Godox AD200 Pro Instruction Manual

Godox AD200 Pro Instruction Manual

Pocket flash
Hide thumbs Also See for AD200 Pro:

Advertisement

Quick Links

Download this manual
Pocket Flash
INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the AD200 Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Godox AD200 Pro

Summary of Contents for Godox AD200 Pro

  • Page 1 Pocket Flash INSTRUCTION MANUAL...
  • Page 2 Thank you for purchasing a GODOX product. WITSTRO TTL Powerful & Portable Flash AD200Pro include three kinds of flash tube and adopts Godox 2.4G wireless X system. When using GODOX 2.4G wireless X system of camera, AD200Pro can be triggered by X2/X1/XPro series flash trigger in TTL/M/Muilt mode, etc.
  • Page 3 Warning Always keep this product dry. Do not use in rain or in damp conditions. Do not disassemble. Should repairs become necessary, this product must be sent to an authorized maintenance center. Keep out of reach of children. Stop using this product if it breaks open due to extrusion, falling or strong hit. Otherwise, electric shock may occur if you touch the electronic parts inside it.
  • Page 4 Name of Parts Body: Light Sensor Flash Head Mounting Power Switch Socket 1/4" Mounting Hole Head Release Button Wireless Control Port 3.5mm Sync Cord Jack Battery Release Button Battery Compartment Lithium Battery Control Panel Type-C USB Port < GR/CH >Group/Channel <...
  • Page 5 Name of Parts Flash Head： Speedlite flash head: Heat Dissipation Hole Head Mounting Socket Modeling Lamp (LED) Optical glass Heat Dissipation Hole Modeling Lamp (LED) Bare bulb flash head: Accessory Locking Ring Tube Socket Accessory Mount Flash Head Mounting Socket Flash Tube...
  • Page 6 Name of Parts VA Panel (1) VA Panel Channel Multi Color Temperature Mode Wireless Battery Level Flash exposure Group compensation amount C.Fn t0.1 Flash frequency Mask Flash high temperature Modeling lamp(LED) Time Standby Beeper S1/S2 ● The display will only show the settings currently applied. ●...
  • Page 7 Name of Parts (4) Radio Transmission Shooting Radio transmission Channel wireless shooting M Mode Group ● S1/S2 C.Fn-F2 Included Accessories (1) Speedlite flash head (2) Bare bulb flash head (3) AD-E2 holder*1 (4) Battery charger*1 (5) Lithium battery pack*1 (6) Protecting bag*1 (7) Instruction manual*1 Separately Sold Accessories The product can be used in combination with the following accessories sold separately, so as to achieve best...
  • Page 8 Name of Parts Attaching Bare bulb flash head 1. Remove the reflector or other 2. Match the red dot on the base of the flash tube with the red dot in the Tube accessories from the flash head. Socket (4). Push the flash tube in until it is securely seated into the socket. Lithium Battery Features 1.
  • Page 9 Power Management ON/OFF Power Switch controls the on/off of the flash unit, turn off the power pack if the flash unit will not be used for an extended period. The product design of power supply with automatic hibernation feature, When unattended operation for a long time (approx.
  • Page 10 Flash Mode — TTL Autoflash This flash has three flash modes: TTL, Manual (M), and Multi (Stroboscopic). In TTL mode, the camera and the flash will work together to calculate the correct exposure for the subject and the background. In this mode, multiple TTL functions are available: FEC, FEB, FEL, HSS, second curtain sync, modeling flash, control with the camera’s menu screen.
  • Page 11 ● With high-speed sync, the faster the shutter speed, the shorter the effective flash range. ● Multi flash mode cannot be set in high-speed sync mode. ● Over-temperature protection may be activated after 20 consecutive high-speed sync flashes. Flash Mode — M: Manual Flash The flash output is adjustable from 1/1 full power to 1/256th power in 1/10th stop increments.
  • Page 12 Optic S1 Secondary Unit Setting In M manual flash mode, press the <MENU> button to enter C.FN-F2 to choose S1 function, so that this flash can function as an optic S1 secondary flash with optic sensor. With this function, the flash will fire synchronously when the main flash fires, the same effect as that by the use of radio triggers.
  • Page 13 Flash Mode — Multi: Stroboscopic Flash With stroboscopic flash, a rapid series of flashes is fired. It can be used to capture a multiple images of a moving subject in a single photograph. You can set the firing frequency (number of flashes per sec. expressed as Hz), the number of flashes, and the flash output.
  • Page 14 Wireless Flash Shooting AD200Pro adopts Godox 2.4G wireless X system, which has good compatibility with other products of our company. As a slave unit, AD200Pro is automatically compatible with Canon/ Nikon/ Sony TTL system according to the master unit. Nikon cameras (use X1T-N), Canon cameras (use X1T-C) and Sony cameras (use X1T-S) can use one or more AD200Pro-TTL flashes simultaneously.
  • Page 15 ● Auto Shooting with Two Slave Groups ● Auto Shooting with Three Slave Groups When using the AD200Pro and Godox X1 series trigger together，the X1 can control the flash function such as: ● Flash Mode: TTL, M, Multi ● Sync Mode: First-curtain sync, second-curtain sync and High-speed sync ●...
  • Page 16 C.Fn: Setting Custom Functions The following table lists the available and unavailable custom functions of this flash. Custom Function Signs Functions Setting Signs Settings & Descriptions Restrictions Beeper S1/S2 mode M mode selection S1 mode S2 mode Auto standby 30 min Auto standby 60 min without...
  • Page 17 Other Applications Wireless Control Function The flash unit is built in with a Wireless Control Port so that you can wirelessly adjust the power level of the flash and the flash triggering. To control the flash wirelessly, you need a FT-16 remote control set (on- camera and on-flash).
  • Page 18 Number of flashes that will activate over-temperature protection in high-speed sync triggering mode: Power Output Times Speedlite flash head Bare bulb flash head 1/2(+0.3,+0.7); 1/4(+0.3,+0.7); 1/8(+0.3,+0.7); 1/16(+0.3,+0.7) 1/32(+0.3,+0.7) 1/64(+0.3,+0.7); 1/128(+0.3,+0.7); 1/256(+0.3,+0.7) 2. Other Protections ● The system provides real-time protection to secure the device and your safety. The following lists prompts for your reference: Prompts on LCD Panel Meaning...
  • Page 19 Technical Data Model AD200Pro Wireless Slave Unit Mode Radio transmission mode (compatible with Nikon & Canon & Sony& Fujifilm & Olympus & Panasonic & Pentax ) M/Multi Flash Mode Wireless off TTL/ M/Multi Slave unit of radio transmission Compatible Cameras under Radio Nikon cameras (X1T-N as master unit) Transmission (as slave unit) Canon EOS cameras (X1T-C as master unit)
  • Page 20 ● USB connection line is not included in this product. The USB port is a Type-C USB socket.Type-C USB connection line is applicable. ● As the firmware upgrade needs the support of Godox G3 software, please download and install the "Godox G3 firmware upgrade software" before upgrading. Then, choose the related firmware file.
  • Page 21 FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 22 Warranty Dear customers, as this warranty card is an important certificate to apply for our maintenance service, please fill in the following form in coordination with the seller and safekeep it. Thank you! Product Model Product Code Number Information Customer Name Contact Number Information...
  • Page 23 If maintenance service is needed, you can directly contact the product distributor or authorized service institutions. You can also contact the Godox after-sale service call and we will offer you service. When applying for maintenance service, you should provide valid wananty card.
  • Page 24 QC PASS : 0755-29609320(8062) : 0755-25723423 : godox@godox.com GODOX Photo Equipment Co., Ltd. Add: Building 2, Yaochuan Industrial Zone, Tangwei Community, Fuhai Street, Bao’an District, Tel: +86-755-29609320(8062) Fax: +86-755-25723423 Shenzhen, China E-mail: godox@godox.com godox.com Made in China...
