5-Tier Wire Shelving Rack
PACKAGE CONTENTS
A
Shelf
x 5
x 4 Top Pole (with pole cap and pole connector preassembled)
x 4 Bottom Pole (with feet leveler preassembled)
B
x 40 +2 extra
Tapered Lock
C
D
5TWL60
Warning:
Maximum weight capacity per shelf is
150lbs when equally distributed on
feet levelers
Maximum entire unit weight capacity is
220lbs when equally distributed on casters.
Failure to follow these instructions may
result in serious injury or death of
yourself and people around you.
Some of the part are heavy and/or has
shape edge, please install it carefully to
avoid hurt you and people around you.
Caution:
Do not stand on or climb on the shelving unit.
Place heavier items on lower shelves
and lighter ones on top shelves.
E
x 4
Wheel
(2 locking, 2 non-locking)
(for mobile option)
G
x 5
H
x 16
Black plastic spacer
(NOTE: Discard the black plastic spacers H.
These between each shelf are only for packing
purpose , not for assembling.)
F
x 4
Feet Leveler
(for stationary option)
Shelf liner
Advertisement
Related Manuals for Dolonm 5TWL60
Summary of Contents for Dolonm 5TWL60
- Page 1 5-Tier Wire Shelving Rack 5TWL60 Warning: Maximum weight capacity per shelf is 150lbs when equally distributed on feet levelers Maximum entire unit weight capacity is 220lbs when equally distributed on casters. Failure to follow these instructions may result in serious injury or death of yourself and people around you.
- Page 2 ASSEMBLY INSTRUCTIONS 1.With the tapered end facing up, snap the two halves of a 5. Screw top pole (C) onto bottom pole(D), hand tighten. tapered lock (B) at the desired height on bottom pole (D). Repeat for the remaining bottom poles (D), making sure the tapered locks (B) are installed at the same grooved line on each bottom pole (D).
