- Page 1 Air conditioner User manual Thank you for purchasing this Samsung air conditioner. Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety information At a Glance Operation Features Operating temperature and humidity Indoor Unit Overview Control Panel Overview Indoor unit display Controlling with the control panel Turning on or off the air conditioner • Controlling temperature • Controlling the fan speed Selecting the operation mode/Locking the control panel Remote Control Overview Replacing batteries •... - Page 3 Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product-specific regulatory obligations, e.g. REACH visit: www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/...
-
Page 4: Safety Information
If you have any questions, call your nearest contact center or find help and information online at www. samsung.com. These warning signs are here to prevent injury to you and others. Please follow them carefully. - Page 5 FOR INSTALLATION WARNING Use the power line with the power specifications of the product or higher and use the power line for this appliance only. In addition, do not use an extension line. • Extending the power line may result in electric shock or fire. •...
- Page 6 Safety information This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line. • Failure to do so may result in electric shock, fire, an explosion, or other problems with the product. •...
- Page 7 FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact your nearest service centre. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 8 Safety information In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power line. Do not touch the appliance or power line. • Do not use a ventilating fan. • A spark may result in an explosion or fire. To reinstall the air conditioner, please contact your nearest service centre.
- Page 9 Do not turn the air conditioner off with the circuit breaker while it is operating. • Turning the air conditioner off and then on again with the circuit breaker may cause a spark and result in electric shock or fire. After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.
- Page 10 Safety information Do not attempt to repair, disassemble, or modify the appliance yourself. • Do not use any fuse (such as copper, steel wire, etc.) other than the standard fuse. • Failing to do so may result in electric shock, fire, problems with the product, or injury.
- Page 11 Do not drink the water from the air conditioner. • The water may be harmful to humans. Do not apply a strong impact to the remote control and do not disassemble the remote control. Do not touch the pipes connected with the product. •...
- Page 12 Safety information FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. • This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut-off the power supply and wait until the fan stops.
-
Page 13: At A Glance
Operation Features Operating temperature and humidity Mode Outdoor temperature Indoor temperature Indoor humidity Cool mode -15°C to 50°C 18°C to 32°C 80% or less Heat mode -20°C to 24°C 30°C or less Dry mode -15°C to 50°C 18°C to 32°C 80% or less CAUTION •... -
Page 14: Indoor Unit Overview
Indoor Unit Overview The actual product may differ slightly from the image depicted below. Air flow blade (up and down) Air flow blade (left and right) Air outlet Control panel Indoor unit display Air filter Remote control holder Air intake Safety hook Opening the panel Hold the upper part of the panel, then pull it slightly forward. -
Page 15: Control Panel Overview
Control Panel Overview Power button Indoor unit display Mode button (Lock button) Temperature button Fan speed button (Turbo function Button) Indoor unit display 02 03 Operation mode indicators Fan speed indicator Defrost operation indicator Set temperature indicator Outdoor unit operation indicator Turbo function indicator / Long reach function indicator / Vertical air swing indicator /... -
Page 16: Controlling With The Control Panel
Controlling with the control panel You can control the air conditioner with the control panel without using the remote control. Turning on or off the air conditioner Press the (Power) button. The air conditioner turns on with a ring sound and then its operation starts. To turn off the air conditioner, press the (Power) button again. -
Page 17: Selecting The Operation Mode/Locking The Control Panel
Selecting the operation mode/ Locking the control panel • Press the (Mode) button to change the operation mode. Each time you press the button, the mode (Lock 3sec) • Press the (Mode) button for 3 seconds. The (Lock) indicator appears and then the control panel is locked with a ring sound. -
Page 18: Remote Control Overview
Remote Control Overview Set temperature indicator Timed on/off indicator Operation mode indicator Unsupported functions NOTE • The Single user, Heater and Purity functions ( are not supported by this model. Low battery indicator Signal transmission indicator Fan speed indicator Vertical air swing indicator / Horizontal air swing indicator Options indicator Power button... -
Page 19: Replacing Batteries • Storing The Remote Control
Replacing batteries When the icon appears in the remote control display, replace the batteries with new ones. Two 1.5V AAA type batteries are required. Two 1.5V AAA type batteries Correct disposal of batteries in this product This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. -
Page 20: Remote Control Operation
Remote Control Operation You can use the air conditioner easily by selecting a mode or function and then by controlling the temperature, fan speed, and air flow direction. Turning on or off the air conditioner You can turn on or off the air conditioner by pressing the (Power) button. -
Page 21: Controlling Fan Speed • Controlling Temperature • Controlling Air Flow Direction
Controlling fan speed You can select the following fan speeds in each mode: Mode Available fan speeds Auto/Dry (Auto) Cool/Heat (Auto), (Med), (High), (Turbo) (Med), (High), (Turbo) Controlling temperature You can control the temperature in each mode as follows: Mode Temperature control Auto/Cool/Dry Adjust by 1°C between 18°C and 30°C... -
Page 22: Power Smart Features
Power Smart Features Auto mode Use the Auto mode when you want the air conditioner to automatically control the Cool mode. The air conditioner will provide the most comfortable atmosphere that it can. Select Auto. NOTE • You cannot change the fan speed. •... -
Page 23: Dry Mode • Fan Mode
Dry mode Use the Dry mode in rainy or humid weather. Select Dry. NOTE • You cannot change fan speed in the Dry mode. • The greater the difference between the set temperature and the current temperature is, the greater the amount of air that is dehumidified is. -
Page 24: Heat Mode
Power Smart Features Heat mode Use the Heat mode to stay warm. Select Heat. NOTE • While the air conditioner warms up, the fan may not operate for a while at the beginning to prevent cold wind. • While the defrost function is running, the indoor unit provides no breeze to prevent cold wind. -
Page 25: Variety Smart Features
Variety Smart Features There is a variety of useful functionality provided by the Samsung air conditioner. Turbo function Use the Turbo function to quickly cool your room. This function provides the most powerful cooling air. NOTE • To turn off the Turbo function, press (Turbo) button again. -
Page 26: Clean Function
Variety Smart Features Clean function Use the Clean function to remove moisture from the inside of the air conditioner for preventing propagation of fungi, bacteria, etc. Select Clean. • When the Clean function is set, the (Clean) indicator appears on the indoor unit display. When the air conditioner is ended, the Clean function starts for 10 minutes and then the air conditioner turns off. -
Page 27: Energy-Saving Operation
Energy-Saving Operation Timed on/Timed off function Use the Timed on/off function to turn the air conditioner on or off after the time that you set. Select On or Off. (Set the on/off time.) NOTE • You can set a time between 0.5 and 24 hours. (When the air conditioner is off) •... -
Page 28: Cleaning And Maintenance
Cleaning at a Glance Cleaning the indoor unit exterior and outdoor unit heat exterior Tepid damp cloth Soft brush Before cleaning, be sure to turn off the air conditioner. Spray water to clean the dust. CAUTION • Do not open the panel when the air conditioner is operating. This action may cause a malfunction or an electrical hazard. -
Page 29: Cleaning The Filter
Cleaning the filter Vacuum cleaner CAUTION • Do not scrub the air filter with a brush or other cleaning utensil. This may damage the filter. • Do not expose the air filter to direct sunlight when drying it. NOTE • Clean the air filter every 2 weeks. Cleaning term may vary depending on the usage and environmental conditions. - Page 30 Cleaning at a Glance Periodical maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. Once every 2 weeks Clean the condensate drain pan. Once a year Required Indoor unit Clean up the heat exchange. Once a year Required Clean the condensate drain pipe.
-
Page 31: Troubleshooting
Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution • Check whether the power is turned on, and then operate the air conditioner again. • Check whether the auxiliary power switch (ELCB, ELB) is turned on. •... - Page 32 Troubleshooting Problem Solution • Check whether is displayed on the indoor unit display. Make sure that the power and communication cables are connected correctly between the indoor and outdoor units, and then restart the air conditioner. If the error is still displayed, contact a service centre. •...
- Page 33 • Condensation may develop due to the difference in temperature. This is a piping connections of normal condition. the outdoor unit. Technical specifications Type Model Net weight (kg) Net dimension (W*H*D) AC100BNPDKH 610*1850*400 INDOOR UNIT AC140BNPDKH 44.5 610*1850*400 AC100BXPDKH 72.5...
-
Page 34: Information About Refrigerant
Information about refrigerant Important information: regulation regarding the refrigerant used This product contains fluorinated greenhouse gases. Do not vent gases into the atmosphere. CAUTION • at least once every 12 months, according to regulation No. 517/2014. This activity must be covered by qualified personnel only. - Page 35 Memo English...
- Page 36 0800 - SAMSUNG ESTONIA 800-7267 www.samsung.com/ee/support SLOVAKIA www.samsung.com/sk/support (0800-726 786) AUSTRALIA 1300 362 603 www.samsung.com/au/support CROATIA 072 726 786 www.samsung.com/hr/support Samsung, PO Box 12987, Blackrock, Co. Dublin. IE or Euro QA Lab. Saxony Way, Yateley, Hampshire GU46 6GG, UK...
