- Page 1 Air conditioner Installation manual AC***BNAPKG • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this Installation manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information Installation Installation Step 1 Choosing the installation location Step 2 Checking and preparing accessories and tools Step 3 Attaching the mounting bracket to the wall Step 4 Drilling the wall penetration Step 5 Purging the unit Step 6 Cutting or flaring the pipes Step 7 Connecting the refrigerant pipes Step 8 Performing leak test... -
Page 3: Safety Information
• This manual explains how to install an indoor unit with equipped. a split system with two SAMSUNG units. The use of • Do not use means to accelerate the defrost operation or other types of units with different control systems may to clean, other than those recommended by Samsung. -
Page 4: Installing The Unit
Safety Information Installing the unit Power supply line, fuse or circuit breaker WARNING WARNING • IMPORTANT: When installing the unit, always remember to Always make sure that the power supply is compliant connect first the refrigerant tubes, then the electrical lines. with current safety standards. - Page 5 • Please cover the air conditioner with PE BAG after CAUTION installation,and remove it when you start to run air • conditioner. Make sure that you earth the cables. Do not connect the earth wire to the gas pipe, water –...
-
Page 6: Installation
Installation Step 1 Choosing the installation location • m : Total refrigerant charge in the system • A : Minimum required room area Installation location requirements • IMPORTANT: it’s mandatory to consider either the table • 1 or taking into consideration the local law regarding There must be no obstacles near the air inlet and outlet. -
Page 7: Step 2 Checking And Preparing Accessories And Tools
Overview of installation location requirements Step 2 Checking and preparing accessories and tools Accessories 100 mm or more (recommended) 125 mm Accessories in the indoor unit package 125 mm or more or more (recommended) (recommended) AC***BNAPKG Drain hose hole Mounting bracket (1) Mounting bracket (1) You can select the direction of AC026/035BNAPKG... -
Page 8: Step 3 Attaching The Mounting Bracket To The Wall
Installation Step 3 Attaching the mounting bracket Step 4 Drilling the wall penetration to the wall Determine the position of the hole through which the piping bundle (consisting of power and communication Hold the mounting bracket against the wall at the cables, refrigerant pipes, and the drain hose) will pass. -
Page 9: Step 5 Purging The Unit
Use a standard 65mm hole saw to drill one hole at the Step 5 Purging the unit selected location, at a 15° downward angle so that the Upon delivery, there may be inert gas inside the indoor unit. drain hose will drain properly. Purge the gas from the indoor unit before connecting the assembly pipe. - Page 10 Installation To prevent a gas leak, remove all burrs at the cut edge of Be sure to use an insulator thick enough to cover the the pipe using a reamer. refrigerant tube to protect the condensate water on the outside of the pipe falling onto the floor and to improve Slide a flare nut on to the pipe and modify the flare.
-
Page 11: Step 7 Connecting The Refrigerant Pipes
Step 7 Connecting the refrigerant pipes The left exit is the only position that does not require bending the pipes. For other positions, bend the pipes so Connect indoor and outdoor units with field-supplied copper that they will exit in the selected exit position. pipes by means of flare connections. -
Page 12: Step 8 Performing Leak Test
Installation Torque the flare connections to the following values: Step 9 Connecting the drain hose Torque (kgf•cm) In Step 4 you determined the exit position for the piping Outer diameter (mm) bundle. If using the right, bottom, or right rear exit, Φ... -
Page 13: Step 10 Connecting The Power And Communication Cables
The indoor unit is powered through the outdoor unit by means CAUTION of a H05 RN-F connection cable (or a more power model), with • insulation in synthetic rubber and a jacket in polychloroprene If the diameter of the connection hose is smaller than (neoprene), in accordance with the requirements specified in the product’s drain hose, leakage may occur. - Page 14 Installation Unit: mm 3 phase AC power, Communication : M4 screw Indoor Unit 1(L) 2(N) 1(L) 2(N) 13.8 10.3 Cable clamp Tightening torque N‧m M3.5 0.8 to 1.2 Outdoor 1.2 to 1.8 Unit (1N‧m=10kgf‧cm) 1(L) 2(N) L1(R) L2(S) L3(T) N •...
-
Page 15: Step 11 Optional: Extending The Power Cable
Step 11 Optional: Extending the power Insert both sides of core wire of the power cable into the connection sleeve. cable Method 1: Push the core wire into the sleeve from – Prepare the following tools. both sides. Method 2: Twist the wire cores together and push it –... -
Page 16: Step 12 Taping The Pipes, Cables, And Drain Hose
Installation Apply heat to the contraction tube to contract it. Step 12 Taping the pipes, cables, and drain hose Method 1 Method 2 Wrap foam insulation around the refrigerant pipes, up Contraction tube Contraction tube to the connection points. The connections must remain accessible for testing later in the installation process. -
Page 17: Step 13 Optional: Installing Dpm (Digital Packaged Multi)
Step 13 Optional: Installing DPM (Digital Step 14 Setting the indoor unit Packaged Multi) addresses and the installation options • To find DPM allowable indoor unit models according You cannot set both of the indoor unit addresses and the to outdoor unit models, refer to outdoor installation installation options in a batch: set both of them respectively. - Page 18 Installation • Make sure that you are entered to the mode for Set a 2-digit value for each option pair in the following order: SEG2 and SEG3 → SEG4 and SEG5 → SEG6 and setting the options: SEG8 → SEG9 and SEG10 → SEG11 and SEG12 → SEG14 and SEG15 →...
- Page 19 Option setting Status Setting SEG6, SEG8 option Press Low Fan button to enter SEG6 value. Press High Fan button to enter SEG8 value. Each time you press the button, will be selected in rotation. SEG6 SEG8 Setting Fan mode Press Mode button to be changed to Fan mode in the ON status. Setting SEG9, SEG10 option Press Low Fan button to enter SEG9 value.
- Page 20 Installation Option setting Status 13 Setting SEG16, SEG17 option Press Low Fan button to enter SEG16 value. Press High Fan button to enter SEG17 value. Each time you press the button, will be selected in rotation. SEG16 SEG17 14 Setting Dry mode Press Mode button to be changed to Dry mode in the OFF status.
- Page 21 Check whether the option values that you have set are correct by pressing the button repeatedly. [SEG2, SEG3] [SEG4, SEG5] [SEG6, SEG8] [SEG9, SEG10] [SEG11, SEG12] [SEG14, SEG15] [SEG16, SEG17] [SEG18, SEG20] [SEG21, SEG22] [SEG23, SEG24] Save the option values into the indoor unit: Press the button with the direction of remote control for set.
-
Page 22: Setting The Indoor Unit Addresses
Installation Setting the indoor unit addresses Option No. for an indoor unit address: 0AXXXX-1XXXXX-2XXXXX-3XXXXX Before installing an indoor unit, be sure to set an address for the indoor unit by taking the following steps: Make sure that the power is supplied to the indoor unit. If the indoor unit is not plugged in, it must include a power supply. Set an address for each indoor unit using the remote control, according to your air conditioning system plan, by referring to the following table and by following the steps in Common steps for setting the addresses and options on page 17. -
Page 23: Setting The Installation Options In A Batch
Example) If you want to set as "MAIN: 3, CHANNEL: 1, RMC: B", SEG1 SEG2 SEG3 SEG4 SEG5 SEG6 SEG7 SEG8 SEG9 SEG10 SEG11 SEG12 Assign option codes except SEG 1, 7 which are page options. Setting the installation options in a batch Make sure that the power is supplied to the indoor unit. - Page 24 Installation Set the indoor unit option by wireless remote controller. Option SEG 1 SEG 2 SEG 3 SEG 4 SEG 5 SEG 6 Use of external room temperature sensor / Minimizing fan Function Page Mode Central control operation when thermostat is off ¹⁾ Indication Details Indication Details Details...
- Page 25 Option SEG 13 SEG 14 SEG 15 SEG 16 SEG 17 SEG 18 Setting the output of Maximum filter usage time ³⁾ Function Page Use of external control Buzzer control extermal control Indication Details Indication Details Indication Details Indication Details Indication Details Disuse...
-
Page 26: Changing The Addresses And Options Individually
Installation • If you input a number other than 0~4 on the individual control of the indoor unit(SEG 20), the indoor is set as "Indoor 1". Example) If you want to set as "Exterior temperature sensor : USE, External control : USE SEG1 SEG2 SEG3... -
Page 27: Step 15 Optional : Setting The Emergency Temperature Output (Eto) Function
Step 15 Optional : Setting the Emergency Temperature Output (ETO) function Emergency Temperature Output (ETO) function CAUTION • In order to deploy the ETO function, the MIM-B14, an external contact interface module, must be installed in each indoor unit. The ETO is a concept of emergency operation of indoor units. If the indoor unit 1 (main indoor unit) stops because of –... - Page 28 Installation [Master] [Slave] ETO operation specifications Main indoor unit Based on the external contact control settings, the main indoor unit decides whether to generate output when an – error (indoor unit stop) occurs. Based on the ETO settings, the main indoor unit decides whether to generate output according to the temperature –...
-
Page 29: Step 16 Optional : Connecting The External Control (Mim-B14), Wired Remote Control And External Floating Switch
3. Set SEG8 for the Install option (02 mode) to '8'. (Refer to "Setting an indoor unit installation option") NOTE • The External Floating switch is not sold separately by Samsung. • External Control (MIM-B14) and External Floating switch cannot be connected simultaneously. Only either of them can be connected at a time. -
Page 30: Appendix
Troubleshooting Troubleshooting Detection of errors • If an error occurs during the operation, an LED flickers and the operation is stopped except the LED. • If you re-operate the air conditioner, it operates normally at first, then detect an error again. LED Display on the receiver &... - Page 31 Abnormal condition Error code 1. COND mid sensor is detached E241 2. Refrigerant leakage (2nd detection) E554 3. Abnomally high temperature on Cond (2nd detection) E450 4. Low pressure s/w (2nd detection) E451 5. Abnomally high temperature on discharged air on outdoor unit (2nd detection) E416 6.
- Page 32 This appliance is filled with R-32.
