Summary of Contents for Hohem iSteadyPro
- Page 1 3-Axis Handheld Stabilizing Gimbal For Action Camera User Guide V2. 0 Get more tutorial videos...
- Page 2 Product Overview Camera Charging Port 1.Thumb Screw 2.Tilt Motor 3.Pan Motor Tilting 320° Rolling 320° 4.1/4 Inch Extension Screw Hole Panning 640° 5.Bluetooth Light Power 6.Hot Key indicator Light 7.Roll Motor 8.Mode Light 9.Joystick 10.Mode Button Charging Port 11.Turn ON/OFF 12.Handle (Battery inside) 1/4 Inch Extension Screw Hole...
- Page 3 B. GoPro Hero 4/3, YI CAM, SJ CAM or other action camera Connect the gimbal and smartphone via bluetooth of similar size: The lens is opposite to the tilt motor. ‘Hohem Gimset’ supports IOS 9.0 and Android 8.0 or above...
- Page 4 Calibration 1.If the gimbal has the following situations, please calibrate it: ① The pitch angle is not leveled with the horizontal surface. ② The roll angle is not parallel to the horizontal surface. ③ Under the lock mode, the panning angle drif ting. 2.Calibration Operation Instruction: Method 1: Off-line Calibration (1) Power on the gimbal (around 3 seconds), long press the mode button...
- Page 5 Installation Stabilizer Charging& Smartphone Charging Fully charge the stabilizer before using it for the first time. A. USB Port: Power bank output A. 4 Led lights indicators (Charging the smartphone, 4 Led lights on means power is 100% action camera etc.) 3 Led lights on means power is 75% 2 Led lights on means power is 50% b.
- Page 6 Install Action Camera Please make sure the gimbal is turned off before mount the camera, and we suggest remove the camera protective case. (1) GoPro Hero 6/5: The lens next to the tilt motor. Put the tilt motor to the RIGHT side, place GoPro 6/5 closely to the back clip as picture and tighten the knob to secure its position.
- Page 7 Operation Instruction Panning right/ lef t Tilting up/ down Bluetooth Light: Solid on: Bluetooth connected Mode light Quickly flash twice: Power on/off Mode Button Power On/Off (Long press for 3 seconds) Hot Key Up: Re-centered Down: Quick locked Mode Button Work Modes Mode Light Instruction...
- Page 8 ‘ ’ or Google Play, and install the app on your mobile phone. * Hohem Gimset’ supports iOS 9.0 and Android 8.0 or above. ‘ APP Guideline (1) Enable the Bluetooth on the smartphone (2) Open the App, select the model then confirm into Bluetooth connection.
- Page 9 Q:Fail to power on the gimbal. A:1.Please check if the power button is defective. 2.Please check if your gimbal is fully charged. (tap the power button once to check the battery status.) 3.Please be noted that the gimbal is not able to power on while it is charging. Q:Gimbal swing, vibrate, motor works with noise.
- Page 10 Firmware Upgrade Please ensure the stabilizer is connected with App via Bluetooth, then enter the “Firmware Upgrade” and follow the tips to upgrade the latest firmware. Warranty Card 1. 15 days upon date of purchase, if there is function problem, the commodity and package without any damage, af ter we check and confirm, we will offer the same product for replacement.
- Page 11 6.For any unknown sources or usage, we will not provide any service. 7.If there is any question, please contact the technician of Hohem Tech, we won't be responsible for any wrong operations by users. 8.Hohem Tech reserves the right for final explanation.
- Page 12 Hohem technology Co.,Ltd Tel: +86 755 86573216 Email: service@hohem-tech.com www.hohem-tech.com Addr: B106,University Creative Park, Xili, Nanshan, Shenzhen, 518055, P.R.China...
