loose. Place the thin cable upward and the thick cable downward.

  • Page 39: Power Wiring Diagram

    13. Installation AC***BNPDKH/EU+ AC***BXPD*H/EU Power wiring diagram 1(L) 2(N) L N F1 F2 Cable tie Communication Outdoor-to-indoor power cable cable power supply cable (Single phase AC 220-240V, should be purchased on-site) Indoor and outdoor unit connection diagram Indoor unit Outdoor unit 1(L) 2(N) 1(L) 2(N) F1 F1...
  • Page 40 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Main power cable specifications The power cable is not supplied with air conditioner. • Select the power supply cable in accordance with relevant local and national regulations. • Wire size must comply with the applicable local and national code. •...

  • Page 41: Performing Gas Leakage Test

    13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Performing gas leakage test Use nitrogen gas at a pressure range between 0.2 and 4.1 MPa when testing the gas leakage. If you apply pressure at over 4.1 MPa, the refrigerant pipes may be damaged. Manifold gauge High pressure side Outdoor unit...

  • Page 42: Evacuating The Air

    13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Evacuating the air 1 Connect the manifold gauge to a vacuum pump. 2 Purge the air from the system using the vacuum pump for about 30 minutes. • Make sure that pressure gauge shows -0.1006 Mpa after about 30 minutes. •...
  • Page 43 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU Refrigerant type GWP value R-410A 2088 • GWP= Global Warming Potential • Calculating tCO₂e : kg x GWP / 1000 (Unit: g) AC100BXPDKH 3000 1000 4000 AC140BXPDNH 3500 2250 5750 Measure the quantity of refrigerant depending on the length of the liquid side pipe. NOTE •...
  • Page 44 13. Installation AC***BNPDKH/EU + AC***BXPD*H/EU NOTE • If you cannot add refrigerant when the operation of the outdoor unit is stopped, open the gas and liquid service valves and add remaining refrigerant by pressing the cooling trial operation button. • After charging, completely open the spindles of the both the gas and liquid side service valves by rotating them anti- clockwise.
  • Page 45 ..Head Office (Suwon Korea) 129, Samsung-Ro, Yeongtong-Gu, Suwon City, Gyeonggi-Do, Korea 16677 Website : www.samsung.com, https://partnerhub.samsung.com Email : airconditioner@samsung.com Images and data in this book may subject to change without prior notice.
