- Page 1 Liam 55" Sideboard FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-40008 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 60 mins Weight limitations are as follows: Maximum Load 70 lb Maximum Load 20 lb...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
- Page 4 PACKAGE CONTENTS...
- Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Side Panel Bottom Panel Medial Panel Large Storage Shelf Panel Small Storage Shelf Panel Back Support Strip Cabinet Door Back Panel Front Base Panel Back Base Panel Left Base Panel Right Base Panel Center Base Panel v.12122022...
- Page 6 PACKAGE CONTENTS 34x + 3x 34x + 3x 12x + 1x 34x + 3x 36x + 3x 24x + 2x 16x + 1x Install all hardware perpendicular to the opening.
- Page 7 PACKAGE CONTENTS 12x + 1x 12x + 1x v.12122022...
- Page 8 Required tools for assembly (Not included) Insert cam bolts to the front, back, left, and right base panels (10, 11, 12, 13).
- Page 9 Attach corner connectors to the front, back, left, and right base panels (10, 11, 12, 13). Insert wood dowel to the center base panel (14). v.12122022...
- Page 10 Assemble the left, right, cand center base panels (12, 13, 14) to the back base panel (11). Assemble the front base panel (10) to the base assembly.
- Page 11 Attach cam bolts to the underside of the bottom panel (3). Assemble the base assembly underneath the bottom panel (3). v.12122022...
- Page 12 Secure the center base panel (14) to the bottom panel (3). Attach cam bolts to the underside of the top panel (1).
- Page 13 Attach cam bolts to the underside of the top panel (1). Insert wood dowels to the side panels (2) and medial panel (4). v.12122022...
- Page 14 Assemble the side panels (2) to the bottom panel (3).
- Page 15 Assemble the medial panel (4) and the back support strips (7) to the bottom panel (3). v.12122022...
- Page 16 Slide the back panels (9) between the side panels (2) and the back support strips (7) .
- Page 17 Assemble the top panel (1) on top of the sideboard assembly. v.12122022...
- Page 18 Insert shelf pegs into the sideboard and put on the storage shelf panels (5, 6). Secure the back panels in place.
- Page 19 Attach door hinges to the cabinet doors (8). Attach door handles to the cabinet doors (8). v.12122022...
- Page 20 Attach the cabinet doors (8) to the sideboard. Adjust the position of the cabinet doors. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 21 Attach anti-tipping straps to the back of the sideboard. v.12122022...
- Page 22 device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole. • Fixed the anti-tipping strap to the wall with provided screws. YOU’RE FINISHED!
- Page 23 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 24 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
- Page 25 v.12122022...
- Page 27 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.12122022...
- Page 28 WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
