TURBO HD
TVI
Bullet &Turret Camera
User Manual
UD.6L0201D2079A01
Thank you for purchasing our product. If there
are any questions, or requests, please do not
hesitate to contact the dealer.
Type
Type I
Type II
Type III
In the model list, "X" indicates single or multiple
letters. For example, DS-2CE56C0T-IRX can be
DS-2CE56C0T-IRMM.
This manual may contain several technical
incorrect places or printing errors, and the
content is subject to change without notice.
The updates will be added to the new version of
this manual. We will readily improve or update
the products or procedures described in the
manual.
0200011051130
Model
DS-2CE16
C0 IR/IRX
DS-2CE16
D0
DS-2CE56C0T-IRX
DS-2CE56D0T-IRX
DS-2CE56C0T-IR
DS-2CE56D0T-IR
T-
T-I
R/IRX
Advertisement
Related Manuals for HIKVISION TURBO HD DS-2CE16C0T-IR
Summary of Contents for HIKVISION TURBO HD DS-2CE16C0T-IR
- Page 1 TURBO HD Bullet &Turret Camera User Manual UD.6L0201D2079A01 Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. Model Type DS-2CE16 C0 IR/IRX Type I DS-2CE16 R/IRX DS-2CE56C0T-IRX Type II DS-2CE56D0T-IRX DS-2CE56C0T-IR Type III...
- Page 2 Privacy Notice Surveillance laws vary by jurisdiction. Check all relevant laws in your jurisdiction before using this product for surveillance purposes to ensure Please refer to the product specification for camera parameters and functions. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules.
- Page 3 upon the purchase of equivalent new equipment, or dispose of it at designated collection points. www.recyclethis.info. For more information see: 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union.
- Page 4 1.2 Overview 1.2.1 Overview of Type I Camera Mounting Base Power Cable HD Video Cable Sun Shield Lens IR LED Figure 1-1 Overview of Type I Camera 1.2.2 Overview of Type II Camera Mounting Base Side Opening Trim Ring Enclosure Camera HD Video Cable Power Cable...
- Page 5 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is power-off during the installation. Check the specification of the products for the installation environment.
- Page 6 3.Connect the corresponding power cable and video cable. 4.Fix the camera to the ceiling with the supplied screws. Figure 2-2 Fix the Camera to the Ceiling 5.Adjust the surveillance angle. 1).Loosen No.3 adjusting screw to adjust the panning position 0 ~ 360 . ( °...
- Page 7 2. Screw the clip plate onto the mounting base loosely. Clip Plate Figure 2-5 Screw the Clip Plate 3. Fix the mounting base to the ceiling with the supplied screws. 4.Route the cables through the side opening and connect the corresponding power cable and video cable.
- Page 8 2.3 Installation of Type Camera Steps: 1.Drill the screw holes and the cable hole on the ceiling according to the supplied drill template. Figure 2-8 The Drill Template 2.Fix the mounting base to the ceiling with the supplied screws. Figure 2-9 Fix the Mounting Base and Camera 3.Route the cables through the cable hole and connect the corresponding power cable and video cables.
