6-Tier Fanshaped Corner Rack
PACKAGE CONTENTS
A
x 5 Shelf
C
x 36 +2 extra
Tapered Lock
H
Wall anchor x 4
Nylon strap x 2
B
x 1 Bottom Shelf
D
x 1
Lower Short Pole
I
J
Screws x4
6TWL72
Warning:
Maximum weight capacity per shelf is
70lbs when weight is equally
distributed.
Maximum entire unit weight capacity is
420bs when equally distributed on
feet levelers.
Failure to follow these instructions may
result in serious injury or death of
yourself and people around you.
Some of the part are heavy and/or has
shape edge, please install it carefully to
avoid hurt you and people around you.
Caution:
Do not stand on or climb on the
shelving unit.
Place heavier items on lower shelves
and lighter ones on top shelves.
F
E
x 3
x 6
Top Pole
Middle
Pole(with
(with pole
pole connector
cap and
preassembled)
pole connector
preassembled)
K
(NOTE: Discard the black plastic spacers K.
x 6
Shelf liner
These between each shelf are only for packing
purpose , not for assembling.)
G
x 3
Bottom Pole
(with feet leveler
preassembled)
L
x 15
Black plastic spacer
Advertisement
Related Manuals for Dolonm 6TWL72
Summary of Contents for Dolonm 6TWL72
- Page 1 6-Tier Fanshaped Corner Rack 6TWL72 Warning: Maximum weight capacity per shelf is 70lbs when weight is equally distributed. Maximum entire unit weight capacity is 420bs when equally distributed on feet levelers. Failure to follow these instructions may result in serious injury or death of yourself and people around you.
- Page 2 ASSEMBLY INSTRUCTIONS 6. Screw top pole (E) onto middle pole(F), hand tighten. 1. With the tapered end facing up, snap the two halves of a tapered lock (C) at the desired height on bottom pole (G). Repeat for the remaining bottom poles (G), making sure the tapered locks (C) are installed at the same grooved line on each bottom pole (G).
