3-TIER WIRE SHELVING RACK
PACKAGE CONTENTS
A
x 6
Shelf
D
x 6
Shelf liner
B
x 48+2 extra
Tapered Lock
E
x 20
Black plastic spacer
(NOTE: Discard the black plastic spacers E.
These between each shelf are only for packing
purpose , not for assembling.)
XLB-2P377
Warning:
Maximum weight capacity per shelf
is 350lbs when equally distributed on
feet levelers.
Failure to follow these instructions may
result in serious injury or death of
yourself and people around you.
Some of the part are heavy and/or has
shape edge, please install it carefully to
avoid hurt you and people around you.
Caution:
Do not stand on or climb on the shelving unit.
Place heavier items on lower shelves
and lighter ones on top shelves.
C
x 8 Pole (with feet leveler preassembled)
F
x 4 Extra Connector
Use it to assemble as 6 Tier Wire Rack
If you don't need expandable features,
you take these parts as replacement
accessories, just in case.
Advertisement
Summary of Contents for Dolonm XLB-2P377
- Page 1 3-TIER WIRE SHELVING RACK XLB-2P377 Warning: Maximum weight capacity per shelf is 350lbs when equally distributed on feet levelers. Failure to follow these instructions may result in serious injury or death of yourself and people around you. Some of the part are heavy and/or has shape edge, please install it carefully to avoid hurt you and people around you.
- Page 2 ASSEMBLY INSTRUCTIONS 1.With the tapered end facing up, snap the two halves of a 4. Repeat steps 1-3 for the remaining shelves (A). tapered lock (B) at the desired height on pole (C). Repeat for the remaining poles (C), making sure the tapered locks (B) are installed at the same grooved line on each pole (C).
