Phoenix Gold QX150.4 Quick Start Manual

QX150.4
SPECIFICATIONS
Continuous Output Power at 1% THD (watts):
QX150.4
Into 4 ohms Stereo @ 12.5 Vdc (IASCA/USAC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 x 4
Into 4 ohms Stereo @ 14.4 Vdc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50 x 4
Into 2 ohms Stereo @ 14.4 Vdc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75 x 4
Into 4 ohms Bridged @ 14.4 Vdc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150 x 2
Recommended Fuse Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25A x 2 ATO style
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11.875L x 9.5W x 2.0H
Common Specifications
Frequency Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±1dB, 20Hz to 20kHz
Signal to Noise Ratio (A-weighted) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>100dB
Input Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200 millivolts to 4 volts
Crossover Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30Hz to 600Hz
Crossover Slope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12dB per Octave
DC Input Voltage Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 volts to 15.5 volts
Typical Current Draw at Idle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<2 amps
Minimum Bridged Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 ohms
Minimum Stereo Load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 ohms
Due to ongoing research and development, features, specifications and availability are subject to change without notice.
LIMITED WARRANTY
Phoenix Gold International, Inc. (or "Phoenix Gold") warrants its products against defects in materials and workmanship for a limited period of time.
For a period of one (1) year from date of original purchase, we will repair or replace the electronic product, at our option, without charge for parts
and labor. Customer must pay all parts, labor and shipping charges after the limited warranty period expires. The limited warranty period for
factory refurbished products expires after ninety (90) days from date of original purchase. This limited warranty applies only to purchases from
authorized Phoenix Gold Electronics/Speaker retailers.
This limited warranty is extended only to the original purchaser and is valid only to consumers in the United States. Consumers are required to
provide a copy of the original sales invoice from an authorized Phoenix Gold dealer when making a claim against this limited warranty. This limited
warranty only covers failures due to defects in materials or workmanship that occur during normal use. It does not cover failures resulting from
accident, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, modification, service by anyone other than Phoenix
Gold, or damage that is attributable to Acts of God. It does not cover costs of transportation to Phoenix Gold or damage in transit.
This warranty will become void if the serial number identification has been wholly or partially removed, altered or erased. Repair or replacement
under the terms of this warranty does not extend the terms of this warranty.
Should a product prove to be defective in workmanship or material, the consumer's sole remedies will be repair or replacement as provided under
the terms of this warranty. Under no circumstances shall Phoenix Gold be liable for loss or damage, direct, consequential or incidental, arising
out of the use of or inability to use the product. There are no express warranties other than described above.
9300 North Decatur • Portland, OR 97203
Tel: 503.286.9300 • F ax: 503.978.3380
w w w.phoenixgold.com
Four Channel Amplifier
QX150.4
Four Channel Amplifier
FEATURES
* For complete manuals, technical tips, FAQ's, system diagrams and new product information visit us @
• Aluminum Alloy Heatsink with Fly Cut Fins
• Seperate Front and Rear crossover circuitry
• 12dB per octave High or Low Pass crossover variable from 30 to 600Hz
• Fully Complimentary Output Stage
• Four gauge power and ground terminal
• Advanced thermal and overload protection
• Gold plated power and speaker terminals
• Gold plated front and rear signal input jacks
• Customed milled Phoenix Gold logo
• Isolated rubber mounting feet for secure, noise free installations
• Optimized muting circuitry eliminates turn-on and turn-off noises
• Linkable using the optional Qlink/2 to connect multiple amplifiers together
