8-Tier Fanshaped Corner Rack
PACKAGE CONTENTS
A
x 8 Shelf
B
x 48 +2 extra
Tapered Lock
Black plastic spacer
(NOTE: Discard the black plastic spacers K.
These between each shelf are only for packing
purpose , not for assembling.)
8TSJX
Warning:
Maximum weight capacity per shelf is
70lbs when weight is equally
distributed.
Maximum entire unit weight capacity is
560bs when equally distributed on
feet levelers.
Failure to follow these instructions may
result in serious injury or death of
yourself and people around you.
Some of the part are heavy and/or has
shape edge, please install it carefully to
avoid hurt you and people around you.
Caution:
Do not stand on or climb on the
shelving unit.
Place heavier items on lower shelves
and lighter ones on top shelves.
D
C
x 3
Top Pole
(with pole
cap and
pole connector
preassembled)
F
x 15
E
x 6
x 3
Middle
Bottom Pole
Pole(with
(with feet leveler
pole connector
preassembled)
preassembled)
Advertisement
Related Manuals for Dolonm 8TSJX
Summary of Contents for Dolonm 8TSJX
- Page 1 8-Tier Fanshaped Corner Rack 8TSJX Warning: Maximum weight capacity per shelf is 70lbs when weight is equally distributed. Maximum entire unit weight capacity is 560bs when equally distributed on feet levelers. Failure to follow these instructions may result in serious injury or death of yourself and people around you.
- Page 2 ASSEMBLY INSTRUCTIONS 1. With the tapered end facing up, snap the two halves of a 6. Screw top pole (C) onto middle pole(D), hand tighten. tapered lock (B) at the desired height on bottom pole (E). Repeat for the remaining bottom poles (E), making sure the tapered locks (B) are installed at the same grooved line on each bottom pole (E).
