USER'S GUIDE
USER'S GUIDE
TEP SERIES
TEP SERIES
PROGRAMMABLE ELECTRONIC
PROGRAMMABLE ELECTRONIC
LINE VOLTAGE THERMOSTAT
LINE VOLTAGE THERMOSTAT
IMPORTANT INSTRUCTIONS
This product must be installed by a qualified electrician.
In order to avoid fire, shock or death, shut off power supply at the circuit
breaker or fuse before wiring.
Before you begin:
• Verify that the heating appliance that is being connected is within the
specified load range.
• Confirm voltage is within the device rating.
• For wiring, use copper conductors only.
• Mount on a certified electrical box only.
Keep this user's guide in a safe place for future reference.
TECHNICAL SPECIFICATIONS
Max. load
(at 120/240 V)
Max. Amps
Wiring
Electrical Rating
Heater Compatibility
Temperature range
Software
Certification
Impulse Voltage
Pollution Degree
TECHNICAL SUPPORT
Thank you for your purchase! Question or problem? Let us solve it
with a single phone call, email or online chat! We'll save you a trip
back to the store!
Cadet Customer Service
Phone:
855.223.3887 (from US)
800.668.6663 (from Canada)
email:
customerservice@cadetheat.com
Live chat: cadetheat.com (contact us)
TEP302DW
1500 W / 3000 W
12.5
Double pole, 4 wire
120/208/240 V 50-60Hz
Compatible with fan-forced or convection heaters
and baseboards
Programmable 5 °C - 30 °C (41 °F - 86 °F)
Readable -40 °C - 70 °C (-40 °F - 158 °F)
LCD may degrade at 0 °C (32 °F)
Class A
cULus
2500
PD2
TEP362DW
1800 W / 3600 W
15
Double pole, 4 wire
TEP402DW
2000 W / 4000 W
16.67
Single pole, 3 wire
7216290100R01
