INTRODUCTION

For a PG7000 Platform to run ver. 2.02 or higher software, it must be equipped with flash memory, a set of larger
NVRAMs (128K) and jumpers must be installed and the BIOS EPROM must be replaced. Two different upgrade kits
corresponding to two PG7000 Platform hardware situations are available: Upgrade A, P/N 401592 is for PG7000s
that already have flash memory; Upgrade B, P/N 401593 is for PG7000s that do not have flash memory.
•
A limited number of PG7000s were delivered between February and July 1999 with ver. 2.00 software. These require Upgrade A
but without the new PG Terminal, use P/N 401594. Refer to the UPGRADING PG7000 PISTON GAUGES FROM ver. 1.0x TO ver.
2.0x commercial document for additional upgrade information.
UPGRADE KIT A, P/N 401592: FLASH WITH EEPROM TO FLASH WITHOUT EEPROM
•
If the PG7000 already has ver. 2.00 or 2.01 software, it has a new PG TERMINAL. Use P/N 401594 to upgrade. It does not
include the terminal.

P/N 401592 Parts List

• 4 102091
• 1 102542
• 1 102543
• 1 401597
Installation Instructions (see Figure 1)
Open the PG7000 base to expose the electronic board. Use the instructions provided in Section 5.6 of the PG7000
manual supplied with the upgrade kit for assistance on disassembly of the base.
Remove EPROM from U45 and replace with EPROM P/N 401597.
Remove NVRAM DS1230Y from U49 and NVRAM DS1386 from U54.
Insert NVRAM DS1245Y into U49 and NVRAM DS1248Y into U54.
Install two jumper shunts on J12.
Install two jumper shunts on J13.
Flash the PG7000 with PG7000 software ver. 2.02d. (This is available for download at DHI web site:
www.dhinstruments.com). Refer to the instructions provided in Section 5.5 of the PG7000 manual. Remember,
a "null modem" cable must be used to connect the PC to the PG7000 COM2 port.
Reboot the PG7000 following the reboot instructions displayed. When asked whether to upgrade answer, "YES".
Repeat step and
PG7000 software upgrades are designed to reformat and transfer data as needed. However, various PG7000 user
settings may be reset and/or deleted. The extent depends on the number of revisions between the original and the
newly flashed version. Be sure to check the metrological aspects including piston-cylinder, mass set, mass bell and
internal sensor calibration files as these may be completely deleted and/or reset. See the PG7000 Manual.
Remove EEPROMS from U41 and U46.
Deliver the upgraded PG7000 Platform to the customer with the new PG Terminal P/N 401284 (not included in
P/N 401594) and the new PG7000 manual P/N 550099.
Instruction Sheet
Shunt, jumper
IC, NVRAM/clock, DS1248Y
IC, NVRAM, DS1245Y
EPROM, PG BIOS ver. 1.02
with the most recent PG7000 software version.
™
PG7000
Flash with EEPROM to Flash
without EEPROM,
Non-Flash to Flash without EEPROM
• 1 401284 PG Terminal (not in P/N 401594)
• 1 550099 Manual, PG7000
• 1 560037 Instruction sheet, upgrade
