- Page 1 E NRICH YOUR DRIVING LIFE User Manual Jump Starter ELITE 1200A S E R IE S JUMP STARTER Model: GE1200 SUPERSAFE is a safety protection technology by GOOLOO...
- Page 2 Thank you for choosing GOOLOO jump starter. To ensure a good user experience, personal safety, and property security, please read all of the instructions carefully before using this product, please keep this manual for easy reference. Charge It First !
- Page 3 Parts and Functional Description 5V/2.4A, 9V/2A Quick Charge Output Port LED Flashlight Switch Indicator Power Switch 12V/10A Output Port LED Flashlight 15V/1A Input Port 5V/2.1A Output Port Jumper Socket Wall Charger Smart Jumper Cable Car Charger...
- Page 4 Operation Instructions Battery Indicator : Press the power switch to check the battery power : Indicator 1 Solid 2 Solid 3 Solid 4 Solid 5 Solid Battery power 100% The indicator will blink one by one during the period of charging.
- Page 5 2. Charged By Car Charger (12V) 1). Plug the car charger into the 12V cigarette lighter socket. 2). Connect the other end of car charger to the 15V/1A input port of GE1200. How to Start a 12V Vehicle Make sure the unit is over 60% charged (check the battery indicator≥3 bars).
- Page 6 3. Check the indicators on the jumper cable and operate following the instructions as below： GREEN LIGHT on and be solid: Indicates the connection is correct and the circuit is working, you can start the vehicle directly. RED LIGHT on and be solid with beeping: Indicates the connection is wrong, you need to correct the battery clamps as step 2 mentioned, wait the GREEN LIGHT on and be solid , then...
- Page 7 12V/10A DC Output (120W Max) ●Cigarette Lighter Socket Output Connect the devices that need to be powered by the Cigarette Lighter Socket (the Cigarette Lighter Socket Adapter is included). ●5.5*2.1mm DC Output You can connect the devices that need to be powered by the 5.5*2.1mm DC port.
- Page 8 Package Content Part Name Quan�ty Host Smart Jumper Cable USB to Type-C Quick Charge Cable Wall Charger Car Charger Cigarette Lighter Socket Adapter User Manual Technical Specification Input: 15V/1A Quick Charge(5V/2.4A,9V/2A) Output: 5V/2.1A; 12V/10A;12V Jump Start Capacity : 66.6Wh 350A(3s) Start Current: Peak Current: 1200A...
- Page 9 Please contact us This unit is over discharged or fiona@gooloo.com heated or swelled defective If there is any problem with our products, please contact us directly at fiona@gooloo.com, our customer service team will work hard to solve the problem within 24 hours.
- Page 10 Q1: What is the operating temperature of this unit and how to store it? A: This unit is lithium polymer battery, operating temperature is -20-60 ºC/ -4-140ºF. If the ambient temperature is higher than 60ºC/140ºF, the internal construction of the polymer lithium-ion cells will be damaged, it may swell and become unsafe.
- Page 11 GREEN LIGHT on and be solid, then start the vehicle within 30s. If it still does not work, contact us at: fiona@gooloo.com ( Attach your order ID). Q6: What should I do if this product can’t be charged? A: Charge it with a 15V wall charger or car charger for a full overnight period.
- Page 12 Q9: Can this product charge other devices while it is being charged? A: Yes. Q10: Can this product charge other devices while starting a vehicle? A: No. Q11: How often does this unit need to recharge? A: It would be best to be recharged every 3 months. Q12: Why it shuts off in 30s when charging for other devices? A: This product may not be able to charge for the devices...
- Page 13 Warning 1. Read this instruction manual carefully before using this unit. 2. Use caution while using this unit. Injury to self, or damage to the unit or the vehicle battery if precautions are not followed. 3. Do Not allow to use by persons who do not have proper knowledge or ability to operate the device without supervision.
- Page 14 11. Make sure the blue plug of the jumper cable is plugged fully into the jumper socket; otherwise, the blue plug could melt. 12. Make sure the battery terminal are clean before starting, and make sure the battery clamps are well connected. If the battery terminals on the vehicle are dirty or corroded, the output power of the unit will be lessened.
- Page 15 21. Do Not modify or disassemble the unit. Only a repair technician may repair this unit. 22. Do Not expose product to extreme heat or fire. 23. Do Not drop or crush the unit. If the unit has received a sharp blow or is damaged in any other way, a qualified battery technician should check it.
- Page 16 C. We are not liable for any incidental or consequential damage that arises from incorrect use or misuse of this product. D. All warranty claims are limited to repair or replacement of the defective product and at the sole discretion of GOOLOO.
- Page 17 Attention Do Not Submerge In Water Do Not Disassemble Do Not Drop Avoid Extreme Temperatures Do Not Place Near or Into Fire...
- Page 18 Customer Service 12+6 Months Limited Warranty Service Lifetime Technical Service Feel Free to Contact Us fiona@gooloo.com (recommend) For FAQ and More Information www.gooloo.com 1-888-886-1805 Mon.-Fri. PST 9:00a.m.-5:00p.m. @gooloofans @GoolooOfficial...
- Page 19 Thank You for Choosing 800205 CONFORMS TO UL STD.2743 Made in China...
