- Page 1 Quick Start Guide SenseFace 7 Series Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
- Page 2 1.Overview SenseFace 7A / 7C Camera Microphone Near-Infrared Flash 7-inch Touch Screen Speaker Fingerprint Sensor Card Reading Area Tamper Switch Terminal Block USB Interface 0.88"(22.3mm) Reset 4.53"(115.0mm)
- Page 3 SenseFace 7B Camera Microphone Near-Infrared Flash 7-inch Touch Screen Card Reading Area Tamper Switch Terminal Block Speaker USB Interface 0.88"(22.3mm) Reset 4.53"(115.0mm) Note: Not all products have the function with , the real product shall prevail.
- Page 4 2.Installation Environment INSTALL INDOORS AVOID INSTALLATION AVOID DIRECT AVOID USE OF ANY ONLY NEAR SUNLIGHT HEAT SOURCE GLASS WINDOWS AND EXPOSURE NEAR THE DEVICE 3.Device Installation Install on the wall ① Attach the mounting template sticker to the wall, and drill holes according to the mounting paper.
- Page 5 4.Standalone Installation Exit button Wiegand Smoke Door Sensor Detector Card Reader Wireless Doorbell RS485 Lock RS485 Reader ZKBio CVAccess TCP/IP 5.Terminal Block Network Interface Power In Auxiliary Input Lock Exit Button Door Sensor 485B RS485 485A Wiegand Out / In 12VOUT Power Out...
- Page 6 6.Ethernet Connection Establish the connection between the device and the software using an Ethernet cable. An illustrative example is provided below: ZKBio CVSecurity IP address: 192.168.1.130 Default IP address: 192.168.1.201 Subnet mask : 255.255.255.0 Subnet mask 255.255.255.0 Tap on to enter the main menu. And then click on [Comm.] > [Ethernet] > [IP Address] to input the IP address.
- Page 7 8.Exit Button, Door Sensor & Auxiliary Connection Smoke Detector +12V DC Exit button Door Sensor 9.RS485 Connection 485+ 485B 485- 485A +12V 12VOUT RS485 Reader...
- Page 8 10.Lock Relay Connection The system supports both Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally opened at power on) is connected with 'NO' and 'COM' terminals, and the NC LOCK (normally closed at power on) is connected with 'NC' and 'COM' terminals.
- Page 9 12.User Registration Click to enter the Main Menu screen. When a super administrator is set up, administrator verif ication is required when entering the menu. For security purposes, it is recommended to register a super administrator when using it for the f irst time. Method 1: Registering on the device Click >...
- Page 10 Method 2: Register on ZKBio CVSecurity software Please set the IP address and cloud service server address in the COMM. menu option on the device. Click [Access] > [Device Management] > [Device] > [Search] > [Search] to search the device on the software. When the device has set the server address and port, it can be added automatically.
- Page 11 Method 3: Register on the phone Once the ZKBio CVSecurity software is installed, the users could enroll their face via a browser application on their own mobile phone. Click [Personnel] > [Parameters], input ‘’http://Server address: Port’’ in the QR Code URL bar. The software will automatically generate a QR code. Scan the QR code or login onto ‘’http://Server address: Port/app/v1/adreg’’...
- Page 12 13.Ethernet and Cloud Server Settings Click > [ COMM. ] > [ Ethernet ] to set the network parameters. If the TCP/IP communication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Click >...
- Page 13 14.Configuring Wi-Fi Click > [COMM.] > [Wi-Fi Settings] to configuring Wi-Fi. When Wi-Fi is enabled, select the searched network. Enter the password, and click Connect to Wi-Fi (OK). The connection succeeds, with icon displayed on the status bar. You can also select Add Wi-Fi Network to add Wi-Fi manually.
- Page 14 Volume Button Music Button Wireless Doorbell 16.SIP Settings This section introduces the application methods of Video Intercom using Local Area Network and Cloud SIP Server. Mode 1: Local Area Network This function needs to be used with the indoor monitor VT07-B01. Step 1: Setting the IP address of the indoor monitor Click [Network] >...
- Page 15 Step 3: Calling the indoor monitor Users can call the indoor monitor in three ways: by IP address, by shortcut and directly. 1. Calling by IP Address or ROOM Number 1) Click > [Intercom] > [SIP Settings] > [Local Settings] to turn off the SIP Server. 2) Then click icon on the standby page to enter the call page.
- Page 16 3) Click [SIP Settings] > [Calling Shortcut Settings] > [Call Mode] > [Standard Mode], and click [ROOM1/2/3/4] to set the room number of the call page. 4) Then you can enter the device number, or click the ROOM shortcut button on the call page to call the indoor monitor.
- Page 17 3) Click [SIP Settings] > [Calling Shortcut Settings] > [Call Mode] > [Standard Mode] > [Direct Calling Mode], and then click [Add] to select the device number you want to directly call from the contact list. 4) Then you can click the icon on the standby screen to directly call the indoor monitor.
- Page 18 Mode 2: Cloud SIP Server This function needs to be used with the ZKBio CVSecurity server, ZKBio Zexus Mobile APP, indoor monitor VT07-B26L-W / VT07-B22L and PC Client BioTalk Pro. There are SIP servers: Cloud SIP and PBX servers. Take Cloud SIP as an example. Note: In Cloud SIP Server mode, ensure that the SIP server of the device is on.
- Page 19 Step 3: Configure Contact List 1. Click [Video Intercom] > [Extension Management] > [Extension Number] > [New] to add the extension numbers. 2. Click [Extension Management] > [Contact List] > [New] to add the contacts. Then click the icon to add extension numbers to it. Define the short number After defining the short number here, you can call the extension number by dialling this number.
- Page 20 Step 4: Synchronize account information to the device Click [Extension Assignment] > [Extension Assignment] to assign an extension number and synchronize the contacts to the device. Note: Ensure that ZKBio CVConnect Client has been installed and activated, otherwise this step cannot be operated normally. Once the SIP is set up correctly, a green dot will appear in the upper right corner of the call page, indicates that the device is connected to the server.
- Page 21 Enter Short Number 322603 Indoor monitor interface 2. Device Call the Phone (ZKBio Zexus App) 1) On the ZKBio CVSecurity software, assign an extension number to the personnel. 2) On the device, enter [Intercom] > [SIP Settings] > [Local Settings] > [Call Number Type], select the call number type as Room Number.
- Page 22 2) Press the key on the device and enter the Short Number of the PC Client in the call interface of the device. Enter Short Number Two-way calls can be made between the device, indoor monitor, ZKBio Zexus App, and PC client (BioTalk Pro). For more details, please refer to the user manual. 17.ONVIF Settings This function needs to be used with the Network Video Recorder (NVR).
- Page 23 On the NVR system, click [Start] > [Menu] > [Channel Manage] > [Add Channel] > [Refresh] to search for the device. Select the checkbox for the device you want to add and edit the parameters in the corresponding text field, then click on [OK] to add it to the connection list. After successfully adding, the video image obtaining from the device can be viewed in real-time.
