Belleze 014-HG-40019 Manual

Stacked sideboard

Advertisement

Stacked Sideboard
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-40019
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 014-HG-40019 and is the answer not in the manual?

Questions and answers

Summary of Contents for Belleze 014-HG-40019

  • Page 1 Stacked Sideboard FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-40019 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 90 mins Weight limitations are as follows: Maximum Load 90 lb Maximum Load 20 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Left Panel Right Panel Medial Panel Storage Shelf Panel Back Support Back Panel Crossbar Left Cabinet Door Right Cabinet Door Long Base Strip Short Base Strip v.08122024...
  • Page 6 PACKAGE CONTENTS 35x + 3x 35x + 3x 35x + 3x 30x + 3x 10x + 1x 10x + 1x 48x + 4x 16x + 2x 16x + 2x 8x + 1x Install all hardware perpendicular to the opening.
  • Page 7 Required tools for assembly (Not included) Attach cam bolts to the bottom panel (2), left panel (3) and right panel (4). v.08122024...
  • Page 8 Attach cam bolts to both sides of the medial panel (5). Flip Attach cam bolts to long base strips (12).
  • Page 9 Insert wood dowels to the left, medial, right panels, (3, 4, 5) and to the crossbars (9). Insert wood dowels all the base strips and the back supports (7, 12, 13). v.08122024...
  • Page 10 Assemble crossbars (9) to the left and right panels (3, 4). Assemble the medial panel (5) between the two crossbars (9).
  • Page 11 Assemble the left panel (3), medial panel (5), right panel (4), and back supports (7) to the bottom panel (2). v.08122024...
  • Page 12 Assemble short base strips (13) between the two long base strips (12). Assemble the base assembly to the underside of the bottom panel (2).
  • Page 13 Slide back panels (8) to the sideboard assembly. v.08122024...
  • Page 14 Attach cam bolts to the bottom side of the top panel (1). Assemble the top panel (1) on top of the sideboard assembly.
  • Page 15 Secure all the back panels in place. Insert shelf pegs into the sideboard and place storage shelf panels (6) on top of the pegs. v.08122024...
  • Page 16 Attach door hinges to all the cabinet doors (10, 11). Attach door handle to all the cabinet doors (10, 11).
  • Page 17 Attach cabinet doors (10, 11) to the sideboard. Rotate v.08122024...
  • Page 18 When the clearance of the door is uneven, Adjust the cabinet door according Up and down Side to side In and out adjustment by adjustment using adjustment by loosening the screws the front adjustment loosening the screws on the mounting screw on the hinge.
  • Page 19 Attach anti-tipping straps to the back of the sideboard. v.08122024...
  • Page 20 Furniture must permanently fixed to the wall stud with included anti-tipping device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole.
  • Page 21 Warning Serious or fatal crushing injuries may occur if the furniture tip-over. Furniture must permanently affixed to the wall with included anti-tipping device in order to prevent the furniture from tipping over. Different wall materials requires different types of wall anchors or screws. Use a suitable wall anchors or screws for your specific wall in order to secure the stability and load bearing capacity of the furniture.
  • Page 22 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 23 © All copyright of this document belongs to BELLEZE. This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.08122024...
  • Page 24: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Encounter any difficulties or missing parts? Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
